OVERVIEW
FEATURES/OPERATIONS
SAFETY AND EMERGENCY FEATURES
23
OVERVIEW
Instrument panel
Steering wheel audio controls1
Telephone controls1
Voice command button1
Multi-Information Display button
Dynamic radar cruise control distance switch2
Headlight, turn signal and front fog light controls
Multi-Information Display
Wiper and washer controls
“AIR BAG ON” and “AIR BAG OFF” indicator
Clock
1
Front passenger seat belt reminder light
Emergency flasher button
Outside rearview mirrors/Rear window defogger button
Audio system
1
Air Conditioning controls1
Theft deterrent system/Engine immobilizer indicator
Steering wheel controls
Type AType A
VIEW switch (multi-terrain monitor)2
“ENGINE START STOP” switch
Four-wheel drive control switch
Cruise control
2/Dynamic radar cruise control2
Tire Pressure Monitoring (warning) System reset
Headlight leveling dial
Power outside rearview mirror controls
Instrument panel light control
Tilt and telescopic steering control
Intuitive parking assist switch
Center differential lock/unlock switch
Roll Sensing of Curtain shield Airbag OFF switch
Heated steering wheel switch
2
VSC/TRAC OFF switch
Headlight cleaner2
1
For vehicles with navigation system, refer to the “Navigation System
Owner’s Manual” for details.
2 If equipped

OVERVIEW
FEATURES/OPERATIONS
SAFETY AND EMERGENCY FEATURES
21
20
FEATURES/OPERATIONS
Air Conditioning/HeatingRear Air Conditioning
Temperature selector (left side)
Temperature selector (right side)
Automatic climate control ON
NOTE: For more information, refer to the Owner’s manual or “Navigation System
Owner’s Manual.”
Front Air Conditioning
Driver side temperature display
Airflow controls (touch to change air outlets)
Passenger side temperature display
Rear AC control button (touch to display rear AC control screen)
Fan speed
Air Conditioning ON/OFF
“4-ZONE” button (touch to set the temperatures independently for driver,
front passenger and rear seats)
Windshield wiper de-icer (if equipped)
Temperature controls (driver side)
CLIMATE (push to display AC control screen)
Automatic climate control ON
Adjusting the temperature setting will cause the airflow vents, air intake and
fan to adjust automatically.
Climate control OFF
Windshield airflow/defogger (fresh air only)
Outside rearview mirror/Rear window defogger
Micro dust and pollen removal mode ON/OFF
Rear Air Conditioning operation mode ON/OFF
Air intake control (switch between outside air and recirculated air mode)
Temperature controls (passenger side)
Type A
Seat heaters and ventilators
Front seats
Push knob to pop the controller out. Turn
clockwise for heater; counterclockwise
for airflow.
Push
OFF
Blows air from the seat
Turns the seat heater on
Fan speed
Airflow vent
Climate control OFF
Second seats
AUT O
TEMP
OFF TEMP
HI
LO
OFF
HI
LO
OFF
HI
LO
OFF
HI
LOLeft
second seatRight
second seat
