- BODY ELECTRICALTROUBLESHOOTING
2379 Author
: Date
:
2004 LAND CRUISER (RM1071U) Rear washer motor does not operate.
1. Rear Washer Motor
2. Rear Washer Switch
3. Wire HarnessBE-52
BE-52
-
Washer fluid does not operate.1. Washer Hose and Nozzle-
*1: Inspect wiper arm and blade set positions.
COMBINATION METER (Meter Gauges and Illumination):
SymptomSuspect AreaSee page
Tachometer, fuel gauge and engine coolant temperature gauge do
not operate.1. GAUGE2 Fuse
2. Combination Meter
3. Wire Harness-
BE-58
-
Speedometer does not operate.
1. Speed Sensor
2. Combination Meter
3. Wire HarnessBE-63
BE-58
-
Tachometer does not operate.
1. Igniter
2. Combination Meter
3. Wire HarnessIG-1
BE-58
-
Fuel gauge does not operate or is in abnormal operation.
1. Fuel Receiver Gauge
2. Fuel Sender Gauge
3. Combination Meter
4. Wire HarnessBE-63
BE-63
BE-58
-
Oil pressure gauge does not operate.
1. Oil Pressure Receiver Gauge
2. Oil Pressure Sender Gauge
3. Combination Meter
4. Wire HarnessBE-63
BE-63
BE-58
-
Voltmeter does not operate.
1. Voltmeter
2. Combination Meter
3. Wire HarnessBE-63
BE-58
-
Engine coolant temperature gauge does not operate or is in ab-
normal operation
1. Engine Coolant Temperature Receiver Gauge
2. Engine Coolant Temperature Sender Gauge
3. Combination Meter
4. Wire HarnessBE-63
BE-63
BE-58
-
All illumination lights do not light up.1. Light Control Rheostat
2. Wire HarnessBE-63
-
Brightness does not change even when rheostat is turned.1. Bulb
2. Wire Harness-
-
Only one illumination light does not light up.1. Bulb
2. Wire Harness-
-
COMBINATION METER (Warning Light):
SymptomSuspect AreaSee page
Warning lights do not light up. (Except discharge, open door and
SRS)1. GAUGE1 Fuse
2. Combination Meter
3. Wire Harness-
BE-58
-
Fuel level warning light does not light up.
1. LED
2. Combination Meter
3. Fuel Sender Gauge
4. Wire Harness-
BE-58
BE-63
-
ABS warning light does not light up.
1. LED
2. ABS ECU
3. Wire Harness-
DI-502
-

BO1JU-03
BE3367
2 - 2.5 mm
(0.024 - 0.026 in.)0.6 - 0.65 mm(0.079 - 0.098 in.)
- BODYFRONT WIPER AND WASHER
BO-35
2609 Author
: Date
:
2004 LAND CRUISER (RM1071U)
ADJUSTMENT
ADJUST WASHER NOZZLE
Using a tool like the one shown in the illustration, change the
direction of the nozzle hole to adjust the point where washer
fluid hits the windshield.

BO1JT-03
H04842
AA
M
BH
D
I
J E
S F
O NL G
P
Q
X
TK R FE U
C
S W
V
BO-34
- BODYFRONT WIPER AND WASHER
2608 Author
: Date
:
2004 LAND CRUISER (RM1071U)
INSPECTION
INSPECT WASHER NOZZLE
While operating the washer, check if the point where the washer
fluid hits the windshield is within the range indicated by the
hatched line.
A: Approx. 311 mm (12.24 in.)
B: Approx. 110 mm (4.33 in.)
C: Approx. 86 mm (3.39 in.)
D: Approx. 116 mm (4.57 in.)
E: Approx. 205 mm (8.07 in.)
F: Approx. 22 mm (0.87 in.)
G: Approx. 138 mm (5.43 in.)
H: Approx. 60 mm (2.36 in.)
I: Approx. 85 mm (3.35 in.)
J: Approx. 364 mm (14.33 in.)
K: Approx. 496 mm (19.53 in.)
L: Approx. 81 mm (3.19 in.)
M: Approx. 35 mm (1.38 in.)
N: Approx. 157 mm (6.18 in.)
O: Approx. 159 mm (6.26 in.)
P: Approx. 63 mm (2.48 in.)
Q: Approx. 169 mm (6.65 in.)
R: Approx. 331 mm (13.03 in.)
S: Approx. 465 mm (18.31 in.)
T: Approx. 468 mm (18.43 in.)
U: Approx. 45 mm (1.77 in.)
V: Approx. 104 mm (4.09 in.)
W: Approx. 119 mm (4.69 in.)
X: Approx. 44 mm (1.73 in.)

BO1JU-03
BE3367
2 - 2.5 mm
(0.024 - 0.026 in.)0.6 - 0.65 mm(0.079 - 0.098 in.)
- BODYFRONT WIPER AND WASHER
BO-35
2609 Author
: Date
:
2004 LAND CRUISER (RM1071U)
ADJUSTMENT
ADJUST WASHER NOZZLE
Using a tool like the one shown in the illustration, change the
direction of the nozzle hole to adjust the point where washer
fluid hits the windshield.

BO1JT-03
H04842
AA
M
BH
D
I
J E
S F
O NL G
P
Q
X
TK R FE U
C
S W
V
BO-34
- BODYFRONT WIPER AND WASHER
2608 Author
: Date
:
2004 LAND CRUISER (RM1071U)
INSPECTION
INSPECT WASHER NOZZLE
While operating the washer, check if the point where the washer
fluid hits the windshield is within the range indicated by the
hatched line.
A: Approx. 311 mm (12.24 in.)
B: Approx. 110 mm (4.33 in.)
C: Approx. 86 mm (3.39 in.)
D: Approx. 116 mm (4.57 in.)
E: Approx. 205 mm (8.07 in.)
F: Approx. 22 mm (0.87 in.)
G: Approx. 138 mm (5.43 in.)
H: Approx. 60 mm (2.36 in.)
I: Approx. 85 mm (3.35 in.)
J: Approx. 364 mm (14.33 in.)
K: Approx. 496 mm (19.53 in.)
L: Approx. 81 mm (3.19 in.)
M: Approx. 35 mm (1.38 in.)
N: Approx. 157 mm (6.18 in.)
O: Approx. 159 mm (6.26 in.)
P: Approx. 63 mm (2.48 in.)
Q: Approx. 169 mm (6.65 in.)
R: Approx. 331 mm (13.03 in.)
S: Approx. 465 mm (18.31 in.)
T: Approx. 468 mm (18.43 in.)
U: Approx. 45 mm (1.77 in.)
V: Approx. 104 mm (4.09 in.)
W: Approx. 119 mm (4.69 in.)
X: Approx. 44 mm (1.73 in.)

BO1JZ-03
BE3367
2 - 2.5 mm
(0.028 - 0.030 in.)0.7 - 0.75 mm(0.079 - 0.098 in.)
- BODYREAR WIPER AND WASHER
BO-41
2615 Author
: Date
:
2004 LAND CRUISER (RM1071U)
ADJUSTMENT
ADJUST WASHER NOZZLE
Using a tool like the one shown in the illustration, change the
direction of the nozzle hole to adjust the point where washer
fluid hits the back door glass.

BO1JY-03
H18919
BA C
E
F D
G
BO-40
- BODYREAR WIPER AND WASHER
2614 Author
: Date
:
2004 LAND CRUISER (RM1071U)
INSPECTION
INSPECT WASHER NOZZLE
While operating the washer, check if the point where the washer
fluid hits the back door glass is within the range indicated in the
illustration.
A: Approx. 40 mm (1.57 in.)
B: Approx. 180 mm (7.09 in.)
C: Approx. 40 mm (1.57 in.)
D: Approx. 30 mm (1.18 in.)
E: Approx. 120 mm (4.72 in.)
F: Approx. 90 mm (3.54 in.)
G: Approx. 15 mm (0.59 in.)

F13209
Reservoir Set Screw
Accumulator Bracket
No. 1 Pump
Bracket Actuator No. 1 TubeAccumulator

O-ring
Silencer Tube Grommet
PistonCylinder Boot
Clevis Reservoir Cap
No. 2 Pump
Bracket SleeveCollar
Booster Pump MotorCushion
Actuator Hose
Non-reusable part N´m (kgf´cm, ft´lbf) : Specified torque


25 (260, 19)
Cushion Fluid Level Warning Switch
Connector Clamp
Hydraulic Brake
Booster
Spring
15 (155, 11)

Wire Harness
Reservoir
1.7 (17.5, 15.2 in.´lbf)
54 (550, 36)
Washer
Master Cylinder
Pressure Sensor
81 (830, 60)
w/ ABS & BA
& TRAC & VSC:


- BRAKEHYDRAULIC BRAKE BOOSTER
BR-59
2195 Author
: Date
:
2004 LAND CRUISER (RM1071U)

F04472
SST
SST
BR12D-05
F04473
SST
F13233
30 mm
Deeper
Socket BR-62
- BRAKEHYDRAULIC BRAKE BOOSTER
2198 Author
: Date
:
2004 LAND CRUISER (RM1071U)
DISASSEMBLY
1. PLACE HYDRAULIC BRAKE BOOSTER IN VISE
Using SST, set the hydraulic brake booster in vise.
SST 09630-00014 (09631-00142),
09950-60010 (09951-00180, 09951-00190)
2. REMOVE FLUID LEVEL WARNING SWITCH CONNEC-
TOR CLAMP
(a) Disconnect the connector.
(b) Remove the bolt and clamp.
3. REMOVE RESERVOIR AND GROMMETS
(a) Remove reservoir cap.
(b) Remove the 3 set screws and pull out the reservoir.
Torque: 1.7 N´m (17.5 kgf´cm, 15.2 in.´lbf)
(c) Remove the 3 grommets.
4. REMOVE CLEVIS AND CYLINDER BOOT
(a) Loosen the lock nut, then remove the clevis and lock nut.
Torque: 25 N´m (260 kgf´cm, 19 ft´lbf)
(b) Remove the cylinder boot.
5. REMOVE BRAKE ACTUATOR TUBE NO. 1
Using SST, remove the brake actuator tube No. 1.
SST 09023-00100
Torque: 15 N´m (155 kgf´cm, 11 ft´lbf)
6. REMOVE BOOSTER PUMP AND ASSEMBLY
(a) Remove the actuator hose.
(b) Remove the 4 screws and wire harness from the booster
and pump.
(c) Remove the 2 bolts, accumulator bracket.
(d) Remove the 2 bolts and booster pump motor assembly.
(e) Remove the bolt and No. 1 pump bracket.
(f) Remove the 2 washers, 2 cushions, 2 collars and sleeve.
(g) Remove the 2 bolts and No. 2 pump bracket.
(h) Remove the cushion from No. 2 pump bracket.
7. ABS & BA & TRAC & VSC only:
REMOVE MASTER CYLINDER PRESSURE SENSOR
Using 30 mm deeper socket wrench and remove the oil pres-
sure sensor.
Torque: 81 N´m (830 kgf´cm, 60 ft´lbf)
NOTICE:
If replacing the master cylinder pressuer sensor, since the
sensor is non-reusable, use a sensor of the supply part No
shown below.
PART NO: 89637-30050

MA02R-05
MA-4
- MAINTENANCEUNDER HOOD
52 Author
: Date
:
2004 LAND CRUISER (RM1071U)
UNDER HOOD
GENERAL MAINTENANCE
1. GENERAL NOTICE

Maintenance items may vary from country to country. Check the owner's manual supplement in which
the maintenance schedule is shown.

Every service item in the periodic maintenance schedule must be performed.

Periodic maintenance service must be performed according to whichever interval in the periodic main-
tenance schedule occurs first, the odometer reading (miles) or the time interval (months).

Maintenance services after the last period should be performed at the same interval as before unless
otherwise noted.

Failure to do even one item can cause the engine to run poorly and increase exhaust emissions.
2. WINDSHIELD WASHER FLUID
Check that there is sufficient fluid in the tank.
3. ENGINE COOLANT LEVEL
Check that the coolant level is between the LEVEL lines on the see-through reservoir at normal tem-
perature (20°C (68°F)).
4. RADIATOR AND HOSES
(a) Check that the front of the radiator is clean and not blocked with leaves, dirt or bugs.
(See page CO-14)
(b) Check the hoses for cracks, kinks, rot or loose connections.
5. BATTERY ELECTROLYTE LEVEL

Check the indicator.

When the indicator color is blue, the condition is satisfactory. A red color indicates that distilled water
must be added, and white indicates that charging is necessary.
6. BRAKE FLUID LEVELS
Check that the brake fluid level is near the upper level line on the see-through reservoir.
(See page BR-4)
7. ENGINE DRIVE BELTS
Check drive belt for fraying, cracks, wear or oiliness.
8. ENGINE OIL LEVEL
Check the level on the dipstick with the engine turned off.
9. POWER STEERING FLUID LEVEL

Check the level on the dipstick.

The level should be in the ºHOTº or ºCOLDº range depending on the fluid temperature.
10. AUTOMATIC TRANSMISSION FLUID LEVEL
Visually check the overflow plug and oil pan for fluid leaks or traces of fluid.
