TOYOTA LAND CRUISER 1998 Factory Repair Manual

H01021AB0119H01082
H10600H10610
"u
ONAirbag
Sensor
Assembly
DTC B0130/63
DLC3
TC CG
P/T Squib RH
DI-780
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
973 Author
: Date
:
2004 LAND CRUISER (RM1071U)
4 Check P/T squib RH.
PREPARATION:
(a) Turn the ignition switch to LOCK.
(b) Disconnect the negative (-) terminal cable from the bat-
tery, and wait at least for 90 seconds.
(c) Connect the seat belt pretensioner RH (P/T squib RH)
connector.
(d) Connect the negative (-) terminal cable to the battery,
and wait at least for 2 seconds.
CHECK:
(a) Turn the ignition switch to ON, and wait at least for 10 se-
conds.
(b) Clear the DTC stored in memory (See page DI-692).
(c) Turn the ignition switch to LOCK, and wait at least for 10
seconds.
(d) Turn the ignition switch to ON, and wait at least for 10 se-
conds.
(e) Check the DTC (See page DI-692).
OK:
DTC B0130/63 is not output.
HINT:
Codes other than code B0130/63 may be output at this time, but
they are not relevant to this check.
NG Replace seat belt pretensioner RH
(P/T squib RH).
OK
From the results of the above inspection, the malfunctioning part can now be considered normal.
To make sure of this, use the simulation method to check.

H01019H02141H02205
Airbag
Sensor
Assembly
PR-
(+)
(-) PR+ P/T Squib RHFloor No. 2 Wire
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI-781
974 Author
: Date
:
2004 LAND CRUISER (RM1071U)
DTC B0131/64 Open in P/T Squib RH Circuit
CIRCUIT DESCRIPTION
The P/T squib RH circuit consists of the airbag sensor assembly and the seat belt pretensioner RH.
It causes the SRS to deploy when the SRS deployment conditions are satisfied.
For details of the function of each component, see OPERATION on page RS-3.
DTC B0131/64 is recorded when an open is detected in the P/T squib RH circuit.
DTC No.DTC Detecting ConditionTrouble Area
B0131/64

Open in P/T squib RH circuit

P/T squib RH malfunction

Airbag sensor assembly malfunction
Seat belt pretensioner RH (P/T squib RH)

Airbag sensor assembly

Floor No. 2 wire
WIRING DIAGRAM
See page DI-777.
INSPECTION PROCEDURE
1 Prepare for inspection (See step 1 on page DI-923).
2 Check floor No. 2 wire (P/T squib RH circuit).
CHECK:
Measure the resistance between PR+ and PR- of the floor No.
2 wire connector on the seat belt pretensioner RH (P/T squib
RH) side.
OK:
Resistance: Below 1 W
NG Repair or replace floor No. 2 wire.
OK
DI6PK-16

H01020H02139AB0119H01083 H10600H10621
Airbag
Sensor
Assembly
PR+
PR-
DTC B0131/64
" u
ON
DLC3
TC CG
P/T Squib RHFloor No. 2 Wire
DI-782
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
975 Author
: Date
:
2004 LAND CRUISER (RM1071U)
3 Check airbag sensor assembly.
PREPARATION:
(a) Connect the connector to the airbag sensor assembly.
(b) Using a service wire, connect PR+ and PR- of the floor
No. 2 wire connector on the seat belt pretensioner RH
(P/T squib RH) side.
(c) Connect the negative (-) terminal cable to the battery,
and wait at least for 2 seconds.
CHECK:
(a) Turn the ignition switch to ON, and wait at least for 10 se-
conds.
(b) Clear the DTC stored in memory (See page DI-692).
(c) Turn the ignition switch to LOCK, and wait at least for 10
seconds.
(d) Turn the ignition switch to ON, and wait at least for 10 se-
conds.
(e) Check the DTC (See page DI-692).
OK:
DTC B0131/64 is not output.
HINT:
Codes other than code B0131/64 may be output at this time, but
they are not relevant to this check.
NG Replace airbag sensor assembly.
OK

AB0119H01021
H01083 H10600H10622
"u
ONAirbag
Sensor
Assembly
DTC B0131/64
DLC3
TC CG
P/T Squib RH
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI-783
976 Author
: Date
:
2004 LAND CRUISER (RM1071U)
4 Check P/T squib RH.
PREPARATION:
(a) Turn the ignition switch to LOCK.
(b) Disconnect the negative (-) terminal cable from the bat-
tery, and wait at least for 90 seconds.
(c) Connect the seat belt pretensioner RH (P/T squib RH)
connector.
(d) Connect the negative (-) terminal cable to the battery,
and wait at least for 2 seconds.
CHECK:
(a) Turn the ignition switch to ON, and wait at least for 10 se-
conds.
(b) Clear the DTC stored in memory (See page DI-692).
(c) Turn the ignition switch to LOCK, and wait at least for 10
seconds.
(d) Turn the ignition switch to ON, and wait at least for 10 se-
conds.
(e) Check the DTC (See page DI-692).
OK:
DTC B0131/64 is not output.
HINT:
Codes other than code B0131/64 may be output at this time, but
they are not relevant to this check.
NG Replace seat belt pretensioner RH
(P/T squib RH).
OK
From the results of the above inspection, the malfunctioning part can now be considered normal.
To make sure of this, use the simulation method to check.

H01019H08392H08393
Airbag
Sensor
Assembly
(+)
(-)PR+ P/T Squib RHFloor No. 2 Wire
DI-784
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
977 Author
: Date
:
2004 LAND CRUISER (RM1071U)
DTC B0132/61 Short in P/T Squib RH Circuit
(to Ground)
CIRCUIT DESCRIPTION
The P/T squib RH circuit consists of the airbag sensor assembly and the seat belt pretensioner RH.
It causes the SRS to deploy when the SRS deployment conditions are satisfied.
For details of the function of each component, see OPERATION on page RS-3.
DTC B0132/61 is recorded when a ground short is detected in the P/T squib RH circuit.
DTC No.DTC Detecting ConditionTrouble Area
B0132/61

Short in P/T squib RH circuit (to ground)

P/T squib RH malfunction

Airbag sensor assembly malfunction
Seat belt pretensioner RH (P/T squib RH)

Airbag sensor assembly

Floor No. 2 wire
WIRING DIAGRAM
See page DI-692.
INSPECTION PROCEDURE
1 Prepare for inspection (See step 1 on page DI-692).
2 Check floor No. 2 wire (P/T squib RH circuit).
CHECK:
Measure the resistance between the body ground and PR+ of
the floor No. 2 wire connector on the seat belt pretensioner RH
(P/T squib RH) side.
OK:
Resistance: 1 MW or Higher
NG Repair or replace floor No. 2 wire.
OK
DI6PL-16

H01020H02139
AB0118AB0119H01079 H10600H10623
Airbag
Sensor
Assembly
PR+
PR-
DTC B0132/61ON " u
DLC3
TC CG
P/T Squib RHFloor No. 2 Wire
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI-785
978 Author
: Date
:
2004 LAND CRUISER (RM1071U)
3 Check airbag sensor assembly.
PREPARATION:
(a) Connect the connector to the airbag sensor assembly.
(b) Using a service wire, connect PR+ and PR- of the floor
No. 2 wire connector on the seat belt pretensioner RH
(P/T squib RH) side.
(c) Connect the negative (-) terminal cable to the battery,
and wait at least for 2 seconds.
CHECK:
(a) Turn the ignition switch to ON, and wait at least for 10 se-
conds.
(b) Clear the DTC stored in memory (See page DI-692).
(c) Turn the ignition switch to LOCK, and wait at least for 10
seconds.
(d) Turn the ignition switch to ON, and wait at least for 10 se-
conds.
(e) Check the DTC (See page DI-692).
OK:
DTC B0132/61 is not output.
HINT:
Codes other than code B0132/61 may be output at this time, but
they are not relevant to this check.
NG Replace airbag sensor assembly.
OK

H01021AB0119H01079
H10600H10624
"u
ONAirbag
Sensor
Assembly
DTC B0132/61 DLC3
TC
CG
P/T Squib RH
DI-786
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
979 Author
: Date
:
2004 LAND CRUISER (RM1071U)
4 Check P/T squib RH.
PREPARATION:
(a) Turn the ignition switch to LOCK.
(b) Disconnect the negative (-) terminal cable from the bat-
tery, and wait at least for 90 seconds.
(c) Connect the seat belt pretensioner RH (P/T squib RH)
connector.
(d) Connect the negative (-) terminal cable to the battery,
and wait at least for 2 seconds.
CHECK:
(a) Turn the ignition switch to ON, and wait at least for 10 se-
conds.
(b) Clear the DTC stored in memory (See page DI-692).
(c) Turn the ignition switch to LOCK, and wait at least for 10
seconds.
(d) Turn the ignition switch to ON, and wait at least for 10 se-
conds.
(e) Check the DTC (See page DI-692).
OK:
DTC B0132/61 is not output.
HINT:
Codes other than code B0132/61 may be output at this time, but
they are not relevant to this check.
NG Replace seat belt pretensioner RH
(P/T squib RH).
OK
From the results of the above inspection, the malfunctioning part can now be considered normal.
To make sure of this, use the simulation method to check. If the malfunctioning part can not be
detected by the simulation method, replace all SRS components including the wire harness.

H01019AB0119H08394H08268
Airbag
Sensor
Assembly
PR+
(+)
(-) ON
P/T Squib RHFloor No. 2 Wire
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI-787
980 Author
: Date
:
2004 LAND CRUISER (RM1071U)
DTC B0133/62 Short in P/T Squib RH Circuit (to B+)
CIRCUIT DESCRIPTION
The P/T squib RH circuit consists of the airbag sensor assembly and the seat belt pretensioner RH.
It causes the SRS to deploy when the SRS deployment conditions are satisfied.
For details of the function of each component, see OPERATION on page RS-3.
DTC B0133/62 is recorded when a B+ short is detected in the P/T squib RH circuit.
DTC No.DTC Detecting ConditionTrouble Area
B0133/62

Short in P/T squib RH circuit (to B+)

P/T squib RH malfunction

Airbag sensor assembly malfunction
Seat belt pretensioner RH (P/T squib RH)

Airbag sensor assembly

Floor No. 2 wire

Dash wire (Bench seat)
WIRING DIAGRAM
See page DI-777.
INSPECTION PROCEDURE
1 Prepare for inspection (See step 1 on page DI-923).
2 Check floor No. 2 wire (P/T squib RH circuit).
PREPARATION:
Connect the negative (-) terminal cable to the battery, and wait
at least for 2 seconds.
CHECK:
(a) Turn the ignition switch to ON.
(b) Measure the voltage between the body ground and PR+
of the floor No. 2 wire connector on the seat belt preten-
sioner RH (P/T squib RH) side.
OK:
Voltage: Below 1 V
NG Repair or replace floor No. 2 wire.
OK
DI6PM-16

H01020H02139AB0119H01081 H10600H10625
Airbag
Sensor
Assembly
PR+
PR-
DTC B0133/62ON " u
DLC3
TC CG
P/T Squib RHFloor No. 2 Wire
DI-788
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
981 Author
: Date
:
2004 LAND CRUISER (RM1071U)
3 Check airbag sensor assembly.
PREPARATION:
(a) Connect the connector to the airbag sensor assembly.
(b) Using a service wire, connect PR+ and PR- of the floor
No. 2 wire connector on the seat belt pretensioner RH
(P/T squib RH) side.
(c) Connect the negative (-) terminal cable to the battery,
and wait at least for 2 seconds.
CHECK:
(a) Turn the ignition switch to ON, and wait at least for 10 se-
conds.
(b) Clear the DTC stored in memory (See page DI-692).
(c) Turn the ignition switch to LOCK, and wait at least for 10
seconds.
(d) Turn the ignition switch to ON, and wait at least for 10 se-
conds.
(e) Check the DTC (See page DI-692).
OK:
DTC B0133/62 is not output.
HINT:
Codes other than code B0133/62 may be output at this time, but
they are not relevant to this check.
NG Replace airbag sensor assembly.
OK

H01021AB0119H01081 H10600H10626
"u
ONAirbag
Sensor
Assembly
DTC B0133/62 DLC3
TC CG
P/T Squib RH
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI-789
982 Author
: Date
:
2004 LAND CRUISER (RM1071U)
4 Check P/T squib RH.
PREPARATION:
(a) Turn ignition switch to LOCK.
(b) Disconnect the negative (-) terminal cable from the bat-
tery, and wait at least for 90 seconds.
(c) Connect the seat belt pretensioner RH (P/T squib RH)
connector.
(d) Connect the negative (-) terminal cable to the battery,
and wait at least for 2 seconds.
CHECK:
(a) Turn the ignition switch to ON, and wait at least for 10 se-
conds.
(b) Clear the DTC stored in memory (See page DI-692).
(c) Turn the ignition switch to LOCK, and wait at least for 10
seconds.
(d) Turn the ignition switch to ON, and wait at least for 10 se-
conds.
(e) Check the DTC (See page DI-692).
OK:
DTC B0133/62 is not output.
HINT:
Codes other than code B0133/62 may be output at this time, but
they are not relevant to this check.
NG Replace seat belt pretensioner RH
(P/T squib RH).
OK
From the results of the above inspection, the malfunctioning part can now be considered normal.
To make sure of this, use the simulation method to check. If the malfunctioning part can not be
detected by the simulation method, replace all SRS components including the wire harness.
