Do-It-Yourself Products
TOYOTA MAINTENANCE & REPAIR SUPPORT13 Genuine Toyota Chemicals
Toyota offers a complete line of products to help you keep
your Toyota looking and running like new. To safeguard your
vehicle’s appearance, you’ ll find everything from fabric spot
remover and glass cleaner to liquid car wash and touch- up paint.
When it’s time to get under the hood (or under the car), products
such as fuel injector cleaner, brake fluid and silicone spray will
help you get the job done. All of these products are formulated
specifically for use with Toyota vehicles, so you can be confident
you’re giving your vehicle the best care possible, inside and out.
Genuine Toyota Antifreeze Coolant
Genuine Toyota Long Life Antifreeze Coolant is the same
high quality, factory- fill product found in all new Toyotas. You’ ll
know it by its distinctive red color. It provides maximum protec-
tion and durability without the use of harmful silicates. And
because it’s compatible with non- metallic materials, it helps
extend the life of water- pump seals. Don’ t trust your engine
to anything less than the best: Genuine Toyota Long Life
Antifreeze Coolant.
Genuine Toyota Motor Oil
Your Toyota’s engine features highly advanced technology
to ensure superior performance, reliability and fuel economy.
Genuine Toyota Motor Oil is formulated with a special combi-
nation of lube- base stocks and an additive blend to maximize
the benefits of this technology. Make sure you’re getting the
most out of your engine by always putting the best into it:
Genuine Toyota Motor Oil.

SCHEDULED MAINTENANCE LOGS22Engine Coolant
Drain and flush the cooling system and refill with an ethylene-
glycol type coolant. A qualified technician should perform
this operation.
Engine Oil and Oil Filter
Replace oil filter and drain and refill engine oil at specified
intervals. For recommended oil grade and viscosity, refer to
your
Owner’s Manual.
Engine Valve Clearance
Inspect for excessive lifter noise and engine vibration and adjust if
necessary. A qualified technician should perform this operation.
Exhaust Pipes and Mountings
Visually inspect the exhaust pipes, muffler and hangers for
cracks, deterioration and damage. Start the engine and listen
carefully for any exhaust gas leakage. Tighten connections or
replace parts as necessary.
Fuel Lines and Connections, Fuel Tank Band
and Fuel Tank Vapor Vent System Hoses
Visually inspect for corrosion, damage, cracks and loose or leaking
connections. Tighten connections or replace parts as necessary.
Fuel Tank Cap Gasket
Visually inspect for cracks, deterioration and damage and
replace if necessary.
Nuts and Bolts on Chassis and Body
Re- tighten the seat mounting bolts and front/rear suspension
member retaining bolts to specified torque.
Propeller Shaft
Lubricate the propeller shaft spiders and slide yokes with
lithium- base chassis grease and the double cardan joint with
molybdenum- disulfide lithium- base chassis grease, and re-
torque the bolt. Only a qualified technician should re- torque
the bolt.
Explanation of Maintenance Items

Maintenance Log.
. Cars & Sienna
SCHEDULED MAINTENANCE LOGS27
30,000 Miles or 24 Months
❑Replace engine air filter ❑ Replace engine oil and oil filter
❑Replace engine coolant ❑ Replace spark plugs (ECHO)2
❑Replace air conditioning filter (Avalon) ❑ Rotate tires (except MR2 Spyder)
❑Inspect the following:__
Ball joints and dust covers__
Drive shaft boots
__
Brake lines and hoses__
Exhaust pipes and mountings
__
Brake linings/drums and brake pads/discs__
Fuel tank cap gasket
__
Differential oil__
Steering gear box
__
Fuel lines and connections, fuel tank band__
Steering linkage and boots
and fuel tank vapor vent system hoses
__
Transmission fluid or oil
Additional Maintenance Items for Special Operating Conditions:1
❑ Inspect nuts and bolts on chassis and body
❑Replace automatic transmission fluid (Avalon, Camry,
Camry Solara, Corolla, Sienna)
❑Replace differential oil3
❑Replace manual transmission oil
30,000 Miles or 24 Months
30,000 Miles or 24 Months
❑Replace engine air filter ❑ Replace engine oil and oil filter
❑Replace engine coolant ❑ Replace non-platinum spark plugs (Echo)1
❑Replace air conditioning filter (Avalon) ❑ Rotate tires
1Specific services apply to specific operating conditions. See pages 18–19 for details.2Required under the terms of the Emission Control Warranty.3Applies to all models with manual transmission and Avalon, Camry,
Camry Solara, Corolla and Sienna models with automatic transmission.
Date: __________________
Mileage: _______________DEALER SERVICE VERIFICATION

Maintenance Log.
. Cars & Sienna
SCHEDULED MAINTENANCE LOGS31
60,000 Miles or 48 Months
❑Replace engine air filter❑Replace engine oil and oil filter
❑Replace engine coolant❑Rotate tires (except MR2 Spyder)
❑Replace air conditioning filter (Avalon)
❑Replace spark plugs (Camry, Camry Solara, ECHO, Sienna)2
❑Inspect the following:__
Ball joints and dust covers__
Drive shaft boots
__
Brake lines and hoses__
Engine valve clearance
__
Brake linings/drums and brake pads/discs__
Exhaust pipes and mountings
__
Charcoal canister (Sienna)
3__
Fuel tank cap gasket
__
Differential oil__
Steering gear box
__
Drive belts
4 __
Steering linkage and boots
__
Fuel lines and connections, fuel tank band__
Transmission fluid or oil
and fuel tank vapor vent system hoses
Additional Maintenance Items for Special Operating Conditions:1
❑Inspect nuts and bolts on chassis and body❑Replace automatic transmission fluid❑Replace differential oil
❑Replace manual transmission oil
60,000 Miles or 48 Months
60,000 Miles or 48 MonthsDate: __________________
Mileage: _______________DEALER SERVICE VERIFICATION
1Specific services apply to specific operating conditions. See pages 18–19 for details.2Required under the terms of the Emission Control Warranty.3Inspect at 60,000 miles or 72 months, whichever comes first.Required only for vehicles in
Required only for vehicles in California, Massachusetts and New York.
4Initial inspection at 60,000 miles. Inspect every 15,000 miles thereafter.

Maintenance Log.
. Cars & Sienna
SCHEDULED MAINTENANCE LOGS35
90,000 Miles or 72 Months
❑Replace engine air filter❑Replace engine oil and oil filter
❑Replace engine coolant❑Replace spark plugs (ECHO)2
❑Replace air conditioning filter (Avalon)❑Rotate tires (except MR2 Spyder)
❑Replace timing belt (Avalon, Camry, Camry Solara, Sienna)
❑Inspect the following:__
Ball joints and dust covers__
Drive shaft boots
__
Brake lines and hoses__
Exhaust pipes and mountings
__
Brake linings/drums and brake pads/discs__
Fuel tank cap gasket
__
Differential oil__
Steering gear box
__
Drive belts__
Steering linkage and boots
__
Fuel lines and connections, fuel tank band__
Transmission fluid or oil
and fuel tank vapor vent system hoses
Additional Maintenance Items for Special Operating Conditions:1
❑Inspect nuts and bolts on chassis and body❑Replace automatic transmission fluid (Avalon, Camry,
Camry Solara, Corolla, Sienna)
❑Replace differential oil3
❑Replace manual transmission oil
90,000 Miles or 72 Months
90,000 Miles or 72 Months
1Specific services apply to specific operating conditions. See pages 18–19 for details.2Required under the terms of the Emission Control Warranty.3Applies to all models with manual transmission and Avalon, Camry,
Camry Solara, Corolla and Sienna models with automatic transmission.
Date: __________________
Mileage: _______________DEALER SERVICE VERIFICATION

Maintenance Log.
. Cars & Sienna
SCHEDULED MAINTENANCE LOGS39
120,000 Miles or 96 Months
❑Replace engine air filter❑Replace engine oil and oil filter
❑Replace engine coolant❑Replace spark plugs (all models)2
❑Rotate tires (except MR2 Spyder)
❑Replace air conditioning filter (Avalon)
❑Inspect the following:__
Ball joints and dust covers__
Drive shaft boots
__
Brake lines and hoses__
Engine valve clearance
__
Brake linings/drums and brake pads/discs__
Exhaust pipes and mountings
__
Charcoal canister (Sienna)
3__
Fuel tank cap gasket
__
Differential oil__
Steering gear box
__
Drive belts__
Steering linkage and boots
__
Fuel lines and connections, fuel tank band__
Transmission fluid or oil
and fuel tank vapor vent system hoses
Additional Maintenance Items for Special Operating Conditions:1
❑Inspect nuts and bolts on chassis and body
❑Replace automatic transmission fluid
❑Replace differential oil
❑Replace manual transmission oil
120,000 Miles or 96 Months
120,000 Miles or 96 Months
1Specific services apply to specific operating conditions. See pages 18–19 for details.2Required under the terms of the Emission Control Warranty.3Inspect at 120,000 miles or 144 months, whichever comes first.Required only for vehicles in
Required only for vehicles in California, Massachusetts and New York.
Date: __________________
Mileage: _______________DEALER SERVICE VERIFICATION

Maintenance Log.
. SUVs & Trucks
SCHEDULED MAINTENANCE LOGS43
30,000 Miles or 24 Months
❑Replace engine air filter❑Replace engine oil and oil filter❑Replace engine coolant❑Rotate tires❑Replace limited-slip differential oil (Land Cruiser)3
❑Replace non-platinum spark plugs (Sequoia, Tacoma, Tundra, 4Runner)4
❑Lubricate propeller shaft (all 4WD except Highlander and RAV4)❑Lubricate wheel bearings and drive shaft bearings (Land Cruiser)❑Re-torque drive shaft bolt (Highlander, 4WD RAV4)❑Re-torque propeller shaft bolt (all models except Highlander and RAV4)❑Inspect the following:__
Automatic transmission fluid__
Fuel tank cap gasket
__
Ball joints and dust covers__
Limited-slip differential oil
(4WD__
Brake lines and hosesHighlander,4WD RAV4)3
__
Brake linings/drums and brake pads/discs__
Manual transmission oil (Tacoma,
__
Drive shaft boots (Land Cruiser; Highlander;Tundra)
RAV4; 4WD Tacoma, Tundra and 4Runner)__
Rear differential oil (all models except
__
Exhaust pipes and mountings2WD Highlander and 2WD RAV4)
__
Front differential oil (4WD models,__
Steering gear box
Highlander, RAV4)__
Steering linkage and boots
__
Fuel lines and connections, fuel tank band__
Transfer case oil (4WD models)
and fuel tank vapor vent system hoses
Additional Maintenance Items for Special Operating Conditions:1
❑Inspect nuts and bolts on chassis and body
❑Replace air conditioning filter (RAV4)
❑Replace automatic transmission fluid (all models except Highlander and RAV4)
❑Replace front differential oil (all 4WD except Highlander and RAV4 w/ auto-
matic transmission; 2WD Highlander and 2WD RAV4 w/ manual transmission)
❑Replace manual transmission oil
❑Replace rear differential oil (including limited-slip)
❑Replace transfer case oil (4WD models)
30,000 Miles or 24 Months
30,000 Miles or 24 Months
1Specific services apply to specific operating conditions. See pages 18–19 for details.2Do not replace if replaced at 20,000 miles/16 months.3If vehicle is equipped with limited-slip differential.4Required under the terms of the Emission Control Warranty.
Date: __________________
Mileage: _______________DEALER SERVICE VERIFICATION

Maintenance Log.
. SUVs & Trucks
SCHEDULED MAINTENANCE LOGS47
60,000 Miles or 48 Months
❑Replace engine air filter❑ Replace engine oil and oil filter❑Replace engine coolant❑ Rotate tires❑Replace limited-slip differential oil (Highlander, Land Cruiser, RAV4)2
❑Replace non-platinum spark plugs (Sequoia, Tacoma, Tundra, 4Runner)3
❑Lubricate propeller shaft (all 4WD except Highlander and RAV4)❑Lubricate wheel bearings and drive shaft bearings (Land Cruiser)❑Re-torque drive shaft bolt (Highlander, 4WD RAV4)❑Re-torque propeller shaft bolt (all models except Highlander and RAV4)❑Inspect the following:__
Automatic transmission fluid__
Exhaust pipes and mountings
__
Ball joints and dust covers__
Front differential oil (4WD models,
__
Brake lines and hosesHighlander, RAV4)
__
Brake linings/drums and brake pads/discs__
Fuel tank cap gasket
__
Charcoal canister (all models except __
Manual transmission oil (Tacoma,
Highlander and RAV4)
4Tundra)
__
Drive belts5__
Rear differential oil (all models except
__
Drive shaft boots (Highlander; Land Cruiser;2WD Highlander and 2WD RAV4)
RAV4; 4WD Tacoma, Tundra and 4Runner)__
Steering gear box
__
Engine valve clearance__
Steering linkage and boots
__
Fuel lines and connections, fuel tank band__
Transfer case oil (4WD models)
and fuel tank vapor vent system hoses
Additional Maintenance Items for Special Operating Conditions:1
❑Inspect nuts and bolts on chassis and body
❑Replace air conditioning filter (RAV4)
❑Replace front differential oil
❑Replace rear differential oil (including limited-slip)
❑Replace transfer case oil (4WD models)
❑Replace transmission fluid or oil
60,000 Miles or 48 Months
60,000 Miles or 48 Months
1Specific services apply to specific operating conditions. See pages 18–19 for details.2If vehicle is equipped with limited-slip differential.3Required under the terms of the Emission Control Warranty.4Inspect at 60,000 miles or 72 months, whichever comes first.
Required only for vehicles in California, Massachusetts and New York.
5Initial inspection at 60,000 miles. Inspect every 15,000 miles thereafter.
Date: __________________
Mileage: _______________DEALER SERVICE VERIFICATION

Maintenance Log.
. SUVs & Trucks
SCHEDULED MAINTENANCE LOGS51
90,000 Miles or 72 Months
❑Replace engine air filter❑Replace engine oil and oil filter❑Replace engine coolant❑Rotate tires❑Replace limited-slip differential oil (Land Cruiser)2
❑Replace non-platinum spark plugs (Sequoia, Tacoma, Tundra, 4Runner)3
❑Replace timing belt (except RAV4, 4-cyl. Highlander and 4-cyl. Tacoma)❑Lubricate propeller shaft (all 4WD except Highlander and RAV4)❑Lubricate wheel bearings and drive shaft bearings (Land Cruiser)❑Re-torque drive shaft bolt (Highlander, 4WD RAV4)❑Re-torque propeller shaft bolt (all models except Highlander and RAV4)❑Replace air conditioning filter (RAV4)❑Inspect the following:__
Automatic transmission fluid__
Front differential oil (4WD models,
__
Ball joints and dust coversHighlander, RAV4)
__
Brake lines and hoses__
Limited-slip differential oil
(4WD __
Brake linings/drums and brake pads/discsHighlander,4WD RAV4)2
__
Drive belts__
Manual transmission oil (Tacoma,
__
Drive shaft boots (Highlander; Land Cruiser;Tundra)
RAV4; 4WD Tacoma, Tundra and 4Runner)__
Rear differential oil (all models except
__
Exhaust pipes and mountings2WD Highlander and 2WD RAV4)
__
Fuel lines and connections, fuel tank band__
Steering gear box
and fuel tank vapor vent system hoses__
Steering linkage and boots
__
Fuel tank cap gasket__
Transfer case oil (4WD models)
Additional Maintenance Items for Special Operating Conditions:1
❑Inspect nuts and bolts on chassis and body
❑Replace automatic transmission fluid (all models except Highlander and RAV4)
❑Replace front differential oil (all 4WD except Highlander and RAV4 w/ auto-
matic transmission; 2WD Highlander and 2WD RAV4 w/ manual transmission)
❑Replace manual transmission oil
❑Replace rear differential oil (including limited-slip)
❑Replace transfer case oil (4WD models)
90,000 Miles or 72 Months
90,000 Miles or 72 Months
1Specific services apply to specific operating conditions. See pages 18–19 for details.2If vehicle is equipped with limited-slip differential.3Required under the terms of the Emission Control Warranty.
Date: __________________
Mileage: _______________DEALER SERVICE VERIFICATION

Maintenance Log.
. SUVs & Trucks
SCHEDULED MAINTENANCE LOGS55
120,000 Miles or 96 Months
❑Replace engine air filter❑Replace engine oil and oil filter❑Replace engine coolant❑Rotate tires❑Replace limited-slip differential oil (Highlander, Land Cruiser, RAV4)3
❑Replace spark plugs (all models)4
❑Lubricate propeller shaft (all 4WD except Highlander and RAV4)❑Lubricate wheel bearings and drive shaft bearings (Land Cruiser)❑Re-torque drive shaft bolt (Highlander, 4WD RAV4)❑Re-torque propeller shaft bolt (all models except Highlander and RAV4)❑Inspect the following:__
Automatic transmission fluid__
Exhaust pipes and mountings
__
Ball joints and dust covers__
Fuel lines and connections, fuel tank
__
Brake lines and hosesband and fuel tank vapor vent
__
Brake linings/drums and brake pads/discssystem hoses
__
Charcoal canister (all models except __ Fuel tank cap gasket
Highlander and RAV4)
5__ Manual transmission oil (Tacoma,
__
Drive beltsTundra)
__
Drive shaft boots (Highlander, Land Cruiser;__
Rear differential oil (all models except
RAV4; 4WD Tacoma, Tundra and 4Runner)2WD Highlander and 2WD RAV4)
__
Engine valve clearance__
Steering gear box
__
Front differential oil (4WD models,__
Steering linkage and boots
Highlander, RAV4)__
Transfer case oil (4WD models)
Additional Maintenance Items for Special Operating Conditions:1
❑Inspect nuts and bolts on chassis and body
❑Replace air conditioning filter (RAV4)
❑Replace front differential oil
❑Replace rear differential oil (including limited-slip)
❑Replace transmission fluid or oil
❑Replace transfer case oil (4WD models)
120,000 Miles or 96 Months
120,000 Miles or 96 Months
1Specific services apply to specific operating conditions. See pages 18–19 for details.2Do not replace if replaced at 110,000 miles/88 months.3If vehicle is equipped with limited-slip differential.4Required under the terms of the Emission Control Warranty.5Inspect at 120,000 miles or 144 months, whichever comes first.
Required only for vehicles in California, Massachusetts and New York.
Date: __________________
Mileage: _______________DEALER SERVICE VERIFICATION
