engine TOYOTA MATRIX 2013 E140 / 2.G Owners Manual

448 6-1. Specifications
Automatic transmission
Fluid capacity (Reference)1.8 L 4-cylinder (2ZR-FE) engine
6.9 qt. (6.5 L, 5.7 Imp. qt.)
2.4 L 4-cylinder (2AZ-FE) engine (2WD
models)
8.2 qt. (7.8 L, 6.9 Imp. qt.)
2.4 L 4-cylinder (2AZ-FE) engine (AWD
models)
8.6 qt. (8.1 L, 7.1 Imp. qt.)
Fluid type Toyota Genuine ATF WS
NOTICE
■Automatic transmission fluid type
Using automatic transmission fluid other than “Toyota Genuine ATF WS”
may cause deterioration in shift quality, locking up of your transmission
accompanied by vibration, and ultimately damage the transmission of your
vehicle.

450 6-1. Specifications
Brakes
*1: Minimum pedal clearance when depressed with a force of 66 lbf (294 N, 30
kgf) while the engine is running
*2: 2.4 L 4-cylinder (2AZ-FE) engine with 18-inch tires or AWD models
*3: Parking brake lever travel when pulled up with a force of 44 lbf (200 N, 20
kgf)
Pedal clearance*1
1.8 L 4-cylinder (2ZR-FE) engine
3.4 in. (87 mm)
2.4 L 4-cylinder (2AZ-FE) engine
• AWD models: 3.4 in. (87 mm)
• 2WD models with P215/45R18 tires:
3.4 in. (87 mm)
• 2WD models with tires other than the
above: 3.3 in. (85 mm)
Pedal free play 0.04  0.24 in. (1  6 mm)
Brake pad wear limit 0.04 in. (1.0 mm)
Parking brake lining wear limit*20.04 in. (1.0 mm)
Parking brake lever travel*36  9 clicks
Fluid type SAE J1703 or FMVSS No.116 DOT 3

454
6-1. Specifications
Fuel infor mation
■Fuel tank opening for unleaded gasoline
To help prevent incorrect fueling, your Toyota has a fuel tank opening that
only accommodates the special nozzle on unleaded fuel pumps.
■If your engine knocks
●Consult your Toyota dealer.
●You may occasionally notice light knocking for a short time while acceler-
ating or driving uphill. This is normal and there is no need for concern.
■Gasoline quality
In very few cases, driveability problems may be caused by the brand of gas-
oline you are using. If driveability problems persist, try changing the brand of
gasoline. If this does not correct the problem, consult your Toyota dealer.
■Gasoline quality standards
●Automotive manufacturers in the U.S., the Europe and Japan have
developed a specification for fuel quality called World-Wide Fuel Charter
(WWFC) that is expected to be applied worldwide.
●The WWFC consists of four categories that are based on required emis-
sion levels. In the U.S., category 4 has been adopted.
●The WWFC improves air quality by lowering emissions in vehicle fleets,
and improves customer satisfaction through better performance.
■Toyota recommends the use of gasoline containing detergent additives
●Toyota recommends the use of gasoline that contains detergent additives
to avoid build-up of engine deposits.
●All gasoline sold in the U.S. contains detergent additives to clean and/or
keep clean intake systems.
Your vehicle must use only unleaded gasoline.
Select octane rating 87 (Research Octane Number 91) or higher. Use
of unleaded gasoline with an octane rating lower than 87 may result
in engine knocking. Persistent knocking can lead to engine damage.
At minimum, the gasoline you use should meet the specifications
of ASTM D4814 in the U.S.A. and CGSB3.5-M93 in Canada.

456 6-1. Specifications
NOTICE
■Notice on fuel quality
●Do not use improper fuels. If improper fuels are used the engine will be
damaged.
●Do not use leaded gasoline.
Leaded gasoline can cause damage to your vehicle’s catalytic converters
causing the emission control system to malfunction.
●Do not use gasohol other than that stated here.
Other gasohol may cause fuel system damage or vehicle performance
problems.
●Using unleaded gasoline with an octane number or rating lower than that
stated here will cause persistent heavy knocking.
At worst, this will lead to engine damage.
■Fuel-related poor driveability
If after using a different type of fuel, poor driveability is encountered (poor
hot starting, vaporization, engine knocking, etc.), discontinue the use of that
type of fuel.
■When refueling with gasohol
Take care not to spill gasohol. It can damage your vehicle's paint.

463 6-1. Specifications
6
Vehicle specifications
Warning: The temperature grades for this tire are established for a
tire that is properly inflated and not overloaded.
Excessive speed, underinflation, or excessive loading, either sepa-
rately or in combination, can cause heat buildup and possible tire fail-
ure.
Glossary of tire terminology
Tire related termMeaning
Cold tire inflation pres-
sureTire pressure when the vehicle has been
parked for three hours or more, or has not
been driven more than 1 mile or 1.5 km under
that condition
Maximum inflation
pressureThe maximum cold inflated pressure to which a
tire may be inflated, shown on the sidewall of
the tire
Recommended infla-
tion pressureCold tire inflation pressure recommended by a
manufacturer
Accessory weightThe combined weight (in excess of those stan-
dard items which may be replaced) of auto-
matic transmission, power steering, power
brakes, power windows, power seats, radio
and heater, to the extent that these items are
available as factory-installed equipment
(whether installed or not)
Curb weightThe weight of a motor vehicle with standard
equipment, including the maximum capacity of
fuel, oil and coolant, and if so equipped, air
conditioning and additional weight optional
engine
Maximum loaded vehi-
cle weightThe sum of:
(a) Curb weight
(b) Accessory weight
(c) Vehicle capacity weight
(d) Production options weight

470 6-2. Customization
Door lock
(vehicles
with power
door lock
system)
(
P. 31)Unlocking using a keyDriver's door
unlocked in one
step, all doors
unlocked in two
stepsAll doors
unlocked in one
step
Opening driver's door
unlocks all doorsOff On
Shifting gears to P
unlocks all doors. (vehi-
cles with an automatic
transmission)On Off
Shifting gears to posi-
tion other than P locks
all doors. (vehicles with
an automatic transmis-
sion)On Off
Illumination
(
P. 279)Time elapsed before
lights turn off15 seconds7.5 seconds
30 seconds
Operation when the
doors are unlocked
(vehicles with power
door lock system)On Off
Operation after the
engine switch is turned
to the “LOCK” positionOn Off
Seat belt
reminder
(
P. 400)Vehicle speed linked
seat belt reminder
buzzerOn Off
ItemFunctionDefault settingCustomized
setting

490 Alphabetical index
Child safety
Airbag precautions ..................80
Battery precautions ....... 346, 429
Child restraint system..............90
Child-protectors .......................32
How your child should wear
the seat belt ..........................50
Installing child restraints ..........94
Moon roof precautions ............63
Power window lock switch.......59
Power window precautions .....60
Removed key battery
precautions ......................... 368
Seat belt extender
precautions ...........................52
Seat belt precautions ..............51
Child-protectors .........................32
Cleaning
Exterior .................................. 314
Interior ................................... 317
Seat belts .............................. 318
Clock ......................................... 292
Compass ................................... 309
Condenser ................................ 342
Console box ............................. 284
Cooling system
Engine overheating ............... 430
Cruise control........................... 148
Cup holder ................................ 285
Curtain shield airbags ...............73
Customizable features............. 469Daytime running light
system .................................... 140
Defogger
Rear window ......................... 193
Side mirror ............................ 193
Dimension ................................ 438
Dinghy towing .................. 181, 182
Display
Trip meter.............................. 132
Do-it-yourself maintenance .... 326
Doors
Door lock ........................... 28, 31
Door windows ......................... 59
Side mirrors............................. 57
Driver's seat belt reminder
light ......................................... 400
Driving
Break-in tips .......................... 109
Correct posture ....................... 71
Procedures............................ 106
Winter driving tips ................. 162D

491 Alphabetical index
Electric power steering........... 152
Emergency flashers
Switch ................................... 388
Emergency, in case of
If a warning light turns on ..... 397
If the engine will not start...... 422
If the shift lever cannot be
shifted from P ..................... 423
If the vehicle has a
discharged battery ............. 425
If the warning buzzer
sounds ............................... 397
If you have a flat tire ............ 408
If you lose your keys............. 424
If you think something is
wrong ................................. 395
If your vehicle becomes
stuck................................... 433
If your vehicle has to be
stopped in an emergency... 435
If your vehicle needs to be
towed ................................. 389
If your vehicle overheats ...... 430Engine
Compartment ........................335
Engine switch ........................118
Hood......................................330
How to start the
engine .................................118
Identification number .............439
If the engine will not start ......422
Ignition switch........................118
Overheating...........................430
Engine coolant
Capacity ................................445
Checking ...............................341
Preparing and checking
before winter .......................162
Engine coolant temperature
gauge ......................................132
Engine immobilizer system.......68
Engine oil
Capacity ................................443
Checking ...............................337
Preparing and checking
before winter .......................162
EPS ............................................152
Event data recorder ...................19E

493 Alphabetical index
I/M test ...................................... 325
Identification number
Engine .................................. 439
Vehicle.................................. 439
Ignition switch ......................... 118
Illuminated entry system ........ 280
Indicator lights ........................ 135
Initialization
Items to initialize ................... 471
Inside rear view mirror.............. 55
Interior lights
Interior lights ......................... 279
Switch ................................... 280
Wattage ................................ 453
Jack
Positioning a floor jack ......... 332
Vehicle-equipped jack .......... 408
Jack handle.............................. 408
Keyless entry ............................. 28
Keys
Engine switch ....................... 118
If you lose your keys............. 424
Ignition switch ....................... 118
Key number ............................ 26
Keyless entry .......................... 28
Keys ....................................... 26
Wireless remote control key ... 28License plate lights
Replacing light bulbs .............378
Switch....................................138
Wattage .................................453
Light bulbs
Replacing ..............................378
Wattage .................................453
Lights
Emergency flasher switch .....388
Fog light switch .....................141
Hazard light switch ................388
Headlights switch ..................138
Interior light switch ................280
Personal light switch .....281, 282
Replacing light bulbs .............378
Turn signal lever....................129
Wattage .................................453
Load capacity ...........................161
Lock steering column ..............120I
J
K
L

494 Alphabetical index
Maintenance
Do-it-yourself
maintenance ....................... 326
General maintenance ............ 322
Maintenance data.................. 438
Maintenance requirements.... 320
Manual transmission
Manual transmission ............. 127
Meter
Instrument panel light
control ................................. 134
Meters ................................... 132
Mirrors
Inside rear view mirror.............55
Side mirror heater ................. 193
Side mirrors .............................57
Vanity mirrors ........................ 291
Moon roof ...................................61
MP3 disc ................................... 215
Noise from under vehicle ..........18
Odometer .................................. 132
Oil
Engine oil .............................. 337
Opener
Fuel filler door .........................64
Hood...................................... 330
Outside rear view mirrors
Adjusting and folding ...............57
Outside temperature
display .................................... 132
Overheating, Engine ................430Parking brake ........................... 130
Parking lights
Replacing light bulb............... 378
Switch ................................... 138
Wattage................................. 453
Personal lights
Switch ........................... 281, 282
Wattage................................. 453
Power outlet ............................. 295
Power windows .......................... 59
Radiator .................................... 342
Radio ......................................... 203
Rear seats
Folding down........................... 44
Rear side marker lights
Replacing light bulb............... 378
Switch ................................... 138
Wattage................................. 453
Rear turn signal lights
Replacing light bulbs ............. 378
Switch ................................... 129
Wattage................................. 453
Rear view mirror
Compass ............................... 309
Rear window defogger ............ 193
Rear window wiper .................. 146
Replacing
Fuses .................................... 369
Key battery ............................ 367
Light bulbs............................. 378
Tires ...................................... 408
Reporting safety defects for
U.S.A. owners ........................ 474
Reset the maintenance
data ......................................... 321M
N
O
P
R
