13Pictorial index
COROLLA H/B_U
Refueling method ............................................... .................. P.171
Fuel type/fuel tan k capacity ................................... .............. P.511
Tires.......................................................... ........................... P.436
Tire size/inflation pressure ................................... ................ P.515
Winter tires/tire chains ....................................... .................. P.246
Checking/rotation/tire pressur e warning system ..................P.436
Coping with flat tires......................................... ............ P.479, 490
Hood ........................................................... ......................... P.427
Opening ............................................................................... P.427
Engine oil ............................................................................. P.511
Coping with overheating ...................................................... P.506
Headlights/daytime running lights .............................. ..... P.160
Turn signal lights ............................................. .................. P.153
Parking lights ................................................. .................... P.160
Front side marker lights ....................................... ............. P.160
Fog lights
*............................................................... ............ P.166
Stop lights/tail lights/ rear side marker lights/
turn signal lights ............................................. ................... P.160
License plate lights........................................... ................. P.160
Tail lights.................................................... ......................... P.160
Back-up lights
Shifting the shift position to R ............................... ....... P.147, 151
*: If equipped
Light bulbs of the exterior lights for driving
(Replacing method: P.455, Watts: P.516)

4557-3. Do-it-yourself maintenance
COROLLA H/B_U
7
Maintenance and care
Check the wattage of the light
bulb to be replaced. ( P.516)
■Front
Front side marker lights
■RearLicense plate lights
■Bulbs that need to be
replaced by your Toyota
dealer
 Headlights
 Parking lights
 Daytime running lights
 Turn signal lights
 Front fog lights (if equipped)
 Tail lights
 Stop lights
 Back-up light
 High mounted stoplight
■LED light bulbs
The lights other than the front side
marker lights and license plate lights
consist of a numbe r of LEDs. If any
of the LEDs burn out, take your
vehicle to your Toyota dealer to
have the light replaced.
■Condensation build-up on the
inside of the lens
Temporary condensation build-up
on the inside of t he headlight lens
does not indicate a malfunction.
Contact your Toyota dealer for more
information in t he following situa-
tions:
●Large drops of water have built up
Light bulbs
You may replace the follow-
ing bulbs yourself. The diffi-
culty level of replacement
varies depending on the
bulb. If necessary bulb
replacement seems difficult
to perform, contact your
Toyota dealer.
For more information about
replacing other light bulbs,
contact your Toyota dealer.
Preparing for light bulb
replacement
Bulb locations

4567-3. Do-it-yourself maintenance
COROLLA H/B_Uon the inside of the lens.
●Water has built up inside the
headlight.
■When replacing light bulbs
 P. 4 5 4
■Front side marker lights
1 Turn the bulb base counter-
clockwise.
2 Remove the light bulb.
3 When installing, reverse the
steps listed.
■License plate lights
1 Remove the light unit.
Insert a flathead screwdriver or
similar into the hole next to the light
and remove it as shown in the illus-
tration.
To prevent damagin g the vehicle,
wrap the flathead screwdriver with a tape.
2
Turn the bulb base counter-
clockwise and remove it.
3 Remove the light bulb.
4 When installing, reverse the
steps listed.
Replacing light bulbs

560Alphabetical Index
COROLLA H/B_U
Glove box ................................ 398
Glove box light ....................... 398
Grocery bag hooks ................ 400
H
Hands-free system ................. 343
Head restraints ....................... 118
Headlights Adaptive Front-lighting System (AFS) .................................. 162
Automatic High Beam system ........................................... 163
Light switch .......................... 160
Replacing light bulbs ............ 455
Head-up display ....................... 89 Driving information display area............................................. 89
Driving support system display area ...................................... 91
Eco Driving Indicator .............. 92
Navigation system-linked display ............................................. 89
Pop-up display ....................... 91
Settings .................................. 90
Heated steering wheel ........... 393
Heaters Automatic air conditioning sys-tem ..................................... 386
Heated steering wheel ......... 393
Outside rear view mirrors ..... 389
Seat heaters ......................... 393
High mounted stoplight Replacing light bulbs ............ 455
Hill-start assist control .......... 241
HOME button .......................... 260
Home screen ........................... 260
Hood Open .................................... 427
Hooks Cargo hooks ......................... 400
Coat hooks ........................... 411
Grocery bag hooks ............... 400 Retaining hooks (floor mat) ....22
Horn .........................................121
I
I/M test .....................................423
Identification Engine .................................. 511
Vehicle ..................................510
Ignition switch (engine switch) ...............................................142Auto power off fun ction .........146
Changing the engine switch modes.................................145
If your vehicle has to be stopped in an emergency .................460
Illuminated entry system .......396
Indicators ..................................72
Info button (Menu screen) .....253
Initial screen............................257 Caution screen .....................257
Restarting the system ...........257
Initialization Items to initialize ...................539
Maintenance .........................420
Power windows ....................125
Tire pressure w arning system
...........................................442
Inside rear view m irror ...........122
Instrument panel light control76, 81
Intercooler coolant Capacity ...............................513
Interior lights...........................395 Front interior light .................395
Rear interior light ..................395
Internet radio...........................307
iPod/iPhone(Apple Carplay ...310
J
Jack Positioning a floor jack .........428

561Alphabetical Index
COROLLA H/B_U
Vehicle-equipped jack .. 481, 491
Jack handle ..................... 481, 491
Jam protection function Power windows .................... 125
K
Keyless entrySmart key system................. 108
Wireless remote control ......... 99
Keys Battery-saving function......... 109
Electronic key ......................... 98
Engine switch ....................... 142
If the electronic key does not operate properly ................. 500
If you lose your keys ............ 500
Key number plate ................... 98
Keyless entry........ 101, 106, 108
Mechanical key ...................... 98
Replacing the battery ........... 450
Warning buzzer .................... 108
Wireless remote control ......... 99
Knee airbags ............................. 29
L
Lane Departure A lert with steer-
ing control (LDA) Operation ............................. 196
Warning messages............... 203
Lane Tracing Assist (LTA) Operation ............................. 186
Warning messages............... 195
Language (multi-information dis- play) ......................................... 87
LATCH anchors ........................ 54
LDA (Lane Departure Alert with steering control)Operation ............................. 196
Warning messages............... 203
LDA (Lane Departure Alert with steering control) switch....... 200 Lever
Auxiliary catch lever .............427
Hood lock release lever ........427
Shift lever .....................147, 151
Turn signal lever ...................153
Wiper lever ...........................166
License plate lights Light switch...........................160
Replacing light bulbs ............456
Wattage ................................516
Light Wattage ................................516
Light bulbs Replacing .............................455
Lights Automatic High Beam system...........................................163
Front interior lights................395
Headlight switch ...................160
Interior lights .........................395
Interior lights list ...................395
Luggage compartment light ..107
Personal lights ......................396
Rear interior lights ................395
Replacing light bulbs ............455
Turn signal lever ...................153
Vanity lights ..........................410
Wattage ................................516
Linking multi-information display and the system .....................265
Lock steering column ............142
LTA (Lane Tracing Assist) Operation..............................186
Warning messages ...............195
Luggage compartment features ...............................................400
Luggage compartment light Wattage ................................516
Luggage cover ........................401

564Alphabetical Index
COROLLA H/B_U
Rear view mirror Inside rear view mirror.......... 122
Outside rear view mirrors ..... 123
Rear view monitor system ..... 232 If you notice any symptoms.. 237
Rear window defogger ........... 389
Rear window wiper ................. 168
Receiving a call using the Blue- tooth
® hands-free system ... 351
Refueling Capacity ............................... 511
Fuel types............................. 511
Opening the fuel tank cap .... 170
Registering/Connecting a Blue- tooth
® device ........................ 266
Profiles ................................. 269
Registering a Bluetooth
® audio
player for the first time........ 269
Registering a Bluetooth
® phone
for the first time .................. 266
Replacing Electronic key battery ........... 450
Fuses ................................... 452
Light bulbs ............................ 455
Reporting safety defects for U.S. owners................................... 542
Resetting the message indicat- ing maintenance is required 420
Road Sign Assist .................... 224
RSA (Road Sign Assist) ......... 224
S
Safety Connect ......................... 58
Screen adjustment ................. 264
Seat belt reminder light . 471, 472
Seat belts .................................. 25 Automatic Locking Retractor .. 27
Child restraint system installation............................................. 47
Cleaning and maintaining the seat belt.............................. 416
Emergency Locking Retractor 27 How to wear your seat belt .....26
How your child should wear the
seat belt ................................26
Pregnant women, proper seat belt use .................................25
Reminder light and buzzer .471, 472
Seat belt extender ..................26
Seat belt pretensioners ..........28
SRS warning light .................469
Seat heaters ............................393
Seating capacity .....................140
Seats Adjustment ........................... 115
Adjustment precautions ........ 115
Child seats/child restraint system installation ............................45
Cleaning ...............................416
Head restraints ..................... 118
Properly sitting in the seat ......23
Seat heaters ....... ..................393
Secondary Collision Brake ....241
Sensor Automatic headlight system .161
Automatic High Beam system...........................................163
BSM (Blind Spot M onitor) .....227
LDA (Lane Departure Alert with steering control)..................196
LTA (Lane Tracing Assist) .....186
Radar sensor ................172, 229
Service reminder message ....420
Setup button (Menu screen) 253, 256
Setup screen ...........................256
Shift lever Continuously variable transmis-sion .....................................147
Manual transmission ............151
Side airbags ..............................29
Side marker lights Light switch...........................160
