change time TOYOTA HIGHLANDER 2013 XU50 / 3.G Navigation Manual

AUDIO/VIDEO SYSTEM
169
(c) Playing a disc
Push the “DISC·AUX” button or push
the “TUNE/FILE”/“AUDIO” knob to dis-
play audio screen and touch the “CD”
tab if the discs are already loaded in the
changer.
The discs set in the changer are played
continuously, starting with the last disc you
inserted. The disc number of the disc cur-
rently being played, the track number and
the time from the beginning of the program
appear on the screen.
When play of one disc ends, the first track
of the following disc starts. When play of
the final disc ends, play of the first disc
starts again.
The changer will skip any empty disc trays.
Vehicles with rear seat entertainment sys-
tem —
If the DVD player is turned on, push the
“DISC·AUX” button again or touch “CD”
tab to switch to the CD changer.
If the rear seat entertainment system is on,
pushing the “DISC·AUX” button switches
the sound of the front audio system and
that of the rear seat entertainment system. (d) Selecting a desired disc
U6021GS
Touch “Change Discs” on
“CD” screen
and touch the desired disc number on
the screen.
The selected disc number is highlighted.
The changer will start playing the selected
disc from the first track.

AUDIO/VIDEO SYSTEM
171
Touch the desired track number. The
changer will start playing the selected
track from the beginning.
: By touching this touch−screen but-
ton, the list moves up by 5 track groups. If
this button is touched when the top page of
the list is displayed, the last page is dis-
played.
: By touching this touch−screen but-
ton, the list moves down by 5 track groups.
If this button is touched when the last page
of the list is displayed, the top page is dis-
played.
 ,  : If  appears to the right of the item
name, the complete name is too long for
the display.
Touch  to scroll to the end of the name.
Touch  to scroll the beginning of the
name.
Fast forward: Push “
” side of the
“SEEK/TRACK” button and hold it to fast
forward the disc. When you release the
button, the changer will resume playing
from that position.
Reverse: Push “
” side of the “SEEK/
TRACK” button and hold it to reverse the
disc. When you release the button, the
changer will resume playing.
U6093GS
SEARCHING FOR A DESIRED TRACK
OR DISC
Searching for a desired track —
Touch “SCAN” on the screen briefly
while the disc is playing.
“SCAN” appears on the screen. The
changer will play the next track for 10 sec-
onds, then scan again. To select a track,
touch “SCAN” on the screen a second
time. If the changer reaches the end of the
disc, it will continue scanning at track 1.
After all the tracks are scanned in one
pass, normal play resumes.
Searching for a desired disc —
Touch “SCAN” on the screen for longer
than a second while the disc is playing.
“D.SCAN” appears on the screen. The
program at the beginning of each audio
disc will be played for 10 seconds. To con-
tinue listening to the program of your
choice, touch “SCAN” on the screen a
second time.
After all the audio discs are scanned in one
pass, normal play resumes.

AUDIO/VIDEO SYSTEM
176
U6096GS
SEARCHING FOR A DESIRED FILE
Touch “SCAN” on the screen briefly
while the disc is playing.
“SCAN” appears on the screen. The
changer will play the next file in the folder
for 10 seconds, then scan again. To select
a file, touch “SCAN” on the screen a sec-
ond time. If the changer reaches the end
of the folder, it will continue scanning from
file 1.
After all the files are scanned in one pass,
normal play resumes.
U6097GS
SEARCHING FOR A DESIRED FOLDER
Touch “SC AN” on the screen for longer
than a second while the disc is playing.
“FLD.SCAN” appears on the screen. The
program at the beginning of each folder will
be played for 10 seconds. To continue lis-
tening to the program of your choice, touch
“SCAN” on the screen a second time.
After all the folders are scanned in one
pass, normal play resumes.

AUDIO/VIDEO SYSTEM
201
U6054GS
SEARCHING BY TITLE
Enter the title number and touch “OK”.
The player starts playing video for that
title number.
When you push either side of the “SEEK/
TRACK” button, you can select a chapter.
If you enter the wrong numbers, touch
to delete the numbers.
When you touch
, the previous
screen returns.
CHANGING THE SUBTITLE
LANGUAGE
Each time you touch “Change”, the lan-
guage is selected from the ones stored
in the discs and changed.
When you touch “Hide”, the subtitle can be
hidden.
When you touch
, the previous
screen returns.

AUDIO/VIDEO SYSTEM
202
U6069GSb
CHANGING THE AUDIO LANGUAGE
Each time you touch “Change”, the lan-
guage is selected from the ones stored
in the discs and changed.
When you touch
, the previous
screen returns.
U6076GS
CHANGING THE ANGLE
The angle can be selected for discs that
are multiangle compatible when the
angle mark appears on the screen.
Each time you touch “Change”, the
angle is selected from the ones stored
in the discs and changed.
When you touch
, and the previous
screen returns.

AUDIO/VIDEO SYSTEM
204

Angle mark
The multiangle mark can be turned on
or off on the screen while the disc
which is multiangle compatible is be-
ing played.
Each time you touch “Angle Mark”, the
angle mark on the screen turns on or off
alternately.
Parental lock
The level of viewer restrictions can be
changed.
1. Touch “Parental Lock”.
2. Enter the 4digit personal code on
the “Key code” screen.
If you enter the wrong numbers, touch
to delete the numbers.
10 touches of
will initialize the per-
sonal code.
To return to the “Setup Menu” screen,
touch
.
3. Touch a parental level (1 — 8) on the
“Select Restriction Level”. Touch the
switch to return to the “Setup
Menu” screen. ENTER AUDIO LANGUAGE CODE
U6059GS
If you touch “Other” on the “Select
Audio Language” screen, “Select
Subtitle Language” screen or “DVD
Language” screen, you can select the
language you want to hear or read by
entering a language code.
1. Enter the 4digit language code.
If you enter the wrong numbers, touch
to delete the numbers.
2. Touch “OK”.
Code
Language
0514English
1001Japanese
0618French
0405German
0920Italian
0519Spanish
2608Chinese
1412Dutch
1620Portuguese
1922Swedish
1821Russian
111 5Korean
0512Greek
0101Afar
0102Abkhazian

AUDIO/VIDEO SYSTEM
216
Touch the desired file or track number. The
changer will start playing the selected file
or track from the beginning.
: By touching this touch−screen but-
ton, the list moves up by 5 file or track
groups. If this touch−screen button is
touched when the top page of the list is dis-
played, the last page is displayed.
: By touching this touch−screen but-
ton, the list moves down by 5 file or track
groups. If this touch−screen button is
touched when the last page of the list is
displayed, the top page is displayed.
Searching for a desired file (USB
memory only)
U6111GS
Touch “SCAN” on the screen briefly
while the music is playing.
“SCAN” appears on the screen. The play-
er will play the next file for 10 seconds,
then scan again. To select a file, touch
“SCAN” on the screen a second time. If
the player reaches the end of the memory,
it will continue scanning at file1.
After all the files are scanned in one pass,
normal play resumes.

AUDIO/VIDEO SYSTEM
229
(e) Searching for a title
Push or select “Search” to dis-
play the screen to search for a title.
Select the title number , and push “ENT” to
input it. Select “Back” to return to the pre-
vious screen.
(f) Changing the subtitle language
Push or select “Sub Title” to dis-
play the subtitle language screen.
Each time
is pushed or “Sub Title”
is selected, another language stored on
the disc is selected.
Select “Back” to return to the previous
screen. (g) Changing the audio language
Push or select “Audio” to display
the audio language screen.
Each time
is pushed or “Audio” is
selected, another language stored on the
disc is selected.
Select “Back” to return to the previous
screen.
(h) Changing the angle
Push or select “Angle” to display
the screen to change the angle.
Each time
is pushed or “Angle” is
selected, the angle changes.
Select “Back” to return to the previous
screen.

AUDIO/VIDEO SYSTEM
239

Turning on or off the angle mark
The angle mark can be turned on for
discs that are multiangle compatible.
Each time you push “ENT” when “Angle
Mark” is selected, the angle mark turns on
or off alternately.Setting viewer restriction levels
Setting a password allows the viewer
restriction to be effective.
Select “Parental Lock”. Enter the pass-
word and push “ENT”. The setting can-
not be changed unless the password is
entered.
When you forget the password, initialize
the password. (See page 240.)
Select a restriction level (18), and
push “ENT”. The smaller the level num-
ber, the stricter the age limit.

AUDIO/VIDEO SYSTEM
240

Setting the display mode
Pushing changes the display
modes sequentially as follows:
Normal → Wide 1 →Wide 2
Returning to the previous screen
Select “BACK” , and push “ENT” .
To initialize the password
Push  on the remote controller or unit ten
times when the screen to enter the person-
al code is displayed.
Adjusting the screen
Push .
Select the brightness, contrast, tone or col-
or, and make adjustments. Push
or
“ENT” to input it.
Brightness, contrast, tone and color
adjustment
“Brightness” “+”:
Brightens the screen.
“Brightness” “”:
Darkens the screen.
“Contrast” “+”:
Strengthens the contrast of the screen.
“Contrast” “”:
Weakens the contrast of the screen.
“Tone” “+”: Strengthens the tone of the
screen.
“Tone” “”: Weakens the tone of the
screen.
“Color” “Red”:
Strengthens the red color of the screen.
“Color” “Green”:
Strengthens the green color of the screen.
