812004 ECHO from Aug. ’03 Prod. (OM52526U)
SP14015
TURN SIGNALS
To signal a turn, push the headlight/
turn signal lever up or down to position
1.
The key must be in the “ON” position.
The lever automatically returns after you
make a turn, but you may have to return
it by hand after you change lanes.
To signal a lane change, move the lever
up or down to the pressure point (position
2) and hold it.
If the turn signal indicator lights (green
lights) on the instrument panel flash faster
than normal, a front or rear turn signal
bulb is burned out.
Emergency flashers
SU14014
To turn on the emergency flashers,
push the switch.
All the turn signal lights will flash. To turn
them off, push the switch once again.
Turn on the emergency flashers to warn
other drivers if your vehicle must be
stopped where it might be a traffic hazard.
Always pull as far off the road as pos-
sible.
The turn signal light switch will not work
when the emergency flashers are operat-
ing.
NOTICE
To prevent the battery from being dis-
charged, do not leave the switch on
longer than necessary when the en-
gine is not running.

2362004 ECHO from Aug. ’03 Prod. (OM52526U)
The inside of the lens of exterior lights
such as headlights may temporarily fog up
when the lens becomes wet in the rain or
in a car wash. This is not a problem
because the fogging is caused by the
temperature difference between the outside
and inside of the lens, just like the
windshield fogged up in the rain. However,
if there is a large drop of water on the
inside of the lens, or if there is water
pooled inside the light, contact your
Toyota dealer.Light bulbsBulb
No.WTy p e
HeadlightsHB260/55A
Front fog lights900651B
Parking·front side
marker/front turn
signal lights
1157NA8/27C
Rear turn signal
lights744021D
Rear side marker
lightsW5W5D
Stop/tail lights744321/5D
Back−up lights744021D
License plate lightsW5W5D
High mounted
stoplight92118D
Interior light—8E
Trunk light1943.8D
A: HB2 halogen bulbs
B: HB4 halogen bulbs
C: Single end bulbs (amber)
D: Wedge base bulbs
E: Double end bulbs
—Headlights
SU73036a
1. Unplug the connector. Remove the
rubber cover.
If the connector is tight, wiggle it.

2382004 ECHO from Aug. ’03 Prod. (OM52526U)
SU73053a
2. Pull the bulb out of the bulb base.
If the connector is tight, wiggle it.
SU73054a
3. Install a new bulb base by turning it
clockwise to the front of the vehicle.
SU73013d
SU73014b
—Parking/front side
marker/front turn signal lights
