TOYOTA MIRAI 2016 1.G Owners Manual

3818-2. Steps to take in an emergency
MIRAI_OM_USA_OM62004U
8
When trouble arises
If you have a flat tire
●Stop the vehicle in a safe place on a hard, flat surface.
● Set the parking brake.
● Shift the shift position to P.
● Stop the fuel cell system.
● Turn on the emergency flashers. ( P. 360)
Your vehicle is not equipped wi th a spare tire, but instead is
equipped with an emergency tire puncture repair kit.
A puncture caused by a nail or screw passing through the tire
tread can be repaired temporarily using the emergency tire
puncture repair kit. (The kit c ontains a bottle of sealant. The
sealant can be used only once to temporarily repair one tire
without removing the nail or screw from the tire.)
After temporarily repairing the tire with the repair kit, have the
tire repaired or replaced by your Toyota dealer.
WARNING
■If you have a flat tire
Do not continue driving with a flat tire.
Driving, even a short distance, with a flat tire can damage the tire, the
wheel, and other parts beyond repair, which could result in an accident.
Before repairing the tire

3828-2. Steps to take in an emergency
MIRAI_OM_USA_OM62004U
Location of the emergency tire puncture repair kit, tools and jack
Wheel nut wrench
Towing eyelet
Emergency tire puncture
repair kit
*: Use of the jack (P. 341)
Jack handle
Jack
*
1
2
3
4
5

3838-2. Steps to take in an emergency
MIRAI_OM_USA_OM62004U
8
When trouble arises
Emergency tire puncture repair kit components
Hose
Air release cap
Air pressure gaugeCompressor switch
Power plug
St ic ke rs1
2
3
4
5
6

3848-2. Steps to take in an emergency
MIRAI_OM_USA_OM62004U
Remove the luggage mat.
Remove the jack handle.
Take out the emergency tire
puncture repair kit.
Check the degree of the tire damage.
A tire should only be repaired with
the emergency tire puncture
repair kit if the damage is caused
by a nail or screw passing through
the tire tread. • Do not remove the nail or screw from the tire. Removing the
object may widen the opening
and disenable emergency
repair with the repair kit.
• To avoid sealant leakage, move th e vehicle until the area of the
puncture, if known, is positi oned at the top of the tire.
Taking out the emergency tire puncture repair kit
1
2
3
Before performing emergency repair

3858-2. Steps to take in an emergency
MIRAI_OM_USA_OM62004U
8
When trouble arises
Take out the repair kit from the plastic bag.
Remove the valve cap from the
valve of the punctured tire.
Remove the air release cap
from the hose.
You will use the air release cap
again. Therefore keep it in a safe
place.
Connect the hose to the valve.
Screw the end of the hose clock-
wise as far as possible.
Make sure that the compressor
switch is off.
Emergency repair method
1
2
3
4
5

3868-2. Steps to take in an emergency
MIRAI_OM_USA_OM62004U
Remove the rubber stopper
from the compressor.
Connect the power plug to the
power outlet socket. (P. 283)
Connect the bottle to the com-
pressor.
Make sure that the bottle is
securely connected.
6
7
8

3878-2. Steps to take in an emergency
MIRAI_OM_USA_OM62004U
8
When trouble arises
Attach the 2 stickers as shown.
Remove any dirt and moisture
from the wheel before attaching
the sticker.
Check the specified tire inflation
pressure.
Tire inflation pressure is specified
on the label as shown. (P. 421)
Start the fuel cell system. ( P. 172)
To inject the sealant and inflate
the tire, turn the compressor
switch on.
9
10
11
12

3888-2. Steps to take in an emergency
MIRAI_OM_USA_OM62004U
Inflate the tire until the specifiedair pressure is reached.
The sealant will be injected
and the pressure will spike to
44 psi (300 kPa, 3.1 kgf/cm
2
or bar) or 58 psi (400 kPa,
4.1 kgf/cm2 or bar), and then
gradually decrease.
The air pressure gauge will
display the actual tire infla-
tion pressure about 1 minute
(15 minutes at low tempera-
ture) after the switch is
turned on.
Inject to specified air pres-
sure.
• Turn the compressor switch off and then check the tire
inflation pressure. Being
careful not to over inflate,
check and repeat the infla-
tion procedure until the
specified tire inflation pres-
sure is reached.
• If the tire inflation pr essure is still lower than the specified point
after inflation for 10 minutes (40 minutes at low temperature) with
the switch on, the tire is too damaged to be repaired. Turn the
compressor switch off and contact your Toyota dealer.
• If the tire inflation pressure exceeds the specified air pressure, let out some air to adjust the tire inflation pressure. ( P. 421)
13
1
2
3

3898-2. Steps to take in an emergency
MIRAI_OM_USA_OM62004U
8
When trouble arises
With the compressor switch off, disconnect the hose from the valve
on the tire and then pull out the power plug from the power outlet
socket.
Some sealant may leak when the hose is removed.
Install the valve cap onto the valve of the emergency repaired tire.
Attach the air release cap to the
end of the hose.
If the air release cap is not
attached, the sealant may leak
and the vehicle may get dirty.
Temporarily store the bottle in the trunk while it is connected to the
compressor.
To spread the liquid sealant evenly within the tire, immediately drive
safely for about 3 miles (5 km) below 50 mph (80 km/h).
After driving for about 3 miles
(5 km), stop your vehicle in a
safe place on a hard, flat sur-
face and remove the air release
cap from the hose before
reconnecting the repair kit.
14
15
16
17
18
19

3908-2. Steps to take in an emergency
MIRAI_OM_USA_OM62004U
Turn the compressor switch on
and wait for several seconds,
and then turn it off. Check the
tire inflation pressure.If the tire inflation pressure is
under 19 psi (130 kPa,
1.3 kgf/cm
2 or bar): The
puncture cannot be repaired.
Contact your Toyota dealer.
If the tire inflation pressure is 19 psi (130 kPa, 1.3 kgf/cm
2 or bar)
or higher, but less than the specified air pressure: Proceed to
step .
If the tire inflation pressure is the specified air pressure: Proceed
to step .
Turn the compressor switch on to in flate the tire until the specified
air pressure is reached. Drive for about 3 miles (5 km) and then
perform step .
Attach the air release cap to the
end of the hose.
If the air release cap is not
attached, the sealant may leak
and the vehicle may get dirty.
Store the bottle in the trunk while it is connected to the compressor.
Taking precautions to avoid su dden braking, sudden acceleration
and sharp turns, drive carefully at under 50 mph (80 km/h) to the
nearest Toyota dealer tire repair or replacement.
20
1
2
21
3
22
21
19
22
23
24
