dimensions TOYOTA COROLLA iM 2017 11.G Owners Manual

324
COROLLA iM_U (OM12K64U)
8-1.Specifications
*: Unladen vehicles
■
Vehicle identification number
The vehicle identification number (VIN) is the legal identifier for
your vehicle. This is the primary identification number for your
Toyota. It is used in registering the ownership of your vehicle.
This number is stamped under
the right-hand front seat.
Maintenance data (fuel, oil level, etc.)
Dimensions and weights
Overall length 170.5 in. (4330 mm)
Overall width 69.3 in. (1760 mm)
Overall height*58.1 in. (1475 mm)
Wheelbase 102.4 in. (2600 mm)
TreadFront 59.6 in. (1515 mm)
Rear 59.3 in. (1505 mm)
Vehicle capacity weight
(occupants + luggage)915 lb. (415 kg)
Vehicle identification

3398-1. Specifications
8
Vehicle specifications
COROLLA iM_U (OM12K64U)■
Typical tire size information
The illustration indicates typical
tire size.
Tire use (P = Passenger car,
T = Temporary use)
Section width (millimeters)
Aspect ratio
(tire height to section width)
Tire construction code
(R = Radial, D = Diagonal)
Wheel diameter (inches)
Load index
(2 digits or 3 digits)
Speed symbol
(alphabet with one letter)
■Tire dimensions
Section width
Tire height
Wheel diameter
Tire size
1
2
3
4
5
6
7
1
2
3

375Alphabetical index
COROLLA iM_U (OM12K64U)
Daytime running light
system .................................... 143
Defogger
Outside rear view
mirrors ................................ 199
Rear window ......................... 199
Windshield ............................ 199
Dimensions .............................. 324
Dinghy towing .................. 125, 126
Display
Multi-information display ......... 76
Warning message ................ 300
Do-it-yourself maintenance .... 233
Door lock
Back door................................ 91
Side doors............................... 88
Wireless remote control .......... 88
Key.......................................... 88
Doors
Back door................................ 91
Door lock................................. 88
Door windows ....................... 106
Open door warning
buzzer............................. 90, 91
Outside rear view mirrors...... 104
Rear door child-protector ........ 90
Side doors............................... 88
Drive information ....................... 78
Driving ...................................... 110
Break-in tips .......................... 112
Correct posture ....................... 24
Procedures ........................... 110
Winter drive tips .................... 192Eco Driving Indicator ................ 81
Electric Power Steering
(EPS) ...................................... 186
Warning light......................... 293
Emergency, in case of
If a warning buzzer
sounds................................ 292
If a warning light turns on ..... 292
If a warning message is
displayed ............................ 300
If the battery is discharged ... 315
If the engine will not start ...... 314
If you have a flat tire ............. 303
If you think something is
wrong ................................. 290
If your vehicle becomes
stuck ................................... 321
If your vehicle has to be
stopped in an emergency ... 283
If your vehicle needs to be
towed.................................. 284
If your vehicle overheats....... 318
