Page 64 of 3115
AC1K7-06
I06697
I06698
I06699
AC-26
- AIR CONDITIONINGFRONT COOLING UNIT
2751 Author: Date:
2004 LAND CRUISER (RM1071U)
DISASSEMBLY
1. REMOVE EVAPORATOR
(a) Disconnect the connector clamp.
(b) Remove the 8 screws and No. 1 cooler cover.
(c) Pull out the evaporator
HINT:
At the time of reassembly, if evaporator is replaced, add com-
pressor oil to the evaporator.
Add: 40 cc (1.4 fl.oz.)
Compressor oil: ND-OIL 8 or equivalent
2. PULL OUT EVAPORATOR TEMPERATURE SENSOR
FROM EVAPORATOR
3. REMOVE EXPANSION VALVE
(a) Remove the grommet.
(b) Pry out the packing.
HINT:
At the time of reassembly, do not reuse the packing.
(c) Using a hexagon wrench (5.0 mm, 0.20 in.), remove the
2 bolts and separate the expansion valve, tube and evap-
orator.
Torque: 3.4 N´m (35 kgf´cm, 30 in.´lbf)
NOTICE:
Cap the open fittings immediately to keep moisture or dirt
out of the system.
HINT:
At the time of reassembly, lubricate 4 new O-rings with com-
pressor oil and install them in the tube.
4. REMOVE DRAIN HOSE
Page 109 of 3115
AC1KO-04
I03973
I05080
Second Ridge
Hose Clip
Water Hose
I03924
- AIR CONDITIONINGREAR HEATER UNIT
AC-47
2772 Author: Date:
2004 LAND CRUISER (RM1071U)
REMOVAL
1. DRAIN ENGINE COOLANT FROM RADIATOR
HINT:
It is not necessary to drain out all the coolant.
2. DISCONNECT WATER HOSES FROM HEATER RA-
DIATOR PIPES
(a) Using pliers, grip the claws of the clip and slide the clip
along the hose
(b) Disconnect the water hoses
HINT:
At the time of installation, push the water hose on to the heater
radiator pipe to the second ridge on the pipe.
3. REMOVE FRONT SEATS
4. REMOVE REAR CONSOLE BOX
5. REMOVE FRONT CONSOLE BOX COVER
6. REMOVE LOWER CENTER CLUSTER FINISH PANEL
7. REMOVE FRONT DOOR SCUFF PLATE
8. REMOVE COWL SIDE TRIMS
9. REMOVE REAR DOOR SCUFF PLATES
10. REMOVE CENTER PILLAR GARNISHES
11. SLIDE FLOOR CARPET BACKWARD
12. REMOVE COOLER BRACKET
Remove the 4 bolts and the cooler bracket.
Page 118 of 3115
AT10Z-02
D12704
A B
OrangeBlue
D12739
D12704
A B
OrangeBlue AT-6
- AUTOMATIC TRANSMISSIONATF TEMPERATURE SENSOR
1860 Author: Date:
ATF TEMPERATURE SENSOR
ON-VEHICLE REPAIR
1. REMOVE ENGINE NO.2 UNDER COVER
2. DRAIN ATF
3. REMOVE OIL PAN (See page AT-1 1)
4. REMOVE OIL STRAINER (See page AT-1 1)
5. REMOVE ATF TEMPERATURE SENSOR
(a) Disconnect the 7 solenoid valve connectors.
(b) Remove the 2 bolts and disconnect the 2 ATF tempera-
ture sensors.
(c) Disconnect the solenoid connector.
(d) Remove the bolt and the transmission wire harness.
6. INSTALL ATF TEMPERATURE SENSOR
(a) Install the transmission wire harness.
(b) Install the bolt.
Torque: 5.4 N´m (55 kgf´cm, 48 in.´lbf)
(c) Connect the solenoid connector.
(d) Connect the 7 solenoid valve connectors.
(e) Connect the 2 ATF temperature sensors with the 2 bolts.
Torque:
A: 11 N´m (112 kgf´cm, 8 ft´lbf)
B: 10 N´m (100 kgf´cm, 7 ft´lbf)
Bolt length:
Bolt A: 36 mm (1.42 in.)
Bolt B: 12 mm (0.47 in.)
Sensor wire harness:
Wire harnessColor
for linear controlOrange
for oil temp warning lampBlue
7. INSTALL OIL STRAINER (See page AT-8)
8. INSTALL OIL PAN (See page AT-8)
9. FILL ATF AND CHECK ATF LEVEL (See page AT-3-1)
10. INSTALL ENGINE NO.2 UNDER COVER
Page 146 of 3115
AT111-02
D13663
AT0103
D12703
D12704
Bolt
- AUTOMATIC TRANSMISSIONVALVE BODY ASSEMBLY
AT-8
1862 Author: Date:
VALVE BODY ASSEMBLY
ON-VEHICLE REPAIR
1. REMOVE ENGINE NO.2 UNDER COVER
2. DRAIN ATF
3. REMOVE OIL PAN
NOTICE:
Some fluid will remain in the oil pan.
(a) Remove the 20 bolts.
(b) Remove the oil pan gasket.
4. EXAMINE PARTICLES IN PAN
Remove the magnets and use them to collect steel particles.
Carefully look at the foreign matter and particles in the pan and
on the magnets to anticipate the type of wear you will find in the
transmission.
Steel (magnetic)...bearing, gear and clutch plate wear
Brass (non-magnetic)...bushing wear
5. REMOVE OIL STRAINER
Remove the 4 bolts, the oil strainer and the O-ring.
NOTICE:
Be careful as some fluid will come out with the oil strainer.
6. DISCONNECT TEMPERATURE SENSOR
(a) Disconnect the 7 solenoid connectors.
(b) Remove 2 bolts and the 2 temperature sensors clamp
from the valve body.
(c) Disconnect the 2 temperature sensor from the valve body.
7. DISCONNECT 7 CONNECTORS FROM SHIFT SOLE-
NOID VALVES
Page 501 of 3115
H05291Point Make
H05292
- BODYSLIDING ROOF
BO-75
2649 Author: Date:
2004 LAND CRUISER (RM1071U)
(d) Turn the drive gear to align the point marks as shown in
the illustration.
(e) Install the cam plate cover.
NOTICE:
At the time of installation, please refer to the following item.
If the sliding roof position and drive gear fully closed posi-
tion are not matched, the sliding roof does not operate nor-
mally.
6. REMOVE SLIDING ROOF HOUSING
(a) Remove the 4 drain hoses from the housing.
(b) Disengage the room light wire harness clamps.
(c) Remove the 8 bolts, 2 nuts and sliding roof housing.
Page 535 of 3115
BR0TA-04
F04974
F04975
- BRAKEFRONT BRAKE CALIPER
BR-19
2155 Author: Date:
2004 LAND CRUISER (RM1071U)
REMOVAL
1. REMOVE FRONT WHEEL
Torque: 103 N´m (1,050 kgf´cm, 76 ft´lbf)
2. DISCONNECT BRAKE LINE
(a) Remove the union bolt and 2 gaskets from the caliper,
then disconnect the flexible hose from the caliper.
Torque: 30 N´m (310 kgf´cm, 22 ft´lbf)
(b) Use a container to catch the brake fluid as it drains out.
3. REMOVE CALIPER
Remove the 2 mounting bolts and remove the caliper.
Torque: 123 N´m (1,250 kgf´cm, 90 ft´lbf)
4. REMOVE CLIP AND 2 PINS
5. REMOVE 2 PAD RETAINER CLIPS
6. REMOVE 2 PADS, ANTI-SQUEAL SHIMS AND PAD
RETAINERS
Page 583 of 3115
BR0JS-03
F04992
BR-28
- BRAKEREAR BRAKE CALIPER
2164 Author: Date:
2004 LAND CRUISER (RM1071U)
REMOVAL
1. DISCONNECT FLEXIBLE HOSE
Remove the union bolt and gasket from the caliper, then discon-
nect the flexible hose from the caliper. Use a container to catch
brake fluid as it drains out.
Torque: 30 N´m (310 kgf´cm, 22 ft´lbf)
HINT:
At the time of installation, please refer to the following item.
Install the flexible hose lock securely in the lock hole in the cali-
per.
2. REMOVE CALIPER
(a) Hold the sliding pin and loosen the 2 installation bolts.
Torque: 26 N´m (270 kgf´cm, 20 ft´lbf)
(b) Remove the 2 installation bolts.
(c) Remove the caliper from the torque plate.
3. REMOVE 2 BRAKE PADS WITH ANTI- SQUEAL
SHIMS
4. REMOVE 4 PAD SUPPORT PLATES
Page 589 of 3115
BR0JS-03
F04992
BR-28
- BRAKEREAR BRAKE CALIPER
2164 Author: Date:
2004 LAND CRUISER (RM1071U)
REMOVAL
1. DISCONNECT FLEXIBLE HOSE
Remove the union bolt and gasket from the caliper, then discon-
nect the flexible hose from the caliper. Use a container to catch
brake fluid as it drains out.
Torque: 30 N´m (310 kgf´cm, 22 ft´lbf)
HINT:
At the time of installation, please refer to the following item.
Install the flexible hose lock securely in the lock hole in the cali-
per.
2. REMOVE CALIPER
(a) Hold the sliding pin and loosen the 2 installation bolts.
Torque: 26 N´m (270 kgf´cm, 20 ft´lbf)
(b) Remove the 2 installation bolts.
(c) Remove the caliper from the torque plate.
3. REMOVE 2 BRAKE PADS WITH ANTI- SQUEAL
SHIMS
4. REMOVE 4 PAD SUPPORT PLATES
Page 611 of 3115
CH06I-04
B00809
B16653
- CHARGINGGENERATOR
CH-7
1842 Author: Date:
2004 LAND CRUISER (RM1071U)
REMOVAL
1. DRAIN ENGINE COOLANT
(See page CO-2)
2. REMOVE GENERATOR DRIVE BELT
Loosen the belt tension by turning the belt tensioner counter-
clockwise, and remove the drive belt.
HINT:
The pulley bolt for the belt tensioner has a left - hand thread.
3. REMOVE ENGINE UNDER COVER NO.1
4. REMOVE RADIATOR ASSEMBLY
(See page CO-17)
5. REMOVE PS VANE PUMP PULLEY
(See page SR-40)
6. REMOVE GENERATOR
(a) Disconnect the generator connector.
(b) Remove the rubber cap and nut, and disconnect the gen-
erator wire.
(c) Disconnect the generator wire clamp from the cord clip on
the generator.
(d) Remove the bolt, 2 nuts and generator.
Page 751 of 3115
CO0J1-02
B04474A/T Oil Cooler Hose
B04475
- COOLINGRADIATOR
CO-17
1778 Author: Date:
2004 LAND CRUISER (RM1071U)
REMOVAL
1. REMOVE ENGINE UNDER COVER NO.1
2. DRAIN ENGINE COOLANT
3. DISCONNECT RADIATOR UPPER HOSE FROM RA-
DIATOR
4. DISCONNECT RADIATOR LOWER HOSE FROM RA-
DIATOR
5. DISCONNECT A/T OIL COOLER HOSES FROM RA-
DIATOR
6. REMOVE RADIATOR RESERVOIR
(a) Disconnect the clamp on the wire from the radiator.
(b) Disconnect the resorvoir hose from the radiator.
(c) Remove the 2 bolts, resorvoir and grommet.
7. REMOVE RADIATOR ASSEMBLY
(a) Remove the 2 nuts, and disconnect the 2 clamps on the
A/C discharge tube from the bracket.
(b) Remove the 2 bolts, and disconnect the 2 brackets on the
wire from the radiator.
(c) Disconnect the A/T oil cooler hoses from the clamp on the
fan shroud.
(d) Loosen the fan pulley mounting nuts holding the fluid cou-
pling to the fan bracket.
(e) Remove generator drive belt. (See page CH-7)
(f) Remove the 3 bolts holding the fan shroud to the radiator.
(g) Remove the 4 fan pulley mounting nuts.
(h) Pull out the fan with fluid coupling, fan pulley and fan
shroud.
(i) Remove the 2 nuts.
