steering wheel TOYOTA FJ CRUISER 2008 1.G Quick Reference Guide

1
INDEX
Engine maintenance 7Fuel tank door release and cap6Hood release 7Indicator symbols 4-5Instrument cluster 4Instrument panel2-3
Keyless entry16
Accessory meter 13Air Conditioning/Heating 16Audio 14-15Auto LSD (Limited Slip Differential) 18Automatic Transmission 8Bottle holders-Rear seat 19Clock 16Cruise control 17Cup holders 18Door-Back 13Four-wheel drive 9Intuitive parking assist 17Light control-Instrument panel17Lights1& turn signals 12Manual Transmission 8Parking brake 10Power outlet-12V DC 19Power outlet-115V AC 19Seat adjustments-Front 10Seats-Folding rear seats 11Seats-Head restraints 10Seats-Removing rear seats 11Tilt steering wheel 8Windows 13
Windshield wipers & washers 12
Door locks 20Seat belts 20Seat belts-Shoulder belt anchor 20Spare tire & tools 21
Tire Pressure Warning System 21
OVERVIEW
FEATURES/OPERATIONS
SAFETY AND EMERGENCY FEATURES
OVERVIEW
FEATURES/OPERATIONS
SAFETY AND
EMERGENCY FEATURES
1Visit your Toyota dealer for information on this and other customizable
options.

OVERVIEW
Instrument panel
2
Power rearview mirror controls*
Instrument panel light control
Headlight and turn signal control
Wiper and washer controls
Back window defogger button
Emergency flasher button
Audio system
Clock
Front passenger occupant classification indicator
Front passenger seat belt reminder light
Air Conditioning controls
Rear differential lock button
*
Active traction control switch*
Sub woofer ON-OFF button*
Power outlet
AUX audio jack
Steering wheel
controls (if equipped)

FEATURES/OPERATIONS
8
Automatic Transmission
Downshifting increases power going uphill, or provides engine braking
downhill. For best fuel economy during normal driving conditions, always
drive with the shift lever in the “D” position.
Park1
Reverse
Neutral
Drive
Third gear
Second gear
First gear
P
R
N
D
4
3
2
L
Fourth gear
Manual Transmission
For safety, the engine will not start unless the clutch pedal is FULLY
depressed. This function can be cancelled by pushing the “Clutch start
cancel switch.”
Tilt steering wheel
Hold the steering wheel, pull the lock release lever, tilt to the desired
angle and release the lever.
Note: Do not attempt to adjust while the vehicle is in motion.
1 The key must be in the “ON” position and the brake pedal depressed
to shift from “Park.”

15
OVERVIEW
FEATURES/OPERATIONS
SAFETY AND EMERGENCY FEATURES
RADIO
Preset buttons Tune in the desired station and press a preset button (1-6)
until you hear a beep. Push desired preset button (1-6) to select.
“SCAN” Push and hold “SCAN” to scan preset stations. Push again to hold
selection.
“ ”
Volume control
“ ”
-In radio modePush to select a preset station; push and hold to seek
the next strong station.
-In CD modePush to skip up or down to the next or previous track.
“MODE”
Push to turn audio ON and select an audio mode. Push and hold to turn
the audio “OFF.”
>>
Steering wheel switches (if equipped)
-+
Subwoofer switch (if equipped)
ON/OFF
By inserting a mini plug into the AUX audio jack, you can listen to music
from a portable audio device through the vehicle’s speaker system.
AUX audio jack
