TOYOTA HIGHLANDER HYBRID 2016 XU50 / 3.G Owners Manual

3515-3. Using the storage features
5
Interior features
HIGHLANDER_HV_U (OM48F12U)
Raise the hooks to use.
Cargo hooks are provided for
securing loose items.
Luggage compartment features
Cargo hooks
Grocery bag hooks
NOTICE
Do not hang any object heavier than 6.6 lb. (3 kg) on the grocery bag hooks.

3525-3. Using the storage features
HIGHLANDER_HV_U (OM48F12U)
Pull the strap upwards to open
the center deck board.
To secure the center deck
board, remove the hook on the
backside of the center deck
board and attach the hook to
the head restraint on the third
seats as shown.
Center deck under tray
1
2
WARNING
Do not drive with the deck board opened. Items may fall out and cause
injury.

353
5
Interior features
HIGHLANDER_HV_U (OM48F12U)
5-4. Using the other interior features
To set the visor in the forward
position, flip it down.
To set the visor in the side posi-
tion, flip down, unhook, and
swing it to the side.
To use the side extender, place
the visor in the side position,
then slide it backward.
Open the cover.
The vanity light turns on.
■ To prevent 12-volt battery discharge
If the vanity lights remain on for 20 minutes while the hybrid system is off, the
lights will turn off automatically.
Other interior features
Sun visors
1
2
3
Vanity mirrors

3545-4. Using the other interior features
HIGHLANDER_HV_U (OM48F12U)
Push the lid.
Push the lid back up half way.
■To use the overhead console from the conversation mirror state
Fully close the lid, then open it again. ( P. 349)
Conversation mirror
1
2

3555-4. Using the other interior features
5
Interior features
HIGHLANDER_HV_U (OM48F12U)
The clock can be adjusted by pressing the buttons.Adjusts the hours
Adjusts the minutes
■The clock is displayed when
The power switch is in ACCESSORY or ON mode.
■ When the 12-volt battery is disconnected
The time display will automatically be set to 1:00.
The temperature display shows temperatures within the range of -40F
(-40
C) to 122F (50C).
Clock
1
2
Outside temperature display
Vehicles with monochrome dis-
playVehicles with color display

3565-4. Using the other interior features
HIGHLANDER_HV_U (OM48F12U)
■The outside temperature is displayed when
The power switch is in ON mode.
■ Display
In the following situations, the correct outside temperature may not be dis-
played, or the display may take longer than normal to change.
●When the vehicle is stopped, or moving at low speeds (less than 15 mph
[25 km/h]).
● When the outside temperature has changed suddenly (at the entrance/exit
of a garage, tunnel, etc.)
■ When the outside temp erature display flashes
Vehicles with monochrome display
If the outside temperature is 37 F (3 C) or less, the temperature display
flashes 10 times, and then illuminates.
Vehicles with color display
If the outside temperature is 37 F (3°C) or less, the ice warning indicator
flashes 10 times, and then illuminates.
■ When “--” or “E” is displayed
The system may be malfunctioning. Take your vehicle to your Toyota dealer.
The power outlet can be used for the following components:
12 V: Accessories that run on less than 10 A
120 VAC: Accessories that use less than 100 W
■12 V
Front
Open the lid.
Power outlets

3575-4. Using the other interior features
5
Interior features
HIGHLANDER_HV_U (OM48F12U)
Console box
Open the console box lid
(
P. 345) and open the lid.
Rear
Open the lid.
■120 VAC (if equipped)
Open the lid.
■ The power outlets can be used when
12 V: The power switch is in ACCESSORY or ON mode.
120 VAC: The power switch is in ON mode.

3585-4. Using the other interior features
HIGHLANDER_HV_U (OM48F12U)
NOTICE
■To avoid damaging the power outlets
Close the power outlet lids when the power outlets are not in use.
Foreign objects or liquids that enter the power outlets may cause a short cir-
cuit.
■ To prevent blown fuses
12 V
Do not use an accessory that uses more than 12 V 10 A.
120 VAC
Do not use a 120 VAC appliance that requires more than 100 W.
If a 120 VAC appliance that consumes more than 100 W is used, the protec-
tion circuit will cut the power supply.
■ To prevent 12-volt battery discharge
Do not use the power outlet longer than necessary when the hybrid system
is off.
■ Appliances that may not operate properly (120 VAC)
The following 120 VAC appliances may not operate properly even if their
power consumption is under 100 W:
●Appliances with high initial peak wattage
● Measuring devices that process precise data
● Other appliances that require an extremely stable power supply

3595-4. Using the other interior features
5
Interior features
HIGHLANDER_HV_U (OM48F12U)
Pull the tab up.
Hook the sunshade on to the
anchors.
To lower the sunshade, pull the tab
up slightly to unhook the shade
from the anchors, and lower it
slowly.
Rear sunshades (if equipped)
1
2
NOTICE
To ensure normal operation of the rear sunshades, observe the following
precautions.
●Do not place anything where it may hinder the opening/closing of a sun-
shade.
● Do not place anything on the rear sunshades.

3605-4. Using the other interior features
HIGHLANDER_HV_U (OM48F12U)
Ty p e A
Fold down the armrest for use.
Ty p e B
Lower the armrest from the
highest position to the lowest
position.
Raise the armrest to the
desired angle.
To unlock the armrest, lift the arm-
rest to raise it to the highest posi-
tion.
Armrest
1
2
NOTICE
To prevent damage to the armrest, do not apply too much load on the arm-
rest.
