Page 9 of 240
OVERVIEW OF INSTRUMENTS AND CONTROLS3
1. Headlight and turn signal switches
2. Wiper and washer switches
3. DPF (Diesel Particulate Filter) system
manual regeneration switch
(If equipped)
4. Emergency flasher switch
5. Air conditioning controls
6. Audio system
7. Rear fog light switch8. Auxiliary box
9. Cup holder
10. Headlight beam level control dial
11 . A s h t r a y
12. Cigarette lighter
13. Heater idle up switch
14. Engine switch
15. Tilt and telescopic steering lock
release lever
Dyna100/150_EE
Page 11 of 240
OVERVIEW OF INSTRUMENTS AND CONTROLS5
1. Card holder
2. Air conditioning controls
3. Emergency flasher switch
4. Heater idle up switch
5. Headlight and turn signal switches
6. Wiper and washer switches
7. Engine switch
8. Tilt and telescopic steering lock
release lever9. Cigarette lighter
10. Headlight beam level control dial
11 . A s h t r a y
12. Auxiliary box
13. Cup holder
14. Rear fog light switch
15. DPF (Diesel Particulate Filter) system
manual regeneration switch
(If equipped)
16. Audio system
Dyna100/150_EE
Page 15 of 240
OVERVIEW OF INSTRUMENTS AND CONTROLS9
Turn signal indicator lights
Engine preheating indicator light
The indicators marked withare service reminder indicators. For
details, see “Service reminder indicators and warning buzzer” on
page 73 in Section 1−5.
Dyna100/150_EE
Page 22 of 240
16KEYS AND DOORS
Tailgate—single cab models
Tailgate—double cab models
Side gates—single cab modelsonly
To lower the tailgate and side gates,
unlock the latches as shown.
On some models, the chains will hold the
tailgate in a straight open position.
See “Luggage stowage precautions” on
page 127 in Section 2 for precautions
when loading luggage.
When closing the gate, make sure it is
securely latched.
CAUTION
If the open tailgate hides the stop/tail
lights, back−up lights, rear retro re-
flectors, rear fog light or rear turn
signal lights while you are parked,
other road users must be warned of
the presence of your vehicle by a
warning triangle or other device.
NOTICE
Avoid driving with the tailgate or side
gates open.
: See “Model code” on page vi in the
beginning of this manual if you are not
sure of your vehicle model.
Dyna100/150_EE
Tailgate and side gates
Page 67 of 240
LIGHTS AND WIPERS61
Section 1−4
OPERATION OF INSTRUMENTS AND
CONTROLS
Lights and Wipers
DHeadlights and turn signals 62..........................
DHeadlight beam level control 63.........................
DEmergency flashers 64.................................
DRear fog light 64.......................................
DInterior light 65........................................
DWindshield wipers and washer 65.......................
Dyna100/150_EE
Page 68 of 240
62LIGHTS AND WIPERS
HEADLIGHTS
To turn on the following lights: Twist
the headlight/turn signal lever knob.
Position 1—Front position, tail, license
plate and instrument panel lights
Position 2—Headlights and all of the
above
However, on some models, all the lights
above also turn on when the engine is
started with the headlight switch off.
With the headlight beam level control
switch—Adjust the headlight beam level
before turning on the headlights. (See
“Headlight beam level control” on page 63
in this Section.)
Light reminder buzzer
A buzzer will remind you to turn the lights
off when the driver ’s door is opened if the
engine switch is turned to the “LOCK”
position with the headlight switch on.
NOTICE
To prevent the battery from being dis-
charged, do not leave the lights on
for a long period when the engine is
not running.
High−Low beams—For high beams, turn
the headlights on and push the lever away
from you (position 1). Pull the lever to-
ward you (position 2) for low beams.
The headlight high beam indicator light
(blue light) on the instrument panel will
tell you that the high beams are on.
Flashing the high beam headlights
(position 3)—Pull the lever all the way
back. The high beam headlights turn off
when you release the lever.
You can flash the high beam headlights
with the knob turned to “OFF”.
Dyna100/150_EE
Headlights and turn signals
Page 69 of 240
LIGHTS AND WIPERS63
TURN SIGNALS
To signal a turn, push the headlight/
turn signal lever up or down to position
1.
The engine switch must be in the “ON”
position.
The lever automatically returns after you
make a turn, but you may have to return
it by hand after you change lanes.
To signal a lane change, move the lever
up or down to the pressure point (position
2) and hold it.
If the turn signal indicator lights (green
lights) on the instrument panel flash faster
than normal, a front or rear turn signal
bulb is burned out. See “Replacing light
bulbs” on page 213 in Section 7−3.To adjust the headlight beam level, turn
the dial.
The following list shows examples of prop-
er dial settings. For loading conditions oth-
er than those listed, adjust the dial posi-
tion so that the beam level is the same
as the one obtained according to the list
when only the driver is in the vehicle. The
higher the number of the dial position, the
lower the headlight beam level.
Always keep the headlight beam at the
proper level, or your headlights may
dazzle other road users.
Loading condition and dial position
No luggage loading (driver only) 0
Driver + full luggage loading 3
Dyna100/150_EE
Headlight beam level control
Page 70 of 240
64LIGHTS AND WIPERS
To turn on the emergency flashers,
push the switch.
All the turn signal lights will flash. To turn
them off, push the switch once again.
Turn on the emergency flashers to warn
other drivers if your vehicle must be
stopped where it might be a traffic hazard.
Always pull as far off the road as possible.
The turn signal light switch will not work
when the emergency flashers are operat-
ing.
NOTICE
To prevent the battery from being dis-
charged, do not leave the switch on
longer than necessary when the en-
gine is not running.
To turn on the rear fog light, push the
switch. It will come on when the head-
lights are turned on.
The rear fog light will go off automatically
when all other lights are turned off.
After the headlight switch is turned off,
the rear fog light does not come on even
if you turn on the headlight switch again.
To turn on the rear fog light, push the
switch again under the condition stated
above.
Dyna100/150_EE
Emergency flashers Rear fog light
Page 92 of 240
86AUDIO SYSTEM
AF (Alternative Frequencies)
This button is used for seeking RDS (Ra-
dio Data System) stations all over the
band (see “RDS display”).
Push “AF” for less than 2 seconds to
receive the same program while tuning in
an RDS station. “AF” will appear on the
display. When reception conditions worsen,
a network which broadcasts the same pro-
gram will be selected using the AF (Alter-
native Frequencies) list from the RDS sta-
tion.
To change the AF mode, push “AF” for at
least 2 seconds. When “REG ON” appears
on the display, the radio will select the
RDS station which has the same PI (Pro-
gram Identification) code. When “REG
OFF” appears on the display, the radio
will select the RDS station which has the
same three−digit number PI (Program
Identification) code.
If the radio cannot find an RDS station for
60 seconds, the radio will mute all the
programs and begin seeking an RDS sta-
tion of the same PI code by using the AF
list. If the radio cannot seek out any sta-
tion in one pass because the signals are
too weak, the radio will begin seeking
again with sensitivity boosted to search
out weak stations. At this time, “DX” will
appear on the display. A beep will sound
and “PI SEEK” will appear on the display
to tell you when this feature starts opera-
tion.
If the signal gets extremely weak, the
radio will stop seeking a station and
“NOTHING” will appear on the display for
2 seconds. After this, if the radio cannot
receive a TA station for 20 seconds, the
radio will begin seeking again.
To cancel the AF mode, push “AF” once
again.BAL (Balance)
This knob lets you adjust the balance be-
tween the right and left speakers.
Pull out “PWR·VOL/BAL” and turn it.
BAND
Push “BAND” to switch between the LW/
MW and UKW bands.
“LW”, “MW” or “U1”, “U2” or “U3” will
appear on the display. Thesesystems al-
low you to set eighteen UKW stations,
three for each buttons.
If the audiosystem is off, you can turn
on the radio by pushing “BAND”.
PRESET (Preset buttons)
These buttons are used to preset and
tune in radio stations.
To preset a station to a button: Tune in
the desired station (see “TUNE” buttons).
Push and hold down the button until you
hear a beep—this will set the station to
the button. The button location will appear
on the display.
To tune in to a preset station: Push the
button for the station you want. The but-
ton location and station frequency will ap-
pear on the display.
These systems can store one LW/MW and
three UKW stations for each button. (The
display will show “LW/MW”, “U1”, “U2” or
“U3” when you push “BAND”.) The preset
station memory will be canceled out if the
power source is interrupted (battery dis-
connected or fuse blown).
Dyna100/150_EE
Page 93 of 240
AUDIO SYSTEM87
PTY (Program Type)
Push “PTY”. If the button is pushed while
receiving a PTY code of the RDS station,
the current program type (“NEWS”,
“SPORT”, “TALK”, “POP”, “CLASSICS”)
will appear on the display. If another pro-
gram type is desired, push “PTY” until
your desired program type appears.
If no PTY code of RDS station is re-
ceived, “NO PTY” will appear on the dis-
play.
If either “TUNE
” or “TUNE”is
pushed while the program type is ap-
peared on the display, the radio will
search a station that carries PTY code. If
the radio cannot seek out any stations,
“NOTHING” will appear on the display.
If the system is left untouched for 6 se-
conds while the program type is displayed,
or if another operation is made, the pro-
gram type display will disappear and the
radio will broadcast a program of the last
program type displayed.
PWR·VOL (Power·Volume)
Push “PWR·VOL” to turn the audiosystem
on and off. Turn “PWR·VOL” to adjust the
volume.
RDS (Radio Data System) display
The radio will automatically switch to the
RDS mode to receive an RDS station
while tuned to UKW broadcasts. “RDS”
and the name of the RDS station will
appear on the display.ST (Stereo reception) display
Your radio automatically changes to stereo
reception when a stereo broadcast is re-
ceived. “ST” appears on the display. If the
signal becomes weak, the radio reduces
the amount of channel separation to pre-
vent the weak signal from creating noise.
If the signal becomes extremely weak, the
radio switches from stereo to mono recep-
tion.
TA (Traffic Announcement)
This button is used for receiving TA sta-
tions all over the band.
EON (Enhanced Other Network)system—
If the RDS station (with EON data) you
are listening to is not broadcasting a traf-
fic information program at the TA (Traffic
Announcement) mode, the radio will be
switched to the traffic information program
automatically by using the EON AF list.
After the traffic information ends, the radio
will return to the initial program automati-
cally. A beep will sound to tell you when
this feature starts and ends the operation.
Push “TA” to switch the radio mode to TP.
“TP” will appear on the display.
In the TP mode, the radio will begin seek-
ing a TP station. When a TP station is
received, the program service name will
appear on the display. When also in AF
mode, the radio will seek a TP station by
using the AF list.
If the radio cannot seek out any TP sta-
tions, “NOTHING” will appear on the dis-
play for 2 seconds and start searching a
TP station again.
Once a TP station is received, if the TP
signal is halted for 20 seconds, the radio
will seek another TP station automatically.
Push “TA” once again to switch the radio
mode to TA. “TA TP” will appear on the
display.
Dyna100/150_EE
