display TOYOTA HIGHLANDER 2010 XU40 / 2.G Navigation Manual

Table of Contents
Quick guide —
— Overview buttons and guidance screen 5. . . . . . . . . . . .
— Registering home 7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
— Registering preset memory points (Quick access) 9 . .
— Operation flow: guiding the route 11 . . . . . . . . . . . . . . . . .
— Setting home as the destination 12 . . . . . . . . . . . . . . . . . .
1 Basic Functions (Basic information before operation)
Initial screen 22
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . .
Touch screen operation 24
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
Inputting letters and numbers/list screen operation 24
. . . . . . . . . . . . .
Function help 28
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . .
Map screen operation 28
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
.
Current position display 28
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Screen scroll operation 29
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Switching the screens 33
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Map scale 35
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . .
Foot print map 36
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . .
Orientation of the map 37
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Quick
Guide

2 Destination Search
Quick reference (“Destination” screen)40
. . . . . . . . . . . . . . . . . . . . . . .
Destination searc h4 1
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . .
Selecting the search area 42
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Destination search by Home 44
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Destination search by Quick access 44
. . . . . . . . . . . . . . . . . . . . . .
Destination search by “Address” 45
. . . . . . . . . . . . . . . . . . . . . . . . .
Destination search by “POI Name” 49
. . . . . . . . . . . . . . . . . . . . . . .
Destination search by “POI Category” 52
. . . . . . . . . . . . . . . . . . . . .
Destination search by “Emergency” 55
. . . . . . . . . . . . . . . . . . . . . . .
Destination search by “Memory” 56
. . . . . . . . . . . . . . . . . . . . . . . . .
Destination search by “Previous” 56
. . . . . . . . . . . . . . . . . . . . . . . . .
Destination search by “Map” 57
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Destination search by “Intersection” 57
. . . . . . . . . . . . . . . . . . . . . .
Destination search by “Freeway Ent./Exit” 58
. . . . . . . . . . . . . . . . .
Destination search by “Coordinates” 59
. . . . . . . . . . . . . . . . . . . . . .
Destination search by “Phone #” 60
. . . . . . . . . . . . . . . . . . . . . . . . .
Starting route guidance 60
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
.
3 Route Guidance
Route guidance screen 66
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
.
Typical voice guidance prompts 69
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Distance and time to destination 71
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Setting and deleting destination 72
. . . . . . . . . . . . . . . . . . . . . . . . . . .
Adding destinations 72
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
Reordering destinations 72
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Deleting destinations 73
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Setting route 74
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . .
Search condition 74
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . .
Detour setting 75
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . .
Route preference 77
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. .
Starting route from adjacent road 77
. . . . . . . . . . . . . . . . . . . . . . . . .
Map view 78
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . .
Display POI icons 78
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. .
Route overview 81
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . .
Route preview 82
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . .
Route trace 83
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . .

5
No.NameFunctionPage
1
Northup or
headingup
symbolThis symbol indicates a map view with
north−up or heading−up. Touching this
symbol changes the map orientation.
37
2Scale indicatorThis figure indicates the map scale.35
3Zoom out buttonTouch this button to reduce the map
scale.35
4“DISP” buttonPush this button to display the “Display”
screen.178
5“INFO” buttonPush this button to display the “Informa-
tion” screen.118, 122, 131, 180, 183
6“Mark”
Touch this button to register the current
position or the cursor position as a
memory point.
30
7“Route”Touch this button to change the route.72, 74
Quick guide —
— Overview buttons and guidance screen

6
No.NameFunctionPage
8“Map View”
Touch this button to browse information
about guidance route, to set the Points
of Interest to be displayed on the
screen, or to record the route.
78, 81, 82, 83
9“ OFF”
Touch this button to obtain a broader
view. Some of the buttons on the screen
are not displayed. They are displayed
again by touching “ON”.
11 0
10“MENU” buttonPush this button to display the “Menu”
screen.7, 9, 88, 89,
90, 92, 106,
268
11Zoom in buttonTouch this button to magnify the map
scale.35
12Foot print map
buttonTouch this button to display the foot print
map and the building information.36
13
Screen
configuration
buttonTouch this button to change the screen
mode.33
14Distance and time
to destinationDisplays the distance, the estimated
travel time to the destination, and the
estimated arrival time at the destination.
71
15“DEST” buttonPush this button to display the “Destina-
tion” screen.11, 12, 40, 41
16“MAP/VOICE”
buttonPush this button to repeat a voice guid-
ance, cancel one touch scroll, start
guidance, and display the current posi-
tion.
28, 70
17
“GPS” mark
(Global
Positioning
System)Whenever the vehicle is receiving sig-
nals from the GPS, this mark is dis-
played.
256
18
Speech
command system
indicatorThe microphone is shown by pushing
the talk switch. The speech command
system can be operated while this indi-
cator is shown.
174

8
0U5005F
0U5006F
5Touch “Enter”.
The “Memory Point” screen is displayed.
6Touch “OK”.
Registration of home is complete.
You can change the icon, quick access,
name, location and phone number. (See
“ — Editing memory points” on page 94.)

10
0U5010F
0U5011F
0U5012F
0U5013F
5Touch “Enter”.
The “Memory Point” screen is displayed.
6Touch “Quick Access”.
7Touch one of preset buttons 1 to
5.
8Touch “OK”.
Registration of preset memory points is
complete.
You can change the icon, quick access,
name, location and phone number. (See
“ — Editing memory points” on page 94.)
The registered points can be used on the
“Destination” screen. (See “ — Destination
search by Quick access” on page 44.)

SECTION 1
BASIC FUNCTIONS
21
BASIC FUNCTIONS
〈Basic information before operation〉
 Initial screen 22
 Touch screen operation 24
 Inputting letters and numbers/list screen operation 24
 Function help 28
 Map screen operation 28
Current position display 28
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Screen scroll operation 29
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Switching the screens 33
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Map scale 35
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . .
Foot print map 36
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. .
Orientation of the map 37
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . .

BASIC FUNCTIONS
22
Vehicles with smart key system —
When the “ENGINE START STOP” switch
is in ACCESSORY or IGNITION ON
mode, the initial screen will be displayed
and the system will begin operating.
Vehicles without smart key system —
When the engine switch is in “ACC” or
“ON” position, the initial screen will be
displayed and the system will begin oper-
ating.
CAUTION
When the vehicle is stopped with the
engine running, always apply the
parking brake for safety.
After a few seconds, the “CAUTION”
screen will be displayed.
After about 5 seconds, the “CAUTION”
screen automatically switches to the map
screen. When the “MAP/VOICE” button
is also pushed, the map screen is dis-
played.
While the “CAUTION” screen is displayed,
the “DEST” or “MENU” button cannot be
operated. And if the “Language” , “Cal-
endar” or “Maintenance” buttons on the
“Information” screen are touched, the
screen will change back to “CAUTION”
screen and then change to the map screen
in about 5 seconds later or if the “MAP/
VOICE” button is pushed.
Initial screen

BASIC FUNCTIONS
23

Maintenance information
This system informs about when to replace
certain parts or components and shows
dealer information (if registered) on the
screen.
When the vehicle reaches a previously set
driving distance or date specified for a
scheduled maintenance check, the “Infor-
mation” screen will be displayed when the
navigation system is in operation.
To disable this screen, touch “Do Not
Display This Message Again.”. This
screen goes off if the screen is not op-
erated for several seconds.
To prevent this information screen from be-
ing displayed again, touch “Do Not
Display This Message Again.” .
To register a maintenance information, see
“Maintenance information” on page 118.
Memo information
This system notifies about a memo entry.
At the specified date, the memo informa-
tion will be displayed when the navigation
system is in operation. The memo informa-
tion screen will be displayed every time the
system is turned on.
The memo of the current date can be
viewed by touching “Memo”. (See “ —
Editing a memo” on page 125.)
To disable this screen, touch “Do Not
Display This Message Again.”. This
screen goes off if the screen is not op-
erated for several seconds.
To prevent this information screen from be-
ing displayed again, touch “Do Not
Display This Message Again.” .
To register a memo information, see “Cal-
endar with memo” on page 122.

BASIC FUNCTIONS
24
This system is operated mainly by the
touch−screen buttons on the screen.
To prevent damage to the screen, light-
ly touch the touchscreen buttons on
the screen with the finger. When a
touchscreen button on the screen is
touched, a beep sounds.
Do not use objects other than the finger
to touch the screen.
INFORMATION
If the system does not respond to a
touch on a touchscreen button,
move the finger away from the
screen and then touch it again.
Dimmed touchscreen buttons
cannot be operated.
Wipe off fingerprints using a glass
cleaning cloth. Do not use chemi-
cal cleaners to clean the touch
screen.
The displayed image may become
darker and moving images may be
slightly distorted when the display
is cold.
Under extremely cold conditions,
the map may not be displayed and
the data input by a user may be de-
leted. Also, the touchscreen but-
tons may be harder than usual to
depress.
When you look at the screen
through polarized material such as
polarized sunglasses, the screen
may be dark and hard to see. If so,
look at the screen from different
angles, adjust the screen settings
on the “Display” screen, or take off
your sunglasses.
When searching for an address or a name,
or entering a memo, letters and numbers
can be input via the touch screen.
INFORMATION
Key layout can be changed. (See “Input key layout” on page 108.)
Touch screen operation
Inputting letters and
numbers/list screen
operation
