SETUP
323
(c) Changing the passcode
The passcode for registering your por-
table player on the system can be
changed. You can change this to 4 to 8
digit number of your choice. The de-
fault is “0000”.
U10019GS
1. Touch “Edit” of “Passcode” on “BT
Audio Setting” screen.
U10020GS
2. Enter the new 48 digits passcode
and touch “OK”.
Each time you touch
, an input digit
is deleted. (d) Changing the device name
You can change a device name. Even if
you change a device name, the name
registered in
your portable player is not
changed.
U10021GS
1. Touch “Edit” of “Device Name” on
“BT Audio Setting” screen.
U10022GS
2. Enter the new device name and
touch “OK”.
INFORMATION
The device names are common to
Bluetooth  audio and Bluetooth
phone.
If you change the device name of the
audio, the device name of the phone
will change at same time.
However, passcodes can be set
separately.

SETUP
324
(e) Initializing the Bluetooth audio
settings
You can initialize the settings.
U10023GS
1. Touch “Default” on “BT Audio Set-
ting” screen.
U10024GS
2. Touch “Yes”. When the navigation system is turned on,
the “Information” screen displays
when it is
time to replace a part or certain compo-
nents. (See page 27.)
1. Push the “SETUP” button.
2. Touch “Vehicle”.
3. Touch “Maintenance”.
Vehicle Settings —
— Maintenance

INDEX
348
Numbers/Symbols
? button
20,33
. . . . . . . . . . . . . . . . . . . . . . . . .
3 Routes selection 74 . . . . . . . . . . . . . . . . . .
A
A/V input port 236
. . . . . . . . . . . . . . . . . . . . .
A2DP(Advanced Audio
Distribution Profile) 178
. . . . . . . . . . . . . . .
Adding destinations 84
. . . . . . . . . . . . . . . . .
Address Book button 20,66
. . . . . . . . . . . . . .
Address book entry information 37 . . . . . . .
Address button 20,55
. . . . . . . . . . . . . . . . . . .
Adjusting the screen (DVD player) 240 . . . .
Alphabet key 28
. . . . . . . . . . . . . . . . . . . . . . .
AM button 146
. . . . . . . . . . . . . . . . . . . . . . . .
Angle mark 203,237
. . . . . . . . . . . . . . . . . . . .
Areas to avoid 115
. . . . . . . . . . . . . . . . . . . . . .
Arrow screen 39,80
. . . . . . . . . . . . . . . . . . . . .
ASL 152
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Audio button 22,317
. . . . . . . . . . . . . . . . . . . .
Audio language 203,237
. . . . . . . . . . . . . . . . .
Audio settings 317
. . . . . . . . . . . . . . . . . . . . .
Audio/video remote controls 218
. . . . . . . . .
Audio/video system 145
. . . . . . . . . . . . . . . .
Audio/video system operating
hints 242
. . . . . . . . . . . . . . . . . . . . . . . . . . .
Auto avoid traffic 98,270,272
. . . . . . . . . . . . .
Auto complete text 270
. . . . . . . . . . . . . . . . .
Auto screen change 260
. . . . . . . . . . . . . . . .
Auto voice guidance 267
. . . . . . . . . . . . . . . .
Automatic recognition 267
. . . . . . . . . . . . . .
Automatic sound levelizer 152
. . . . . . . . . . .
AUX port 155
. . . . . . . . . . . . . . . . . . . . . . . . .
AVRCP(Audio/Video Remote
Control Profile) 178
. . . . . . . . . . . . . . . . . .
B
Balance 152
. . . . . . . . . . . . . . . . . . . . . . . . . .
Basic function 25
. . . . . . . . . . . . . . . . . . . . . .
Bass 152
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Beep 260
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Before using the rear seat
entertainment system controller 224 . . . .
Bluetooth
122,178,309,317
. . . . . . . . . . . . .
Bluetooth audio operation 178
. . . . . . . . . .
Bluetooth audio player 178,317
. . . . . . . . . .
Bluetooth connection statue
at start up 315 . . . . . . . . . . . . . . . . . . . . . .
Bluetooth
 information 318
. . . . . . . . . . . . . .
Brightness 31
. . . . . . . . . . . . . . . . . . . . . . . . .
Building information 43
. . . . . . . . . . . . . . . . .
C
Calendar 143
. . . . . . . . . . . . . . . . . . . . . . . . .
Calendar button 23,143
. . . . . . . . . . . . . . . . .
Calibration 270,275
. . . . . . . . . . . . . . . . . . . . .
Call by call history 135
. . . . . . . . . . . . . . . . .
Call by dial 132
. . . . . . . . . . . . . . . . . . . . . . . .
Call by phonebook 133
. . . . . . . . . . . . . . . . .
Call by POI call 139
. . . . . . . . . . . . . . . . . . . .
Call by speed dial 135
. . . . . . . . . . . . . . . . . .
Call by voice recognition 137
. . . . . . . . . . . .
Call history 135
. . . . . . . . . . . . . . . . . . . . . . .
Call on the Bluetooth
 phone 132
. . . . . . . .
Categories 61
. . . . . . . . . . . . . . . . . . . . . . . . .
CAUTION screen 26
. . . . . . . . . . . . . . . . . . .
CD changer operation 166
. . . . . . . . . . . . . .
Cellular p hone 122
. . . . . . . . . . . . . . . . . . . . .
Change “Icon” 111
. . . . . . . . . . . . . . . . . . . . . .
Change “Location” 113,118
. . . . . . . . . . . . . .
Change “Name” 117
. . . . . . . . . . . . . . . . . . . .
Change “Phone #” 113
. . . . . . . . . . . . . . . . . .
Change “Show Name” 112
. . . . . . . . . . . . . . .
Change “Size” 118
. . . . . . . . . . . . . . . . . . . . . .
Changing a device name 318
. . . . . . . . . . . .
Changing the angle 202
. . . . . . . . . . . . . . . .
Changing the audio language 202
. . . . . . . .
Changing the Bluetooth
 settings 310 . . . . .
Changing the device name 323
. . . . . . . . . .
Changing the handsfree power 310 . . . . . . .
Changing the map DVD −ROM 343 . . . . . . .
Changing the passcode 323
. . . . . . . . . . . . .
Changing the subtitle language 201 . . . . . . .
Channel category 161
. . . . . . . . . . . . . . . . . .
City center 62
. . . . . . . . . . . . . . . . . . . . . . . . .
City name 55,60
. . . . . . . . . . . . . . . . . . . . . . .
City to search 55,60
. . . . . . . . . . . . . . . . . . . .
Clock button 22,265
. . . . . . . . . . . . . . . . . . . .
Clock settings 265
. . . . . . . . . . . . . . . . . . . . .
Color 31
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Command list 47
. . . . . . . . . . . . . . . . . . . . . .
Compass mode 41
. . . . . . . . . . . . . . . . . . . . .
Compass mode screen 39,41
. . . . . . . . . . . .
Connecting a Bluetooth

audio player 182,322
. . . . . . . . . . . . . . . . .
Connecting a Bluetooth
 phone 129 . . . . . .
Connecting a USB memory or
iPod 211 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Contacts 133,292 . . . . . . . . . . . . . . . . . . . . . .
Contrast 31 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Coordinates button 20,71
. . . . . . . . . . . . . . . .
Current position display 33 . . . . . . . . . . . . . .
Current position/tire change
calibration 275
. . . . . . . . . . . . . . . . . . . . . .
Cursor position as a destination 34 . . . . . . .
Cursor position as an address book
entry 35
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Customize POI icons 270
. . . . . . . . . . . . . . .

INDEX
349
D
Database version
345
. . . . . . . . . . . . . . . . . .
Daylight saving time 266
. . . . . . . . . . . . . . . .
Dealer setting 327
. . . . . . . . . . . . . . . . . . . . .
Default 203,271,275,280,313,316,324 . . . . .
Del. Dest. button 20,71
. . . . . . . . . . . . . . . . . .
Delete personal data 260,264
. . . . . . . . . . . .
Deleting a Bluetooth
 phone 287
. . . . . . . . .
Deleting address book entries 114 . . . . . . . .
Deleting areas to avoid 119
. . . . . . . . . . . . . .
Deleting call history 304
. . . . . . . . . . . . . . . .
Deleting destinations 85
. . . . . . . . . . . . . . . .
Deleting home 105
. . . . . . . . . . . . . . . . . . . . .
Deleting preset destinations 108
. . . . . . . . .
Deleting previous destinations 119 . . . . . . . .
Deleting set destinations 71,85
. . . . . . . . . . .
Deleting the phonebook data 295
. . . . . . . .
Deleting the speed dial 303
. . . . . . . . . . . . .
Deleting the voice tag 309
. . . . . . . . . . . . . .
Description of DVD controls 200
. . . . . . . . .
Description of settings 199
. . . . . . . . . . . . . .
Description of video CD controls 209 . . . . .
Description of video CD settings 208 . . . . .
DEST button 10,12,14,16,17,20,52
. . . . . . .
Destination information 38
. . . . . . . . . . . . . .
Destination screen 20,52
. . . . . . . . . . . . . . . .
Destination search 51,52
. . . . . . . . . . . . . . . .
Destination search by “Address Book” 66
. . . . . . . . . . . . . . . . . . .
Destination search by “Address” 55. . . . . .
Destination search by “Coordinates” 71
. . . . . . . . . . . . . . . . . . . .
Destination search by
“Emergency” 66
. . . . . . . . . . . . . . . . . . . . .
Destination search by “Intersection & Freeway” 67
. . . . . . . . . . .
Destination search by “Map” 70
. . . . . . . . . .
Destination search by “Point of Interest” 59
. . . . . . . . . . . . . . . . .
Destination search by
“Previous Destinations” 65
. . . . . . . . . . . .
Destination search by Home 54
. . . . . . . . . .
Destination search by Preset destinations 54
. . . . . . . . . . . . . . .
Detailed navigation settings 269
. . . . . . . . .
Details 314
. . . . . . . . . . . . . . . . . . . . . . . . . . .
Detour setting 86
. . . . . . . . . . . . . . . . . . . . . .
Dialing by name 137
. . . . . . . . . . . . . . . . . . .
DISC·AUX button 146
. . . . . . . . . . . . . . . . . .
Disc coverage area 345
.
. . . . . . . . . . . . . . .
Disc slot 187
. . . . . . . . . . . . . . . . . . . . . . . . . .
DISP button 10,31
. . . . . . . . . . . . . . . . . . . . . . Display phone status
315
. . . . . . . . . . . . . . .
Display POI icons 92
. . . . . . . . . . . . . . . . . . .
Displaying DVD controls 199
. . . . . . . . . . . .
Displaying the title and name 163
. . . . . . . .
Displaying video CD controls 209
. . . . . . . .
Displaying video CD settings 208
. . . . . . . .
Distance and time to destination 10,83
. . . .
Driving speeds 270,271
. . . . . . . . . . . . . . . . .
DSP control 152
. . . . . . . . . . . . . . . . . . . . . . .
Dual map 41
. . . . . . . . . . . . . . . . . . . . . . . . . .
Dual map screen 39,41
. . . . . . . . . . . . . . . . .
DVD controls 199
. . . . . . . . . . . . . . . . . . . . . .
DVD language 203,237
. . . . . . . . . . . . . . . . . .
DVD player operation 187
. . . . . . . . . . . . . . .
DVD settings 198
. . . . . . . . . . . . . . . . . . . . . .
E
Edit “Dealer” or “Contact” 328
. . . . . . . . . . .
Edit “Location” 328
. . . . . . . . . . . . . . . . . . . . .
Edit “Phone #” 329
. . . . . . . . . . . . . . . . . . . . .
Edit route 75
. . . . . . . . . . . . . . . . . . . . . . . . . .
Editing address book entries 110
. . . . . . . . . .
Editing area to avoid 116
. . . . . . . . . . . . . . . .
Editing home 104
. . . . . . . . . . . . . . . . . . . . . .
Editing preset destinations 107
. . . . . . . . . .
Editing the Bluetooth
 phone 285
. . . . . . . . .
Editing the device name 312
. . . . . . . . . . . .
Editing the passcode 312
. . . . . . . . . . . . . . .
Editing the phonebook data 293
. . . . . . . . . .
Editing the speed dial 302
. . . . . . . . . . . . . . .
Editing the voice tag 308
. . . . . . . . . . . . . . . .
Eject button 188
. . . . . . . . . . . . . . . . . . . . . . .
Ejecting a disc 188
. . . . . . . . . . . . . . . . . . . .
Ejecting discs 167
. . . . . . . . . . . . . . . . . . . . .
Emergency button 20,66
. . . . . . . . . . . . . . . .
Enter a Bluetooth
 phone 127
. . . . . . . . . . .
Enter audio language code 204
. . . . . . . . . .
Estimated arrival time 83
. . . . . . . . . . . . . . .
Estimated travel time 83
. . . . . . . . . . . . . . . .
F
FM1·2 button 146 . . . . . . . . . . . . . . . . . . . . . .
Foot print map 10,42 . . . . . . . . . . . . . . . . . . . .
Foot print map button 42
. . . . . . . . . . . . . . . .
Freeway exit information screen 78 . . . . . . .
Freeway screen 39
. . . . . . . . . . . . . . . . . . . .
Function help 33
. . . . . . . . . . . . . . . . . . . . . .
Function menu display screen 146 . . . . . . .
Function menu tab 146
. . . . . . . . . . . . . . . . .

INDEX
350
G
General button
22,260
. . . . . . . . . . . . . . . . . .
General settings 260 . . . . . . . . . . . . . . . . . . .
Go Home button 20,54
. . . . . . . . . . . . . . . . . .
GPS 332 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
GPS mark 10,332 . . . . . . . . . . . . . . . . . . . . . .
Guidance screen for the freeway 79 . . . . . .
Guidance screen on the freeway 39 . . . . . .
Guidance with street names 270
. . . . . . . . .
Guiding the route 16
. . . . . . . . . . . . . . . . . . .
H
Hands −free system 122
. . . . . . . . . . . . . . . .
Hands −free system for
cellular phone 122
. . . . . . . . . . . . . . . . . . .
Heading −up 10,43
. . . . . . . . . . . . . . . . . . . . . .
Heading −up symbol 43
. . . . . . . . . . . . . . . . .
Headphone jacks 224
. . . . . . . . . . . . . . . . . .
Help 33
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
HFP (Hands Free Profile) 122
. . . . . . . . . . .
Home 12,103
. . . . . . . . . . . . . . . . . . . . . . . . . .
I
If the player malfunctions 178,210
. . . . . . . .
Important information about
this manual 3 . . . . . . . . . . . . . . . . . . . . . . .
Incoming call display 314 . . . . . . . . . . . . . . .
INFO/PHONE
button 10,23,127,143,345 . . . . . . . . . . . . . .
Information about the icon 36
. . . . . . . . . . . .
Information items 326
. . . . . . . . . . . . . . . . . .
Information screen 23
. . . . . . . . . . . . . . . . . .
Initial screen 26
. . . . . . . . . . . . . . . . . . . . . . .
Initializing the Bluetooth

audio settings 324 . . . . . . . . . . . . . . . . . . .
Initializing the Bluetooth

phone settings 313 . . . . . . . . . . . . . . . . . .
Initializing the detailed phone
settings 316 . . . . . . . . . . . . . . . . . . . . . . . .
Input numbers 28 . . . . . . . . . . . . . . . . . . . . . .
Input symbols 29 . . . . . . . . . . . . . . . . . . . . . .
Inputting letters and numbers/
List screen operation 28 . . . . . . . . . . . . . .
Inserting discs 166 . . . . . . . . . . . . . . . . . . . . .
Inserting the disc 187 . . . . . . . . . . . . . . . . . .
Interrupt call 142 . . . . . . . . . . . . . . . . . . . . . .
Intersection & Freeway button 20,67
. . . . . .
Intersection guidance screen 39,79
. . . . . . .
iPod compatibility 242 . . . . . . . . . . . . . . . . . .
iPod op eration 211. . . . . . . . . . . . . . . . . . . . . .
K
Keyboard layout 260
. . . . . . . . . . . . . . . . . . .
L
Language 260
. . . . . . . . . . . . . . . . . . . . . . . . .
Last 5 cities 57,63
. . . . . . . . . . . . . . . . . . . . . .
Limitations of the navigation
system 332
. . . . . . . . . . . . . . . . . . . . . . . . .
Line color 260
. . . . . . . . . . . . . . . . . . . . . . . . .
List 29
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
List All Categories button 61,64,93,274
. . .
Listening to satellite radio 161
. . . . . . . . . . .
Listening to the radio 155
. . . . . . . . . . . . . . .
List screen operation 28
. . . . . . . . . . . . . . . .
LOAD·EJECT/CLOSE
button 146,166,167
. . . . . . . . . . . . . . . . . . .
Local POI list 94
. . . . . . . . . . . . . . . . . . . . . . .
M
Maintenance 324
. . . . . . . . . . . . . . . . . . . . . .
Maintenance information 27
. . . . . . . . . . . . .
Maintenance information setting 325 . . . . . .
Manage phone 280
. . . . . . . . . . . . . . . . . . . .
Map button 20,70
. . . . . . . . . . . . . . . . . . . . . .
Map data 345
. . . . . . . . . . . . . . . . . . . . . . . . .
Map Data button 23,345
. . . . . . . . . . . . . . . . .
Map database information and updates 334
. . . . . . . . . . . . . . . . . . . . . . . .
Map DVD 345
. . . . . . . . . . . . . . . . . . . . . . . . .
Map DVD− ROM 343
. . . . . . . . . . . . . . . . . . .
Map icons 44
. . . . . . . . . . . . . . . . . . . . . . . . .
Map scale 42
. . . . . . . . . . . . . . . . . . . . . . . . .
Map screen 10
. . . . . . . . . . . . . . . . . . . . . . . .
Map screen operation 33
. . . . . . . . . . . . . . .
MAP/VOICE button 10,33,34,82
. . . . . . . . .
Mark button 10,35
. . . . . . . . . . . . . . . . . . . . . .
Marks shown on DVD video discs 230 . . . .
Memory point names 112
. . . . . . . . . . . . . . . .
Message button 157
. . . . . . . . . . . . . . . . . . .
Microphone 46,123
. . . . . . . . . . . . . . . . . . . . .
Mid 152
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
MP3 173,192
. . . . . . . . . . . . . . . . . . . . . . . . . .
My places 101
. . . . . . . . . . . . . . . . . . . . . . . .

INDEX
351
N
Names of
areas to be avoided 117 . . . . . . . .
Navi. button 22,102,269
. . . . . . . . . . . . . . . . .
Navigation settings 102,269 . . . . . . . . . . . . . .
Navigation settings screen 102,269 . . . . . . .
Navigation system function index 18. . . . . .
North−up 10,43
. . . . . . . . . . . . . . . . . . . . . . . .
North−up symbol 43
. . . . . . . . . . . . . . . . . . .
O
Off function 10,270,275
. . . . . . . . . . . . . . . . .
One−touch scroll 34
. . . . . . . . . . . . . . . . . . .
Operating a Bluetooth

audio player 178 . . . . . . . . . . . . . . . . . . . .
Operating a DVD disc 226. . . . . . . . . . . . . .
Operating a DVD video disc 196 . . . . . . . . .
Operating a MP3 disc 192,235 . . . . . . . . . . .
Operating a MP3/WMA disc 173 . . . . . . . . .
Operating a video CD 207,232
. . . . . . . . . . .
Operating an audio CD 170
. . . . . . . . . . . . .
Operating an audio disc 234
. . . . . . . . . . . . .
Operating by voice
recognition 141,288
. . . . . . . . . . . . . . . . . . .
OPP (Object Push Profile) 122
. . . . . . . . . .
Orientation of the map 43
. . . . . . . . . . . . . . .
P
Parental lock 203,237
. . . . . . . . . . . . . . . . . . .
Pause guidance 91
. . . . . . . . . . . . . . . . . . . .
Pausing and resuming guidance 91 . . . . . . .
PBAP
(Phone Book Access Profile) 122 . . . . . .
Phone button 22,23,278
. . . . . . . . . . . . . . . . .
Phonebook 133,288
. . . . . . . . . . . . . . . . . . . .
Playing a Bluetooth
 audio 184
. . . . . . . . . .
Playing a disc 169,189
. . . . . . . . . . . . . . . . . .
Playing a DVD disc 198
. . . . . . . . . . . . . . . .
Playing a MP3 disc 192
. . . . . . . . . . . . . . . . .
Playing a MP3/WMA disc 173
. . . . . . . . . . .
Playing a USB memory or iPod 212. . . . . .
Playing a video CD 207
. . . . . . . . . . . . . . . . .
Playing an audio CD 170
. . . . . . . . . . . . . . .
Playing an audio disc 189
. . . . . . . . . . . . . . .
POI as a destination 95
. . . . . . . . . . . . . . . . .
POI category change 274
. . . . . . . . . . . . . . .
POI information 36
. . . . . . . . . . . . . . . . . . . . .
Point of Interest button 20,59
. . . . . . . . . . . . .
POIs near the search point 64
. . . . . . . . . . .
POIs to be displayed 93
. . . . . . . . . . . . . . . .
Pop−up information 270,277
. . . . . . . . . . . . .
Portable audio players 155,178,211
. . . . . . .
Position/direction c alibration 276
. . . . . . . . . Preset
destination 14,54
. . . . . . . . . . . . . . . . .
Preset destination touch screen
buttons 20,54
. . . . . . . . . . . . . . . . . . . . . . . .
Presetting a satellite radio
channel 162
. . . . . . . . . . . . . . . . . . . . . . . .
Presetting a station 156
. . . . . . . . . . . . . . . .
Previous Destinations button 20,65
. . . . . . .
PWR/VOL knob 146
. . . . . . . . . . . . . . . . . . .
Q
Quick ref erence 20,22,23
. . . . . . . . . . . . . . .
R
Radio data system 157
. . . . . . . . . . . . . . . . .
Radio ID 160
. . . . . . . . . . . . . . . . . . . . . . . . . .
Radio operation 155,160
. . . . . . . . . . . . . . . .
RAND button 172,177,186,191,195
. . . . . . .
RDS 157
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear seat entertainment system (DVD player) 221
. . . . . . . . . . . . . . . . . . . .
Rear system lock 260,262
. . . . . . . . . . . . . . .
Rear view monitor system 254
. . . . . . . . . . .
Rear view monitor system camera 257
. . . . . . . . . . . . . . . . . . . . . . . . .
Receive on the Bluetooth

phone 139 . . . . . . . . . . . . . . . . . . . . . . . . . .
Reconnecting the Bluetooth

audio 184 . . . . . . . . . . . . . . . . . . . . . . . . . .
Reconnecting the Bluetooth

phone 132 . . . . . . . . . . . . . . . . . . . . . . . . . .
Registering a Bluetooth
 phone 281 . . . . . .
Registering address book entries 109 . . . . .
Registering areas to avoid 115
. . . . . . . . . . . .
Registering home 12,103
. . . . . . . . . . . . . . . .
Registering preset destinations 14,106
. . . .
Registering the phonebook data 292 . . . . . .
Registering the speed dial 298
. . . . . . . . . . .
Registering the voice tag 306
. . . . . . . . . . . .
Removing a Bluetooth
 audio 321 . . . . . . . .
Reordering destinations 84 . . . . . . . . . . . . . .
Replacing the rear seat entertainment
system controller batteries 241 . . . . . . . .
Resume guidance 92 . . . . . . . . . . . . . . . . . . .
Ring volume setting 279 . . . . . . . . . . . . . . . .
Route button 10,84,85,86,87,89,91
. . . . . . .
Route guidance 77 . . . . . . . . . . . . . . . . . . . . .
Route guidance screen 78
. . . . . . . . . . . . . .
Route overview 87
. . . . . . . . . . . . . . . . . . . . .
Route preference 89
. . . . . . . . . . . . . . . . . . .
Route preview 88
. . . . . . . . . . . . . . . . . . . . . .
Route trace 96
. . . . . . . . . . . . . . . . . . . . . . . .
RPT button 172,177,186,191,195
. . . . . . . .

INDEX
352
S
Safety instruction
3
. . . . . . . . . . . . . . . . . . . .
SAT button 146
. . . . . . . . . . . . . . . . . . . . . . . .
Satellite radio tuner malfunctions 164 . . . . .
Satellite tuner 160
. . . . . . . . . . . . . . . . . . . . .
Scale indicator 10,42
. . . . . . . . . . . . . . . . . . .
SCAN button 171,176,191,194,195
. . . . . . .
Screen adjustment 31
. . . . . . . . . . . . . . . . . .
Screen configuration button 10,39
. . . . . . . .
Screen for navigation settings 270 . . . . . . .
Screen for voice settings 267
. . . . . . . . . . . .
Screen layout function 275
. . . . . . . . . . . . . .
Screen off 31
. . . . . . . . . . . . . . . . . . . . . . . . .
Screen scroll operation 34
. . . . . . . . . . . . . .
Screen size 153
. . . . . . . . . . . . . . . . . . . . . . .
Screens for clock settings 266
. . . . . . . . . . .
Screens for general settings 260
. . . . . . . . .
Search area 52
. . . . . . . . . . . . . . . . . . . . . . . .
Search by “Address Book” 66
. . . . . . . . . . .
Search by “Address” 55
. . . . . . . . . . . . . . . .
Search by “Category” 61
. . . . . . . . . . . . . . . .
Search by “Coordinates” 71
. . . . . . . . . . . . .
Search by “Emergency” 66
. . . . . . . . . . . . . .
Search by “Intersection & Freeway” 67
. . . . . . . . . . .
Search by “Map” 70
. . . . . . . . . . . . . . . . . . . .
Search by “Name” 59
. . . . . . . . . . . . . . . . . .
Search by “Phone #” 64
. . . . . . . . . . . . . . . .
Search by “Point of Interest” 59
. . . . . . . . . .
Search by “Previous Destinations” 65 . . . . .
Search by Freeway Entrance/Exit 69 . . . . .
Search by Home 54
. . . . . . . . . . . . . . . . . . . .
Search by Intersection 68
. . . . . . . . . . . . . . .
Search by Preset destinations 54
. . . . . . . .
Search by street address 57
. . . . . . . . . . . .
Search point from along my route 62 . . . . .
Search point from
near a destination 63
. . . . . . . . . . . . . . . . .
Search point from near city center 62 . . . . .
Search point from near here 62
. . . . . . . . . .
Searching by title 201
.
. . . . . . . . . . . . . . . . .
Searching by track 210
. . . . . . . . . . . . . . . . .
Searching for a desired disc 171
. . . . . . . . .
Searching for a desired file 176,194. . . . . . .
Searching for a desired folder 176,195. . . . .
Searching for a desired track 171,191 . . . . .
SEEK/TRACK button 146,157,162,
. . . . . . .
170,174,185,190,193,201,210
Select POI icons 274
. . . . . . . . . . . . . . . . . . .
Select portable player 317
. . . . . . . . . . . . . .
Select route features 90
. . . . . . . . . . . . . . . .
Select route type 89
. . . . . . . . . . . . . . . . . . .
Selecting a Bluetooth
 phone 283
. . . . . . . .
Selecting a city to search 55,60
. . . . . . . . . .
Selecting a desired album 186
. . . . . . . . . . . Selecting a
desired disc 169
. . . . . . . . . . . . .
Selecting a desired file 174,193
. . . . . . . . . . .
Selecting a desired folder 173,192
. . . . . . . .
Selecting a desired track 170,185,189,190
. . . . . . . . . . . . . . . .
Selecting a keyboard layout 263
. . . . . . . . .
Selecting a language 261
. . . . . . . . . . . . . . .
Selecting a menu item 200
. . . . . . . . . . . . . .
Selecting a satellite radio channel 162 . . . .
Selecting a station 157
. . . . . . . . . . . . . . . . .
Selecting connection method 319
. . . . . . . .
Selecting from the categories 61
. . . . . . . . .
Selecting from the last 5 cities 63
. . . . . . . .
Selecting the desired mode 218
. . . . . . . . . .
Selecting the line color 262
. . . . . . . . . . . . . .
Selecting the search area 52
. . . . . . . . . . . .
Setting a nd deleting destinations 84 . . . . . .
Setting Bluetooth
 audio 319
. . . . . . . . . . . .
Setting home as the destination 17 . . . . . . .
Setting route 86
. . . . . . . . . . . . . . . . . . . . . . .
Setting the phonebook 289
. . . . . . . . . . . . . .
Setting the voice tag 305
. . . . . . . . . . . . . . .
Setting up the “Address Book” 108 . . . . . . .
Setting up the “Areas to A void” 114. . . . . . . .
Setting up the “Home” 103
. . . . . . . . . . . . . .
Setting up the
“Preset Destinations” 105
. . . . . . . . . . . . .
Setup 259
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
SETUP button 10,22,102,260,265,
. . . . . . . .
267,269,278,317,324
Setup menu 203
. . . . . . . . . . . . . . . . . . . . . . .
Setup operation from
the rear seat 207
. . . . . . . . . . . . . . . . . . . .
Setup screen 22
. . . . . . . . . . . . . . . . . . . . . . .
Show free flowing traffic 98,270,273 . . . . . .
Show on map 92
. . . . . . . . . . . . . . . . . . . . . .
Show on Map button 92,96
. . . . . . . . . . . . . .
Show on map button 10
. . . . . . . . . . . . . . . .
Show XM
 NavTraffic
information 98,99 . . . . . . . . . . . . . . . . . . . .
Single map 40 . . . . . . . . . . . . . . . . . . . . . . . .
Single map screen 39,40
. . . . . . . . . . . . . . . .
Sort 30 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Sound icons 111 . . . . . . . . . . . . . . . . . . . . . . .
Speech command system 44,148
. . . . . . . . .
Speed dial 135,298,302,303
. . . . . . . . . . . . .
Speed dials setting 297
. . . . . . . . . . . . . . . . .
Starting route from adjacent road 91 . . . . . .
Starting route guidance 72
. . . . . . . . . . . . . .
Steering switches 218
. . . . . . . . . . . . . . . . . .
Street name 55,57
. . . . . . . . . . . . . . . . . . . . . .
Subtitle language 203,237
. . . . . . . . . . . . . . .
Surround function 152
. . . . . . . . . . . . . . . . . .
Switching between audio
functions 149
. . . . . . . . . . . . . . . . . . . . . . .
Switching the screens 39
. . . . . . . . . . . . . . .

INDEX
353
T
Talk on the Bluetooth phone
140
. . . . . . . .
Talk switch 44,148
. . . . . . . . . . . . . . . . . . . . . .
Telephone 122
. . . . . . . . . . . . . . . . . . . . . . . .
Telephone and information 121
. . . . . . . . . .
Telephone settings 278
. . . . . . . . . . . . . . . . .
Telephone switch 123
. . . . . . . . . . . . . . . . . .
Time zone 266
. . . . . . . . . . . . . . . . . . . . . . . .
Tire change calibration 275,277
. . . . . . . . . . .
Tone 31,152
. . . . . . . . . . . . . . . . . . . . . . . . . . .
Tone and balance 152
. . . . . . . . . . . . . . . . . .
Touch screen operation 27
. . . . . . . . . . . . . .
Traffic announcement 159
. . . . . . . . . . . . . .
Traffic button 159
. . . . . . . . . . . . . . . . . . . . . .
Traffic voice guidance 98,267,268
. . . . . . . .
Transferring a phone number 290
. . . . . . . .
Treble 152
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
TUNE/FILE/AUDIO knob146,174
. . . . . . . . .
Turning the audio system
on and off 149
. . . . . . . . . . . . . . . . . . . . . .
Turn list screen 39,80
. . . . . . . . . . . . . . . . . . .
TypeSeek button 157
. . . . . . . . . . . . . . . . . . .
Typical voice guidance prompts 81 . . . . . . .
U
Unit of measurement 260,263
. . . . . . . . . . . .
USB memory information 242 . . . . . . . . . . .
USB memory operation 211 . . . . . . . . . . . . . .
USB port 155 . . . . . . . . . . . . . . . . . . . . . . . . .
Using your audio/video system 147 . . . . . . .
V
Vehicle button 22,324
. . . . . . . . . . . . . . . . . . .
Vehicle settings 324 . . . . . . . . . . . . . . . . . . . .
Video CD controls 209 . . . . . . . . . . . . . . . . .
Voice button 22,267
. . . . . . . . . . . . . . . . . . . .
Voice guidance in all modes 267. . . . . . . . .
Voice recognition 137,141,288
. . . . . . . . . . .
Voice recognition guidance 267
. . . . . . . . . .
Voice settings 267
. . . . . . . . . . . . . . . . . . . . .
Voice tag 137,305
. . . . . . . . . . . . . . . . . . . . . .
Voice volume 268
. . . . . . . . . . . . . . . . . . . . . .
Voice volume setting 279
. . . . . . . . . . . . . . .
Volume 218,268,279
. . . . . . . . . . . . . . . . . . . .
Volume setting 279
. . . . . . . . . . . . . . . . . . . .
W
WMA 173
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
X
XM indicator 10
. . . . . . . . . . . . . . . . . . . . . .
XM NavTraffic 98
. . . . . . . . . . . . . . . . . . . . .
XM NavTraf fic icon 99. . . . . . . . . . . . . . . . .
XM NavTraffic indicator 99
. . . . . . . . . . . . .
XM NavTraffic information arrow 99 . . . . .
XM NavTraffic text information 39 . . . . . . .
XM Satellite Radio broadcast 160 . . . . . . .
Z
Zoom in button 10,42
. . . . . . . . . . . . . . . . . . .
Zoom out button 10,42
. . . . . . . . . . . . . . . . . .
