phone TOYOTA HIGHLANDER 2008 XU40 / 2.G Navigation Manual

OTHER FUNCTIONS
137
(iv) By received calls
You can call by received calls. When a
call is received, the system memorizes
up to 5 numbers. If it is more than 5, the
oldest number is deleted.
This cannot be operated while driving.
1. Touch “Call Log” to display “Outgo-
ing Call” screen.
2. Touch “Incoming Calls” to display
“Incoming Calls” screen.
When a telephone number registered
in the phone book is received, the
name and the number are displayed.
Received calls which you did not
answer are also memorized in the
system and “Abs.” is displayed on the
left side of the number.
Received calls which you refused are
also memorized in the system and
“
” is displayed on the left side of the
number.
Unnoticed telephone number such as
a public telephone is not memorized in
the system.
3. Select the desired number from the
list.
Touch or push the switch of the
steering wheel.
An international phone call may not be
made depending on the cellular phone
which you have.

OTHER FUNCTIONS
138
(v) By speed dial
You can call by registered telephone
number which you selected from a
phone book, dialed numbers and re-
ceived calls. (See page 144 for register-
ing the speed dial.)
1. Touch “Speed Dial” to display
“Speed Dial” screen.
2. Touch the desired number to call.
You can change the page by touching
“Speed Dial 2” or “Speed Dial 3”.
When you push the telephone button while
driving, the screen above appears. Touch
the desired name to call. (The telephone
number is not displayed.)(vi) By voice recognition
You can call by giving a command. (For
the operation and command of voice
recognition, see “Speech command
system” on page 174 and “Help
screen” on page 177.)

OTHER FUNCTIONS
139
Dialing by name
You can call by giving a voice tag regis-
tered in the phone book. For setting the
voice recognition, see “Setting the
voice recognition” on page 157.
Example: Call DAD
You: Push the talk switch.
System: “After the beep, please say the
name.”
You: “DAD”
System: “DAD chosen, when ready,
please briefly push the talk
switch or push the off−hook
switch to dial.”
You: Push the talk switch.
System: “After the beep, please say
“Dial”.”
You: “Dial.”
System: “Dialing the name.”
Now you are calling DAD.
“Next” is displayed when multiple entries
are found for a searched name.
Up to 6 entries can be displayed including
the first searched one.
Do the following to change the entry to the
next one.
Touch “Next”
Push the talk switch to say “Next Can-
didate”.
Calling without the voice recognition
After the entry number is displayed, you
can also call by pushing the telephone
switch or touching “Dial”.
Cancelling the voice recognition
The voice recognition will be cancelled
when you do the following.
Keep on pushing the talk switch
Push the switch of the steering
wheel.
Touch “Cancel”. (Except for recogniz-
ing the command)
Say “Cancel”

OTHER FUNCTIONS
140
Dialing by phone number
You can call by giving a desired num-
ber.
You: Push the talk switch.
System: “After the beep, please say the
number.”
You: “812387”
System: “When ready, please briefly
push the talk switch or push
the off−hook switch to dial.”
You: Push the talk switch.
System: “After the beep, please
continue to add numbers or
say “Dial”.”
You: “Dial.”
System: “Dialing the number.”
Now you are calling 812387.
Sending a tone
You can send a tone by giving a desired
number.
You: Push the talk switch.
System: “Say numbers, pound, or star.”
You: “1234.”
System: “1234.” “Push the talk switch.”
You: Push the talk switch.
System: “Send? Say Yes or No.”
You: “Yes.”
System: “Sending.”
Now you are sending the tone.

OTHER FUNCTIONS
141
(vii) By POI call
You can call by touching when
it is displayed on the screen from Navi-
gation system. (See page 31 for de-
tails.)
(c) Receive on the Bluetooth
phone
When a call is received, this screen is
displayed with a sound. Touch
or
push the
switch of the steering
wheel to talk on the phone.
To hang up the phone:
Touch
or push the switch of
the steering wheel again.
To refuse to receive the call:
Touch
and hold it.
To adjust the volume of received call:
Touch
“–” or “+” or use the volume
switch of the steering wheel.
On the international phone call, the other
party’s name may not be displayed cor-
rectly depending on the cellular phone
which you have.

OTHER FUNCTIONS
142
(d) Talk on the Bluetooth
phone
While you are talking on the phone, this
screen is displayed. You can do the op-
eration below on the screen.
To adjust the volume of the other party’s
voice:
Touch
“–” or “+” or use the volume
switch of the steering wheel.
To hang up the phone:
Touch
or push the switch of
the steering wheel.
To mute your voice:
Touch “Mute”.
To input a Key:
Touch “09”.
To transfer the call
Touch “Transfer Call”.
You cannot change from Hands−free call
to cellular phone call while driving.
When you change from cellular phone call
to Hands−free call, the Hands−free screen
will be displayed and you can operate it on
the screen.
Transferring method and behavior are dif-
ferent depending on the cellular phone
which you have.
For the operation of the phone, see the
manual that comes with your cellular
phone.
Touch the desired number to input the key.
To hang up the phone:
Touch
or push the switch of
the steering wheel.
This cannot be operated while driving.

OTHER FUNCTIONS
143
If the continuous tone signal is regis-
tered in a phone book, this screen ap-
pears. (If not registered, “Send” and
“Exit” are not displayed.)
Confirm the number displayed on the
screen and touch “Send”. The number
before marked sign will be sent.
When you touch “Exit”, this function will
be finished and normal tone screen ap-
pears.
To hang up the phone:
Touch
or push the switch of
the steering wheel.
The continuous tone signal is the marked
sign (p or w) and the number following tele-
phone number. (ex. 056133p0123w#1
)
You can do this operation when you want
to operate an answering machine or use a
telephone service in bank for example.
You can register the phone number and
the code number in the phone book.
Sending a tone by the speed tone
You can send a tone by the speed tone.
(For registering the speed tone, see
“Registering the speed tone” on page
146.)
1. Touch “Speed Tone”.
2. Touch the desired switch to send a
tone.

OTHER FUNCTIONS
144
(e) Change the settings of the
Bluetooth phone
Touch “Settings” to display “Settings”
screen.
You can change the settings of the
phone.(i) Registering the speed dial
You can register the desired telephone
number from phone book, dialed num-
bers and received calls. Up to 17 speed
dial numbers can be registered.
The 6th entry is the speed dial for redialing.
1. Touch “Speed Dial” to display the
“Speed Dial Settings” screen.
2. Touch “Register” of “Speed Dial”.
3. Select the data you want to register.

OTHER FUNCTIONS
145
4. Touch the desired telephone num-
ber.
5. Touch the touchscreen button you
want to register in.
The latest dialed number is registered in
the 6th item (speed redial).
6. If you select a touchscreen button
you registered before, this screen is
displayed.
Touch “Yes” if you want to overwrite it.
Deleting the speed dial individually
You can delete “01” “17” of the speed
dial individually.
If you delete them all at once, all of 17 num-
bers are deleted.
1. Touch “Delete” of “Speed Dial”.
2. Touch the touchscreen button you
want to delete.
3. Touch “Yes”.

OTHER FUNCTIONS
152
Auto answer
When a call is received, the display au-
tomatically changes to the talking
screen and you can start to talk on the
phone (without touching any switch) af-
ter the preset time.
Touch “ON” of “Auto Answer” and “”
or “+” to adjust the waiting time of auto
answer within 1 60 seconds.
The Bluetooth connection status at
startup
Vehicles with smart key system —
When the “ENGINE START STOP”
switch is in ACCESSORY or IGNITION
ON mode and the Bluetooth is auto-
matically connected, the connection
check is displayed.
Vehicles without smart key system —
When the engine switch is in “ACC” or
“ON” position and the Bluetooth is au-
tomatically connected, the connection
check is displayed.
Touch “ON” or “OFF” of “Show
Bluetooth∗ connection status at start
up”.
∗: Bluetooth is a registered trademark of
Bluetooth SIG. Inc.
