351
6-1. Specifications
6
Vehicle specifications
Electrical system
Differential
*: Your Scion vehicle is filled with “Toyota Genuine Differential Gear Oil” at the
factory. Use Scion approved “Toyota Genuine Differential Gear Oil” or an
equivalent of matching quality to satisfy the above specification. Please con-
tact your Scion dealer for further details.
Battery
Specific gravity reading at
68 F (20 C): 1.250  1.290 Fully charged
1.160  1.200 Half charged
1.060  1.100 Discharged
Charging rates
Quick charge
Slow charge15 A max.
5 A max.
Oil capacity (Refer-
ence)
1.20 qt. (1.15 L, 1.01 Imp. qt.)
Oil type and viscosity*Without LSD
• Toyota Genuine Differential Gear Oil LT
• Other gear oil that meets API GL-5 and SAE 75W-85
With LSD • Toyota Genuine Differential Gear Oil LX
• Other LSD gear oil that meets API GL-5 and SAE 75W-85
NOTICE
■ Differential gear oil
Using a differential gear oil other than “Toyota Genuine Differential Gear Oil”
may cause occurrences of rattling noises while idling and poor fuel con-
sumption.
Never use different brands together.

367
6-1. Specifications
6
Vehicle specifications
Tire related termMeaning
Normal occupant
weight 150 lb. (68 kg) times the number of occupants
specified in the second column of Table 1
* that
follows
Occupant distribution Distribution of occupants in a vehicle as speci-
fied in the third column of Table 1
* below
Production options
weight The combined weight of installed regular pro-
duction options weighing over 5 lb. (2.3 kg) in
excess of the standard items which they
replace, not previously considered in curb
weight or accessory weight, including heavy
duty brakes, ride levelers, roof rack, heavy duty
battery, and special trim
Rim A metal support for a tire or a tire and tube
assembly upon which the tire beads are seated
Rim diameter
(Wheel diameter) Nominal diameter of the bead seat
Rim size designation Rim diameter and width
Rim type designation The industry manufacturer’s designation for a
rim by style or code
Rim width Nominal distance between rim flanges
Vehicle capacity
weight (Total load
capacity) The rated cargo and luggage load plus 150 lb.
(68 kg) times the vehicle’s designated seating
capacity
Vehicle maximum load
on the tire The load on an individual tire that is determined
by distributing to each axle its share of the
maximum loaded vehicle weight, and dividing
by two

406 Alphabetical index
CareExterior .................................. 222
Interior ................................... 226
Seat belts .............................. 227
Cargo capacity ......................... 182
Chains ....................................... 189
Child restraint system Booster seats,
definition ............................. 107
Booster seats, installation ........................... 111
Convertible seats, definition ............................. 107
Convertible seats,
installation ........................... 111
Front passenger occupant classification system .............99
Infant seats, definition ............................. 107
Infant seats,
installation ........................... 111
Installing CRS with LATCH anchors .................. 112
Installing CRS with seat belts ............................ 114
Installing CRS with
top tether straps .................. 117
Child safety Airbag precautions ..................92
Battery precautions ....... 253, 334
Child restraint system............ 107
How your child should
wear the seat belt .................42
Installing child restraints ........ 111
Power window lock switch.......52
Power window precautions ...........................54
Removed key battery
precautions ......................... 274
Seat belt guide ........................41
Seat belt precautions ..............44
Trunk precautions ...................30 Cleaning
Exterior.................................. 222
Interior ................................... 226
Seat belts .............................. 227
Clock ......................................... 214
Condenser ................................ 249
Console tray ............................. 210
Cooling system
Engine overheating ............... 336
Cruise control .......................... 171
Cup holders .............................. 210
Customizable features ............ 373
Daytime running light system .................................... 165
Defogger
Rear window ......................... 201
Side mirror ............................ 201
Dimension ................................ 344
Dinghy towing .......................... 192
Display Multi-information display ....... 159
Trip information ..................... 160
Do-it-yourself maintenance .... 236
Doors Door lock ........................... 22, 25
Door windows ......................... 52
Side mirrors............................. 49
Driver's seat belt reminder light ........................ 311
Driving
Break-in tips .......................... 125
Correct posture ....................... 62
Procedures............................ 122
Winter drive tips .................... 187C
D

407
Alphabetical index
Electric power steering........... 176
Emergency flashers
Switch ................................... 298
Emergency, in case of If the engine will not start...... 329
If the shift lever cannot
be shifted from P ................ 330
If the vehicle has a
discharged battery ............. 332
If the warning buzzer sounds ............................... 308
If the warning light turns on .............................. 308
If you have a flat tire ............ 318
If you lose your keys............. 331
If you think something is wrong ................................. 306
If your vehicle becomes stuck................................... 339
If your vehicle has to be
stopped in an
emergency ......................... 341
If your vehicle needs to
be towed ............................ 299
If your vehicle overheats ...... 336 Engine
Compartment ........................243
Engine switch ........................135
Hood......................................239
How to start the engine .........135
Identification number .............345
If the engine will not start ......329
Ignition switch........................135
Overheating...........................336
Engine coolant Capacity ................................350
Checking ...............................247
Engine coolan t temperature
gauge ......................................151
Engine immobilizer system.......59
Engine oil Capacity ................................348
Checking ...............................244
Preparing and checking before winter .......................187
Engine switch ...........................135
Engine switch light ..................205
EPS ............................................176
Event data recorder ...................16E

410 Alphabetical index
Parking brake ........................... 149
Parking lightsReplacing light bulbs ............. 284
Switch.................................... 164
Wattage ................................. 355
Power outlets ........................... 216
Power windows ..........................52
Radiator .................................... 249
Rear seats ...................................36
Rear side marker lights Replacing light bulbs ............. 284
Wattage ................................. 355
Rear turn signal lights Replacing light bulbs ............. 284
Switch.................................... 148
Wattage ................................. 355
Rear window defogger ............ 201
Replacing Fuses .................................... 276
Key battery ............................ 273
Light bulbs ............................. 284
Tires ...................................... 318
Reporting safety defects for U.S. owners ...................... 376
REV indicator ........................... 125 Seat belts
Adjusting the seat belt............. 40
Automatic Locking
Retractor (ALR) .................... 42
Child restraint system
installation........................... 111
Cleaning and maintaining the seat belts ...................... 227
Emergency Locking Retractor (ELR) .................... 42
How to wear your seat belt ..... 40
How your child should
wear the seat belt ................. 42
Pregnant women,
proper seat belt use .............. 45
Reminder light ....................... 311
Seat belt guide ........................ 41
Seat belt pretensioners ........... 41
Seating capacity ...................... 186P
R
S

413
Alphabetical index
Warning buzzers
Electric power steering ......... 309
Seat belt reminder ................ 311
Warning lights Automatic transmission
fluid temperature
warning light ....................... 311
Anti-lock brake
system................................ 309
Brake assist system ............. 309
Brake system........................ 308
Charging system .... .............. 308
Cruise control indicator light ...................... 309
Electric power steering system warning light .......... 309
Electronic engine control
system................................ 309
Engine oil pressure............... 308
Low fuel level........................ 311
Low tire pressure .................. 311
Malfunction indicator lamp ................................... 309
Open door ............................ 311
Pretensioners ....................... 309
Seat belt reminder light .................................... 311
Slip indicator light ................. 309
SRS airbags ......................... 309
Tire pressure warning system................................ 311
Washer
Checking .............................. 254
Preparing and checking before winter ...................... 187
Switch ................................... 168
Washing and waxing............... 222 Weight
Cargo capacity ......................182
Load limits .............................186
Weight ...................................344
Wheels ......................................267
Window glasses ........................52
Window lock switch ...................52
Windows
Power windows .......................52
Rear window defogger ..........201
Washer ..................................168
Windshield wipers ...................168
Wireless remote control key Locking/Unlocking ...................22
Replacing the battery ............273
Wireless remote control key ....22W
