Transfer Indicator Switch
Connector
(Neutral Switch)
Transfer Indicator
Switch Connector
(Center Diff. Lock)Transfer Indicator Switch Connector
(Low Switch)
Motor Actuator Connector
No. 1 Vehicle Speed Sensor Connector Rear Propeller Shaft
Breather Hose
Transfer
Ground Cable
106 (1,080, 78)
69 (700, 51)
69 (700, 51)
Clip
Plate Washer
Wave Washer
Transfer Shift Lever Rod
AssemblyBushing
69 (700, 51)
69 (700, 51)
Transfer Case Protector
: Specified torque
N´m (kgf´cm, ft´lbf)Front Propeller ShaftCrossmember
50 (510, 37)
50 (510, 37)
74 (750, 54)
50 (510, 37)
28 (290, 21)
106 (1,080, 78)
106 (1,080, 78)
106 (1,080, 78)
80 (820, 59)
80 (820, 59)
80 (820, 59)
80 (820, 59)
- TRANSFERTRANSFER UNIT
TR-3
1891 Author: Date:
2004 LAND CRUISER (RM1071U)
TRANSFER UNIT
COMPONENTS
Q09804
5 mm (0.20 in.)
or More
Hose
ClipPipe
D02643
- TRANSFERTRANSFER UNIT
TR-5
1893 Author: Date:
2004 LAND CRUISER (RM1071U)
8. DISCONNECT BREATHER HOSE
HINT:
At the time of installation, assemble the clip to the position
shown in the illustration.
9. DISCONNECT NO. 1 VEHICLE SPEED SENSOR, 3
TRANSFER INDICATOR SWITCH AND MOTOR AC-
TUATOR CONNECTORS
10. JACK UP TRANSFER SLIGHTLY
Using a transmission jack, support the transfer.
11. REMOVE TRANSFER FROM TRANSMISSION
(a) Disconnect the wire harness from the transfer.
(b) Remove the 6 transfer adaptor rear mounting bolts.
Torque: 69 N´m (700 kgf´cm, 51 ft´lbf)
(c) Pull out the transfer down and toward the rear.
