1093-3. Route guidance
3
Navigation system
HIGHLANDER_HIGHLANDER HV_NAVI_(U)
1Select “Turn List” on the map
mode screen. ( P.85)
2 Check that the turn list
screen is displayed.
Turn direction
Next street or destination
name
Distance between turns On this screen, information
about the next turn on the guid-
ance route can be displayed.
1
Select “Turn-by-Turn Arrow”
on the map mode screen.
( P.85)
2 Check that the turn-by-turn
arrow screen is displayed.
Exit number or street name
Turn direction
Distance to the next turn
Turn list screen
A
B
C
7XUQE\WXUQD\
UURZVFUHHQ
A
B
C

1103-3. Route guidance
HIGHLANDER_HIGHLANDER HV_NAVI_(U)
●If a voice guidance command can-
not be heard, press the “MAP”
button to hear it again.
●To adjust the voice guidance vol-
ume: P. 7 2
●To mute the voice guidance:
 P. 1 0 5
●Voice guidance may be made
early or late.
●If the navigation system cannot
determine the current position cor-
rectly, you may not hear voice
guidance or may not see the mag-
nified intersection on the screen.
1 Select on the map
screen. ( P. 8 0 )
2 Select the desired item to be
set.
Select to display the over-
view of the entire route.
( P.102)
Select to reorder destina-
tions. ( P. 1 1 1 )
Select to change route type.
( P. 1 1 1 )
Select to set route prefer-
ences. ( P. 111 )
Select to set detours.
( P. 1 1 2 )
Select to start from adjacent
road. ( P.113)
 To hide the route options
screen, touch any part of the
map screen.
3 Check that the route over-
view is displayed. ( P.102)
Typical voice guid-
ance prompts
As the vehicle approaches
an intersection, or point,
where maneuvering the
vehicle is necessary, the
navigation system’s voice
guidance will provide vari-
ous messages.
WA R N I N G
●Be sure to obey the traffic regu-
lations and keep the road condi-
t i o n i n m i n d e s p e c i a l l y w h e n y o u
are driving on IPD roads (roads
that are not completely digitized
in our database). The route
guidance may not have the
updated information such as the
direction of a one way street.
Editing route
Displaying the edit route
screen
A
B
C
D
E
F

1113-3. Route guidance
3
Navigation system
HIGHLANDER_HIGHLANDER HV_NAVI_(U)
When more than 1 destination
has been set, the arrival order of
the destinations can be
changed.
1Select on the map
screen. ( P.80)
2 Select “Reorder”.
3 Select the desired destina-
tion and select “Move Up” or
“Move Down” to change the
arrival order. Then select
“OK”.
1 Select on the map
screen. ( P.80)
2 Select “Route Type”.
3 Select the desired route type.
 The entire route from the
starting point to the destina-
tion is displayed. ( P.102)
 During driving, the route guid-
ance starts after selecting the
desired route type. The conditions to determine the
route can be selected from vari-
ous choices such as freeways,
toll roads, ferries, etc.
1
Select on the map
screen. ( P. 8 0 )
2 Select “Preference”.
3 Select the desired route pref-
erences and select “OK”.
●Even if the “Avoid Freeways”
route preference is turned off, the
route may not be able to avoid
freeways in some cases.
●If the calculated route includes a
trip by ferry, the route guidance
shows a sea route. After traveling
by ferry, the curre nt position may
be incorrect. Upon reception of
GPS signals, it is automatically
corrected.
Reordering destinations
Selecting route typeSetting route preferences

1123-3. Route guidance
HIGHLANDER_HIGHLANDER HV_NAVI_(U)
During the route guidance, the
route can be changed to detour
around a section of the route
where a delay is caused by road
repairs, an accident, etc.
1Select on the map
screen. ( P.80)
2 Select “Detour”.
3 Select the desired detour dis-
tance.
Select to detour within 1 mile
of the current position.
Select to detour within 3
miles of the current position.
Select to detour within 5
miles of the current position.
Select to detour on the entire
route.
Select to make the navigation
system search for the route
based on traffic congestion
information received from
traffic information.
* ( P. 9 0 )
*: This function is not available in
some countries or areas.
●This picture shows an example of
how the navigation system would guide around a delay caused by a
traffic jam.
This position indi cates the loca-
tion of a traffic jam caused by
road repairs, an accident, etc.
This route indicates the detour
suggested by the navigation
system.
●When the vehicle is on a freeway,
the detour distance selections are
5, 15 and 25 miles (or 5, 15 and
25 km if units are in km).
●The navigation system may not be
able to calculate a detour route
depending on the selected dis-
tance and surrounding road condi-
tions.
Detour setting
A
B
C
D
E
A
B

1133-3. Route guidance
3
Navigation system
HIGHLANDER_HIGHLANDER HV_NAVI_(U)
When a freeway and a surface
road run in parallel, the naviga-
tion system may show the guid-
ance route going on the freeway
while driving on the surface
road, or vice versa.
If this happens, you can
instantly choose the adjacent
road for the route guidance.
1Select on the map
screen. ( P.80)
2 Select “Adjacent Road”.
●When there is no adjacent road,
this screen button will not be dis-
played.
Adjacent road

1143-4. Setup
HIGHLANDER_HIGHLANDER HV_NAVI_(U)
3-4.Setup
1Press the “MENU” button.
8-inch display model
12.3-inch display model
2 Select “Setup”.
3 Select “Navigation”. 4
Select the desired item to be
set.
Select to set home. ( P.115)
Select to set the favorites list.
( P. 1 1 5 )
Select to set areas to avoid.
( P. 1 1 7 )
Select to set detailed naviga-
tion settings. ( P. 1 1 9 )
●When “Useful Navi. Information
Settings” is displayed on the
screen: P. 1 2 8
Navigation settings
Home, favorites list entries,
areas to avoid can be set as
memory points. The regis-
tered points can be used as
the destinations. ( P.93)
Registered areas to avoid,
will be avoided when the
navigation system searches
for a route.
Displaying navigation set-
tings screen
Navigation settings
screen
A
B
C
D

1153-4. Setup
3
Navigation system
HIGHLANDER_HIGHLANDER HV_NAVI_(U)
If home has been registered,
that information can be recalled
by selecting “Home” on the
destination screen. (P.93)
1 Display the navigation set-
tings screen. ( P.114)
2 Select “Home”.
3 Select “Address”( P.97) or
“Current Location” to search
for your home.
4 Select “OK” when the editing
home screen appears.
1 Display the navigation set-
tings screen. ( P.114)
2 Select “Home”.
3 Select the desired item to be
edited.
Select to edit the home
name.
Select to edit location infor-
mation.
Select to change the icon to be displayed on the map
screen. (
P.117)
Select to set display of the
home name on/off.
Select to delete registered
home location.
4 Select “OK”.
Points on the map can be regis-
tered.
1 Display the navigation set-
tings screen. ( P. 1 1 4 )
2 Select “Favorites”.
3 Select the desired item.
Select to edit the favorites
list.
“Add New”: Select to register
favorites list entries.
( P. 1 1 6 )
“Sort”: Select to sort (date,
name, icon) favorite list
entries.
“Delete All”: Select to delete
all favorite list entries.
Setting up home
Registering home
Editing home
A
B
C
6HWWLQJXSID\
YRULWHVOLVW
D
E
A

1173-4. Setup
3
Navigation system
HIGHLANDER_HIGHLANDER HV_NAVI_(U)
1Select “Icon”.
2 Select the desired icon.
■Icons with sound
A sound for some favorites list
entries can be set. When the
vehicle approaches the location
of the favorites list entry, the
selected sound will be heard.
: Select to play the sound.
●When “Bell (with Direction)” is
selected, select an arrow to adjust
the direction and select “OK”.
●The bell sounds only when the
vehicle approaches this point in
the direction th at has been set.
Areas to be avoided because of
traffic jams, construction work or
other reasons can be registered
as “Areas to Avoid”.
1Display the navigation set-
tings screen. ( P. 1 1 4 )
2 Select “Areas to Avoid”.
3 Select the desired item.
Select to edit the list of areas
to avoid.
“Add New”: Select to register
areas to avoid. ( P. 1 1 8 )
“Delete All”: Select to delete
all areas to avoid.
Changing the icon
Setting up areas to avoid
A

1193-4. Setup
3
Navigation system
HIGHLANDER_HIGHLANDER HV_NAVI_(U)
1Press the “MENU” button.
8-inch display model
12.3-inch display model
2 Select “Setup”.
3 Select “Navigation”.
4 Select “Detailed Navi. Set-
tings”. 5
Select the desired items to
be set.
 “Low Fuel Warning Pop-up”
Select to set display of low fuel
warning on/off. ( P.120)
 “Unverified Roads Guidance
Warning”
Select to set unverified roads guid-
ance warning on/off.
“Guidance on Unverified
Roads”
Select to set IPD road (roads that
are not completely digitized in our
database) guidance on/off.
 “Guidance with Street Names”
Select to set the voice guidance for
the next street name on/off.
“Favorite POI Categories”
Select to set favorite POI catego-
ries that are used for POI selection
to display on the map screen.
( P.121)
 “Calibration”
Select to adjust the current position
mark manually or to adjust miscal-
culation of the distance caused by
tire replacement. ( P.121)
Detailed navigation
settings
Settings are available for
pop-up information, favor-
ite POI categories, low fuel
warning, etc.
Displaying the detailed
navigation settings
screen
Detailed navigation set-
tings screen

1213-4. Setup
3
Navigation system
HIGHLANDER_HIGHLANDER HV_NAVI_(U)
Up to 6 POI icons, which are
used for selecting POIs on the
map screen, can be selected as
favorites.
1Display the detailed naviga-
tion settings screen.
( P.119)
2 Select “Favorite POI Catego-
ries”.
3 Select the desired category
to be changed.
“Default”: Select to set the default
categories.
4Select the desired POI cate-
gory.
“List All Categories”: Select to dis-
play all POI categories.
5Select the desired POI icon.
6 Select “OK”. The current position mark can
be adjusted manually. Miscalcu-
lation of the distance caused by
tire replacement can also be
adjusted.
1
Display the detailed naviga-
tion settings screen.
( P. 1 1 9 )
2 Select “Calibration”.
3 Select the desired item.
 For additional information on
the accuracy of a current
position: P.129
When driving, the current posi-
tion mark will be automatically
corrected by GPS signals. If
GPS reception is poor due to
location, the current position
mark can be adjusted manually.
1 Select “Position/Direction”.
2 Scroll the map to the desired
point ( P.84) and select
“OK”.
3 Select an arrow to adjust the
direction of the current posi-
tion mark and select “OK”.
Favorite POI categories
(Select POI icons)
Current position/Tire
change calibration
Position/Direction calibra-
tion
