10
When your vehicle is receiving signals from
the satellites, the “GPS” mark appears at the
top left of the screen.
The GPS signal may be physically ob-
structed, leading to inaccurate vehicle posi-
tion on the map display. Tunnels, tall build-
ings, trucks, or even the placement of objects
on the instrument panel may obstruct the
GPS signals.
The installation of window tinting may also ob-
struct the GPS signals. Most window tinting
contains some metallic content that will inter-
fere with the GPS signal reception. We ad-
vice against the use of window tinting on ve-
hicles equipped with navigation systems.
The GPS satellites may not send signals due
to repairs or improvements being made to
them.Even when the navigation system is receiving
clear GPS signals, the vehicle position may
not be shown accurately or inappropriate
route guidance may occur in some cases.
(a) Accurate current vehicle
position may not be shown in
the following cases:
When driving on a small angled Y−shaped
road.
When driving on a winding road.
When driving on a slippery road such as
in sand, gravel, snow, etc.
When driving on a long straight road.
When freeway and surface streets run in
parallel.
After moving by ferry or vehicle carrier.
When a long route is searched during high
speed driving.
When driving without setting the current
position calibration correctly.
After repeating a change of direction by
going forward and backward, or turning on
a turntable in the parking lot.
When leaving a covered parking lot or
parking garage.
When a roof carrier is installed.
When driving with tire chains installed.
When the tires are worn.
After replacing a tire or tires.
When using tires that are smaller or larger
than the factory specifications.

158
(c) Outside temperature
display
Outside temperature is displayed on the
screen.
The displayed temperature ranges from
−30
C (−22
F) up to 50
C (122
F). If the
temperature does not appear on the display
or it shows “− − −”, take your vehicle to your
dealer.
(d) Operating tips
To cool off your vehicle after it has been
parked in the hot sun, drive with the win-
dows open for a few minutes. After the ex-
cess heat has blown away, close the win-
dows. This vents the hot air, allowing the
air conditioning to cool the interior more
quickly.
Make sure the air intake grilles in front of
the windshield are not blocked (by leaves
or snow, for example).
If air flow control is not satisfactory, check
the side vents. (See “(e) Side vents”.)
On humid days, do not blow cold air on the
windshield. The windshield could fog up
because of the difference in air tempera-
ture on the inside and outside of the wind-
shield.
Keep the area under the front seats clear
to allow air to circulate throughout the ve-
hicle.
On cold days, set the fan speed to high for
a minute to help clear the intake ducts of
snow or moisture. This can reduce the
amount of fogging on the windows.
When driving on dusty roads, close all win-
dows. If dust thrown up by the vehicle is
still drawn into the vehicle after closing the
windows, it is recommended that the air in-
take control button be set to the FRESH
mode to take in the fresh air and the fan
speed selector to any setting except OFF.
If following another vehicle on a dusty
road, or driving in windy and dusty condi-
tions, it is recommended that the air intake
be temporarily set to the RECIRCULATED
mode, which will close off the outside pas-
sage and prevent outside air and dust
from entering the vehicle interior.

159 Heating
For best results, set controls to:
For automatic operation —
Push in the “AUTO” button.
Temperature —To the desired tempera-
ture
Air intake — FRESH (outside air)
Air conditioning — OFF
For manual operation —
Fan speed — To the desired fan speed
Temperature —Towards high tempera-
ture
Air intake — FRESH (outside air)
Air flow — FLOOR
Air conditioning — OFF
For quick heating, select RECIRCU-
LATED mode for a few minutes. To keep
the windows from fogging, select FRESH
mode after the vehicle interior has been
warmed.
Touch the “A/C” switch on for dehumidified
heating.
Choose floor/windshield air flow to heat
the vehicle interior while defrosting or de-
fogging the windshield.Air conditioning
For best results, set controls to:
For automatic operation —
Push in the “AUTO” button.
Temperature — To the desired tempera-
ture
Air intake — FRESH (outside air)
Air conditioning — ON
For manual operation —
Fan speed — To the desired fan speed
Temperature — Towards low temperature
Air intake — FRESH (outside air)
Air flow — PANEL
Air conditioning —ON
For quick cooling, select RECIRCU-
LATED mode for a few minutes.Ventilation
For best results, set controls to:
For automatic operation —
Push in the “AUTO” button.
Temperature — Towards low temperature
Air intake — FRESH (outside air)
Air conditioning — OFF
For manual operation —
Fan speed — To the desired fan speed
Temperature — Towards low temperature
Air intake — FRESH (outside air)
Air flow — PANEL
Air conditioning — OFF
Defogging and defrosting
— The inside of the windshield
For best results, set controls to:
For automatic operation —
Temperature — Towards high temperature
to heat;
low temperature to cool
Air intake — FRESH (outside air)
Air flow — WINDSHIELD

161
(f) Checking and replacing
the air conditioning filter
The air conditioning filter information label
is placed in the glove box as shown and in-
dicates that a filter has been installed.
The air conditioning filter prevents dust from
entering the vehicle through the air condition-
ing vent.
The air conditioning filter is behind the
glove box.
The air conditioning filter may clog after long
use. The filter may need to be replaced if the
air flow of the air conditioner and heater expe-
riences extreme reductions in operating effi-
ciency, or if the windows become to fog up
easily.
If the symptoms of air conditioning efficiency
problems occur, contact your nearest dealer
to have the filter checked and replaced.To maintain the air conditioning efficiency, in-
spect and replace the air conditioning filter ac-
cording to the maintenance schedule. In
dusty areas or areas with heavy traffic flow,
such as inner city or desert areas, early re-
placement may be required. (For scheduled
maintenance information, please refer to the
“Scheduled Maintenance Guide” or “Owner’s
Manual Supplement”.)
