Checking the engine oil level
SU72001
Low levelFull level
Add
oil O.K.
To o
full
With the engine at operating tempera-
ture and turned off, check the oil level
on the dipstick.
1. To get a true reading, the vehicle should be on a level spot. After turning
off the engine, wait a few minutes for
the oil to drain back into the bottom of
the engine.
2. Pull out the dipstick, and wipe it clean with a rag.
3. Reinsert the dipstick—Push it in as far as it will go, or the reading will not be
correct.
4. Pull the dipstick out and look at the oil level on the end.
NOTICE
To avoid drops of the engine oil fal-
ling when you pull out the engine oil
dipstick, make sure to hold a rag un-
der the dipstick.
CAUTION
Be careful not to touch the hot ex-
haust manifold.
If the oil level is below or only slightly
above the low level, add engine oil of
the same type as already in the engine.
Remove the oil filler cap and add engine
oil in small quantities at a time, checking
the dipstick.
The approximate quantity of oil needed to
fill between the low level and the full level
on the dipstick is indicated below for ref-
erence.
When the level reaches within the correct
range, install the f iller cap handtight.
Oil quantity, L (qt., lmp. qt.): 1.5 (1.6, 1.3)
NOTICE
Be careful not to drop the engine
oil on the vehicle components.
 Avoid overfilling, or the engine
could be damaged.
 Check the oil level on the dipstick
once again after adding the oil.
Engine oil selection
Use API grade SJ “EnergyConserving”,
SL “EnergyConserving” or ILSAC
multigrade engine oil.
Recommended viscosity (SAE):
OIL05U
SAE 5W30 is the best choice for your
vehicle, for good fuel economy, and
good starting in cold weather.

2001MY ECHO (U) L/O0008
1962002 ECHO (OM52463U)
Look at the seethrough coolant reser-
voir when the engine is cold. The cool-
ant level is satisfactory if it is between
the “FULL” and “LOW” lines on the
reservoir. If the level is low, add ethyl-
eneglycol type coolant for a proper
corrosion protection of aluminum com-
ponents.
The coolant level in the reservoir will vary
with engine temperature. However, if the
level is on or below the “LOW” line, add
coolant. Bring the level up to the “FULL”
line.
Always use ethyleneglycol type coolant
for a proper corrosion protection of alumi-
num components. See information in the
next column.
If the coolant level drops within a short
time after replenishing, there may be a
leak in the system. Visually check the
radiator, hoses, engine coolant filler cap,
radiator cap and drain cock and water
pump.
If you can find no leak, have your Toyota
dealer test the cap pressure and check
for leaks in the cooling system.CAUTION
To prevent burning yourself, do not
remove the radiator cap when the en-
gine is hot.
Coolant type selection
Use of improper coolants may damage
your engine cooling system. Your coolant
must contain ethyleneglycol type coolant
for a proper corrosion protection of your
engine that contains aluminum compo-
nents. Use “TOYOTA Long Life Coolant”
or equivalent.
In addition to preventing freezing and sub-
sequent damage to the engine, this will
also prevent corrosion. Further supplemen-
tal inhibitors or additives are neither need-
ed nor recommended.
Read the coolant container for information
on freeze protection. Follow the manufac-
turer’s directions for how much to mix
with plain water (preferably demineralized
water or distilled water). The total capacity
of the cooling system is given in Section
8. We recommend to use 50% solution for
your Toyota, to provide protection down to
about 35
C (31 F). When it is extreme-
ly cold, to provide protection down to
about 50 °C (58 °F), 60% solution is rec-
ommended. Do not use more than 70%
solution for better coolant performance.NOTICE
Do not use alcohol type antifreeze or
plain water alone.
Checking the engine coolant
level

2002MY ECHO (U) L/O0109
1972002 ECHO (OM52463U)
Checking the radiator
If the radiator is extremely dirty or you
are not sure of its condition, take your
vehicle to Toyota dealer.
CAUTION
To prevent yourself from burning, be
careful not to touch the radiator when
the engine is hot.
NOTICE
To prevent damage to the radiator, do
not perform the work by yourself.
Checking brake fluid
SU72002
To check the fluid level, simply look at
the seethrough reservoir. The level
should be between the “MAX” and
“MIN” lines on the reservoir.
It is normal for the brake fluid level to go
down slightly as the brake pads wear. So
be sure to keep the reservoir filled.
If the reservoir needs frequent refilling, it
may indicate a serious mechanical prob-
lem.
If the level is low, add SAE J1703 or
FMVSS No.116 DOT 3 brake fluid to the
brake reservoir. Remove and replace the reservoir cap by
hand. Fill the brake fluid to the dotted
line. This brings the fluid to the correct
level when you put the cap back on.
Use only newly opened brake fluid. Once
opened, brake fluid absorbs moisture from
the air, and excess moisture can cause a
dangerous loss of braking.
CAUTION
Take care when filling the r
eservoir
because brake fluid can harm your
eyes and damage painted surfaces. If
fluid gets in your eyes, flush your
eyes with clean water immediately. If
you still feel uncomfortable with your
eyes, go to the doctor.
NOTICE
If you spill some of the fluid, be sure
to wash it off with water to prevent
it from damaging the parts or paint.

2001MY ECHO (U) L/O0008
1982002 ECHO (OM52463U)
Checking power steering fluid
SU72009Open
Close
Check the fluid level through the reser-
voir. If necessary, add automatic trans-
mission fluid DEXRON II or III.
If the vehicle has been driven around 80
km/h (50 mph) for 20 minutes (a little
more in frigid temperatures), the fluid is
hot (60 C—80 C or 140 F—175 F). You
may also check the level when the fluid
is cold (about room temperature,
10 C—30 C or 50 F—85 F) if the engine
has not been run for about five hours.
SU72010
If cold O.K.
If cold add
If hot O.K.
If hot add
a. Clean all dirt from outside of the reser-
voir tank.
b. Remove the rubber cap. c. Remove the reservoir cap by turning it counterclockwise and wipe the dipstick
clean.
d. Reinstall the reservoir cap.
e. Remove the reservoir cap again and look at the fluid level. If the fluid is
cold, the lever should be in the “COLD”
range on the dipstick. Similarly, if it is
hot, the fluid level should be in the
“HOT” range. If the level is at the low
side of either range, add automatic
transmission fluid DEXRON II or III to
bring the level within the range.

2002MY ECHO (U) L/O0109
2072002 ECHO (OM52463U)
NOTICE
Be sure the engine and all accesso-
ries are off before performing main-
tenance.
 When checking the battery, remove
the ground cable from the negative
terminal (“” mark) first and rein-
stall it last.
 Be careful not to cause a short cir-
cuit with tools.
 Take care no solution gets into the
battery when washing it.
—Checking battery c ondition
SU73002
Ty p e A
Green DarkClear or
light yellow
Blue white
Red
Ty p e B
CHECKING BY THE INDICATOR
Check the battery condition by the indi-
cator color.
Indicator color
ConditionTy p e ATy p e B
GREENBLUEGood
DARKWHITE
Charging necessary.
Have battery
checked by your
Toyota dealer.
CLEARor
LIGHT
YELLOW
RED
Have battery
checked by your
Toyota dealer.
Battery recharging precautions
During recharging, the battery is pro-
ducing hydrogen gas.
Therefore, before recharging:
1. If recharging with the battery installed on the vehicle, be sure to disconnect
the ground cable.
2. Be sure the power switch on the re- charger is off when connecting the
charger cables to the battery and when
disconnecting them.
CAUTION
Always charge the battery in an un-
confined area. Do not charge the
battery in a garage or closed room
where there is not sufficient ventila-
tion.
Only do a slow charge (5A or less).
Charging at a quicker rate is dan-
gerous. The battery may explode,
causing personal injuries.
NOTICE
Never recharge the battery while the
engine is running. Also, be sure all
accessories are turned off.

2002MY ECHO (U) L/O0109
2172002 ECHO (OM52463U)
Service specifications
ENGINE
Valve clearance (engine cold), mm (in.):Intake 0.150.25 (0.0060.010)
Exhaust 0.250.35 (0.0100.014)
Spark plug type: DENSO K16RU
NGK BKR5EYA
Spark plug gap, mm(in.): 0.8 (0.031)
Drive belt tension measured with Bor-
roughs drive belt tension gauge No.
BT3373F (used belt), lbf: Generator belt 100 20
Power steering pump belt 65 10 ENGINE LUBRICATION
Oil capacity (drain and ref
ill), L (qt., Imp.
qt.):
With filter 3.7 (3.9, 3.3)
Without filter 3.4 (3.6, 3.0)
Oil grade: API grade SJ “EnergyConserving”, SL
“EnergyConserving” or ILSAC multi-
grade engine oil is recommended.
Recommended oil viscosity (SAE):
OIL05U
COOLING SYSTEM
Total capacity, L (qt., Imp. qt.): Manual transmission 4.4 (4.7, 3.9)
Automatic transmission 4.3 (4.5, 3.8)
Coolant type:
“TOYOTA Long Life Coolant” or equiva-
lent
With ethyleneglycol type coolant for a
proper corrosion protection of aluminum
components
Do not use alcohol type antifreeze or
plain water alone.
BATTERY
Open voltage
∗ at 20 C (68 F):
12.612.8 V Fully charged
12.212.4 V Half charged
11.812.0 V Discharged
∗: Voltage that is checked 20 minutes af-
ter the key is removed with all the lights
turned off
Charging rates: 5 A max.

2001MY ECHO (U) L/O0008
2262002 ECHO (OM52463U)
A
Adding washer fluid209
. . . . . . . . . . . . . . . .
Adjustment
Front seats 26
. . . . . . . . . . . . . . . . . . . . . . .
Seat belt 32
. . . . . . . . . . . . . . . . . . . . . . . . .
Air conditioning system 120
. . . . . . . . . . . . .
Airbags 40
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Aluminum wheel precautions 203 . . . . . . . .
Antiglare inside rear view mirror 71 . . . . .
Antilock brake system warning light 82
. . . . . . . . . . . . . . . . . . . . . .
Antitheft steering column lock 88 . . . . . . .
Appearance care Cleaning the interior 177
. . . . . . . . . . . . . .
Protecting your Toyota from
corrosion 174
. . . . . . . . . . . . . . . . . . . . . .
Washing and waxing 175
. . . . . . . . . . . . . .
Automatic transmission
Driving with a automatic transmission 89
. . . . . . . . . . . . . . . . . . . .
Shift pattern 89
. . . . . . . . . . . . . . . . . . . . . .
Shift speed 89
. . . . . . . . . . . . . . . . . . . . . . .
Auxiliary box 130
. . . . . . . . . . . . . . . . . . . . . .
Auxiliary catch, Engine hood 19
. . . . . . . . .
B
Battery
Checking battery condition 206 . . . . . . . .
Gas caution 206 . . . . . . . . . . . . . . . . . . . . .
Handling safety 206 . . . . . . . . . . . . . . . . . .
Recharging precautions 207 . . . . . . . . . . .
Winter driving tips 150 . . . . . . . . . . . . . . . . Before starting the engine 148
. . . . . . . . . . .
Brake pad wear indicators 142 . . . . . . . . . . .
Brake system 139 . . . . . . . . . . . . . . . . . . . . . .
Brake system warning light 82 . . . . . . . . . .
Brakes Fluid level 194 . . . . . . . . . . . . . . . . . . . . . . .
Pad wear indicators 142 . . . . . . . . . . . . . .
Parking 94 . . . . . . . . . . . . . . . . . . . . . . . . . .
Breakin tips 134 . . . . . . . . . . . . . . . . . . . . . .
Brightness control 76 . . . . . . . . . . . . . . . . . . .
C
Car audio system 95
. . . . . . . . . . . . . . . . . . .
Carbon monoxide caution 138
. . . . . . . . . . .
Checking and replacing fuses 208 . . . . . . . .
Checking brake fluid 197
. . . . . . . . . . . . . . . .
Checking the engine oil level 194 . . . . . . . .
Checking the radiator 197
. . . . . . . . . . . . . . .
Child restraint Child restraint system 54
. . . . . . . . . . . . .
Installation 56
. . . . . . . . . . . . . . . . . . . . . . .
Precautions 53
. . . . . . . . . . . . . . . . . . . . . .
Types of child restraint system 55 . . . . . .
Cigarette lighter and ashtray 128
. . . . . . . . .
Cleaning the interior 177
. . . . . . . . . . . . . . . .
Clock 128
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cold weather Operation 150
. . . . . . . . . . . . .
Controls, Instrument panel 2,4
. . . . . . . . . .
Cooling system
Coolant level 196
. . . . . . . . . . . . . . . . . . . .
Engine overheating 159
. . . . . . . . . . . . . . .
Radiator and reservoir 196
. . . . . . . . . . . . Radiator cap
159
. . . . . . . . . . . . . . . . . . . . .
Winter driving tips 150
. . . . . . . . . . . . . . . .
Corrosion prevention 174
. . . . . . . . . . . . . . .
Cup holders 131
. . . . . . . . . . . . . . . . . . . . . . .
D
Defogger, Rear window 77
. . . . . . . . . . . . . .
Dimmer switch, Headlight 74
. . . . . . . . . . . .
Dinghy towing 151
. . . . . . . . . . . . . . . . . . . . .
Directional signals 74
. . . . . . . . . . . . . . . . . .
Discharge warning light 82
. . . . . . . . . . . . . .
Doityourself maintenance
Parts and tools 189
. . . . . . . . . . . . . . . . . . .
Service precautions 187
. . . . . . . . . . . . . .
Does your vehicle need repairing? 183 . . .
Driving Automatic transmission 89
. . . . . . . . . . . .
Driving tips 149,150
. . . . . . . . . . . . . . . . . .
Manual transmission 93
. . . . . . . . . . . . . .
Driving tips
Driving tips in various conditions 149
. . . . . . . . . . . . . . . . . . . . .
Driving with a
automatic transmission 89
. . . . . . . . . .
Driving with a manual transmission 93
. . . . . . . . . . . . .
Economical driving 153
. . . . . . . . . . . . . . .
Good driving practice 89,93
. . . . . . . . . . .
Winter driving tips 150
. . . . . . . . . . . . . . . .
During Breakin 134
. . . . . . . . . . . . . . . . . . . . . . . .

2002MY ECHO (U) L/O0109
2272002 ECHO (OM52463U)
E
Economical drivingSaving money on both fuel
and repairs 153 . . . . . . . . . . . . . . . . . . . .
Electrical system Battery 206,207 . . . . . . . . . . . . . . . . . . . . . .
Fuse locations 187 . . . . . . . . . . . . . . . . . . .
Fuses 208 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Emergency flasher switch 75 . . . . . . . . . . . .
Emergency, In case of Blown fuse 208 . . . . . . . . . . . . . . . . . . . . . .
Emergency flasher switch 75 . . . . . . . . . .
Flat tire 160 . . . . . . . . . . . . . . . . . . . . . . . . .
If you cannot shift automatic transmission selector lever 171 . . . . . .
If you lose your keys 172 . . . . . . . . . . . . . .
If your engine stalls while driving 159 . . . . . . . . . . . . . . . . . . .
If your vehicle needs to be towed 168 . . . . . . . . . . . . . . . . . . . .
If your vehicle will not start 156 . . . . . . . .
Jump starting 157 . . . . . . . . . . . . . . . . . . . .
Overheating 159 . . . . . . . . . . . . . . . . . . . . .
Towing 168 . . . . . . . . . . . . . . . . . . . . . . . . . .
Emissions inspection and maintenance (I/M) programs 184 . . . . . . .
Engine Before starting the engine 148 . . . . . . . . .
Checking the coolant level 196 . . . . . . . .
Emission control device 136 . . . . . . . . . . .
Engine compartment 186 . . . . . . . . . . . . . .
Exhaust gas caution 138 . . . . . . . . . . . . . . Hood release 19
. . . . . . . . . . . . . . . . . . . . .
Oil consumption 138 . . . . . . . . . . . . . . . . . .
Oil level 194 . . . . . . . . . . . . . . . . . . . . . . . . .
Overheating 159 . . . . . . . . . . . . . . . . . . . . .
Starting procedure 147 . . . . . . . . . . . . . . .
Threeway catalytic converter 136 . . . . .
Engine coolant
Temperature gauge 80 . . . . . . . . . . . . . . . .
Winter driving tips 150 . . . . . . . . . . . . . . . .
Engine coolant temperature gauge 80 . . . .
Engine oil Winter driving tips 150 . . . . . . . . . . . . . . . .
Exhaust gas caution 138 . . . . . . . . . . . . . . . .
F
Facts about engine oil
consumption 138 . . . . . . . . . . . . . . . . . . . . .
Flasher, Headlight 74 . . . . . . . . . . . . . . . . . . .
Flat tire After changing wheels 167 . . . . . . . . . . . .
Changing tires 165 . . . . . . . . . . . . . . . . . . .
If you have a flat tire 160 . . . . . . . . . . . . . .
Jack point 164 . . . . . . . . . . . . . . . . . . . . . . .
Jacking precautions 160 . . . . . . . . . . . . . .
Jacking up 164 . . . . . . . . . . . . . . . . . . . . . .
Loosening wheel nuts 164 . . . . . . . . . . . . .
Lowering vehicle 166 . . . . . . . . . . . . . . . . .
Reinstalling w heel ornament 167 . . . . . . .
Removing wheel ornament 164 . . . . . . . .
Wheel block 163 . . . . . . . . . . . . . . . . . . . . .
Wheel nuts 166 . . . . . . . . . . . . . . . . . . . . . .
Floor mat 131 . . . . . . . . . . . . . . . . . . . . . . . . . . Fluid level
Brake 197 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power steering 198 . . . . . . . . . . . . . . . . . . .
Washer fluid 209 . . . . . . . . . . . . . . . . . . . . .
Folddown rear seat 29 . . . . . . . . . . . . . . . . .
Foreign countries, Operation in 136 . . . . . .
Front passenger ’s seat 28 . . . . . . . . . . . . . .
Front seats 26,27 . . . . . . . . . . . . . . . . . . . . . .
Fuel Filler door o pener 22. . . . . . . . . . . . . . . . .
Fuel economy 153 . . . . . . . . . . . . . . . . . . . .
Fuel information 134 . . . . . . . . . . . . . . . . . .
Gauge 80 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Operation in foreign countries 136 . . . . .
Tank cap 22 . . . . . . . . . . . . . . . . . . . . . . . . .
Fuse locations 187 . . . . . . . . . . . . . . . . . . . . .
Fuses Fuse box 208 . . . . . . . . . . . . . . . . . . . . . . . .
G
Gauge
Engine coolant temperature 80 . . . . . . . .
Fuel 80 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Glove box 130 . . . . . . . . . . . . . . . . . . . . . . . . .
Good driving practice Automatic transmission 89 . . . . . . . . . . . .
Manual transmission 93 . . . . . . . . . . . . . .
H
Hazard switch 75
. . . . . . . . . . . . . . . . . . . . . .
Head restraints 31
. . . . . . . . . . . . . . . . . . . . .
Headlight switch 74
. . . . . . . . . . . . . . . . . . . .
