seat memory TOYOTA HIGHLANDER 2013 XU50 / 3.G Navigation Manual

7
4 My Places
Navigation settings102
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
.
Setting up the “Home” 103 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Setting up the “Preset Destinations” 105
. . . . . . . . . . . . . . . . . . . . . .
Setting up the “Address Book” 108
. . . . . . . . . . . . . . . . . . . . . . . . . . .
Setting up the “Areas to Avoid” 114
. . . . . . . . . . . . . . . . . . . . . . . . . . .
Deleting previous destinations 119
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
5 Telephone and Information
Telephone (Handsfree system for cellular phone) 122
. . . . . . . . .
Enter a Bluetooth  phone 127 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Call on the Bluetooth  phone 132 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Receive on the Bluetooth  phone 139 . . . . . . . . . . . . . . . . . . . . . . . .
Talk on the Bluetooth  phone 140 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Calendar 143 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . .
6 Audio/video system
Quick reference 146
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . .
Using your audio/video system 147
. . . . . . . . . . . . . . . . . . . . . . . . . . .
Some basics 147
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . .
Radio operation 155
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. .
Radio operation (XM  Satellite Radio broadcast) 160
. . . . . . . . . . .
CD changer operation 166
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Bluetooth  audio operation 178
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DVD player operation 187
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
USB memory/iPod operation 211
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Audio/video remote controls (steering switches) 218
. . . . . . . . . . . . . .
Rear seat entertainment system features 221
. . . . . . . . . . . . . . . . . .
Using the DVD player (DVD video) 226
. . . . . . . . . . . . . . . . . . . . . . .
Using the DVD player (video CD) 232
. . . . . . . . . . . . . . . . . . . . . . . .
Using the DVD player (audio CD/CD text) 234
. . . . . . . . . . . . . . . . .
Using the DVD player (MP3 discs) 235
. . . . . . . . . . . . . . . . . . . . . . .
Using the video mode 236
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Changing the initial setting 237
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Replacing the batteries 241
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Audio/video system operating hints 242
. . . . . . . . . . . . . . . . . . . . . . . . .
7 Rear View Monitor System
Rear view monitor system 254
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

SECTION 6
AUDIO/VIDEO SYSTEM
145
AUDIO/VIDEO SYSTEM
Quick reference 146 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. .
 Using your audio/video system 147
. . . . . . . . . . . . . . . . . . . . . . .
Some basics 147 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. .
Radio operation 155 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\

Radio operation (XM  Satellite Radio broadcast) 160 . . . . . . . .
CD changer operation 166 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Bluetooth  audio operation 178 . . . . . . . . . . . . . . . . . . . . . . . . . . .
DVD player operation 187 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
USB memory/iPod operation 211 . . . . . . . . . . . . . . . . . . . . . . . . .
 Audio/video remote controls (steering switches) 218 . . . . . . . . . . .
 Rear seat entertainment system features 221
. . . . . . . . . . . . . .
Using the DVD player (DVD video) 226 . . . . . . . . . . . . . . . . . . . .
Using the DVD player (video CD) 232 . . . . . . . . . . . . . . . . . . . . .
Using the DVD player (audio CD/CD text) 234 . . . . . . . . . . . . . .
Using the DVD player (MP3 discs) 235 . . . . . . . . . . . . . . . . . . . .
Using the video mode 236 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Changing the initial setting 237 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Replacing the batteries 241 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
 Audio/video system operating hints 242 . . . . . . . . . . . . . . . . . . . . . .

AUDIO/VIDEO SYSTEM
146
Operations such as selecting a preset station and adjusting the sound balance are c\
ar-
ried out on the touch screen. To display the audio screen, push the “TUNE/FILE”/“AU-
DIO” knob.
1Function menu display screen
To control the radio, CD changer,
DVD player*, Bluetooth  audio play-
er, AUX or USB memory/iPod, touch
the touch−screen buttons. For de-
tails, see page 150.
2Function menu tab
To control the radio, CD changer,
DVD player*, Bluetooth  audio play-
er, AUX or USB memory/iPod, touch
the touch−screen tabs. For details,
see page 149.
*: Vehicles with rear seat entertainment system
3“SEEK/TRACK” button
Push either side of this button to seek
up or down for a station, or to access
a desired track, file or chapter. For
details, see pages 157, 170, 174,
185, 190, 193 and 214.
4“TUNE/FILE”/“AUDIO” knob
Push this knob to display the audio
control screen, and turn this knob to
move the station band and files up or
down. For details, see pages 149,
156, 161, 174 and 214.
Quick reference

AUDIO/VIDEO SYSTEM
147
5“LOAD·/ CLOSE” button
Push this button to display the
“Load·Eject” screen or close the dis-
play. For details, see page 166.
6“PWR/VOL” knob
Push this knob to turn the audio sys-
tem on and off, and turn it to adjust the
volume. For details, see page 149.
7“SAT” button
Push this button to choose a SAT sta-
tion. For details, see pages 149 and
161.
8“DISC·AUX” button
Push this button to turn the
Bluetooth  audio player, AUX, USB
memory/iPod, CD changer or DVD
player* on. For details, see pages
149, 155, 169, 184 and 189.
*: Vehicles with rear seat entertainment system
9“FM 1·2” button
Push this button to choose an FM sta-
tion. Each time this button is pushed,
the mode switches between FM1 and
FM2. For details, see pages 149 and
155.
10“AM” button
Push this button to choose an AM sta-
tion. For details, see pages 149 and
155. This section describes some of the basic
features of your audio system. Some in-
formation may not
pertain to your system.
Vehicles with smart key system—
Your audio system works when the “EN-
GINE START STOP” switch is turned to
ACCESSORY or IGNITION ON mode.
Vehicles without smart key system—
Your audio system works when the engine
switch is turned to the “ACC” or “ON” posi-
tion.
CAUTION
For vehicles sold in U.S.A. and
Canada:
Part 15 of the FCC Rules
FCC Warning:
Changes or modifications in
construction not expressly approved
by the party responsible for com-
pliance could void the user’s author-
ity to operate the equipment.
CAUTION: Radio Frequency Radi-
ation Exposure
This device is approved for Mobile
Application only and, to comply with
applicable FCC radio frequency ex-
posure regulations, must be used
with a distance of at least 7.9 in. (20
cm) between the antenna and the
body of any person at all time during
use.
Using your audio/video
system —
— Some basics

AUDIO/VIDEO SYSTEM
151
U6084GS
U6086GS
U6085GS
U6078GS
U6079GS
The touchscreen buttons for radio, CD
changer, DVD player*, Bluetooth
audio player, AUX and USB memory/
iPod, operation are displayed on the
function touchscreen button display
screen when the audio control mode is
selected. Touch them lightly and
directly on the screen.
*: Vehicles with rear seat entertainment
system
Touch the tab to select the desired mode
when the audio control mode is selected.
The selected switch is highlighted.
INFORMATION
If the system does not respond to a
touch of a touchscreen button,
move your finger away from the
screen and then touch it again.
You cannot operate dimmed
touchscreen buttons.
Wipe off fingerprints using a glass
cleaning cloth. Do not use chemi-
cal cleaners to clean the touch
screen.

AUDIO/VIDEO SYSTEM
155
(h) Your DVD player
(with rear seat entertainment system)
The sound of the rear seat entertainment
system can be enjoyed by pushing the
“DISC·AUX” button or touching the
“DVD” tab on AUDIO screen.
(i) AUX port
The sound of portable audio players
connected to the AUX port can be enjoyed.
Push the “DISC·AUX” button or push the
“TUNE/FILE”/“AUDIO” knob to display
audio screen and touch the “AUX” tab to
switch to AUX mode. When the portable
audio player is not connected to the AUX
port, the tab will tone down. For details,
refer to the “Owner’s Manual” .
(j) USB port
It is available to connect a USB memory/
iPod with the USB port. When the USB
memory/iPod is not connected with the
USB port, the tab will tone down. For de-
tails, see “(a) Connecting a USB memory
or iPod” on page 211. (a) Listening to the radio
Push the “AM” or “FM 1·2” button or
push the “TUNE/FILE”/“AUDIO” knob
to display audio screen and touch the
“AM” or “FM” tab to choose either an
AM or FM station.
“AM”, “FM1” or “FM2” appears on the
screen.
If your vehicle is equipped with a satellite
radio broadcast system, when you push
the
“SAT” button or touch the “SAT” tab
on AUDIO screen, “SAT1”, “SAT2” or
“SAT3” station appears on the display. For
details about satellite radio broadcast, see
“—Radio operation (XM  Satellite Radio
broadcast)” on page 160.
— Radio operation

AUDIO/VIDEO SYSTEM
211
Connecting a USB memory or iPod en-
ables you to enjoy music from the ve-
hicle speakers.
CAUTION
Do not operate the player’s controls
or connect the USB memory or iPod
while driving.
NOTICE
Do not leave your portable player in
the car. In particular, high tempera-
tures inside the vehicle may dam-
age the portable player.
Do not push down on or apply un-
necessary pressure to the portable
player while it is connected as this
may damage the portable player or
its terminal.
Do not insert foreign objects into
the port as this may damage the
portable player or its terminal.
(a) Connecting a USB memory or iPod
Vehicles with seat heater
Vehicles without seat heater
Open the cover and connect a USB
memory or iPod using an iPod cable.
Turn on the power of the USB memory or
iPod if it is not turned on.
— USB memory/iPod
operation

AUDIO/VIDEO SYSTEM
219
2“” switch
Radio
This switch has the following features—
To select a preset station:
Quickly push and release the “
” or “”
side of the switch. Do this again to select
the next preset station.
To seek a station:
Push and hold the “
” or “” side of the
switch until you hear a beep. Do this again
to find the next station. If you push the
switch on either side during the seek
mode, seeking will be cancelled.
To step up or down the frequency, push
and hold the switch even after you hear a
beep. When you release from the switch,
the radio will begin seeking up or down for
a station. Do this again to find the next sta-
tion.
XM  Satellite Radio—
To select a preset channel, push the “
”
or “” side of the switch. Repeat until a
desired channel is found.
CD changer
Use this switch to skip up or down to a dif-
ferent track in either direction.
To select a desired track or file:
Quickly push and release the “
” or “”
side of the switch until the track you want
to listen to is set. If you want to return to the
beginning of the current track, push the
“
” side of the switch once, quickly.
To select a desired disc:
Push and hold the “
” or “” switch until
you hear a beep to change to the next or
the previous disc. Repeat this operation
until you reach the disc you want to listen
to. Vehicles
with rear seat entertainment sys-
tem —
DVD player
While the DVD player is in operation, the
chapter or track can be changed by push-
ing the “
” or “” switch.
Bluetooth  audio player
Use this switch to skip up or down to a dif-
ferent track or album in either direction.
To select a desired track:
Quickly push and release the “
” or “”
side of the switch until the track you want
to listen to is set. If you want to return to the
beginning of the current track, push the
“
” side of the switch once quickly.
To select a desired album:
Push and hold “
” or “” switch until
you hear a beep to change to the next or
the previous album. Repeat this operation
until you reach the album you want to listen
to.
USB memory/iPod
Use this switch to skip up or down to a dif-
ferent track, file, album or folder in either
direction.
To select a desired track or file:
Quickly push and release the “
” or “”
side of the switch until the track or file you
want to listen to is set. If you want to return
to the beginning of the current track or file,
push the “
” side of the switch once,
quickly.
To select a desired album or folder:
Push and hold “
” or “” switch until
you hear a beep to change to the next or
the previous album or folder. Repeat this
operation until you reach the album or fold-
er you want to listen to.

AUDIO/VIDEO SYSTEM
249
6U5161aX003.mp3
001.mp3
002.mp3
Folder 1
Folder 2004.mp3
005.mp3
Folder 3006.mp3
MP3 player (rear seat entertainment system)
6U5161aX
001.mp3
002.wma
Folder 1003.mp3
Folder 2
004.mp3
005.wma
Folder 3006.mp3
MP3/WMA player (front audio system)
The play order of the compact disc with
the structure shown above is as fol-
lows:
MP3 player (rear seat entertainment sys-
tem)
001.mp3 002.mp3 . . . 006.mp3
MP3/WMA player (front audio system)
001.mp3 002.wma . . . 006.mp3
MP3 player (rear seat entertainment
system)—It is possible to play up to
253 folders on one disc.
MP3/WMA player (front audio sys-
tem)—It is possible to play up to 192
folders or 255 files on one disc.
USB memory player— It is possible to
play up to 999 folders or 255 files per
folder.
The order changes depending on the
PC and MP3/WMA encoding software
you use.

INDEX
348
Numbers/Symbols
? button
20,33
. . . . . . . . . . . . . . . . . . . . . . . . .
3 Routes selection 74 . . . . . . . . . . . . . . . . . .
A
A/V input port 236
. . . . . . . . . . . . . . . . . . . . .
A2DP(Advanced Audio
Distribution Profile) 178
. . . . . . . . . . . . . . .
Adding destinations 84
. . . . . . . . . . . . . . . . .
Address Book button 20,66
. . . . . . . . . . . . . .
Address book entry information 37 . . . . . . .
Address button 20,55
. . . . . . . . . . . . . . . . . . .
Adjusting the screen (DVD player) 240 . . . .
Alphabet key 28
. . . . . . . . . . . . . . . . . . . . . . .
AM button 146
. . . . . . . . . . . . . . . . . . . . . . . .
Angle mark 203,237
. . . . . . . . . . . . . . . . . . . .
Areas to avoid 115
. . . . . . . . . . . . . . . . . . . . . .
Arrow screen 39,80
. . . . . . . . . . . . . . . . . . . . .
ASL 152
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Audio button 22,317
. . . . . . . . . . . . . . . . . . . .
Audio language 203,237
. . . . . . . . . . . . . . . . .
Audio settings 317
. . . . . . . . . . . . . . . . . . . . .
Audio/video remote controls 218
. . . . . . . . .
Audio/video system 145
. . . . . . . . . . . . . . . .
Audio/video system operating
hints 242
. . . . . . . . . . . . . . . . . . . . . . . . . . .
Auto avoid traffic 98,270,272
. . . . . . . . . . . . .
Auto complete text 270
. . . . . . . . . . . . . . . . .
Auto screen change 260
. . . . . . . . . . . . . . . .
Auto voice guidance 267
. . . . . . . . . . . . . . . .
Automatic recognition 267
. . . . . . . . . . . . . .
Automatic sound levelizer 152
. . . . . . . . . . .
AUX port 155
. . . . . . . . . . . . . . . . . . . . . . . . .
AVRCP(Audio/Video Remote
Control Profile) 178
. . . . . . . . . . . . . . . . . .
B
Balance 152
. . . . . . . . . . . . . . . . . . . . . . . . . .
Basic function 25
. . . . . . . . . . . . . . . . . . . . . .
Bass 152
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Beep 260
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Before using the rear seat
entertainment system controller 224 . . . .
Bluetooth
122,178,309,317
. . . . . . . . . . . . .
Bluetooth audio operation 178
. . . . . . . . . .
Bluetooth audio player 178,317
. . . . . . . . . .
Bluetooth connection statue
at start up 315 . . . . . . . . . . . . . . . . . . . . . .
Bluetooth
 information 318
. . . . . . . . . . . . . .
Brightness 31
. . . . . . . . . . . . . . . . . . . . . . . . .
Building information 43
. . . . . . . . . . . . . . . . .
C
Calendar 143
. . . . . . . . . . . . . . . . . . . . . . . . .
Calendar button 23,143
. . . . . . . . . . . . . . . . .
Calibration 270,275
. . . . . . . . . . . . . . . . . . . . .
Call by call history 135
. . . . . . . . . . . . . . . . .
Call by dial 132
. . . . . . . . . . . . . . . . . . . . . . . .
Call by phonebook 133
. . . . . . . . . . . . . . . . .
Call by POI call 139
. . . . . . . . . . . . . . . . . . . .
Call by speed dial 135
. . . . . . . . . . . . . . . . . .
Call by voice recognition 137
. . . . . . . . . . . .
Call history 135
. . . . . . . . . . . . . . . . . . . . . . .
Call on the Bluetooth
 phone 132
. . . . . . . .
Categories 61
. . . . . . . . . . . . . . . . . . . . . . . . .
CAUTION screen 26
. . . . . . . . . . . . . . . . . . .
CD changer operation 166
. . . . . . . . . . . . . .
Cellular p hone 122
. . . . . . . . . . . . . . . . . . . . .
Change “Icon” 111
. . . . . . . . . . . . . . . . . . . . . .
Change “Location” 113,118
. . . . . . . . . . . . . .
Change “Name” 117
. . . . . . . . . . . . . . . . . . . .
Change “Phone #” 113
. . . . . . . . . . . . . . . . . .
Change “Show Name” 112
. . . . . . . . . . . . . . .
Change “Size” 118
. . . . . . . . . . . . . . . . . . . . . .
Changing a device name 318
. . . . . . . . . . . .
Changing the angle 202
. . . . . . . . . . . . . . . .
Changing the audio language 202
. . . . . . . .
Changing the Bluetooth
 settings 310 . . . . .
Changing the device name 323
. . . . . . . . . .
Changing the handsfree power 310 . . . . . . .
Changing the map DVD −ROM 343 . . . . . . .
Changing the passcode 323
. . . . . . . . . . . . .
Changing the subtitle language 201 . . . . . . .
Channel category 161
. . . . . . . . . . . . . . . . . .
City center 62
. . . . . . . . . . . . . . . . . . . . . . . . .
City name 55,60
. . . . . . . . . . . . . . . . . . . . . . .
City to search 55,60
. . . . . . . . . . . . . . . . . . . .
Clock button 22,265
. . . . . . . . . . . . . . . . . . . .
Clock settings 265
. . . . . . . . . . . . . . . . . . . . .
Color 31
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Command list 47
. . . . . . . . . . . . . . . . . . . . . .
Compass mode 41
. . . . . . . . . . . . . . . . . . . . .
Compass mode screen 39,41
. . . . . . . . . . . .
Connecting a Bluetooth

audio player 182,322
. . . . . . . . . . . . . . . . .
Connecting a Bluetooth
 phone 129 . . . . . .
Connecting a USB memory or
iPod 211 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Contacts 133,292 . . . . . . . . . . . . . . . . . . . . . .
Contrast 31 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Coordinates button 20,71
. . . . . . . . . . . . . . . .
Current position display 33 . . . . . . . . . . . . . .
Current position/tire change
calibration 275
. . . . . . . . . . . . . . . . . . . . . .
Cursor position as a destination 34 . . . . . . .
Cursor position as an address book
entry 35
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Customize POI icons 270
. . . . . . . . . . . . . . .
