128
4. Touch “Enter” or say “Enter destina-
tion”, and the system starts searching for
a route to your home. (If the destination is
already registered, “Add” or “Replace” is
displayed on the screen.)
Touch or say “Cancel”, and the search will be
canceled.
INFORMATION
In the following conditions, the system
may not recognize the command proper-
ly.
The command is not correct or clear.
There are some noises such as wind
noise, etc.
Help screen
This system has a function which displays
the voice recognition help screen. You
can see the command list and operating
guide on it.
(a) Command List
1. Touch the “Command List” tab on
the upper side of the screen and the
switches on the right side of the screen to
select the desired category.
2. You can scroll through the list of the
command list by touching “
” or “”
switch.
Touch the
“OK” switch after you check it.(b) Operating Guide
1. Touch the “Operating Guide” tab
on the upper side of the screen and the
switches on the right side of the screen to
select the desired category.
2. You can scroll through the list of the op-
erating guide by touching “
” or “”
switch.
Touch the
“OK” switch after you check it.

129
Setting screen
1. Push the “INFO” button on the bezel
to display the “Information Menu” screen.
2. Touch the
“Screen Setting” switch.
(a) Automatic transition
You can select a function that enables au-
tomatic return to the navigation screen
from the audio screen.
5u008
Select the “ON” or “OFF” and then
touch the “OK”.
ON: The navigation screen automatically re-
turns from the audio or air conditioner screen
20 seconds after the end of audio or air condi-
tioner screen operation.
OFF: The audio or air conditioner screen re-
mains on.(b) Background color
You can select a background color.
Select the desired background color and
then touch the
“OK”.
Screen adjustment
You can adjust the brightness or contrast
of the screen depending on the brightness
of your surroundings. You also can turn
the display off.
Push the
“DISPLAY” button on the bez-
el to display the “Display” screen.

130
5u009
Contrast and brightness adjustment
CONTRAST “+”:
Strengthens the contrast of the screen.
CONTRAST “–”:
Weakens the contrast of the screen.
BRIGHTNESS “+”: Brightens the screen.
BRIGHTNESS “–”: Darkens the screen.
The screen turns off when you push the
“SCREEN OFF”. To turn the display screen
back on, push any bezel switch such as “OP-
TION”, etc. The selected screen appears.Color and tone adjustment
You can adjust the color and the tone while
the DVD video and Video CD are being
played.
COLOR “RED”:
Strengthens the red color of the screen.
COLOR “GREEN”:
Strengthens the green color of the screen.
TONE “+”: Strengthens the tone of the
screen.
TONE “–”: Weakens the tone of the screen.
5u0095u009
Depending on the position of the headlight
switch, the screen changes to the day
mode or night mode.
To display the screen in the day mode even
with the headlight switch on, touch “DAY
MODE” on the adjustment screen for bright-
ness and contrast control.
However, if the instrument panel light control
switch is turned fully to the right, mode switch-
ing cannot be done. It remains in the day
mode. In this case, “DAY MODE” is not shown
on the screen.
If the screen is set in the day mode with the
headlight switch turned to on, this condition is
memorized in the system even with the en-
gine turned off.

132
Automatic air conditioning controls
Page
1Temperature control button 135. . . .
2Automatic control button 134. . . . . .
3OFF button 134. . . . . . . . . . . . . . . . . . .
4Front windshield button 137. . . . . . . .
5Air conditioning operation
screen display button 134. . . . . . . . . .
6Air intake control button 136. . . . . . .
7Air conditioning onoff switch 137. .
8Air flow control switch 135. . . . . . . . .
9Fan speed control switch 136. . . . . .

134 The automatic air conditioning automat-
ically maintains the set temperature.
This air conditioning features automatic fan
speed and air flow control which automati-
cally selects the most suitable fan speed
and air flow to control the temperature. The
ignition key must be in the “ON” position.
CLIMATE: Push this button to display
switches for automatic air conditioning con-
trols.
NOTICE
To prevent the battery from being dis-
charged, do not leave the air condition-
ing on longer than necessary when the
engine is not running.
oxu002
By pushing the switch above, you can op-
erate the speech command system.
For the operation of the speech command
system and the command, see page 126 and
128.
(a) Climate control
SETTING OPERATION automatic control
1. Push the “AUTO” button.
Air flow quantity, switching of the diffusers,
on−off of the air conditioning, and switching of
the air intake between RECIRCULATED AIR
and OUTSIDE AIR are automatically ad-
justed. The operation status is shown by
each indicator.
When one of the manual control buttons is de-
pressed while operating in automatic mode,
the mode relevant to the depressed button is
set. Other conditions continue to be adjusted
automatically.
Push the “OFF” button to turn the air condi-
tioning off.
It is recommended that you close the lower
vent. For details about this, see page 139.

137 If manual onoff of the air conditioning is
desired
Push the “A/C” switch to turn the air condi-
tioning on and push it again to turn the air
conditioning off. If you turn off the air condi-
tioning manually, the EXHAUST GAS AUTO-
MATIC mode will be cancelled.
If the outside temperature is lowered down to
around 0C (32F), the air conditioning will
turn off automatically. At this time, the indica-
tor on the A/C button is off and the EXHAUST
GAS AUTOMATIC indicator light remains on.
However, the EXHAUST GAS AUTOMATIC
mode does not operate. When the air condi-
tioning turns on as with the raised tempera-
ture, the EXHAUST GAS AUTOMATIC mode
resumes.
If the system is used for ventilation, heating in
dry weather or removing frost or exterior fog
on the windshield, turn the air conditioning off
once it is no longer required. This will improve
fuel economy. The air conditioning can be
used for year−round automatic temperature
control including cooling and dehumidifying
operation.
(b) Windshield defogging and de-
frosting
To remove interior fog on the windshield
Push the “FRONT WINDSHIELD” button.
To remove frost or exterior fog on the
windshield
1. Push the upper side of the temperature
control button until maximum figure appears
on the temperature display.
2. Push the “FRONT WINDSHIELD” but-
ton.
3. Push the “HI” of the air flow control switch
to obtain a maximum air flow.
4. Leave the air conditioning on−off button
off.
For further information for removing frost and
fog, see “Lower vent” on page 139.When the “FRONT WINDSHIELD” button is
pushed while operating in automatic mode,
the air conditioning is set to operate and the
OUTSIDE AIR mode is set.
Push the “A/C” switch for dehumidified heat-
ing or cooling. This setting clears the front
view more quickly.
If you push the “FRONT WINDSHIELD” but-
ton once again while in the FRONT WIND-
SHIELD mode, the mode then returns to the
last mode used.
CAUTION
Do not use the “FRONT WINDSHIELD”
button during cooled air operation in ex-
tremely humid weather. The difference
between the temperature of the outside
air and that of the windshield could
cause the outer surface of the wind-
shield to fog up blocking your vision.

For the JBL brand audio system, “JBL” logo is provided on the panel.
7ulc001a
142
Audio system
Quick reference for your audio system
Page
1Audio operation screen display
button 143. . . . . . . . . . . . . . . . . . . . . . . .
2Function switch display
screen 144. . . . . . . . . . . . . . . . . . . . . . .
3Cassette tape slot 157. . . . . . . . . . . . .
4Frequency turning knob 147. . . . . . .
5[Radio mode] Preset tuning 148. . . .
[Tape mode] Side change of
cassette tape 157. . . . . . . . . . . . . . . . .
[DISC mode] Disc selection 161. . . .
6SCAN button 148, 162. . . . . . . . . . . . . .
7Mode selectors 144. . . . . . . . . . . . . . . .
8Stopping and ejecting a
cassette tape 157. . . . . . . . . . . . . . . . .
9[Radio mode] Seek tuning 148. . . . . .
[Tape/DISC mode] Direct access to
a desired program 158, 162. . . . . . . . .
10Turning the system on and
adjusting volume 143. . . . . . . . . . . . . .

143
Using your audio system:
some basics
This section describes some of the basic fea-
tures of the Toyota audio system. Some in-
formation may not pertain to your system.
Your audio system works when the ignition
key is in the “ACC” or “ON” position.
NOTICE
To prevent the battery from being
discharged, do not leave the car audio
on longer than necessary when the
engine is not running.
oxu002
By pushing the above button, you can op-
erate the speech command system.
For the operation of the speech command
system and the command, see page 126 and
128.
(a) Turning the system on and off
UNX602
POWERVOL: Push this knob to turn the au-
dio system on and off. Turn this knob to adjust
the volume. The system turns on in the last
mode used.
AUDIO: Push this button to display switches
for audio system.
VI

144
7wlc002a
Push the “AM”, “FM”, “TAPE” or “DISC”
button to turn on that mode. The selected
mode turns on directly.
Push these buttons if you want to switch from
one mode to another.
If the tape or disc is not set, the cassette play-
er or compact disc player does not turn on.
You can turn off the cassette player by eject-
ing the cassette tape. If the audio system was
previously off, then the entire audio system
will be turned off when you eject the cassette
tape. If another function was previously play-
ing, it will come on again.
lxb001a
lxb006a
lxb008a
The switches for radio, cassette tape and
disc player operation are displayed on the
liquid crystal display. Touch them lightly
and directly on the screen.
The selected switch is highlighted in green.

145
(b) Tone and balance
How good an audio program sounds to you is
largely determined by the mix of the treble,
mid−range, and bass levels. In fact, different
kinds of music and vocal programs usually
sound better with different mixes of treble,
mid−range, and bass.
A good balance of the left and right stereo
channels and of the front and rear sound lev-
els is also important.
Keep in mind that if you are listening to a ste-
reo recording or broadcast, changing the
right/left balance will increase the volume of
one group of sounds while decreasing the
volume of another.
lxb001a
Touching the “SOUND” switch on the
screen displays the sound adjustment
screen.BASS “+” or “–”: Adjusts low−pitched
tones.
MID “+” or “–”: Adjusts mid−pitched tones.
TREB “+” or “–”: Adjusts high−pitched
tones.
“FRONT” or “REAR”: Adjusts sound bal-
ance between the front and rear speakers.
“L” or “R”: Adjusts sound balance between
the left and right speakers.
“OK”: The previous screen returns.
VI
