ECO mode TOYOTA HIGHLANDER 2009 XU40 / 2.G Navigation Manual

AUDIO/VIDEO SYSTEM
225
(f) Operating a DVD video disc
NOTE: The playback condition of some
DVD video discs may be determined by
a DVD video software producer. This
DVD player plays a disc as the software
producer intended. So some functions
may not work properly. Be sure to read
the instruction manual for the DVD vid-
eo disc separately provided. For the
detailed information about DVD video
discs, see “(i) DVD player and DVD vid-
eo disc information”.
Precautions on DVD video disc
When recording with a DVD video or video
CD, audio tracks may not record in some
cases while the menu is displayed. As au-
dio will not play in this case, verify that the
video tracks are playing and then activate
playback.
When playback of a disc is completed:
If an audio CD or MP3 disc is playing,
the first track or file starts.
If a DVD video or video CD is playing,
playback will stop or the menu screen
will be displayed.
The title/chapter number and playback
time display may not appear while playing
back certain DVD video discs.
CAUTION
Conversational speech on some
DVDs is recorded at a low volume to
emphasize the impact of sound ef-
fects. If you adjust the volume as-
suming that the conversations repre-
sent the maximum volume level that
the DVD will play, you may be startled
by louder sound effects or when you
change to a different audio source.
The louder sounds may have a signif-
icant impact on the human body or
pose a driving hazard. Keep this in
mind when you adjust the volume.
Vehicles with smart key system —
This “DVD Hint!” screen appears when
the video screen is first displayed after
the “ENGINE START STOP” switch is in
ACCESSORY or IGNITION ON mode.
Vehicles without smart key system —
This “DVD Hint!” screen appears when
the video screen is first displayed after
the engine switch is in “ACC” or “ON”
position.
Touch “OK” when you read the message.

AUDIO/VIDEO SYSTEM
226
PLAYING A DVD DISC
Push the “TUNE/FILE”/“AUDIO” knob
to display this screen.
When you touch “WIDE”, the screen
mode can be changed.
It you touch “PICTURE” when the vehicle
is completely stopped and the parking
brake is applied, the video screen returns.
DISPLAYING DVD CONTROLS
If you touch a part of the screen, where
controls are not located while watching
video, DVD controls will appear.
“Page2”: Touching this will display on the
second page of DVD controls.
“Page1”: Touching this will display the top
page of DVD controls.
“Hide Buttons”: Touching this will turn off
the controls from the screen.
If “
” appears on the screen when you
touch a control, the operation relevant to
the control is not permitted.

AUDIO/VIDEO SYSTEM
235
(g) Operating a video CD
PLAYING A VIDEO CD
Push the “AUDIO” button to display
this screen.
When you touch “WIDE”, the screen
mode can be changed.
It you touch “PICTURE” when the vehicle
is completely stopped and the parking
brake is applied, the video screen returns.
DISPLAYING VIDEO CD CONTROLS
If you touch the part where controls are not
located while you are watching video on
the video CD, video CD controls will ap-
pear.
“Page2”: Touching this will display on the
second page of video CD controls.
“Page1”: Touching this will display on the
top page of video CD controls.
“Hide Buttons”: Touching this will turn off
the controls from the screen.
If “
” appears on the display when you
touch a control, the operation is not per-
mitted.

AUDIO/VIDEO SYSTEM
236
DESCRIPTION OF VIDEO CD CON-
TROLS
Controls on top page
“Select Number”: The track or number
search screen appears. (See “SEARCH-
ING BY TRACK” on page 237.)
“Prev. Menu”: When you touch this while
the disc menu is displayed, the previous
page appears on the screen. If you touch
this while the player is playing video, the
previous track is searched and played.
“Next Menu”: When you touch this while
the disc menu is displayed, the next page
appears on the display. If you touch this
while the player is playing video, the next
track is searched and played.
“Main/Sub”: A multiplex transmission
changing control. The mode changes from
Main/Sub to Main, to Sub and back to
Main/Sub by touching this control.
“Return”: Touching this will display the
predetermined scene and start playing
from there.
Controls on second page
: Use this to pause the video
screen. When you touch this again, the
video screen advance frame by frame.
 : Touch this to fast reverse during
playback.
 : Touch this to pause during playback
and resume playing during pause.
 : Touch this to fast forward during the
playback and start playing slowly during
pause.

INDEX
270
Numbers/Symbols
? button
40,86,87
. . . . . . . . . . . . . . . . . . . . . .
3 Routes selection 63 . . . . . . . . . . . . . . . . . .
A
Adaptive volume control 150
. . . . . . . . . . . .
Adding a memo 124
. . . . . . . . . . . . . . . . . . . .
Adding destinations 72
. . . . . . . . . . . . . . . . .
Address button 40
. . . . . . . . . . . . . . . . . . . . .
Alphabet key 25
. . . . . . . . . . . . . . . . . . . . . . .
AM·SAT button 186
. . . . . . . . . . . . . . . . . . . .
Angle mark 230
. . . . . . . . . . . . . . . . . . . . . . .
Area to avoid 101
. . . . . . . . . . . . . . . . . . . . . .
Arrow screen 33,68
. . . . . . . . . . . . . . . . . . . . .
Audio language 230
. . . . . . . . . . . . . . . . . . . .
Audio remote controls 240
. . . . . . . . . . . . . .
Auto answer 152
. . . . . . . . . . . . . . . . . . . . . .
Auto voice guidance 87,113
. . . . . . . . . . . . . .
Automatic transition 180
. . . . . . . . . . . . . . . .
Automatic volume settings for
high speed 150
. . . . . . . . . . . . . . . . . . . . . .
AUX adapter 193
. . . . . . . . . . . . . . . . . . . . . .
B
BASS 190
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Beep setting 183
. . . . . . . . . . . . . . . . . . . . . .
Bluetooth  127
. . . . . . . . . . . . . . . . . . . . . . . .
Bluetooth  information 170
. . . . . . . . . . . . . .
Brightness 178
. . . . . . . . . . . . . . . . . . . . . . . .
Building information 36
. . . . . . . . . . . . . . . . .
C
Calendar with memo 122
. . . . . . . . . . . . . . .
Calibration 87
. . . . . . . . . . . . . . . . . . . . . . . . .
Call by dial 135
. . . . . . . . . . . . . . . . . . . . . . . .
Call by dialed numbers 136
. . . . . . . . . . . . .
Call by phone book 135
. . . . . . . . . . . . . . . . .
Call by POI 141
. . . . . . . . . . . . . . . . . . . . . . .
Call by received calls 137
. . . . . . . . . . . . . . .
Call by speed dial 138
. . . . . . . . . . . . . . . . . .
Call by voice recognition 138
. . . . . . . . . . . .
Call on the Bluetooth phone 135
. . . . . . . .
Categories 52
. . . . . . . . . . . . . . . . . . . . . . . . .
CAUTION screen 22
. . . . . . . . . . . . . . . . . . .
CD changer operation 204
. . . . . . . . . . . . . . Cellular p
hone 127
. . . . . . . . . . . . . . . . . . . . .
Change “Area Size” 105
. . . . . . . . . . . . . . . .
Change “Icon” 95
. . . . . . . . . . . . . . . . . . . . . .
Change “Location” 98,104
. . . . . . . . . . . . . . .
Change “Name” 97,103
. . . . . . . . . . . . . . . . .
Change “Phone #” 99
. . . . . . . . . . . . . . . . . .
Change “Quick Access” 96
. . . . . . . . . . . . . .
Change button 40
. . . . . . . . . . . . . . . . . . . . .
Change the route 62
. . . . . . . . . . . . . . . . . . .
Changing the angle 230
. . . . . . . . . . . . . . . .
Changing the audio language 229
. . . . . . . .
Changing the map DVD −ROM 267 . . . . . . .
Changing the subtitle language 229 . . . . . . .
Chapter 239
. . . . . . . . . . . . . . . . . . . . . . . . . .
City center 53
. . . . . . . . . . . . . . . . . . . . . . . . .
City name 47,50
. . . . . . . . . . . . . . . . . . . . . . .
City to search 47,50
. . . . . . . . . . . . . . . . . . . .
Color 178
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Command list 177
. . . . . . . . . . . . . . . . . . . . .
Compass mode 35
. . . . . . . . . . . . . . . . . . . . .
Compass mode screen 33
. . . . . . . . . . . . . .
Connecting a Bluetooth  phone 133 . . . . . .
Contrast 178
. . . . . . . . . . . . . . . . . . . . . . . . . .
Coordinates button
40
. . . . . . . . . . . . . . . . . .
Current position as the
search point 53
. . . . . . . . . . . . . . . . . . . . .
Current position display 28
. . . . . . . . . . . . . .
Current position/tire change calibration 115
. . . . . . . . . . . . . . . . . . . . . . .
Cursor position as a destination 30 . . . . . . .
Cursor position as a memory point 30 . . . .
D
Database version 268
. . . . . . . . . . . . . . . . . .
Dealer setting 120
. . . . . . . . . . . . . . . . . . . . .
Default 87
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Delete personal data 182
. . . . . . . . . . . . . . .
Deleting “Quick Access” 97
. . . . . . . . . . . . .
Deleting a Bluetooth  phone 173
. . . . . . . . .
Deleting a group name 163
. . . . . . . . . . . . . .
Deleting all of the speed dial 146
. . . . . . . . .
Deleting all the group name 164
. . . . . . . . .
Deleting all the phone data160
. . . . . . . . . .
Deleting all the speed tone149
. . . . . . . . . .
Deleting area to avoid 105
. . . . . . . . . . . . . .
Deleting destinations 73
. . . . . . . . . . . . . . . .
Deleting home 101
. . . . . . . . . . . . . . . . . . . . .
Deleting memory points 99
. . . . . . . . . . . . . .
Deleting previous points 106
. . . . . . . . . . . .
Deleting the phone data 159
. . . . . . . . . . . . .

INDEX
274
Sound icons96
. . . . . . . . . . . . . . . . . . . . . . .
Speech command system 174
. . . . . . . . . . .
Speech command system
indicator 10
. . . . . . . . . . . . . . . . . . . . . . . . .
Speed dial 138,144,145,146
. . . . . . . . . . . . .
Speed tone 143,146,147,148
. . . . . . . . . . . .
Starting route from adjacent road 77 . . . . . .
Starting route guidance 60
. . . . . . . . . . . . . .
Steering switches 240
. . . . . . . . . . . . . . . . . .
Street name 45
. . . . . . . . . . . . . . . . . . . . . . . .
Subtitle language 230
. . . . . . . . . . . . . . . . . .
Suspend guidance 88
. . . . . . . . . . . . . . . . . .
Suspend Guidance button 86
. . . . . . . . . . . .
Suspending and resuming guidance 88
. . . . . . . . . . . . . . . . . . . . . . . .
Switch color 181
. . . . . . . . . . . . . . . . . . . . . . .
Switching the screens 33
. . . . . . . . . . . . . . .
T
Talk on the Bluetooth phone 142. . . . . . . .
Talk switch 138,174 . . . . . . . . . . . . . . . . . . . . .
Telephone switch 127 . . . . . . . . . . . . . . . . . .
Time zone 87,109
. . . . . . . . . . . . . . . . . . . . . .
Tire change calibration 116 . . . . . . . . . . . . . . .
Title 239 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tone 140,178 . . . . . . . . . . . . . . . . . . . . . . . . . .
Tone and balance 190 . . . . . . . . . . . . . . . . . .
Touch screen operation 24 . . . . . . . . . . . . . .
TRACK LIST button 208,219
. . . . . . . . . . . . .
Traffic announcement 197 . . . . . . . . . . . . . .
Traffic restrict. notification 87 . . . . . . . . . . . .
Transfer phonebook 154 . . . . . . . . . . . . . . . .
Transferring a telephone number 154 . . . . .
TREB 190 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
TUNE/FILE (AUDIO) knob 186 . . . . . . . . . .
Turn list screen 33,68 . . . . . . . . . . . . . . . . . . .
Turning the audio system on and off 188
. . . . . . . . . . . . . . . . . . . . . .
TYPE SCAN button 200
. . . . . . . . . . . . . . . .
TYPE SEEK button 195
. . . . . . . . . . . . . . . .
Typical voice guidance prompts 69 . . . . . . .
U
User selection 90
. . . . . . . . . . . . . . . . . . . . . .
V
Video CD controls 236
. . . . . . . . . . . . . . . . .
Viewer restrictions 239
. . . . . . . . . . . . . . . . .
Voice guidance in all modes 87,1 13
. . . . . . .
Voice recognition guidance 87,112
. . . . . . . .
Voice tag 139
. . . . . . . . . . . . . . . . . . . . . . . . .
Volume 89
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Volume button 86
. . . . . . . . . . . . . . . . . . . . . .
X
XM  Satellite Radio broadcast 198 . . . . . . .
Z
Zoom in button 10
. . . . . . . . . . . . . . . . . . . . .
Zoom out button 10
. . . . . . . . . . . . . . . . . . . .

11
No.NameFunctionPage
8“Map View”
Touch this button to browse information
about guidance route, to set the Points
of Interest to be displayed on the
screen, or to record the route.
78, 81, 82, 83
9“ OFF”
Touch this button to obtain a broader
view. Some of the buttons on the screen
are not displayed. They are displayed
again by touching “ON”.
11 0
10“MENU” buttonPush this button to display the “Menu”
screen.12, 14, 88, 89,
90, 92, 106, 268
11Zoom in buttonTouch this button to magnify the map
scale.35
12Foot print map
buttonTouch this button to display the foot print
map and the building information.36
13
Screen
configuration
buttonTouch this button to change the screen
mode.33
14Distance and time
to destinationDisplays the distance, the estimated
travel time to the destination, and the
estimated arrival time at the destination.
71
15“DEST” buttonPush this button to display the “Destina-
tion” screen.16, 17, 40, 41
16“MAP/VOICE”
buttonPush this button to repeat a voice guid-
ance, cancel one touch scroll, start
guidance, and display the current posi-
tion.
28, 70
17
“GPS” mark
(Global
Positioning
System)Whenever the vehicle is receiving sig-
nals from the GPS, this mark is dis-
played.
256
18
Speech
command system
indicatorThe microphone is shown by pushing
the talk switch. The speech command
system can be operated while this indi-
cator is shown.
174
