Safety Instruction
0NAN001
To use your system as safely as possible,
follow all the safety tips shown below.
This system is intended to assist you in
reaching your destination and, if used
properly, can do so. You, as the driver,
are solely responsible for the safe opera-
tion of your vehicle and the safety of your
passengers.
Do not use any feature of this system to
the extent it distracts you from safe driv-
ing. Your first priority while you are driving
should always be the safe operation of
your vehicle. While you are driving, be
sure to observe all traffic regulations.Before attempting to use this system while
you are driving, learn how to use it and
become thoroughly familiar with it. Read
the entire “Navigation System Owner’s
Manual” to make sure you understand the
system. Do not allow others to use this
system until they have read and under-
stood these and other instructions in this
manual.
For your safety, some functions may be-
come inoperable when you start driving.
Unavailable switches are dimmed. You can
input your destination and select your
route only when the vehicle is not moving.
CAUTION
For safety, the driver should not
operate the navigation system while
he/she is driving. Inattention to the
road and traffic may cause an acci-
dent.
While you are driving, be sure to
follow the traffic regulations and
keep the road condition in mind. If
a traffic sign on the road has been
changed, route guidance may pro-
vide wrong information such as the
direction of a one way street.

Corolla_MATRIX_Navi_U (L/O 0208)
72003 MY COROLLA MATRIX (OM12774U)
7. By “Previous start point”: Yo u c a n
enter a point where the system has
started to guide last time. See page 22
for the detailed steps.
8. By “Freeway Ent./Exit”: You can enter
the name of the freeway (interstate)
entrance or exit. See page 20 for the
detailed steps.
9. By “Map selection”: You can select a
destination simply by selecting the
location on the displayed map. See
page 22 for the detailed steps.
10. By “Preset destination (
1~5)”: Yo u
can choose the destination by selecting
one of the preset destination switch. In
this case, it is necessary to register
your desired destination beforehand.
See page 23 for the detailed steps.
11 . B y “
(home)”: You can select
your own home without entering the
address each time. In this case, it is
necessary to register your home be-
forehand. See page 23 for the detailed
steps.
INFORMATION
 When inputting the destination, the
response to the switch may be slow.
 “Points of interest” are mainly reg-
istered in “Detailed map coverage
areas”. The registration is made
based on the NavTech “Standard
POI Inclusion List”.
 If there is no point registered,
switches such as “Marked points”,
“Home”, “Previous destination” and
“Previous starting point” are
dimmed and not available.
 The route for returning may not be
the same as that for going.
 The route guidance to the destina-
tion may not be the shortest route
or a route without traffic conges-
tion.
 Route guidance may not be avail-
able if there is no road data for the
specified location.
 When setting the destination, you
should use the map on a scale of
one half mile or smaller.
To select an “Address”, “Point of
interest”, “Freeway Ent./Exit” or “In-
tersection” in a different region, a
search area’s change is necessary.
CAUTION
While you are driving, be sure to fol-
low traffic regulations and keep the
road condition in mind. If a traffic
sign on the road has been changed,
the route guidance may provide
wrong information.

Corolla_MATRIX_Navi_U (L/O 0208)
1012003 MY COROLLA MATRIX (OM12774U)
5NAN008
5NAN017
(e) Traffic announcement
“TA” button
When in FM1 or FM2 mode, push and
release the “TA” button for less than 2
seconds to toggle the TA icon on and off
and change the radio’s response to traffic
announcements. Push and hold the “TA”
button for more than 2 seconds to cause
the tuner to seek to the next RDS station
capable to broadcasting traffic announce-
ments. If the tuner stops on a radio sta-
tion that is an active traffic program, “TP”
will be displayed and TA will be set to
on. If no traffic program is found during
traffic seek, TA will still be turned on. If
a traffic interrupt is received and TA is
active, the volume will be increased to
the predefined interrupt volume setting for
the duration of the traffic interrupt. If TA
is on and the audio mode is compact
disc or compact disc auto changer opera-
tion, a traffic interrupt will also pause
playback and change the audio mode to
tuner. The volume will be increased to
the predefined interrupt volume setting for
the duration of the traffic interrupt. Once
the traffic interrupt has ended, the pre-
vious audio mode will resume.You can decrease the volume indepen-
dently from the memorized interrupt vol-
ume range while receiving a TA station.
Traffic announcement can be canceled by
pressing the “TA” button again.

Corolla_MATRIX_Navi_U (L/O 0208)
1092003 MY COROLLA MATRIX (OM12774U)
AM
Fading—AM broadcasts are reflected by
the upper atmosphere—especially at
night. These reflected signals can inter-
fere with those received directly from the
radio station, causing the radio station to
sound alternately strong and weak.
Station interference—When a reflected
signal and a signal received directly from
a radio station are very nearly the same
frequency, they can interfere with each
other, making it difficult to hear the
broadcast.
Static—AM is easily affected by external
sources of electrical noise, such as high
tension power lines, lightening, or electri-
cal motors. This results in static. CARING FOR YOUR COMPACT DISC
PLAYER AND DISCS
Your compact disc player is intended
for use with 12 cm (4.7 in.) discs only.
Extremely high temperatures can keep
your compact disc player from work-
ing. On hot days, use the air condi-
tioning to cool the vehicle interior be-
fore you listen to a disc.
Bumpy roads or other vibrations may
make your compact disc player skip.
If moisture gets into your compact
disc player, you may not hear any
sound even though your compact disc
player appears to be working. Remove
the disc from the player and wait until
it dries.
CAUTION
Compact disc player
s use an invis-
ible laser beam which could cause
hazardous radiatio n exposure if di-
rected outside the unit. Be sure to
operate the player correctly.
Use only compact discs marked as
shown above. The following products
may not be playable on your compact
disc player.
Copy −protected CD
CD− R (CD −Recordable)
CD− RW (CD −Re− writable)
CD− ROM

Corolla_MATRIX_Navi_U (L/O 0208)
11 02003 MY COROLLA MATRIX (OM12774U)
Special shaped discs
Low quality discs
Labeled discs
NOTICE
To prevent damage to the player or
changer, do not use special shaped,
low quality or labeled discs such as
those shown in the illustrations.
CorrectWrong
Handle compact discs carefully, espe-
cially when you are inserting them.
Hold them on the edge and do not
bend them. Avoid getting fingerprints
on them, particularly on the shiny
side.
Dirt, scrapes, warping, pin holes, or
other disc damage could cause the
player to skip or to repeat a section
of a track. (To see a pin hole, hold
the disc up to the light.)
Remove discs from the compact disc
player when you are not listening to
them. Store them in their plastic cases
away from moisture, heat, and direct
sunlight.
