headlights TOYOTA LAND CRUISER 1986 Factory Repair Manual

I20844
0.4 °
3 m (9.84 ft) H 20.9 mm
(0.823 in.)
7
V RH Line
90 °
V LH Line4V LH LineV Line V RH Line 65
6
V LH LineV Line
V RH Line 6
5
6
H4
O: step No.
7
H4
20.9 mm
(0.823 in.) 1,146mm (45.1 in.) Low Beam:
High Beam:20.9 mm
(0.823 in.)
20.9 mm
(0.823 in.)
1,146mm (45.1 in.)
1,146mm
(45.1 in.)H RH and
H LH lines High Beam
Low Beam
- BODY ELECTRICALHEADLIGHT AND TAILLIGHT SYSTEM
BE-35
2408 Author
: Date
:
2004 LAND CRUISER (RM1071U)
ADJUST HEADLIGHT AIM ONLY
(a) Place the vehicle in the following conditions.

The area around the headlight is not deformed.

The vehicle is parked on a level surface.

Tire inflation pressure is the specified value.

A driver is in the driver's seat and the vehicle is in a state ready for driving (with a tank full).

The vehicle has been bounced several times.
(b) Check the headlight aiming.
(1) Prepare a thick white paper.
(2) Stand the paper perpendicular to the ground at the position 9.84 ft away from the headlights.
(3) Ensure that the center line of the vehicle and the paper face forms a 90-degree angle as shown
in the illustration.
(4) Draw a horizontal line (H line) on the paper, showing where the headlights should strike.
(5) Draw a vertical line (V line) to where the center line of the vehicle is to be.
(6) Draw 2 vertical lines (by connecting the low and high beam center marks) to where the both head-
lights should strike (V RH and V LH lines).
(7) Draw a horizontal line (by connecting the both low beam center marks) to where the headlights
should strike (H RH and H LH lines).
HINT:
The H RH and H LH line is 0.4° below the horizontal line (H line) of the light axis.
(8) Start the engine.
(9) Turn the headlights ON.
(10) Check that the headlights properly strike the position shown in the illustration.
(11) If not, adjust the lights in the vertical direction.
HINT:
As shown in the illustration, adjust each aim of the RH and LH lights.
(c) When adjusting it in the vertical direction:
Using adjusting bolt A, adjust the headlight aim to within the specified range.

Z03473
Ammeter
Disconnect Wire
from Terminal B
Battery
VoltmeterB
Generator CH-4
- CHARGINGCHARGING SYSTEM
1839 Author
: Date
:
2004 LAND CRUISER (RM1071U)
8. CHECK CHARGE WARNING LIGHT CIRCUIT
(a) Warm up the engine and then turn it off.
(b) Switch off all accessories.
(c) Turn the ignition switch ON, and check that the charge
warning light is lit.
(d) Start the engine, and check that the light goes off.
If the light does not go off as specified, troubleshoot the charge
light circuit.
9. INSPECT CHARGING CIRCUIT WITHOUT LOAD
HINT:
If a battery/generator tester is available, connect the tester to
the charging circuit as per manufacturer's instructions.
(a) If a tester is not available, connect a voltmeter and amme-
ter to the charging circuit as follows:

Disconnect the wire from terminal B of the genera-
tor, and connect it to the negative (-) tester probe
of the ammeter.

Connect the positive (+) tester probe of the amme-
ter to terminal B of the generator.

Connect the positive (+) tester probe of the voltme-
ter to terminal B of the generator.

Ground the negative (-) tester probe of the voltme-
ter.
(b) Check the charging circuit as follows:
With the engine running from idling to 2,000 rpm, check
the reading on the ammeter and voltmeter.
Standard amperage:
10 A or less
Standard voltage:
13.2 - 14.8 V
If the value is not specified, check the generator.
10. INSPECT CHARGING CIRCUIT WITH LOAD
(a) With the engine running at 2,000 rpm, turn on the high
beam headlights and place the heater blower switch at HI.
(b) Check the reading on the ammeter.
Standard amperage:
30 A or more
If the ammeter reading is less than the standard amperage, re-
pair the generator.
HINT:
If the battery is fully charged, the indication will sometimes be
less than standard amperage.
11. REINSTALL ENGINE UNDER COVER NO.1

DI01Q-07
THEFT DETERRENT SYSTEM Check Sheet
Inspector 's name:
Customer 's Name
Date VehicleRegistration No.
Registration Year
Frame No.
Odometer Reading / /km
Mile
Weather Conditions
When Problem
Occurred Frequency Problem OccursWeather
Outdoor Temperature
/ /

Constantly
Sometimes ( Times per day, month)

Once only Brought In

Theft deterrent system cannot be set.

Indicator light does not flash when the theft deterrent system is set.
(It stays ON or does not light at all.)

Theft deterrent system
does not operate.
When unlocked using the
door lock knob.

When the engine hood is
opened.

Once set system
cannot be canceled.

When door is unlocked using key or wireless door lock control system.

When the key is inserted in the ignition key cylinder and turned to ACC or ON
position.
(However, only when the system has never operated)

When the luggage compartment door is opened with the key.

System cannot be
canceled during warning
operation.
When door is unlocked using key or wireless door lock control system.

When the key is inserted in the ignition key cylinder and turned to ACC or ON
position.

Warning operation starts when the system is set and the door or luggage compartment door is opened with
the key.

Others.
Date Problem First Occurred

Fine
Cloudy
Rainy
Snowy

Various/Others

Hot
Warm
Cool

Cold (Approx. 5F ( 5C))
Problem Symptom
Malfunction

Horns only

Theft deterrent horn only

Headlights only

Taillights only

Starter cut only

Door lock operation only
DI-954
- DIAGNOSTICSTHEFT DETERRENT SYSTEM
1147 Author
: Date
:
2004 LAND CRUISER (RM1071U)
CUSTOMER PROBLEM ANALYSIS CHECK

2004 LAND CRUISER (EWD548U)
18E GLOSSARY OF TERMS AND SYMBOLS
BATTERY
Stores chemical energy and
converts it into electrical energy.
Provides DC current for the auto's
various electrical circuits.GROUND
The point at which wiring attaches to
the Body, thereby providing a return
path for an electrical circuit; without a
ground, current cannot flow.
CAPACITOR (Condenser)
A small holding unit for temporary
storage of electrical voltage.HEADLIGHTS
Current flow causes a headlight
filament to heat up and emit light. A
headlight may have either a single
(1) filament or a double (2) filament
1. SINGLE
FILAMENT
CIGARETTE LIGHTER
An electric resistance heating
element.2. DOUBLE
FILAMENT
CIRCUIT BREAKER
Basically a reusable fuse, a circuit
breaker will heat and open if too
much current flows through it.
Some units automatically reset when
cool, others must be manually reset.HORN
An electric device which sounds a
loud audible signal.
DIODE
A semiconductor which allows
current flow in only one direction.IGNITION COIL
Converts low-voltage DC current
into high-voltage ignition current for
firing the spark plugs.
DIODE, ZENERA diode which allows current flow in one
direction but blocks reverse flow only up
to a specific voltage. Above that potential,
it passes the excess voltage. This acts as
a simple voltage regulator.LIGHT
Current flow through a filament
causes the filament to heat up and
emit light.
PHOTODIODE
The photodiode is a semiconductor
which controls the current flow
according to the amount of light.LED (LIGHT EMITTING DIODE)
Upon current flow, these diodes emit
light without producing the heat of a
comparable light.
DISTRIBUTOR, IIA
Channels high-voltage current from
the ignition coil to the individual
spark plugs.METER, ANALOG
Current flow activates a magnetic
coil which causes a needle to move,
thereby providing a relative display
against a background calibration.
FUSEA thin metal strip which burns through
when too much current flows through it,
thereby stopping current flow and
protecting a circuit from damage.
FUSIBLE LINK
METER, DIGITAL
Current flow activates one or many
LED's, LCD's, or fluorescent
displays, which provide a relative or
digital display.
FUEL
FUSIBLE LINK
A heavy-gauge wire placed in high
amperage circuits which burns through on
overloads, thereby protecting the circuit.
The numbers indicate the crosssection
surface area of the wires.(for Medium Current Fuse)
(for High Current Fuse or
Fusible Link)MOTOR
A power unit which converts
electrical energy into mechanical
energy, especially rotary motion.
M

MA02Q-01
MA-2
- MAINTENANCEINSIDE VEHICLE
50 Author
: Date
:
2004 LAND CRUISER (RM1071U)
INSIDE VEHICLE
GENERAL MAINTENANCE
These are the maintenance and inspection items which are considered to be owner's responsibility. They
can be done by the owner or be can have them done at a service shop. These items include those which
should be checked on a daily basis, those which, in most cases, do not require (special) tools and those
which are considered to be reasonable for the owner to do. Items and procedures for general maintenance
are as follows.
1. GENERAL NOTES

Maintenance items may very from country and country. Check the owner's manual supplement in
which the maintenance schedule is shown.

Every service items in the periodic maintenance schedule must be performed.

Periodic maintenance service must be performed according to whichever interval in the periodic main-
tenance schedule occurs first, the odometer reading (miles) or the time interval (months).

Maintenance service after the last period should be performed at the same time interval as before un-
less otherwise noted.

Failure to do even one item an cause the engine to run poorly and increase exhaust emissions.
2. LIGHTS
(a) Check that the headlights, stop lights, taillights, turn signal lights, and other lights are all working.
(b) Check the headlights aim.
3. WARNING LIGHTS AND BUZZERS
Check that all warning lights and buzzers function properly.
4. HORN
Check that it is working.
5. WINDSHIELD GLASS
Check for scratches, pits or abrasions.
6. WINDSHIELD WIPER AND WASHER
(a) Check operation of the wipers and washer.
(b) Check that the wipers do not streak.
7. WINDSHIELD DEFROSTER
Check that air comes out from the defroster outlet when operating the heater or air conditioner at defroster
mode.
8. REAR VIEW MIRROR
Check that it is mounted securely.
9. SUN VISORS
Check that they move freely and mounted securely.
10. STEELING WHEEL
Check that it has the specified freeplay. Be alert for changes in steering condition, such as hard steering,
excessive freeplay or strange noises.
11. SEATS
(a) Check that all front seat controls such as seat adjusters, seatback recliner, etc. operate smoothly.
(b) Check that all latches lock securely in any position.
(c) Check that the head restraints move up and down smoothly and that the locks hold securely in any
latch position.
(d) For folding-down rear seat backs, check that the latches look securely.
12. SEAT BELTS
(a) Check that the seat belt system such as buckles, retractors and anchors operate properly and smooth-
ly.
(b) Check that the belt webbing is not cut, frayed, worn or damaged.
