570
6-1. Specifications
Maintenance data (fuel, oil level, etc.)
Dimensions and weights
Overall length188.8 in. (4795 mm)
Overall width75.2 in. (1910 mm)
Overall height 69.3 in. (1760 mm)
Wheelbase109.8 in. (2790 mm)
Front tread 64.0 in. (1625 mm)
Rear tread64.0 in. (1625 mm)
Vehicle capacity weight
(Occupant + luggage) 1200 lb. (544 kg)
Trailer Weight Rating
(Trailer weight + cargo)3500 lb. (1500 kg)

575
6-1. Specifications
6
Vehicle specifications
Lubrication system
*: The engine oil capacity is a reference quantity to be used when exchanging. Warm up the engine and turn off the hybrid system, wait
more than 5 minutes, and check the oil level on the dipstick.
■ Engine oil selection
“Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use
Toyota approved “Toyota Genuine Motor Oil” or equivalent to satisfy
the following grade and viscosity.
Oil grade: ILSAC multigrade engine oil
Recommended viscosity: SAE 0W-20
SAE 0W-20 is the best choice for
good fuel economy and good
starting in cold weather.
If SAE 0W-20 is not available,
SAE 5W-20 oil may be used.
However, it must be replaced
with SAE 0W-20 at the next oil
change.
Oil capacity
(Drain and refill 
reference*) Without filter
With filter 6.0 qt. (5.7 L, 5.0 Imp. qt.)
6.4 qt. (6.1 L, 5.4 Imp. qt.)
Outside temperature

593
6-1. Specifications
6
Vehicle specifications
Warning: The temperature grades for this tire are established for a
tire that is properly inflated and not overloaded.
Excessive speed, underinflation, or
excessive loading, either sepa-
rately or in combination, can caus e heat buildup and possible tire fail-
ure.
Glossary of tire terminology
Tire related termMeaning
Cold tire inflation pres-
sure Tire pressure when the vehicle has been
parked for three hours or more, or has not
been driven more than 1 mile or 1.5 km under
that condition
Maximum inflation
pressure The maximum cold inflated
pressure to which a
tire may be inflated, s hown on the sidewall of
the tire
Recommended infla-
tion pressure Cold tire inflation pressure recommended by a
manufacturer
Accessory weight The combined weight (in excess of those stan-
dard items which may be replaced) of auto-
matic transmission, power steering, power
brakes, power windows, power seats, radio
and heater, to the extent that these items are
available as factory-installed equipment
(whether installed or not)
Curb weight The weight of a motor vehicle with standard
equipment, including the maximum capacity of
fuel, oil and coolant, and if so equipped, air
conditioning and additional weight optional
engine
Maximum loaded vehi-
cle weight The sum of:
(a) Curb weight
(b) Accessory weight
(c) Vehicle capacity weight
(d) Production options weight

625
Alphabetical index
Engine
Compartment........................ 462
Engine switch ............... 179, 184
Hood ..................................... 458
How to start the
hybrid system ..................... 179
Identification number ............ 571
If the hybrid system will not start .............................. 552
Ignition switch ............... 179, 184
Overheating .......................... 562
Power switch ........................ 179
Engine compartment cover .... 463
Engine coolan t temperature
gauge ..................................... 196
Engine oil Capacity ............................... 575
Checking .............................. 464
Preparing and checking before winter ...................... 251
Engine oil maintenance data ........................................ 448
Engine switch .................. 179, 184
Engine/power control unit
coolantCapacity ............................... 577
Checking .............................. 467
Preparing and checking before winter ...................... 251
EPS ........................................... 234
EV-Drive Mode ......................... 188
Event data recorder .................. 26 Floor mat...................................427
Fluid
Brake .....................................471
Washer ..................................472
Fog lights
Replacing light bulbs .............510
Switch....................................219
Wattage .................................583
Front automatic air conditioning system..............284
Front fog lights
Replacing light bulbs .............510
Switch....................................219
Wattage .................................583
Front manual air conditioning system..............278
Front passenger occupant
classification system ............145
Front passenger's seat belt reminder light.........................531
Front seats Adjustment ..............................83
Front side marker lights
Replacing light bulbs .............510
Switch....................................213
Wattage .................................583
Front turn signal lights Replacing light bulbs .............510
Wattage .................................583
Fuel Capacity ................................573
Fuel gauge ............................196
Gas station information .........636
Information ............................584
Refueling ...............................118
Type ......................................573
Fuel door...................................118
Fuel filler door ..........................118
Fuses.........................................497F

632 Alphabetical index
Warning buzzersBrake system ........................ 528
Moon roof .............................. 533
Open door ............................. 531
Seat belt reminder ................. 531
Warning lights Anti-lock brake system .......... 529
Brake assist system .............. 529
Brake system ........................ 528
Charging system .... ............... 529
Electric power steering
system ................................ 529
Electronic engine control system ................................ 529
Engine oil pressure ............... 529
Malfunction indicator lamp .... 529
Master warning light .............. 531
Open door ............................. 531
Pretensioners ........................ 529
Seat belt reminder light ......... 531
SRS airbags .......................... 529
Tire pressure warning light .... 531
Warning messages .................. 538
Washer
Checking ............................... 472
Preparing and checking before winter ....................... 251
Switch............................ 221, 224
Washing and waxing ............... 442 Weight
Cargo capacity ...................... 246
Load limits ............................. 250
Weight ................................... 570
Wheels ...................................... 488
Window glasses ...................... 110
Window lock switch................. 110
Windows
Power windows ..................... 110
Rear window defogger .......... 300
Washer.......................... 221, 224
Windshield wiper de-icer ........ 302
Windshield wipers ................... 221
Wireless remote control key Replacing the battery ............ 494
Wireless remote control .......... 59
WMA disc.................................. 322W

636
GAS STATION INFORMATION
Auxiliary catch leverP. 458Fuel filler doorP. 1 1 8
Hood release lever P. 4 5 8Fuel filler door opener P. 1 1 8Tire inflation pressure
P. 581
Back door openerP. 7 0
Fuel tank capacity (Reference) 17. 2 gal. (65.0 L, 14.3 Imp. gal.)
Fuel typeUnleaded gasoline with an Octane Rating
of 87 (Research Octane Number 91)
Cold tire inflation
pressure
P. 5 8 1
Engine oil capacity
(Drain and refill

reference) qt. (L, Imp. qt.)
Without filter 6.0 (5.7, 5.0)
With filter 6.4 (6.1, 5.4)
Engine oil type Toyota Genuine Motor Oil or equivalent
Oil grade: P. 575
ILSAC multigrade engine oil
Recommended oil viscosity: SAE 0W-20
