Instrument panel overview
1. Side vents
2. Instrument cluster
3. Center vents
4. Rear view mirror remote control levers
5. Auxiliary box
6. Power door lock switches(with power windows)
7. Power window switches
8. Glove box
9. Automatic transmission selector lever or manual transmission gear shift lever
10. Parking brake lever 11. Power door lock switch (without power windows)
12. Hood lock release lever
13. Window lock switch
SU11001

2002MY ECHO (U) L/O0109
252002 ECHO (OM52463U)
OPERATION OF INSTRUMENTS AND
CONTROLS
Seats, Seat belts, Steering wheel and Mirrors
Seats26
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . .
Front seats 26
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . .
Folddown rear seat 29
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . .
Head restraints 31
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . .
Seat belts 32
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . . .
SRS driver and front passenger airbags 40
. . . . . . . . . . . . . . . . . . . . . . . .
SRS side airbags 48
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . .
Child restraint 53
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . .
Tilt steering wheel 69
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . .
Outside rear view mirrors 70
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
.
Antiglare inside rear view mirror 71
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Vanity mirror 72
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . .
SECTION 1 3

2001MY ECHO (U) L/O0008
702002 ECHO (OM52463U)
CAUTION
Do not adjust the steering wheel
while the vehicle is moving. It may
cause the driver to mishandle the
vehicle and an accident may occur
resulting in death or serious inju-
ries.
After adjusting the steering wheel,
try moving it up and down to make
sure it is locked in position.
Outside rear view mirrors—
SU13058
Adjust the mirror so that you can just
see the side of your vehicle in the mir-
ror.
Be careful when judging the size or dis-
tance of any object seen in the outside
rear view mirror on the passenger ’s side.
It is a convex mirror with a curved sur-
face. Any object seen in a convex mirror
will look smaller and farther away than
when seen in a flat mirror.
CAUTION
Do not adjust the mirror while the
vehicle is moving. Doing so may
cause the driver to mishandle the ve-
hicle and an accident may occur re-
sulting in death or serious injuries.

2002MY ECHO (U) L/O0109
712002 ECHO (OM52463U)
SY13077a
To adjust the rear view mirror, simply
operate the control lever.
NOTICE
If ice should jam the mirror, do not
operate the control or scrape the mir-
ror face. Use a spray deicer to free
the mirror.
SP13503
Adjust the mirror so you can just see
the rear of your vehicle in the mirror.
To reduce glare from the headlights of
the vehicle behind you during night
driving, operate the lever on the lower
edge of the mirror.
Daylight driving—Lever at position 1
The reflection in the mirror has greater
clarity at this position.
Night driving—Lever at position 2
Remember that by reducing glare you also
lose some rear view clarity.
CAUTION
Do not adjust the mirror while the
vehicle is moving. Doing so may
cause the driver to mishandle the ve-
hicle and an accident may occur re-
sulting in personal injuries.
—Rear view mirror remote
controlAntiglare inside rear view
mirror

2001MY ECHO (U) L/O0008
1482002 ECHO (OM52463U)
Before starting the engine
1. Check the area around the vehicle be-fore entering it.
2. Adjust seat position, seatback angle, head restraint height and steering
wheel angle.
3. Adjust inside and outside rear view mirrors.
4. Lock all doors.
5. Fasten seat belts. 1. Apply the parking brake firmly.
2. Turn off unnecessary lights and acces-
sories.
3. Manual transmission: Press the clutch
pedal to the floor and shift the trans-
mission into neutral. Hold the clutch
pedal to the floor until the engine is
started. A starter safety device will pre-
vent the starter from operating if the
clutch pedal is not fully depressed.
Automatic transmission: Put the se-
lector lever in “P”. If you need to re-
start the engine while the vehicle is
moving, put the selector lever in “N”.
A starter safety device will prevent the
starter from operating if the selector
lever is in any drive position.
4. Automatic transmission only: De-
press the brake pedal and hold it to
the floor until driving off.
(b) Starting the engine
Before starting the engine, be sure to
follow the instructions in “(a) Before
cranking”.
Normal starting procedure
The multiport fuel injection system/sequen-
tial multiport fuel injection system in your
engine automatically controls the proper
airfuel mixture for starting. You can start
a cold or hot engine as follows:
1. With your foot off the accelerator ped- al, crank the engine by turning the key
to “START”. Release it when the en-
gine starts.
2. After the engine runs for about 10 se- conds, you are ready to drive.
If the weather is below freezing, let the
engine warm up for a few minutes before
driving.
If the engine stalls...
Simply restart it, using the correct proce-
dure given in normal starting.
If the engine will not start...
See “If your vehicle will not start” in Sec-
tion 4.
How to start the engine—
(a) Before cranking

2001MY ECHO (U) L/O0008
2262002 ECHO (OM52463U)
A
Adding washer fluid209
. . . . . . . . . . . . . . . .
Adjustment
Front seats 26
. . . . . . . . . . . . . . . . . . . . . . .
Seat belt 32
. . . . . . . . . . . . . . . . . . . . . . . . .
Air conditioning system 120
. . . . . . . . . . . . .
Airbags 40
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Aluminum wheel precautions 203 . . . . . . . .
Antiglare inside rear view mirror 71 . . . . .
Antilock brake system warning light 82
. . . . . . . . . . . . . . . . . . . . . .
Antitheft steering column lock 88 . . . . . . .
Appearance care Cleaning the interior 177
. . . . . . . . . . . . . .
Protecting your Toyota from
corrosion 174
. . . . . . . . . . . . . . . . . . . . . .
Washing and waxing 175
. . . . . . . . . . . . . .
Automatic transmission
Driving with a automatic transmission 89
. . . . . . . . . . . . . . . . . . . .
Shift pattern 89
. . . . . . . . . . . . . . . . . . . . . .
Shift speed 89
. . . . . . . . . . . . . . . . . . . . . . .
Auxiliary box 130
. . . . . . . . . . . . . . . . . . . . . .
Auxiliary catch, Engine hood 19
. . . . . . . . .
B
Battery
Checking battery condition 206 . . . . . . . .
Gas caution 206 . . . . . . . . . . . . . . . . . . . . .
Handling safety 206 . . . . . . . . . . . . . . . . . .
Recharging precautions 207 . . . . . . . . . . .
Winter driving tips 150 . . . . . . . . . . . . . . . . Before starting the engine 148
. . . . . . . . . . .
Brake pad wear indicators 142 . . . . . . . . . . .
Brake system 139 . . . . . . . . . . . . . . . . . . . . . .
Brake system warning light 82 . . . . . . . . . .
Brakes Fluid level 194 . . . . . . . . . . . . . . . . . . . . . . .
Pad wear indicators 142 . . . . . . . . . . . . . .
Parking 94 . . . . . . . . . . . . . . . . . . . . . . . . . .
Breakin tips 134 . . . . . . . . . . . . . . . . . . . . . .
Brightness control 76 . . . . . . . . . . . . . . . . . . .
C
Car audio system 95
. . . . . . . . . . . . . . . . . . .
Carbon monoxide caution 138
. . . . . . . . . . .
Checking and replacing fuses 208 . . . . . . . .
Checking brake fluid 197
. . . . . . . . . . . . . . . .
Checking the engine oil level 194 . . . . . . . .
Checking the radiator 197
. . . . . . . . . . . . . . .
Child restraint Child restraint system 54
. . . . . . . . . . . . .
Installation 56
. . . . . . . . . . . . . . . . . . . . . . .
Precautions 53
. . . . . . . . . . . . . . . . . . . . . .
Types of child restraint system 55 . . . . . .
Cigarette lighter and ashtray 128
. . . . . . . . .
Cleaning the interior 177
. . . . . . . . . . . . . . . .
Clock 128
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cold weather Operation 150
. . . . . . . . . . . . .
Controls, Instrument panel 2,4
. . . . . . . . . .
Cooling system
Coolant level 196
. . . . . . . . . . . . . . . . . . . .
Engine overheating 159
. . . . . . . . . . . . . . .
Radiator and reservoir 196
. . . . . . . . . . . . Radiator cap
159
. . . . . . . . . . . . . . . . . . . . .
Winter driving tips 150
. . . . . . . . . . . . . . . .
Corrosion prevention 174
. . . . . . . . . . . . . . .
Cup holders 131
. . . . . . . . . . . . . . . . . . . . . . .
D
Defogger, Rear window 77
. . . . . . . . . . . . . .
Dimmer switch, Headlight 74
. . . . . . . . . . . .
Dinghy towing 151
. . . . . . . . . . . . . . . . . . . . .
Directional signals 74
. . . . . . . . . . . . . . . . . .
Discharge warning light 82
. . . . . . . . . . . . . .
Doityourself maintenance
Parts and tools 189
. . . . . . . . . . . . . . . . . . .
Service precautions 187
. . . . . . . . . . . . . .
Does your vehicle need repairing? 183 . . .
Driving Automatic transmission 89
. . . . . . . . . . . .
Driving tips 149,150
. . . . . . . . . . . . . . . . . .
Manual transmission 93
. . . . . . . . . . . . . .
Driving tips
Driving tips in various conditions 149
. . . . . . . . . . . . . . . . . . . . .
Driving with a
automatic transmission 89
. . . . . . . . . .
Driving with a manual transmission 93
. . . . . . . . . . . . .
Economical driving 153
. . . . . . . . . . . . . . .
Good driving practice 89,93
. . . . . . . . . . .
Winter driving tips 150
. . . . . . . . . . . . . . . .
During Breakin 134
. . . . . . . . . . . . . . . . . . . . . . . .
