3317-2. Steps to take in an emergency
7
When trouble arises
necessary.
This message may appear if the
vehicle is stopped on a slope. Move
the vehicle to a level surface and
check to see if the message disap-
pears.
■If “Engine Stopped Steering
Power Low” is displayed
This message is displayed if the
engine is stopped while driving.
When steering wheel operations are
heavier than usual, grip the steering
wheel firmly and operate it using
more force th an usual.
■If “Auto Power OFF to Conserve
Battery” is displayed
Power was cut off due to the auto-
matic power off function. Next time
when starting the engine, increase
the engine speed slightly and main-
tain that level for approximately 5
minutes to recha rge the battery.
■If “Headlight System Malfunc-
tion Visit Your Dealer” is dis-
played
The following systems may be mal-
functioning. Have the vehicle
inspected by your Toyota dealer
immediately.
●The LED headlight system
●The automatic headlight leveling
system (if equipped)
●AHB (Automatic High Beam)
■If “System Malfunction Visit
Your Dealer” is displayed
Indicates one of the following sys-
tems is disabled.
●PCS (Pre-Collision system)
●LDA (Lane Departure Alert)
●LTA (Lane Tracing Assist)
●AHB (Automatic High Beam)
●Dynamic radar cruise control
●RSA (Road Sign Assist)
(if equipped)
●PDA (Proactive Driving Assist)
●BSM (Blind Spot Monitor)
(if equipped)
●SEA (Safe Exit Assist)
(if equipped)
Have the vehicle inspected by your
Toyota dealer immediately.
■If “System Stopped See
Owner’s Manual” is displayed
Indicates one of the following sys-
tems is disabled.
●PCS (Pre-Collision system)
●LDA (Lane Departure Alert)
●LTA (Lane Tracing Assist)
●AHB (Automatic High Beam)
●Dynamic radar cruise control
●RSA (Road Sign Assist)
(if equipped)
●PDA (Proactive Driving Assist)
●BSM (Blind Spot Monitor)
(if equipped)
●RCTA (Rear Cross Traffic
Alert) (if equipped)
●SEA (Safe Exit Assist)
(if equipped)
Follow the following correction
methods.
• Check the voltage of the battery
• Check the sensors that the Toyota Safety Sense 3.0 uses for foreign
matter covering them. Remove
them if any. ( P.162)
• Check the sensors that the BSM (Blind Spot Monitor), RCTA (Rear
Cross Traffic Alert) and SEA (Safe
Exit Assist) uses for foreign matter
covering them. Remove them if
any. ( P.210, 220)
Indicates the sensors may not be
operating properly. ( P.165, 212,
217, 223)
When problems are solved and the
sensors are operational, this indica-

3587-2. Steps to take in an emergency
4Press the engine switch
shortly and firmly.
In the event that the engine still
cannot be started, contact your
Toyota dealer.
■Stopping the engine
Shift the shift lever to P and press
the engine switch as you normally
do when stopping the engine.
■Electronic key battery
As the above proc edure is a tempo-
rary measure, it is recommended
that the electronic key battery be
replaced immediate ly when the bat-
tery is depleted. ( P.304)
■Changing engine switch modes
Release the brake pedal and press
the engine switch in step 3 above.
The engine does not start and
modes will be cha nged each time
the switch is pressed. ( P.135)
If the vehicle batter y
is discharged
The following procedures
may be used to start the
engine if the vehicle’s bat-
tery is discharged.
You can also call your Toy-
ota dealer or a qualified
repair shop.

3637-2. Steps to take in an emergency
7
When trouble arises
able.
6Start the engine and turn the
air conditioning system on to
check that the radiator cool-
ing fan operates and to check
for coolant leaks from the
radiator or hoses.
The fan operates when the air con-
ditioning system is turned on imme-
diately after a cold start. Confirm
that the fan is op erating by check-
ing the fan sound and air flow. If it is
difficult to check these, turn the air
conditioning system on and off
repeatedly. (The fan may not oper-
ate in freezing temperatures.)
7 If the fan is not operating:
Stop the engine immediately
and contact your Toyota
dealer.
If the fan is operating:
Have the vehicle inspected at
the nearest Toyota dealer.
WARNING
■When inspecting under the
hood of your vehicle
Observe the following precau-
tions. Failure to do so may result
in serious injury such as burns.
●If steam is seen coming from
under the hood, do not open the
hood until the steam has sub-
sided. The engine compart-
ment may be very hot.
●Keep hands and clothing (espe-
cially a tie, a sca rf or a muffler)
away from the fan and belts.
Failure to do so may cause the
hands or clothing to be caught,
resulting in serious injury.
●Do not loosen the coolant reser-
voir caps while the engine and
radiator are hot.
High temperature steam or
coolant could spray out.
NOTICE
■When adding engine coolant
Add coolant slowly after the
engine has cooled down suffi-
ciently. Adding cool coolant to a
hot engine too quickly can cause
damage to the engine.
■To prevent damage to the
cooling system
Observe the following precau-
tions:
●Avoid contaminating the coolant
with foreign matter (such as
sand or dust etc.).
●Do not use any coolant additive.

3647-2. Steps to take in an emergency
1Stop the engine. Set the
parking brake and shift the
shift lever to P.
2 Remove the mud, snow or
sand from around the front
wheels.
3 Place wood, stones or some
other material under the front
wheels to help provide trac-
tion.
4 Restart the engine.
5 Shift the shift lever to D or R
and release the parking
brake. Then, while exercising
caution, depress the acceler-
ator pedal.
■When it is difficult to free the
vehicle
Press the switch to turn off
TRAC.
If the vehicle becomes
stuck
Carry out the following pro-
cedures if the tires spin or
the vehicle becomes stuck
in mud, dirt or snow:
Recovering procedure
WARNING
■When attempting to free a
stuck vehicle
If you choose to push the vehicle
back and forth to free it, make
sure the surrounding area is clear
to avoid striking other vehicles,
objects or people. The vehicle
may also lunge forward or lunge
back suddenly as it becomes free.
Use extreme caution.
■When shifting the shift lever
Be careful not to shift the shift
lever with the accelerator pedal
depressed.
This may lead to unexpected
rapid acceleration of the vehicle
that may cause an accident
resulting in death o r serious injury.
NOTICE
■To avoid damaging the trans-
mission and other compo-
nents
●Avoid spinning the front wheels
and depressing the accelerator
pedal more than necessary.
●If the vehicle remains stuck
even after these procedures are
performed, the vehicle may
require towing to be freed.

409What to do if... (Troubleshooting)
Is the engine switch in ON?
If you cannot release the shift lever
by depressing the brake pedal with
the engine switch in ON. ( P.139)
 Is the window lock switch
pressed?
The power window except for the
one at the driver’s seat cannot be
operated if the win dow lock switch
is pressed. ( P.119)
 The auto power off function
will be operated if the vehicle
is left in ACC or ON mode
(the engine is not running) for
a period of time. ( P.136)
 The seat belt reminder light is
flashing
Are the driver and the front passen-
ger wearing the seat belts?
( P.323)
 The parking brake indicator is
on
Is the parking br ake released?
(  P.142)
Depending on the situation,
other types of warning buzzer
may also sound. ( P.320, 330)
 Did anyone inside the vehicle
open a door during setting the
alarm?
The sensor detects it and the alarm
sounds. ( P. 6 5 )
Do one of the following to deac-
tivate or stop the alarms:
 Unlock the doors.
 Turn the engine switch to
ACC or ON, or start the
engine. (The alarm will be
deactivated or stopped after a
few seconds.)
 Is the electronic key left inside
the vehicle?
Check the message on the
multi-informat ion display. (P.330)
 When a warning light turns on
or a warning message is dis-
played, refer to P.320, 330.
The shift lever cannot be
shifted from P even if you
depress the brake pedal
The windows do not open
or close by operating the
power window switches
The engine switch is
turned off automatically
A warning buzzer sounds
during driving
An alarm is activated and
the horn sounds (vehicles
with an alarm)
A warning buzzer sounds
when leaving the vehicle
A warning light turns on
or a warning message is
displayed

413Alphabetical Index
Door lockBack door ............................... 99
Side doors .............................. 95
Smart key system................. 102
Wireless remote control ......... 93
Doors Automatic door locking and unlocking system.................. 99
Back door ............................... 99
Door glasses ........................ 117
Door lock .......................... 95, 99
Open door warning buzzer96, 98
Outside rear view mirrors ..... 115
Rear door child-protectors...... 98
Side doors .............................. 95
Drive distance ..................... 81, 86
Drive information ............... 81, 86
Drive-Start Control (DSC) ...... 127
Driving Break-in tips ......................... 123
Correct driving posture ........... 25
Driving mode select switch... 224
Procedures ........................... 122
Winter drive tips ................... 230
Driving information display78, 84
Driving range ...................... 79, 84
Driving support system informa- tion display ....................... 80, 85
DSC (Drive-Start Control) ...... 127
Dynamic radar cruise control 193
E
Eco Driving Indicator ......... 79, 84
Eco Driving Indicator Light79, 84
EDR (Event data recorder)......... 8
Elapsed time ....................... 81, 86
Electric Power Steering (EPS) ............................................... 226Warning light ........................ 322
Electronic key ........................... 92 Battery-saving function......... 103 If the electronic key does not
operate properly .................356
Replacing the battery ...........304
Emergency Driving Stop System ...............................................204
Emergency flashers ...............312
Emergency tire puncture repair kit ...........................................334
Emergency, in case of If a warning buzzer sounds ..320
If a warning light turns on .....320
If a warning message is dis-played .................................330
If the battery is d ischarged ...358
If the electronic key does not operate properly .................356
If the engine will not start......354
If the vehicle is submerged or water on the road is rising ..313
If you have a flat tire .............334
If you lose your keys.............356
If you think something is wrong ...........................................318
If your vehicle becomes stuck ...........................................364
If your vehicle has to be stopped in an emergency .................312
If your vehicle needs to be towed ...........................................315
If your vehicle ove rheats ......362
Engine ACCESSORY mode . ............135
Compartment........................275
Engine switch .......................133
Fuel pump shut off system ...319
Hood .....................................273
How to start the engine ........133
Identification number ............367
If the engine will not start......354
If your vehicle has to be stopped in an emergency .................312

415Alphabetical Index
H
Head restraints ....................... 110
HeadlightsAHB (Automatic High Beam) 150
Light switch .......................... 148
Replacing light bulbs ............ 309
Heated steering wheel ........... 241
Heaters Automatic air conditioning sys-tem ..................................... 234
Heated steering wheel ......... 241
Outside rear view mirrors ..... 237
Seat heaters ......................... 241
High mounted stoplight Replacing light bulbs ............ 309
Hill-start assist control .......... 226
Hood Open .................................... 273
Hooks Cargo hooks ......................... 248
Coat hooks ........................... 258
Grocery bag hooks ............... 248
Retaining hooks (floor mat) .... 24
Horn ......................................... 113
I
I/M test ..................................... 270
Identification Engine .................................. 367
Vehicle.................................. 366
Ignition switch (engine switch) ............................................... 133Auto power off function ........ 136
Changing the engine switch modes ................................ 135
If your vehicle has to be stopped in an emergency................. 312
Illuminated entry system ....... 244
Indicators .................................. 70
Initialization Items to initialize................... 395 Maintenance .........................266
Power windows .................... 117
Inside rear view m irror ........... 114
Instrument panel light control74, 77
Intercooler coolant Capacity ...............................369
Interior lights...........................243 Front interior light .................243
Rear interior light ..................243
J
JackPositioning a floor jack .........274
Vehicle-equipped jack ..336, 347
Jack handle .....................336, 347
Jam protection function Power windows .................... 117
K
Keyless entrySmart key system .................102
Wireless remote control..........93
Keys Battery-saving function .........103
Electronic key .........................92
Engine switch .......................133
If the electronic key does not operate properly .................356
If you lose your keys.............356
Key number plate ...................92
Keyless entry ..........95, 101, 102
Mechanical key.......................92
Replacing the battery ...........304
Warning buzzer ....................103
Wireless remote control..........93
Knee airbags .............................31
L
Lane Departure Alert (LDA) ...182

420Alphabetical Index
If you have a flat tire ............. 334
Inflation pressure.................. 299
Information ........................... 375
Rotating tires ........................ 284
Size ...................................... 370
Snow tires ............................ 230
Tire pressure warning system........................................... 285
Warning light ........................ 324
Tools ................................ 336, 347
Top tether strap ........................ 57
Total load capacity ................. 366
To w i n g Dinghy towing....................... 132
Emergency towing................ 315
Towing eyelet ....................... 317
Trailer towing ........................ 131
Toyota Safety Sense AHB (Automatic High Beam) 150
Cruise control ....................... 201
Dynamic radar cruise control 193
Emergency Driving Stop System........................................... 204
LDA (Lane Departure Alert) .. 182
LTA (Lane Tracing Assist) ..... 177
PCS (Pre-Collision System) . 167
RSA (Road Sign Assist) ....... 206
Toyota Safety Sense 3.0 ........ 161
Toyota Safety Sense 3.0[Toyota Safety Sense 3.0]PDA(Proactive driving assist)[PDA(Proactive driving
assist)] ................................ 187
TRAC (Traction Control) ........ 226
Traction Control (TRAC) ........ 226
Trailer towing .......................... 131
Transmission Continuously variable transmis-sion..................................... 137
Driving mode select switch... 224
M mode ................................ 140
Paddle shift switches.... 139, 140 Trip meters ..........................73, 76
Turn signal lights
Replacing light bulbs ............309
Turn signal lever ...................141
U
USB charging port ..................250
V
Vanity lights ............................257Wattage ................................372
Vanity mirrors .........................257
Vehicle data recording ...............6
Vehicle identification number366
Vehicle information display81, 86
Vehicle Stability Control (VSC) ...............................................225
VSC (Vehicle Stability Control) ...............................................225
W
Warning buzzers ABS ......................................322
Airbags .................................321
Approach warning ................199
Brake hold ............................327
Brake Override System ........322
Brake system ........................320
Charging system ..................321
Downshifting .........................141
Drive-Start Control ................322
Electric power steering .........322
Engine ..................................321
High coolant temperature .....320
LDA (Lane Departure Alert) 182, 325
Low engine oil pressure .......321
LTA (Lane Tracing Assist) ...177, 324
Open door ........................96, 98
