stop start TOYOTA HIGHLANDER 2007 XU40 / 2.G Navigation Manual

ii
Important information about this manual
For safety reasons, this manual indicates
items requiring particular attention with the
following marks.
CAUTION
This is a warning against anything
which may cause injury to people if the
warning is ignored. You are informed
about what you must or must not do in
order to reduce the risk of injury to
yourself and others.
NOTICE
This is a warning against anything
which may cause damage to the ve-
hicle or its equipment if the warning is
ignored. You are informed about what
you must or must not do in order to
avoid or reduce the risk of damage to
your vehicle and its equipment.
INFORMATION
This provides additional information.
Initial screen
When you start the engine or turn the ignition
switch to the “ACC” position, the initial
screen appears and the system begins
operating.
CAUTION
When the vehicle is stopped with the
engine running, always apply the park-
ing brake for safety.
After a few seconds, the “CAUTION” screen
appears.
Touch either “English” or
“Français” to select a language. Read
and follow the instructions.
When you touch the
“I Agree” switch
on the screen, the map screen appears.
You can access this screen when you push
the
“INFO” button and touch the “Lan-
guage”
switch. Then you can select a lan-
guage.

38
— Destination input by
“Previous”
Touch the “Previous” switch on the
“Destination” screen.
The previous starting point and up to 99 pre-
viously set destinations are displayed on the
screen.
Touch the switch of the desired destina-
tion. The screen changes and displays the
map location of the selected destination
and the route preference. (See “ — Enter-
ing destination” on page 42.)
“Date”: To list the previous destinations in or-
der of registered date.
“Name”: To list the previous destinations in
alphabetical order.
INFORMATION
You can delete the list of previous des-
tinations while your vehicle is stopped,
if you no longer need them. (See page
95.)
— Destination input by “Map”
Touch the “Map” switch on the “Destina-
tion” screen.
The screen changes and displays the map
location that was previously displayed
just before the destination input operation
and the route preference. (See “ — Enter-
ing destination” on page 42.)
INFORMATION
Guidance starts if you touch the “En-
ter” switch even while driving. Howev-
er, the cursor cannot be moved.

42
Starting route guidance —
— Entering destination
After you input the destination, the screen
changes and displays the map location of
the selected destination and the route
preference.
SCREEN A
1. When you touch an arrow facing the
desired point, the map scrolls in that
direction. When you release your finger,
scrolling stops.
2. To set the destination and display
SCREEN B, touch the
“Enter” switch.
When the destination is already set, the
“Add to ” switch and the “Replace
” switch are displayed.
“Add to
”: To add a destination.“Replace
”: To delete the existing destina-
tions and set a new one.
“Change”: To change the route preference.
(See page 43.)
“Info.”: If this switch is displayed on the top
of the screen, touch the switch to see name,
address, and phone number, etc.
SCREEN B
3. To start guidance, touch the
“Guide”switch.
“3 Routes”: To select the desired route from
three possible routes. (See page 43.)
“Route”: To change the route. (See pages
46 and 48.)
INFORMATION
Guidance can be suspended or re-
sumed. (See page 66.)
If you keep touching the
“Guide”switch until a beep sounds, Demo
mode will start.

56 Touch the
“Map” switch of your desired
point. The point which you choose is dis-
played on the map screen.Route preview
1. Touch the “Map View” switch.
2. Touch the “Route Preview” switch.
:To indicate the next destination.
:To preview the route to the next des-
tination.
:To preview the route to the next des-
tination in fast−forward mode.
:To stop the preview.
:To review the route to the previous
destination or starting point.
:To review the route to the previous
destination or starting point in fast−
forward mode.
:To indicate the previous destination
or starting point.

11 3 “After refueling”
The average fuel consumption is calculated
and displayed based on total driving distance
and total fuel consumption with the engine
running.
The displayed value is updated every 10 sec-
onds.
Every time you refuel the vehicle, the calcula-
tion is reset. When refueling, be sure to stop
your vehicle and turn the ignition switch off.
“Cruising range”
The distance the vehicle can travel with the
remaining fuel is calculated and displayed
based on the quantity of remaining fuel and
past fuel consumption.
The driving range display indicates the
approximate distance that you can drive until
the fuel gauge reaches “E”. It is different from
the actual distance traveled.
The displayed value is updated every time the
fuel equivalent for 1 mile or 1 km is consumed.
Every time you refuel the vehicle, the calcula-
tion is reset. When refueling, be sure to stop
your vehicle and turn the ignition switch off.
The actual driving range varies with driving
habits and road conditions. If fuel consump-
tion is good, the driving range will be longer.
If fuel consumption is poor, the driving range
will be shorter.If the low fuel level warning light comes on, re-
fuel even if the display indicates that the ve-
hicle can be driven further.
“Average speed”
The average speed is calculated and dis-
played based on the total driving distance and
the total driving time after the engine is star-
ted.
The displayed value is updated every 10 sec-
onds.
“Distance”
The distance after engine starting is dis-
played.
“Reset”
To reset the calculations of “Average speed”
and “Distance”.
Screen setting
1. Push the “INFO” button to display the
“Information Menu” screen.
2. Touch the “Screen Setting” switch.

128
(e) Traffic announcement
“TRAF” switch:
A station that regularly broadcasts traffic in-
formation is automatically located.
When you push the “TRAF” switch, “TRAF
SEEK” appears on the display and the radio
will start seeking any traffic program station.
If any traffic program station is not found,
“NOTHING” appears on the display.
If the traffic program station is found, the
name for traffic program station is displayed
and “TRAF” is lit for a while until traffic an-
nouncement is received.
— Cassette tape player
operation
(a) Inserting or ejecting a cassette tape
Put the cassette tape in the slot with the
exposed tape side to the right and lightly
push it in.
To stop and eject the cassette tape, push
the “
” button.
The player will automatically start when you
insert the cassette tape. At this time, “TAPE”
appears on the screen.
If a metal or chrome equivalent cassette tape
is put in the cassette player, the player will au-
tomatically recognize it and “MTL” appears
on the screen.
(b) Playing a cassette tape
Push the “TAPE” button if a cassette tape
is already in the slot.
Dolby
B NR∗:
If you are listening to a tape that was recorded
with Dolby Noise Reduction, touch the
switch on the screen. The symbol is high-
lighted in yellow.
The Dolby NR mode reduces tape noise by
about 10 dB. For best sound reproduction,
play your tapes with the Dolby NR on or off ac-
cording to the mode used for recording the
tape.
To play a tape recorded without Dolby NR,
touch the switch once again.

138
CAUTION
Conversational speech on some DVDs
is recorded at a low volume to empha-
size the impact of sound effects. If you
adjust the volume assuming that the
conversations represent the maximum
volume level that the DVD will play, you
may be startled by louder sound effects
or when you change to a different audio
source. The louder sounds may have a
significant impact on the human body or
pose a driving hazard. Keep this in mind
when you adjust the volume.
This “DVD Hint!” screen appears when the
video screen is first displayed after you
turn the ignition key to “ACC” or “ON”.
Touch “OK” when you read the message.DVD video
DVD audio
PLAYING A DVD DISC
Push the “AUDIO” button to display DVD
screen.
It you touch the “PICTURE” switch when the
vehicle is completely stopped and the parking
brake is applied, the video screen returns.

139
DISPLAYING DVD CONTROLS
If you touch a part of the screen, where con-
trols are not located while you are watching
video, DVD controls will appear.
“Page2”: Touching this will display on the
second page of DVD controls.
“Page1”: Touching this will display the top
page of DVD controls.
“Hide Buttons” switch: Touching this will
turn off the controls from the screen.
If “
” appears on the screen when you touch
a control, the operation relevant to the control
is not permitted.
DESCRIPTION OF DVD VIDEO
CONTROLS
Top page controls
“Menu” and “Top Menu”: If you touch any
of the above controls, the menu screen for
DVD video appears. (For the operation, see
the manual that come with the DVD video disc
provided separately.)
“
”: The menu control key appears on
the screen. (See page 140.)
“
”: Touching this will pause the video
screen. When you touch this again, the video
screen advances frame by frame.
“”: Touching this will fast reverse during
playback and reverse slowly during pause.
“”: Touching this switch will resume normal
play after stop or pause.
“”: Touching this will fast forward during
playback and forward slowly during pause.
Second page controls
“Setup”: The initial set up screen appears.
(See page 143.)
“Search”: The title search screen appears.
(See page 141.)
“Return”: Touching this will display the pre-
determined scene and start playing from
there.
“Audio”: The audio changing screen ap-
pears. (See page 142.)
“Sub title”: The subtitle changing screen ap-
pears. (See page 142.)
“Angle”: The angle selection screen ap-
pears. (See page 143.)

140
DESCRIPTION OF DVD AUDIO
CONTROLS
Top page controls
“Top Menu”: If you touch this switch, the
menu screen for DVD audio appears. (For
operation, refer to the DVD audio disc manual
that is provided separately.)
“Audio”: The audio changing screen ap-
pears. (See page 143.)
“
”: The menu control key appears on
the screen. (See page 140.)
“
”: Touch this switch to pause the disc.
“”: Touching this will fast reverse.
“”: Touching this will resume normal play
after stop or pause.
“”: Touching this will fast forward.
Second page controls
“Setup”: The initial set up screen appears.
(See page 143.)
“Search”: The group search screen ap-
pears. (See page 141.)
“Return”: Touching this will display the pre-
determined scene and start playing from
there.
“Prev. Still”: Touch this switch to reverse the
still pictures. (See page 142.)
“Next Still”: Touch this switch to forward the
still pictures. (See page 142.)
“Sub title”: The subtitle changing screen ap-
pears. (See page 142.)
“Angle”: The angle selection screen ap-
pears. (See page 143.)SELECTING A MENU ITEM
Enter the menu item using “”, “”, “”
and “” switches and touch “Enter”. The
player starts playing DVD for that menu
item. (For details, see the manual that
comes with the DVD provided separately.)
Each time you touch “Move Buttons”, the
controls on the screen move upward and
downward.
When you touch “< disappear. To display them again, touch “ON”
switch.
When you touch “Back”, the previous screen
returns.
