691
HIGHLANDER_U (OM48F09U)
10
For owners
AVERTISSEMENT
■Précautions concernant les coussins gonflables SRS
●Si un cache en vinyle recouvre la partie où le coussin gonflable de genoux
pour conducteur SRS se déploie, veillez à l'enlever.
● N’utilisez aucun accessoire de siège qui couvrirait les zones de déploie-
ment des coussins gonflables latéraux SRS et du coussin gonflable
d'assise SRS, car il risquerait de gêner le déploiement des coussins gon-
flables. De tels accessoires peuvent empêcher les coussins gonflables
latéraux et le coussin gonflable d’assise de fonctionner correctement,
désactiver le dispositif ou entraîner le déploiement accidentel des cous-
sins gonflables latéraux et du coussin gonflable d’assise, entraînant la
mort ou des blessures graves.
● Ne faites pas subir de chocs ou de pressions excessives à la zone renfer-
mant les composants de coussin gonflable SRS.
En effet, cela pourrait entraîner un fonctionnement anormal des coussins
gonflables SRS.
● Ne touchez aucun composant du système immédiatement après le
déploiement (gonflage) des coussins gonflables SRS, car ils peuvent être
chauds.
● Si vous avez des difficultés à respirer après le déploiement des coussins
gonflables SRS, ouvrez une porte ou une vitre pour faire entrer de l’air
frais, ou bien descendez du véhicule si cela ne présente pas de danger.
Essuyez tout résidu dès que possible afin d’éviter d’éventuelles irritations
de la peau.
● Si les parties renfermant les coussins gonflables SRS, telles que la garni-
ture du volant et les garnitures de montants avant et arrière, sont abîmées
ou craquelées, faites-les remplacer par votre concessionnaire Toyota.
● Ne disposez rien sur le siège du passager avant, comme par exemple un
coussin. Cela aurait pour conséquence de répartir le poids du passager
sur toute la surface du siège, ce qui empêche le capteur de détecter cor-
rectement le poids du passager. Il en résulte que les coussins gonflables
avant SRS du passager avant risquent de ne pas se déployer en cas de
collision.

692
HIGHLANDER_U (OM48F09U)
AVERTISSEMENT
■Modification et mise au rebut d es éléments du système de coussins
gonflables SRS
Consultez votre concessionnaire Toyota avant de mettre votre véhicule au
rebut ou de procéder à l'une des modifications suivantes. Les coussins gon-
flables SRS peuvent être défaillants ou se déployer (se gonfler) accidentel-
lement, provoquant la mort ou de graves blessures.
● Installation, dépose, démontage et réparation des coussins gonflables
SRS
● Réparations, modifications, démontage ou remplacement du volant, du
tableau de bord, de la planche de bord, des sièges ou de leur garniture,
des montants avant, latéraux et arrière ou des rails latéraux de toit
● Réparations ou modifications des ailes avant, du pare-chocs avant ou des
flancs de l’habitacle
● Installation d’un protège-calandre (pare-buffle, pare-kangourou, etc.), de
chasse-neiges, de treuils ou d'une galerie de pavillon
● Modifications du système de suspension du véhicule
● Installation d’appareils électroniques, tels qu’un émetteur/récepteur radio
mobile ou un lecteur CD
● Aménagements de votre véhicule pour une personne atteinte d’un handi-
cap physique

693
Index
HIGHLANDER_U (OM48F09U)What to do if...
(Troubleshooting) .................... 694
Alphabetical index ..................... 700

694
HIGHLANDER_U (OM48F09U)
What to do if... (Troubleshooting)
What to do if... (Troubleshooting)
●If you lose your keys or mechanical keys, new genuine keys or mechanical
keys can be made by your Toyota dealer. (P. 115)
●If you lose your keys or electronic keys, the risk of vehicle theft increases
significantly. Contact your Toyota dealer immediately. ( P. 118)
●Is the key battery weak or depleted? (P. 538)
●Vehicles with a smart key system:
Is the engine switch in IGNITION ON mode?
When locking the doors, turn the engine switch off. ( P. 229)
●Vehicles with a smart key system:
Is the electronic key left inside the vehicle?
When locking the doors, make sure that you have the electronic key on
your person.
●The function may not operate properly due to the condition of the radio
wave. (P. 115, 149)
●Is the child-protector lock set?
The rear door cannot be opened from inside the vehicle when the lock is
set. Open the rear door from outside and then unlock the child-protector
lock. (P. 124)
If you have a problem, check the following before contacting
your Toyota dealer.
The doors cannot be locked, unlocked, opened or closed
You lose your keys
The doors cannot be locked or unlocked
The rear door cannot be opened

695What to do if... (Troubleshooting)
HIGHLANDER_U (OM48F09U)
●Is the shift lever in P? (P. 225)
●Is the steering wheel unlocked? ( P. 225)
●Is the battery discharged? (P. 627)
●Did you press the engine switch while firmly depressing the brake pedal?
( P. 228)
●Is the shift lever in P? ( P. 230)
●Is the electronic key anywhere detectable inside the vehicle?
( P. 147)
●Is the steering wheel unlocked? ( P. 231)
●Is the electronic key battery weak or depleted?
In this case, the engine can be started in a temporary way.
( P. 625)
●Is the battery discharged? ( P. 627)
If you think something is wrong
The engine does not start
(vehicles without a smart key system)
The engine does not start
(vehicles with a smart key system)

696What to do if... (Troubleshooting)
HIGHLANDER_U (OM48F09U)
●Vehicles without a smart key system:
Is the engine switch in the “ON” position?
If you cannot release the shift lever by depressing the brake pedal with the
engine switch in the “ON” position. (P. 623)
●Vehicles with a smart key system:
Is the engine switch in IGNITION ON mode?
If you cannot release the shift lever by depressing the brake pedal with the
engine switch in IGNITION ON mode. ( P. 623)
●Vehicles without a smart key system:
It is locked to prevent theft of the vehicle if the key is pulled from the engine
switch. (P. 226)
●Vehicles with a smart key system:
It is locked automatically to prevent theft of the vehicle. ( P. 231)
●Is the window lock switch pressed?
The power window except for the one at the driver’s seat cannot be oper-
ated if the window lock switch is pressed. (P. 178)
The shift lever cannot be shifted from P even if you depress
the brake pedal
The steering wheel cannot be turned after the engine is
stopped
The windows do not open or close by operating the power
window switches

697What to do if... (Troubleshooting)
HIGHLANDER_U (OM48F09U)
●The auto power off function will be operated if the vehicle is left in ACCES-
SORY or IGNITION ON mode (the engine is not running) for a period of
time. (P. 230)
●The seat belt reminder light is flashing
Are the driver and the front passenger wearing the seat belts? ( P. 571)
●The parking brake indicator is on
Is the parking brake released? (P. 240)
Depending on the situation, other types of warning buzzer may also sound.
(  P. 569, 578)

●Did anyone inside the vehicle open a door during setting the alarm?
The sensor detects it and the alarm sounds. ( P. 82)
Vehicles without a smart key system:
To stop the alarm, turn the engine switch to the “ON” position or start the
engine.
Vehicles with a smart key system:
To stop the alarm, turn the engine switch to IGNITION ON mode or start the
engine.
The engine switch is tu rned off automatically
(vehicles with a smart key system)
A warning buzzer sounds during driving
An alarm is activated and the horn sounds
(vehicles with an alarm)

698What to do if... (Troubleshooting)
HIGHLANDER_U (OM48F09U)
●Is the electronic key left inside the vehicle or the moon roof or panoramic
moon roof open?
Check the message on the multi-information display. ( P. 578)
●When a warning light turns on or a warning message or indicator is dis-
played, refer to P. 569, 578.
A warning buzzer sounds when leaving the vehicle
(vehicles with a smart key system)
A warning light turns on or a warning message or indicator
is displayed

699What to do if... (Troubleshooting)
HIGHLANDER_U (OM48F09U)
●Stop the vehicle in a safe place and replace the flat tire with the spare tire.
( P. 596)
●Try the procedure for when the vehicle becomes stuck in mud, dirt, or
snow. ( P. 635)
When a problem has occurred
If you have a flat tire
The vehicle becomes stuck

700
HIGHLANDER_U (OM48F09U)
Alphabetical index
Alphabetical index
A/CAir conditioning filter ............. 536
Front automatic air
conditioning system ............ 432
Front manual air conditioning
system ......... ....................... 426
Rear automatic air conditioning system ............ 442
Rear manual air conditioning system ......... ....................... 439
ABS
(Anti-lock Brake
System) .................................. 301Function ................................ 301
Warning light ......................... 570
Air conditioning filter .............. 536
Air conditioning system Air conditioning filter ............. 536
Front automatic air conditioning system ............ 432
Front manual air conditioning system ......... ....................... 426
Rear automatic air
conditioning system ............ 442
Rear manual air conditioning system ......... ....................... 439 Airbags ....................................... 40
Airbag operating conditions .... 48
Airbag precautions for
your child .............................. 43
Airbag warning light .............. 570
Correct driving posture ........... 28
Curtain shield airbag operating conditions ............. 49
Curtain shield airbag precautions........................... 46
Front passenger occupant
classification syst em ............ 53
General airbag precautions .... 43
Locations of airbags ............... 40
Modification and disposal of airbags ............... 47
Side airbag operating
conditions ............................. 49
Side airbag precautions .......... 43
Side and curtain shield airbags operating
conditions ............................. 49
Side and curtain shield
airbags precautions .............. 43
SRS airbags ........................... 40
Alarm .......................................... 82 Alarm ...................................... 82
Warning buzzer ............ 569, 578
All-wheel drive system............ 300
Anchor brackets ........................ 65
Antennas (smart key system) .................................. 146
