bluetooth TOYOTA LAND CRUISER 2015 J200 Quick Reference Guide

OVERVIEW
FEATURES/OPERATIONS
SAFETY AND EMERGENCY FEATURES
1
This Quick Reference Guide is a summary of basic vehicle
operations. It contains brief descriptions of fundamental operations
so you can locate and use the vehicle’s main equipment quickly
and easily.
The Quick Reference Guide is not intended as a substitute for the
Owner’s Manual located in your vehicle’s glove box. We strongly
encourage you to review the Owner’s Manual and supplementary
manuals so you will have a better understanding of your vehicle’s
capabilities and limitations.
Your dealership and the entire staff of Toyota Motor Sales, U.S.A.,
Inc. wish you many years of satisfied driving in your new Land
Cruiser.
A word about safe vehicle operations
This Quick Reference Guide is not a full description of Land
Cruiser operations. Every Land Cruiser owner should review the
Owner’s Manual that accompanies this vehicle.
Pay special attention to the boxed information highlighted in
color throughout the Owner’s Manual. Each box contains safe
operating instructions to help you avoid injury or equipment
malfunction.
All information in this Quick Reference Guide is current at the
time of printing. Toyota reserves the right to make changes at
any time without notice.
2015
Land Cruiser
INDEX
Engine maintenance 9
Fuel tank door release and cap 8
Hood release 8
Indicator symbols 4-5
Instrument cluster 4
Instrument panel 2-3
Keyless entry
1 6
Light control-Instrument panel 9
Smart Key system
1,2 7
Air Conditioning/Heating 20-21
Audio 18-19
Auto lock/unlock
1 10
Automatic Transmission 10
Back door 17
Bluetooth
® Device Pairing 18
Cooler box 29
Crawl control 22
Cruise control 23
Cup holders 28
Door locks 27
Dynamic radar cruise control 24-25
Four-wheel drive 11
Garage door opener (HomeLink
®)3 25
Lights1 & turn signals 15
Mirrors-Side 17
Moonroof 17
Multi-Information Display
2 26
Parking brake 29
Power outlets-12V DC 29
Power outlet-120V AC 29
Rear seat entertainment system 28
Seat adjustments-Front 12
Seat adjustments-Rear 12
Seat heaters and ventilators 21-22
Seats-Head restraints 12
Seats-Tumbling second row seats 13
Seats-Tumbling third row seats 14
Steering lock release 11
Tilt and telescopic steering wheel 26
Telephone controls (Bluetooth
®) 27Windows-Power 16
Window wipers & washers 16
Doors-Child safety locks 31
Floor mat installation 33
Seat belts 30
Seat belts-Shoulder belt anchor 30
Spare tire & tools 31
Star Safety System
TM 32
Tire Pressure Monitoring (warning) System 30
OVERVIEW
FEATURES/OPERATIONS
SAFETY AND
EMERGENCY FEATURES
1
Visit your Toyota dealer for information on customizing this feature.2 Programmable by customer. Refer to the Owner’s Manual for instructions and more information.3 HomeLink® is a registered trademark of Johnson Controls, Inc.

OVERVIEWFEATURES/OPERATIONS
SAFETY AND EMERGENCY FEATURES
19
18
FEATURES/OPERATIONS
AudioiPod®/USB/AUX port
“ ”
Use to search within the
selected audio medium
(radio, CD, iPod
®, etc.).
“MODE”
Push to turn audio ON and to
select an audio mode. Push and
hold to turn audio system OFF.
Steering wheel switches
MODE
Volume
control
vv
Push to
turn ON/
OFF
Eject disc Mute/PauseDisc slotTurn to
search
selected
media (radio,
CD, DVD,
iPod
®, etc.)
Display
audio
control
screen
Display
audio
setup
screen
Function tabs:
Select media
mode
NOTE: For more information, refer to the Owner’s Manual or “Navigation System
Owner’s Manual.”
Seek station/
track/presets
or rewind/FF
Type A
iPod®/USB port
By connecting a USB-compatible portable audio device or USB memory to the
USB port, you can listen to music from the portable audio device or USB memory
through the vehicle’s speaker system.
AUX port
By inserting a mini plug into the AUX port, you can listen to music from a portable
audio device through the vehicle’s speaker system while in AUX mode.
1. Press the “Setup” button on the multimedia faceplate.
2. Touch “Bluetooth” on the display screen.
3. Touch “Add” on the display screen.
4. Go to your phone and access Settings - Bluetooth.
5. On your phone touch device to be paired.
6. Confirm the PIN. Touch “Ok” or “Pair”
Once you have connected the Bluetooth device, it is automatically connected
whenever the “POWER” switch is in the ACCESSORY or ON mode.
** For detailed pairing instructions, see your audio system owner’s manual.
Bluetooth Device Pairing**

OVERVIEW
FEATURES/OPERATIONS
SAFETY AND EMERGENCY FEATURES
27
26
FEATURES/OPERATIONS
Multi-Information Display
Push “DISP” to scroll through the following information screens:
(1) Front tire angle
(2) Miles left on remaining fuel
(3) Average gas mileage after refueling
(4) Current gas mileage
(5) Average gas mileage and Eco Driving Indicator Zone Display
(6) Average vehicle speed
(7) Speedometer
(8) Turn-by-turn navigation setting screen (vehicles with navigation system)
(9) Tire inflation pressure
(10) Display OFF
Bluetooth® technology allows dialing or receipt of calls without taking hands from
the steering wheel or using a cable to connect the telephone and the system.
Refer to “Hands-free system (for cellular phone),” Section 4 in the Navigation
System Owner’s Manual , for more information about phone connections and
compatibility.
MicrophoneDisplay
Type BType A
Steering wheel telephone switches
Start callStart call
End callEnd call
Voice
command
button
Voice
command
button
Door locks
LockUnlock
Telephone controls (Bluetooth®)
Up
Toward
driver
Down
NOTE: Do not attempt to adjust while the vehicle is in motion.
Tilt and telescopic steering wheel
Away
from
driver
Control switch
