seats TOYOTA LAND CRUISER 2014 J200 Navigation Manual

5
191
1
2
3
4
5
6
7
8
L/C200_Navi_OM60L27U_(U)
13.06.03 19:43
9
10
8. USB MEMORY OPERATION ...... 236
CONNECTING A USB MEMORY ....... 236
PLAYING A USB MEMORY ................ 237
9. iPod OPERATION ....................... 241
CONNECTING iPod ............................ 241
PLAYING iPod MUSIC ........................ 242
PLAYING iPod VIDEO......................... 245
iPod VIDEO OPTIONS ........................ 248
10. Bluetooth® AUDIO
OPERATION .............................. 249
CONNECTING A Bluetooth®
AUDIO PLAYE
R................................ 252
PLAYING Bluetooth
® AUDIO .............. 253
11. VTR OPERATION ........................ 258
CONNECTING AUDIO/VIDEO DEVICE ............................................. 258
PLAYING VTR ..................................... 259
VTR OPTIONS .................................... 259
12. REAR SEAT ENTERTAINMENT SYSTEM FEATURES ................ 260
DISPLAY ............................................. 261
REAR SEAT ENTERTAINMENT SYSTEM CONTROLLER .................. 261
HEADPHONE JACKS ......................... 262
HEADPHONES ................................... 262
VOLUME ............................................. 262
OPENING AND CLOSING THE DISPLAY ........................................... 263
TILTING THE DISPLAY ...................... 263
CAUTION SCREEN ............................ 263
CHANGING THE SOURCE ................. 264
CHANGING THE SPEAKER OUTPUT ........................................... 264 OPERATION FROM THE
FRONT SEATS ................................. 266
USING THE RADIO ............................. 266
USING THE RADIO (INTERNET RADIO BROADCAST)....................... 267
PLAYING iPod ..................................... 268
PLAYING A USB MEMORY ................ 269
PLAYING Bluetooth
® AUDIO ............... 269
PLAYING AN AUDIO CD/CD TEXT ..................................... 270
PLAYING MP3/WMA DISCS ............... 271
PLAYING DVD VIDEO......................... 271
USING THE VIDEO MODE ................. 277
CHANGING SETTINGS....................... 278
13. AUDIO/VIDEO REMOTE CONTROLS (STEERING
SWITCHES)............................... 281
14. AUDIO/VIDEO SYSTEM OPERATING HINTS.................. 283
RADIO RECEPTION............................ 283
iPod ...................................................... 284
USB MEMORY .................................... 285
CARING FOR YOUR DVD PLAYER AND DISC.................. 285
MP3/WMA FILES ................................. 287
CD-R AND CD-RW DISCS .................. 289
TERMS ................................................ 289
1. AUDIO SETTINGS ...................... 293
HD Radio™ SYSTEM SETTINGS ....... 293
iPod AND EXTERNAL VIDEO SETTINGS ........................................ 294
2SETUP
AUDIO/VIDEO SYSTEM

233
1. AUDIO/VIDEO SYSTEM OPERATION
5
AUDIO/VIDEO SYSTEM
L/C200_Navi_OM60L27U_(U)
13.06.03 19:41
Vehicles with rear seat entertainment
system
Front passengers can cancel this setup
operation by touching “Play”. The player
will resume normal play.
Likewise, a rear passenger can cancel a
front passenger’s selection of the setup
menu.
To lock the rear seat entertainment sys-
tem, see “OPERATION FROM THE
FRONT SEATS” on page 266.
If “Check DISC” appears on the screen:
It indicates that the disc is dirty, damaged,
or it was inserted upside down. Clean the
disc or insert it correctly. If a disc which is
not playable is inserted, “Check DISC” will
also appear on the screen. For appropriate
discs for the player, see “AUDIO/VIDEO
SYSTEM OPERATING HINTS” on page
283.
If “Region code error” appears on the
screen: It indicates that the DVD region
code is not set properly.
If the malfunction is not rectified: Take
your vehicle to your Toyota dealer.
SETUP OPERATION FROM THE
REAR SEAT
This screen appears when a rear pas-
senger selects the setup menu.IF THE PLAYER
MALFUNCTIONS
If the player or another unit equipped
with the player malfunctions, the audio/
video system will display a message.
These are described below.
INFORMATION
●If an MP3/WMA disc contains CD-DA
files only, the CD-DA files can be played.
If an MP3/WMA disc contains CD-DA
files and files other than CD-DA files,
only MP3/WMA files can be played.

266
1. AUDIO/VIDEO SYSTEM OPERATION
L/C200_Navi_OM60L27U_(U)
13.06.03 19:41
1Press the “AUDIO” button.
2Touch the “Rear” tab or press the
“AUDIO” button repeatedly until the
“Rear” tab is selected.
3Touch the desired button. The selected
button indicator is highlighted.
1Select radio mode on the source
screen to display the control screen.
1Press the “” or “” button of
“FOL/CH” until the desired station/
channel band appears on the
screen.
OPERATION FROM THE
FRONT SEATS
The rear seat display can be operated
from the front seats.
No.Function
Turns the rear display open or close.
Locks the system so passengers in
the rear seats cannot operate the
rear entertainment system.
Enables the front speakers to output
the front audio system’s audio
source.
USING THE RADIO
When a different audio source is se-
lected at the front seats, radio mode
cannot be selected at the rear seats.
SELECTING A PRESET
STATION/CHANNEL

268
1. AUDIO/VIDEO SYSTEM OPERATION
L/C200_Navi_OM60L27U_(U)
13.06.03 19:41
1Connect iPod. (See “CONNECTING
iPod” on page 241.)
2Select iPod mode on the source
screen to display the control screen.
1Press the button.
1Press the or button repeated-
ly until the desired track number ap-
pears on the screen.
1Press the or button, or press
and hold the or button.
Press the “SOURCE” button and the sys-
tem will return to the iPod control screen.
PLAYING iPod
When a different audio source is se-
lected at the front seats, iPod mode
cannot be selected at the rear seats.
PLAYING AND PAUSING iPod
SELECTING A DESIRED
TRACK
FAST FORWARDING OR
REWINDING
DISPLAYING iPod VIDEO
If iPod mode is selected again at the
rear seats when iPod video is being
displayed in the front monitor, iPod vid-
eo can be displayed.
INFORMATION
●Depending on the iPod that is connected
to the system, certain functions may not
be available.

269
1. AUDIO/VIDEO SYSTEM OPERATION
5
AUDIO/VIDEO SYSTEM
L/C200_Navi_OM60L27U_(U)
13.06.03 19:41
1Connect a USB memory. (See “CON-
NECTING A USB MEMORY” on page
236.)
2Select USB mode on the source
screen to display the control screen.
1Press the button.
1Press the “” or “” button of “FOL/
CH” until the desired folder/album
number appears on the screen.
1Press the or button repeated-
ly until the desired file/track number
appears on the screen.
1Press the or button, or press
and hold the or button.
1Select BT-A mode on the source
screen to display the control screen.
PLAYING A USB MEMORY
When a different audio source is se-
lected at the front seats, USB mode
cannot be selected at the rear seats.
PLAYING AND PAUSING A USB
MEMORY
SELECTING A DESIRED
FOLDER OR ALBUM
SELECTING A DESIRED FILE
OR TRACK
FAST FORWARDING OR
REWINDING
INFORMATION
●Depending on the USB memory that is
connected to the system, certain
functions may not be available.
PLAYING Bluetooth® AUDIO
When a different audio source is se-
lected at the front seats, BT-A mode
cannot be selected at the rear seats.

298
L/C200_Navi_OM60L27U_(U)
13.06.03 19:43
1. AIR CONDITIONING SYSTEM OPERATION
1. QUICK REFERENCE
*1: Driver side temperature display
*2: Outside temperature display
*3: Passenger side temperature display
Operations such as changing the air outlets or fan speed are carried out on the
screen. Press the “CLIMATE” button to display the air conditioning control screen.
No.NameFunctionPage
Air flow control buttonsTouch to change the air outlets.303
Rear air conditioning
control buttonTouch to display the rear air conditioning control
screen.308
Windshield wiper
de-icer (If equipped)Touch to prevent ice from building up on the
windshield and wiper blades.Owner’s
Manual
“4-ZONE”Touch to set the temperatures independently for
the driver’s, front passenger’s and rear seats.301
“A/C”Touch to change the air conditioning between on
and off.306
*1*2*3

301
1. AIR CONDITIONING SYSTEM OPERATION
6
AIR CONDITIONING
L/C200_Navi_OM60L27U_(U)
13.06.03 19:43
3. FRONT AUTOMATIC AIR CONDITIONING SYSTEM
1Press the “AUTO” button.
1Press the “” button on “TEMP” to in-
crease the temperature and “” to de-
crease the temperature.
The temperature for the driver’s and front
passenger’s seats can be set separately.
Only the “” and “” button on “TEMP”
(driver’s side) can be used to adjust the
temperature for all seats.
■4-ZONE
1Touch “4-ZONE”.
When the indicator on “4-ZONE” is on,
the temperature for the driver’s, front pas-
senger’s and rear seats can be set sepa-
rately.
Operating the passenger’s side or rear
temperature control will enter individual
mode. (For details, refer to “Owner’s Man-
ual”.)
USING THE AIR
CONDITIONING SYSTEM
SWITCHING TO AUTOMATIC
OPERATION MODE
Air outlets and fan speed are automat-
ically adjusted according to the tem-
perature setting.
Press the “OFF” button to turn the fan
off.
INFORMATION
●While the cool box is on, the front air
conditioning system cannot be turned
off.
●When the outside temperature is 32F
(0C) or below, the cool box may not
operate.
SETTING THE VEHICLE
INTERIOR TEMPERATURE
“4-ZONE” is used to set the tempera-
tures independently for the driver’s
seat, front passenger seat and rear
seats.

303
1. AIR CONDITIONING SYSTEM OPERATION
6
AIR CONDITIONING
L/C200_Navi_OM60L27U_(U)
13.06.03 19:43
1Touch any mode on the screen.
 Left-hand front seat
Right-hand front seat
Different air outlets for the left-hand and
right-hand front seats can be chosen.
Air flows to the upper body (Panel)
*1: Depending on the rear air conditioning
setting
*
2: Automatic air flow mode only
Air flows to the upper body and feet (Bi-
level)
*1: Depending on the rear air conditioning
setting
SWITCHING THE AIR OUTLETS
AND AIR FLOW
The outlets from which air is delivered
can be selected manually by touching
the screen button.
No.Function
Panel
Bi-level
Floor
Floor/windshield
*1
*1*2
*2
*1
*1

393
L/C200_Navi_OM60L27U_(U)
13.06.03 19:56
Q
Quick guide ............................................... 10
Quick reference ................ 20, 132, 192, 298
R
Radio ...................................................... 201
Listening to the radio ........................... 201
Presetting a station ............................. 201
Radio broadcast data system.............. 202
Selecting a station ............................... 202
Traffic announcement ......................... 203
Radio broadcast data system ................. 202
Rear air conditioning control button ........ 298
REAR button ........................................... 298
Rear seat entertainment system
features ............................................... 260
Caution screen .................................... 263
Changing settings ............................... 278
Changing the source ........................... 264
Changing the speaker output .............. 264
Controller............................................. 261
Display ................................................ 261
Headphone jacks ................................ 262
Headphones ........................................ 262
Opening and closing the display ......... 263
Operation from the front seats ............ 266
Playing a USB memory ....................... 269
Playing an audio CD/CD text .............. 270
Playing Bluetooth
® audio .................... 269
Playing DVD video .............................. 271
Playing iPod ........................................ 268
Playing MP3/WMA discs ..................... 271
Tilting the display ................................ 263
Using the radio .................................... 266
Using the radio
(Internet radio broadcast) ................ 267
Using the video mode ......................... 277
Volume ................................................ 262Rear view monitor system....................... 360
Area displayed on screen .................... 362
Camera................................................ 362
Driving precautions.............................. 360
If you notice any symptoms ................. 364
Rear view monitor system
precautions ...................................... 362
Screen display ..................................... 361
Things you should know ...................... 364
Rear window and
outside rear view mirror
defogger button ................................... 298
Receive on the Bluetooth
® phone........... 149
Register a Bluetooth® phone .................. 138
Connecting a Bluetooth® phone .......... 139
Reconnecting the Bluetooth®
phone ............................................... 141
Registering home ...................................... 12
Registering preset destinations................. 14
Reordering destinations ............................ 87
Resuming guidance .................................. 93
Route guidance ......................................... 76
Route guidance screen ............................. 80
Route overview ......................................... 90
Route preference ...................................... 91
Route trace ............................................... 97
