display TOYOTA LAND CRUISER 2010 J200 Navigation Manual

AUDIO/VIDEO SYSTEM
217

Headphone jacks
1To use the headphones, connect
them to the jack.
2To adjust the volume
1. Push the knob.
2. Turn the knob clockwise to increase
the volume. Turn the knob counter-
clockwise to decrease the volume.
3. Push the knob again.
Headphones
To listen to the rear audio, use headpho-
nes.
With some headphones generally avail-
able in the market, it may be difficult to
catch signals properly. Toyota recom-
mends the use of T oyota genuine wireless
headphones.
Please contact your Toyota dealer for fur-
ther details.
Volume
Adjust the volume when you connect the
headphones to the jack. Loud sounds may
have a significant impact on the human
body.
Caution screen
This screen appears for a few seconds
when the rear display is opened. During
this time, only “OPEN/CLOSE” can be op-
erated.

AUDIO/VIDEO SYSTEM
218

Changing the source
1Turning on the
audio source selection
screen
2Inputting the selected icon
3Selecting an icon
Push “SOURCE” to display the audio
source selection screen.
Select an audio source.
Changing the speaker output
To play the rear audio over the speakers in
the vehicle, turn “Speaker Output” on.

AUDIO/VIDEO SYSTEM
219
CAUTION
When the rear seat entertainment
system is not used, keep the dis-
play closed. In the event of an acci-
dent or sudden braking, an occu-
pant may hit the opened display, re-
sulting in injury.
While driving
Do not use headphones.
Doing so may cause an accident,
resulting in death or serious injury.
To prevent accidents and electric
shock
Do not disassemble or modify the
remote control.
When the remote control is not
used
Stow the remote control. Injuries may result in the event of an acci-
dent or sudden braking.
Closing the display, never use any
part of your body to intentionally
activate the jam protection func-
tion.
Conversational speech on some
DVDs is recorded at a low volume
to emphasize the impact of sound
effects. If you adjust the volume
assuming that the conversations
represent the maximum volume
level that the DVD will play, you
may be startled by louder sound ef-
fects or when you change to a dif-
ferent audio source. The louder
sounds may have a significant im-
pact on the human body or pose a
driving hazard. Keep this in mind
when you adjust the volume.
Removed battery and other parts:
Keep away from children.
These parts are small and if swal-
lowed by a child they can cause
choking.
NOTICE
Cleaning the display
Wipe the display with a dry soft
cloth.
If the screen is wiped with a rough
cloth, the surface of the screen
may be scratched.
To prevent damage to the remote
controlKeep the remote control away from
direct sunlight, temperature heat
and high humidity.
Do not drop or knock the remote
control against hard objects.
Do not sit on or place heavy ob-
jects on the remote control.
Do not close the display using your
hand. Doing so may result in a mal-
function.
For normal operation after replac-
ing the battery, observe the follow-
ing precautions to prevent acci-
dents:
Always work with dry hands.
Moisture may cause the battery
to rust.
Do not touch or move any other
components inside the remote
control.
Do not bend either of the battery
terminals.
INFORMATION
Rear seat entertainment system can
be locked to prevent rear passengers
from operating the entertainment
system. (see “ Rear system lock”
on page 270.)

AUDIO/VIDEO SYSTEM
220
Select radio mode on the source screen to
display the control screen.
1Tuning the station
2Selecting a preset station
Tuning the station
Push “
” or “” of “TUNE” until the de-
sired station appears on the screen.
Push “
” or “” of “TUNE” and the sta-
tions will be searched automatically one
after another.
Selecting a preset station
Push “
” or “” of “DISC·CH” until the
desired station band appears on the
screen.
1Turning on DVD changer mode
2Selecting a disc
Selecting a disc
Push “” or “” of “DISC·CH” until the
desired disc number appears on the
screen.
Audio CD, CD text 221
. . . . . . . . . . . .
MP3/WMA disc 221
. . . . . . . . . . . . . .
DVD video/audio 222
. . . . . . . . . . . . .
Video CD 232
. . . . . . . . . . . . . . . . . . . .
— Using the radio— Using the DVD changer

AUDIO/VIDEO SYSTEM
223

DVD video and DVD audio
Push “OPTION” if no icons are shown
while watching a DVD video or DVD audio,
and following screens appear.
DVD video
DVD audio
“Settings”: Selecting this will display set-
ting screen.
“Hide Buttons”: Selecting this will turn off
the icons from the screen.
If “
” appears on the screen when you
select a control, the operation relevant to
the control is not permitted. DESCRIPTION OF DVD VIDEO CON-
TROLS
“Menu” and “Top Menu”:
If you select
any of the above controls, the menu
screen for DVD video appears. (For the
operation, see the manual that come with
the DVD video disc provided separately.)
: Selecting this will fast rewind dur-
ing playback.
: Selecting this will stop the video
screen.
: Selecting this will pause/resume
the video screen.
: Selecting this will fast forward dur-
ing playback and forward frame by frame
during pause.

AUDIO/VIDEO SYSTEM
225
DESCRIPTION OF DVD VIDEO SET-
TINGS
“Setup”: The initial set up screen ap-
pears. (See page 230.)
“Search”: The title search screen ap-
pears. (See page 226.)
“Return”: Selecting this will display the
predetermined scene and start playing
from there.
“Audio”: The audio changing screen ap-
pears. (See page 228.)
“Subtitle”: The subtitle changing screen
appears. (See page 228.)
“Angle”: The angle selection screen ap-
pears. (See page 229.)
When you select
, the previous
screen returns. DESCRIPTION OF DVD AUDIO SET-
TINGS
“Setup”:
The initial set up screen ap-
pears. (See page 230.)
“Select Number”: The track or number
search screen appears. (See page 227.)
“Search”: The group search screen ap-
pears.
“Return”: Selecting this will display the
predetermined scene and start playing
from there.
“Prev. Page”: Select this button to rewind
the pages.
“Next Page”: Select this button to forward
the pages.
“Subtitle”: The subtitle changing screen
appears. (See page 228.)
“Angle”: The angle selection screen ap-
pears. (See page 229.)
When you select
, the previous
screen returns.

AUDIO/VIDEO SYSTEM
233

Video CD
Push “OPTION” if no icons are shown
while watching a video CD, and following
screen appears.
“Settings”: Selecting this will display set-
ting screen.
“Hide Buttons”: Selecting this will turn off
the icons from the screen.
If “
” appears on the display when you
select a control, the operation is not per-
mitted. DESCRIPTION OF VIDEO CD
CONTROLS
:
Select this to fast rewind during
playback.
: Selecting this will stop the video
screen.
: Use this to pause/resume the vid-
eo screen.
: Select this to fast forward during
the playback and start playing frame by
frame during pause.

AUDIO/VIDEO SYSTEM
234
VIDEO CD SETTINGS
When “Settings” is selected on the con-
trol icon screen, the following screen will
appear.DESCRIPTION OF VIDEO CD
SETTINGS
“Select Number”: The track or number
search screen appears. (See “SEARCH-
ING BY TRACK” on page 235.)
“Return”: Selecting this will display the
predetermined scene and start playing
from there.
“Prev. Page”: When you select this while
the disc menu is displayed, the previous
page appears on the screen. If you select
this while the player is playing video, the
previous track is searched and played.
“Next Page”: When you select this while
the disc menu is displayed, the next page
appears on the display. If you select this
while the player is playing video, the next
track is searched and played.
“MAIN/SUB”: A multiplex transmission
changing control. The mode changes from
Main/Sub to Main, to Sub and back to
Main/Sub by selecting this control.

AUDIO/VIDEO SYSTEM
235
SEARCHING BY TRACK
Select “Select Number” on the settings
screen.
Enter the track numbers and select
“OK”. The player starts playing video
for that title number.
You can select a track number by pushing
“
” or “” of “TUNE” .
If you enter the wrong numbers, select
to delete the numbers.
Select
, and the previous screen re-
turns.
Push “VIDEO” to select the video mode.
Before switching to the video mode, con-
nect the audio −video equipment to the A/V
input adapter.
When “Speaker Output” is off, any au-
dio−video source can be selected for the
other rear display. See “
 Changing the
speaker output” on page 218.
— Using the video mode

AUDIO/VIDEO SYSTEM
236

Using the adapter
Open the cover.
The A/V input adapter is composed of 3 in-
put adapters.
Yellow: Image input adapter
White: Left channel audio input adapter
Red: Right channel audio input adapter
The rear seat entertainment system plays
videos and sound when audio
−video
equipment is connected to the A/V input
adapter. For details, refer to the manufac-
turer’s instructions.
NOTICE
When the A/V input adapter is not in
use, keep the A/V input adapter cover
closed. Inserting anything other than
an appropriate plug may cause elec-
trical failure or a short circuit.
Changing to PAL format
Push “DISPLAY”.
If the video does not appear, turn “ PA L
VIDEO” on.
“PAL VIDEO” will be displayed when PAL
format equipment is connected to the A/V
input adapter.
