TOYOTA HIGHLANDER 2017 XU50 / 3.G Owners Manual

1513-3. Adjusting the seats
3
Operation of each component
HIGHLANDER_U (OM0E017U)■
Second seats
■Third seats
Seatback angle adjustment
strap
Rear seats
Adjustment procedure
Without a side tableWith a side table
Seat position adjustment lever
Seatback angle adjustment lever
Pull the lever until the lock is completely released.
1
2

1523-3. Adjusting the seats
HIGHLANDER_U (OM0E017U)■
Getting in the vehicle
Pull the lever and tilt the seat-
back forward.
Move the seat to the front-most
position.
■Getting out of the vehicle
Pull the lever on the side of the
seatback and tilt the seatback
forward.
Move the seat to the front-most
position.
■After passengers have entered/exited the vehicle
Lift up the seatback and slide t
he seat backward until it locks.
Moving a second seat for third seat access

1533-3. Adjusting the seats
3
Operation of each component
HIGHLANDER_U (OM0E017U)■
Before folding down the second seats
Stow the armrest. ( →P. 478)
With a side table: Stow the side table. ( →P. 480)
Stow the second seat belt buckles.
Pass the outer seat belts
through the seat belt hangers
and secure the seat belt
plates.
This prevents the shoulder belts
from being damaged.
Make sure that the seat belts
are removed from the hangers
before using them.
Lower the head restraints to the lowest position. ( →P. 162)
Folding down the second seats
1
2
3
Without a side tableWith a side table
4
5

1543-3. Adjusting the seats
HIGHLANDER_U (OM0E017U)■
Folding down the second seats
Pull the lever and tilt the seatback forward.
Each seatback may be folded separately.
Pull the lever to unlock the
seatback. The seatback will
be folded down.
■After folding down the second seats
Slide the folded second seats
backward until they lock.
1
From insideFrom outside
2

1553-3. Adjusting the seats
3
Operation of each component
HIGHLANDER_U (OM0E017U)■
Returning the second seats
Lift up the seatbacks until they
lock.
■Before folding down the third seats
Stow the third seat belt buck-
les.
Pass the outer seat belts
through the seat belt hangers
and secure the seat belt
plates.
This prevents the shoulder belts
from being damaged.
Make sure that the seat belts
are removed from the hangers
before using them.
Lower the head restraints to the lowest position. ( →P. 162)
Folding down the third seats
1
2
3

1563-3. Adjusting the seats
HIGHLANDER_U (OM0E017U)■
Folding down the third seats
While pulling the straps, fold
down the seatbacks.
■Returning the third seats
From insideFrom outside
Lift up the seatbacks until they
lock. Pull the straps and raise the
seatbacks until they lock.
After using either strap, use the
Velcro on the end of the strap to
attach it to the seatback.

1573-3. Adjusting the seats
3
Operation of each component
HIGHLANDER_U (OM0E017U)
WARNING
■When folding the rear seatbacks down
Observe the following precautions. Failure to do so may result in death or
serious injury.
● Do not fold the seatbacks down while driving.
● Stop the vehicle on level ground, set the parking brake and shift the shift
lever to P.
● Do not allow anyone to sit on a folded seatback or in the luggage compart-
ment while driving.
● Do not allow children to enter the luggage compartment.
● Do not fold down a rear seatback when there are passengers sitting in the
rear seats or when there is luggage placed on the rear seats.
● Be careful not to catch your hand when folding the rear seatbacks.
■ Seat adjustment
● To reduce the risk of sliding under the lap belt during a collision, do not
recline the seat more than necessary.
If the seat is too reclined, the lap belt may slide past the hips and apply
restraint forces directly to the abdomen, or your neck may contact the
shoulder belt, increasing the risk of death or serious injury in the event of
an accident.
Adjustments should not be made while driving as the seat may unexpect-
edly move and cause the driver to lose control of the vehicle.
● Be careful that the seat does not hit passengers or luggage.
● Be careful not to get your hands or feet caught in the seat.
■ After adjusting or returning the seats
Observe the following precautions. Failure to do so may result in death or
serious injury.
● Make sure that the seat and seatback are securely locked in position by
lightly rocking them back and forth.
● Check that the seat belts are not twisted or caught in the seatback.

1583-3. Adjusting the seats
HIGHLANDER_U (OM0E017U)
Your preferred driving position (the position of the driver’s seat and
outside rear view mirrors) can be recorded and recalled by pressing a
button.
Two different driving positions can be recorded into memory.
■Recording procedureTurn the engine switch to IGNITION ON mode.
Adjust the driver’s seat and outside rear view mirrors to the
desired positions.
While pressing the “SET”
button, or within 3 seconds
after the “SET” button is
pressed, press button “1” or
“2” until the buzzer sounds.
If the selected button has
already been preset, the previ-
ously recorded position will be
overwritten.
Driving position memory∗
∗: If equipped
This feature automatically adjusts the driver’s seat and outside
rear view mirrors to make entering and exiting the vehicle easier
or to suit your preferences.
Driving position memory
1
2
3

1593-3. Adjusting the seats
3
Operation of each component
HIGHLANDER_U (OM0E017U)■
Recall procedure
Check that the shift lever is in P.
Turn the engine switch to IGNITION ON mode.
Press one of the buttons for
the driving position you want
to recall until the buzzer
sounds.
■To stop the position recall operation part-way through
Perform any of the following:
● Press the “SET” button.
● Press button “1” or “2”.
● Operate any of the seat adjustment switches (only cancels seat position
recall).
■ Seat positions that can be memorized ( →P. 149)
The seat position, with the exception of the portions adjusted by the seat
cushion length switch and lumbar support switch, can be recorded.
■ Operating the driving position memo ry after turning the engine switch
off
Recorded seat positions can be activated up to 180 seconds after the driver’s
door is opened and another 60 seconds after it is closed again.
■ In order to correctly use the dr iving position memory function
If a seat position is already in the furthest possible position and the seat is
operated in the same direction, the recorded position may be slightly different
when it is recalled.
1
2
3

1603-3. Adjusting the seats
HIGHLANDER_U (OM0E017U)
Each electronic key can be registered to recall your preferred driving
position.
■Registering procedure
Record your driving position to button “1” or “2” before performing
the following:
Carry only the key you want to register, and then close the driver’s
door.
If 2 or more keys are in the vehicle, the driving position cannot be
recorded properly.
Check that the shift lever is in P.
Turn the engine switch to IGNITION ON mode.
Recall the driving position that you want to record.
While pressing the recalled
button, press and hold the
door lock switch (either lock
or unlock) until the buzzer
sounds.
If the button could not be regis-
tered, the buzzer sounds contin-
uously for approximately 3
seconds.
■
Recall procedure
Carry the electronic key that has been registered to the driving
position, and then unlock and open the driver’s door using the
smart key system or wi reless remote control.
The driving position will move to the recorded position.
If the driving position is in a position that has already been recorded, the
seat and outside rear view mirrors will not move.
Memory recall function
1
2
3
4
