- SFITHROTTLE BODY
SF-33
1732 Author: Date:
2004 LAND CRUISER (RM1071U)
THROTTLE BODY
ON-VEHICLE INSPECTION
1. REMOVE V-BANK COVER
2. INSPECT SYSTEM OPERATION
(a) Inspect the throttle control motor for operating sound.
(1) Turn the ignition switch ON.
(2) When turning the accelerator pedal position sensor
lever, check the running sound of the motor. Also,
check that there is no friction sound.
If operation is not as specified, check the throttle control motor
(See step 3), wiring and ECM.
(b) Inspect the accelerator pedal position sensor.
(1) Connect the TOYOTA hand-held tester or OBD II
scan tool to the DLC3.
(2) Check that the MIL does not come on.
(3) When turning the accelerator pedal position sensor
lever to the full- open position, check that the
throttle valve opening percentage (THROTTLE
POS) of CURRENT DATA shows the standard val-
ue.
Standard throttle valve opening percentage:
60 % or more
If operation is not as specified, check that the accelerator pedal
position sensor (See page DI-318), wiring and ECM.
If you have no TOYOTA hand-held tester or OBD II scan tool,
measure the voltage between terminal VPA and E2 of the ECM
connector.
(c) Inspect the air assist system.
(1) Start the engine and check that the MIL does not
come on.
(2) Allow the engine to warm up to normal operating
temperature.
(3) Turn the A/C compressor ON to OFF, and check the
idle speed.
Page 2678 of 3115
B15314B16468
OhmmeterM-
M+
SF-34
- SFITHROTTLE BODY
1733 Author: Date:
2004 LAND CRUISER (RM1071U)
Idle speed (Transmission in neutral): 700 ± 50 rpm
NOTICE:
Perform inspection under the condition with no electrical
load.
(d) After checking the above (b) to (d), perform the running
test and check that there is no incongruity.
3. INSPECT THROTTLE CONTROL MOTOR
(a) Disconnect the throttle connector.
(b) Using an ohmmeter, measure the motor resistance be-
tween terminal M+ and M-.
Motor resistance: 0.3 - 100 W at 20°C (68°F)
If the resistance is not as specified, replace the throttle body.
(c) Reconnect the throttle body connector.
4. INSPECT THROTTLE POSITION SENSOR (See page
DI-84)
If necessary, replace the throttle body.
NOTICE:
Be careful not to give a shock to the throttle body.
Be careful not to disassemble the throttle body.
5. REINSTALL V-BANK COVER
Page 2682 of 3115
SF0Y8-09
B16464
Vacuum HoseVSV for Vapor Pressure Sensor VSV Connector for Vapor Pressure Sensor
Vacuum Hose
- SFIVSV FOR VAPOR PRESSURE SENSOR
SF-45
1744 Author: Date:
2004 LAND CRUISER (RM1071U)
VSV FOR VAPOR PRESSURE SENSOR
COMPONENTS
Page 2683 of 3115
B08661
Ohmmeter
Continuity
SF0PM-1 1
B08662
Ohmmeter
No Continuity
B08663
Air E F
B08664Battery Air F
E SF-46
- SFIVSV FOR VAPOR PRESSURE SENSOR
1745 Author: Date:
2004 LAND CRUISER (RM1071U)
INSPECTION
1. REMOVE VSV
2. INSPECT VSV
(a) Inspect VSV for open circuit.
Using an ohmmeter, check that there is continuity be-
tween the terminals.
Resistance: 30 - 36 W at 20°C (68°F)
If there is no continuity, replace the VSV.
(b) Inspect the VSV for ground.
Using an ohmmeter, check that there is no continuity be-
tween each terminal and the body.
If there is a continuity, replace the VSV.
(c) Inspect the VSV operation.
(1) Check that air flows from the ports E to F.
(2) Apply the battery positive voltage across the termi-
nals.
(3) Check that air flows from the ports E to F.
If operation is not as specified, replace VSV.
3. REINSTALL VSV
Page 2684 of 3115
SF0PP-10
B16451
Vapor Pressure Sensor ConnectorVapor Pressure Sensor
Joint Clip
- SFIVAPOR PRESSURE SENSOR
SF-51
1750 Author: Date:
2004 LAND CRUISER (RM1071U)
VAPOR PRESSURE SENSOR
COMPONENTS
Page 2685 of 3115
SF0PQ-10
B16452
13
Voltmeter
B09192
2
3Voltmeter SF-52
- SFIVAPOR PRESSURE SENSOR
1751 Author: Date:
2004 LAND CRUISER (RM1071U)
INSPECTION
1. INSPECT POWER SOURCE VOLTAGE OF VAPOR
PRESSURE SENSOR
(a) Disconnect the vapor pressure sensor connector.
(b) Turn the ignition switch ON.
(c) Using a voltmeter, measure the voltage between connec-
tor terminal 1 and 3 of the wiring harness side.
Voltage: 4.5 - 5.5 V
(d) Turn the ignition switch OFF.
(e) Reconnect the vapor pressure sensor connector.
2. INSPECT POWER OUTPUT OF VAPOR PRESSURE
SENSOR
(a) Turn the ignition switch ON.
(b) Remove the fuel tank cap.
(c) Connect a voltmeter to terminal 2 and 3, and measure the
output voltage.
Voltage: 3.0 - 3.6 V
(d) Reinstall the fuel tank cap.
(e) Turn the ignition switch OFF.
Page 2686 of 3115
RS0BK-08
H20939
Center Lower Cluster Finish Panel
17.5 (178, 13)Airbag Sensor Assembly
Front Console Box
Transfer Shift Lever Knob Front Seat LH
Upper Console Panel
Rear Console Box
Front Seat RH
N´m (kgf´cm, ft´lbf) : Specified torque
17.5 (178, 13)
- SUPPLEMENTAL RESTRAINT SYSTEMAIRBAG SENSOR ASSEMBLY
RS-69
2344 Author: Date:
2004 LAND CRUISER (RM1071U)
AIRBAG SENSOR ASSEMBLY
COMPONENTS
Page 2687 of 3115
RS0BM-03
- SUPPLEMENTAL RESTRAINT SYSTEMAIRBAG SENSOR ASSEMBLY
RS-71
2346 Author: Date:
2004 LAND CRUISER (RM1071U)
INSPECTION
1. Vehicle not involved in collision:
INSPECT SUPPLEMENTAL RESTRAINT SYSTEM
Do a diagnostic system check (See page DI-692).
2. Vehicle involved in collision and airbag is not deployed:
INSPECT SUPPLEMENTAL RESTRAINT SYSTEM
Do a diagnostic system check (See page DI-692).
3. Vehicle involved in collision and airbag is deployed:
INSPECT SUPPLEMENTAL RESTRAINT SYSTEM
Replace the airbag sensor assembly (See page RS-69).
Page 2688 of 3115
RS0BO-08
H20940
- SUPPLEMENTAL RESTRAINT SYSTEMAIRBAG SENSOR ASSEMBLY
RS-73
2348 Author: Date:
2004 LAND CRUISER (RM1071U)
INSTALLATION
NOTICE:
Never use SRS parts from another vehicle. When re-
placing parts, replace them with new parts.
Never reuse the airbag sensor assembly involved in
a collision when the airbag has deployed.
Never repair a sensor in order to reuse it.
HINT:
For step 2 to 6, refer to page BO-91.
1. INSTALL AIRBAG SENSOR ASSEMBLY
(a) Install the airbag sensor assembly with the 3 bolts.
Torque: 17.5 N´m (178 kgf´cm, 13 ft´lbf)
(b) Connect the airbag sensor connectors.
NOTICE:
Connection of the connector is done after the sensor
assembly has been installed.
Make sure the sensor assembly is installed with the
specified torque.
If the sensor assembly has been dropped, or there are
cracks, dents or other defects in the case, bracket or
connector, replace the sensor assembly with a new
one.
When installing the sensor assembly, take care that
the SRS wiring does not interfere with other parts and
is not pinched between other parts.
After installing, shake the sensor assembly to check
that there is no looseness.
2. INSTALL CENTER LOWER INSTRUMENT CLUSTER
FINISH PANEL ASSEMBLY
3. INSTALL FRONT CONSOLE BOX
4. INSTALL REAR CONSOLE BOX WITH CONSOLE
REAR END PANEL
5. INSTALL UPPER CONSOLE PANEL
6. INSTALL TRANSFER SHIFT LEVER KNOB
7. INSTALL FRONT SEAT (See page BO-1 17)
8. INSPECT SRS WARNING LIGHT (See page DI-692)
Page 2689 of 3115
RS0BL-08
H20940
RS-70
- SUPPLEMENTAL RESTRAINT SYSTEMAIRBAG SENSOR ASSEMBLY
2345 Author: Date:
2004 LAND CRUISER (RM1071U)
REMOVAL
NOTICE:
Do not open the cover or the case of the ECU and various
electrical devices unless absolutely necessary.
(If the IC terminals are touched, the IC may be destroyed by
static electricity.)
HINT:
For step 2 to 6, refer to page BO-84.
1. REMOVE FRONT SEAT (See page BO-105)
2. REMOVE TRANSFER SHIFT LEVER KNOB
3. REMOVE UPPER CONSOLE PANEL
4. REMOVE REAR CONSOLE BOX WITH CONSOLE
REAR END PANEL
5. REMOVE FRONT CONSOLE BOX
6. REMOVE CENTER LOWER CLUSTER FINISH PANEL
ASSEMBLY
7. REMOVE AIRBAG SENSOR ASSEMBLY
(a) Disconnect the airbag sensor connectors.
NOTICE:
Disconnect the connectors with the airbag sensor assem-
bly installed.
(b) Remove the 3 bolts and the airbag sensor assembly.
