- AUTOMATIC TRANSMISSIONAIR COOLED OIL COOLER
AT-19
1873 Author
: Date
:
INSTALLATION
Installation is in the reverse order of removal (See page AT-17).
HINT:
After installtion, check fluid level (See page AT-3-1).

AT147-03
D13650
Refill Plug
Overflow Plug
D14352
Overflow Tube
AT-3-1
- AUTOMATIC TRANSMISSIONAUTOMATIC TRANSMISSION SYSTEM
1855 Author
: Date
:
2004 LAND CRUISER (RM1071U)
AUTOMATIC TRANSMISSION
FLUID
OPERATION
1. BEFORE TRANSMISSION FILL

This transmission requires Toyota Genuine ATF WS.

It is necessary to refill the transmission with the correct
amount of fluid.

The vehicle must remain level while adjusting the trans-
mission fluid level.

On vehicles equipped with active suspension, turn the
suspension control switch OFF if it is necessary to jack up
the vehicle with the engine running.
2. TRANSMISSION PAN FILL
(a) Remove the refill plug and overflow plug.
(b) Fill the transmission through the refill hole until fluid be-
gins to trickle out of the overflow tube.
(c) Reinstall the overflow plug.

A04550
9 1011 12 13141516 12345678
DLC3 CG
TC
- AUTOMATIC TRANSMISSIONAUTOMATIC TRANSMISSION SYSTEM
AT-3-2
1856 Author
: Date
:
2004 LAND CRUISER (RM1071U)
3. TRANSMISSION FILL
(a) Fill the transmission with the correct amount of fluid as
listed in the table below.
(b) Reinstall the refill plug to avoid fluid splash.
RepairFill Amount
Transmission pan and drain plug remov-
al1.3 liters (1.37 US qts, 1.14 Imp. qts)
Transmission valve body removal3.9 liters (4.12 US qts, 3.43 Imp. qts)
Torque converter removal5.3 liters (5.60 US qts, 4.66 Imp. qts)
Entire transmission assembly5.3 liters (5.60 US qts, 4.66 Imp. qts)
HINT:
If you cannot add the listed amount of fluid, do the following:
(1) Install the refill plug.
(2) Allow the engine to idle with air conditioning OFF.
(3) Move the shift lever through entire gear range to cir-
culate fluid.
(4) Wait for 30 seconds with the engine idling.
(5) Stop the engine.
(6) Remove the refill plug and add fluid.
(7) Reinstall the refill plug.
4. FLUID CIRCULATION
(a) Allow the engine to idle with the air conditioning OFF.
(b) Move the shift lever through entire gear range to circulate
fluid.
5. FLUID TEMPERATURE CHECK
NOTICE:
The fluid temperature should be less than 30C (86F) be-
fore beginning the fluid temperature check.
(a) With hand-held tester
(1) Connect the hand-held tester to the DLC3.
(2) Select the tester menus: OBD/MOBD, ENGINE,
DATA LIST and A/T.
(3) Check A/T OIL TEMP.
(4) Allow the engine to idle until the fluid temperature
reaches 46C (115F).

D14352
Overflow Tube
AT-3-3
- AUTOMATIC TRANSMISSIONAUTOMATIC TRANSMISSION SYSTEM
1857 Author
: Date
:
2004 LAND CRUISER (RM1071U)
(b) Without hand-held tester (Using A/T OIL TEMP indicator)
(1) Connect terminals between CG (4) and TC (13) of
the DLC3 using SST (09843-18040).
(2) Move the shift lever back and forth between N and
D at 1.5 seconds interval for six seconds.
(3) The D shift indicator on the combination meter
comes on for two seconds. This indicates that the
fluid temperature check mode has been started.
(4) The D shift indicator comes on again when the fluid
temperature reaches 46C (115F) and blinks
when it exceeds 56C (130F).
(5) Allow the engine to idle until the fluid temperature
reaches 46C (115F).
6. FLUID LEVEL CHECK
NOTICE:
The fluid temperature must be between 46C (115F) and
56C (130F) to check the fluid level.
(a) Remove the overflow plug with the engine idling.
(b) Check that the fluid comes out of the overflow tube.

If fluid does not come out, proceed to step 7.

If fluid comes out, wait until the overflow slows to a
trickle and proceed to step 8.
7. TRANSMISSION REFILL
(a) Install the overflow plug.
(b) Stop the engine.
(c) Remove the refill plug.
(d) Add 0.4 liters (0.42 US qts, 0.35 lmp. qts) of fluid.
(e) Allow the engine to idle and wait for 10 seconds.
(f) Proceed to step 6.
8. COMPLETE
(a) Install the overflow plug with a new gasket.
(b) Stop the engine.
(c) Install the refill plug with a new gasket.
Torque:
20 NVm (205 kgfVcm, 15 ftVlbf) for overflow plug
39 NVm (400 kgfVcm, 29 ftVlbf) for refill plug

AT080-04
D13664
Air Cleaner Cap
Radiator Reservoir
Fan and Fluid
Coupling Assembly
Fan Shroud
x6x4
80 (820, 59)
80 (820, 59)
80 (820, 59)
80 (820, 59)
Front Propeller Shaft
48 (490, 35)
Hole Plug
18 (185, 13)
Torque Converter
Clutch
50 (510, 37)
74 (750, 54)
50 (510, 37)
N´m (kgf´cm, ft´lbf) : Specified torque

Non-reusable partTransfer Case Protector
Engine Mouting
Insulator RRx4 x6
37 (377, 27)
71 (724, 52)

LH Front Exhaust Pipe





Transmission
with Transfer
106 (1,080, 78)
106 (1,080, 78)
106 (1,080, 78)
Ground
Cable
Transmission
Shift Control Rod
Pin
Rear Propeller Shaft






RH Front Exhaust Pipe
Transfer Shift
Lever Boot
Upper Console Panel Transfer Shift Lever Knob
5.4 (55, 48 in.´lbf)
Clip
Transfer Shift
Lever
Engine No. 1
Under Cover
Crossmember
12 (122, 9)
59 (600, 43)
29 (296, 21)
Engine No. 2
Under Cover

20 (204, 15)
34 (347, 25)
Oil Cooler Pipe
29 (296, 21)29 (296, 21)
- AUTOMATIC TRANSMISSIONAUTOMATIC TRANSMISSION UNIT
AT-29
1883 Author
: Date
:
2004 LAND CRUISER (RM1071U)
AUTOMATIC TRANSMISSION UNIT
COMPONENTS

AT12V-01
D12652
(a)
(b)
(b)
(c)
Lock
D12653
D12654
D12655
AT-30
- AUTOMATIC TRANSMISSIONAUTOMATIC TRANSMISSION UNIT
1884 Author
: Date
:
2004 LAND CRUISER (RM1071U)
REMOVAL
1. REMOVE BATTERY
2. REMOVE AIR CLEANER CAP DRIVE BELT, FAN AND
FLUID COUPLING ASSEMBLY, FAN SHROUD AND
RADIATOR RESERVOIR
(See page CO-17)
3. DISCONNECT CONNECTORS
(a) Release the lock and disconnect the transmission wire
connector.
(b) Disconnect the 2 transmission wire connectors.
(c) Separate the connector clamp.
4. REMOVE TRANSFER SHIFT LEVER BOOT
(a) Remove the transfer shift lever knob.
(b) Remove upper console panel (See page BO-84).
(c) Remove the 4 bolts and the transfer shift lever boot.
Torque: 5.4 N´m (55 kgf´cm, 48 in.´lbf)
5. REMOVE ENGINE NO. 1 AND NO. 2 UNDER COVERS
6. REMOVE LH AND RH FRONT EXHAUST PIPES
(See page EM-1 15)
7. REMOVE FRONT AND REAR PROPELLER SHAFTS
(See page PR-4)
8. SEPARATE TRANSMISSION SHIFT CONTROL ROD
Remove the clip and pin and separate the shift control rod.
9. SEPARATE TRANSFER SHIFT LEVER
Remove the nut and separate the transfer shift lever rod assem-
bly.
Torque: 12 N´m (122 kgf´cm, 9 ft´lbf)

AT111-02
D13663
AT0103
D12703
D12704
Bolt
- AUTOMATIC TRANSMISSIONVALVE BODY ASSEMBLY
AT-8
1862 Author
: Date
:
VALVE BODY ASSEMBLY
ON-VEHICLE REPAIR
1. REMOVE ENGINE NO.2 UNDER COVER
2. DRAIN ATF
3. REMOVE OIL PAN
NOTICE:
Some fluid will remain in the oil pan.
(a) Remove the 20 bolts.
(b) Remove the oil pan gasket.
4. EXAMINE PARTICLES IN PAN
Remove the magnets and use them to collect steel particles.
Carefully look at the foreign matter and particles in the pan and
on the magnets to anticipate the type of wear you will find in the
transmission.
Steel (magnetic)...bearing, gear and clutch plate wear
Brass (non-magnetic)...bushing wear
5. REMOVE OIL STRAINER
Remove the 4 bolts, the oil strainer and the O-ring.
NOTICE:
Be careful as some fluid will come out with the oil strainer.
6. DISCONNECT TEMPERATURE SENSOR
(a) Disconnect the 7 solenoid connectors.
(b) Remove 2 bolts and the 2 temperature sensors clamp
from the valve body.
(c) Disconnect the 2 temperature sensor from the valve body.
7. DISCONNECT 7 CONNECTORS FROM SHIFT SOLE-
NOID VALVES

- AUTOMATIC TRANSMISSIONVALVE BODY ASSEMBLY
AT-1 1
1865 Author
: Date
:
16. FILL ATF AND CHECK ATF LEVEL
(a) Install a new gasket and a drain plug.
Torque: 20 N´m (204 kgf´cm, 15 ft´lbf)
(b) Remove the refill plug.
(c) Fill new fluid through the refill hole (See page AT-3-1).
17. INSTALL ENGINE NO.2 UNDER COVER

DI-410
- DIAGNOSTICSAUTOMATIC TRANSMISSION
603 Author
: Date
:
2004 LAND CRUISER (RM1071U)
DTC P0710 Transmission Fluid Temperature Sensor ºAº
Circuit
DTC P0712 Transmission Fluid Temperature Sensor ºAº
Circuit Low Input
DTC P0713 Transmission Fluid Temperature Sensor ºAº
Circuit High Input
CIRCUIT DESCRIPTION
The ATF temperature sensor converts fluid temperature into a resistance value which is input into the ECM.
DTC No.DTC Detecting ConditionTrouble Area
P0710
(a) and (b) is detected momentary within 0.5 sec. when neither
P0712 or P0713 is not detected (1-trip detection logic)
(a) ATF temperature sensor resistance is less than 79 W.
(b) ATF temperature sensor resistance is more than 156 kW.
HINT:
Within 0.5 sec. the malfunction switches from (a) to (b) or from
(b) to (a)

Open or short in ATF temperature sensor No. 1 circuit

ATF temperature sensor No. 1
P0712ATF temperature sensor resistance is less than 79 W. for 0.5
sec. or more (1-trip detection logic)
ECM
P0713
ATF temperature sensor resistance is more than 156 kW. 15
minutes or more after the engine start DTC is detected for 0.5
sec. or more (1-trip detection logic)
MONITOR DESCRIPTION
The automatic transmission fluid (ATF) temperature sensor converts ATF temperature to an electrical resis-
tance value. Based on the resistance, the ECM determines the ATF temperature, and the ECM detects an
opens or shorts in the ATF temperature circuit. If the resistance value of the ATF temperature is less than
79 W
*1 or more than 156 kW*2, the ECM interprets this as a fault in the ATF sensor or wiring. The ECM will
turn on the MIL and store the DTC.
*1: 150C (302F) or more is indicated regardless of the actual ATF temperature.
*2: -40C (-40F) is indicated regardless of the actual ATF temperature.
HINT:
The ATF temperature can be checked on the OBD II scan tool or hand-held tester display.
DIC2Z-01

1
152 3 4 5 6 7 8
9 10 11 12
13 14
D11994OT+OT-
- DIAGNOSTICSAUTOMATIC TRANSMISSION
DI-413
606 Author
: Date
:
2004 LAND CRUISER (RM1071U)
INSPECTION PROCEDURE
HINT:
According to the DATA LIST displayed by the OBD ll scan tool or Hand-held tester, you can read the value
of the switch, sensor, actuator and so on without parts removal. Reading the DATA LIST as a first step of
troubleshooting is one method to shorten labor time.
(a) Warm up the engine.
(b) Turn the ignition switch OFF.
(c) Connect the OBD ll scan tool or Hand-held tester to the DLC3.
(d) Turn the ignition switch ON.
(e) Push the ºONº button of OBD ll scan tool or Hand-held tester.
(f) Select the item º/DIAGNOSIS/ENHANCED OBD ll/DATA LIST/ALL (or ATM)º.
(g) According to the display on tester, read the ºDATA LISTº.
ItemMeasurement Item/
Display (Range)Normal ConditionDiagnostic Note
AT FLUID TEMP
ATF Temp. Sensor No.1 Value/
min.: -40°C (-40°F)
max.: 215°C (419°F)80°C (176°F)
(After Stall Test)
If the value is º-40°C (-40°F)º or
º215°C (419°F)º, ATF temp. sen-
sor No. 1 circuit is opened or
shorted.
HINT:
When DTC P0712 is output and OBD ll scan tool or hand-held tester output is 150°C (302°F), there is a
short circuit.
Measure the resistance between THO1 (THO) and body ground.
Temperature DisplayedMalfunction
-40°C (-40°F)Open circuit
150°C (302°F) or moreShort circuit
1 Check transmission wire.
PREPARATION:
Disconnect the transmission wire connector from the transmis-
sion.
CHECK:
Measure the resistance between terminals OT+ and OT-.
OK:
79 W to 156 kW
CHECK:
Measure resistance between terminals OT+ and OT- of the
transmission wire connector and body ground.
OK:
Resistance: 1 MW or higher
NG Replace the transmission wire (ATF tempera-
ture sensor).
OK
