TOYOTA MR2 SPYDER 2000 Owners Manual (in English)

MR2 U
1382000 MR2 (OM17475U)
CAUTION
Never get under the vehicle when the
vehicle is supported by the jack
alone.
Changing wheels
SB41028
6. Remove the wheel nuts and changetires.
Lift the flat tire straight off and put it
aside.
Roll the compact spare wheel into position
and align the holes in the wheel with the
bolts. Then lift up the wheel and get at
least the top bolt started through its hole.
Wiggle the tire and press it back over the
other bolts.
SB41044
Before putting wheels on, remove any cor-
rosion on the mounting surfaces with a
wire brush or such. Installation of wheels
without good metal−to−metal contact at the
mounting surface can cause wheel nuts to
loosen and eventually cause a wheel to
come off while driving. Therefore after the
first 1600 km (1000 miles), check to see
that the wheel nuts are tight.

MR2 U
1392000 MR2 (OM17475U)
Reinstalling wheel nuts
SB41030
7. Reinstall all the wheel nuts with fin-ger tight.
Reinstall the wheel nuts (tapered end in-
ward) and tighten them as much as you
can by finger. Press back on the tire back
and see if you can tighten them more.
Lowering your vehicle
SB41031
8. Lower the vehicle completely and tighten the wheel nuts.
Turn the jack handle counterclockwise to
lower the vehicle.
Use only the wheel nut wrench and turn
it clockwise to tighten the nuts. Do not
use other tools or any additional leverage
other than your hands, such as a hammer,
pipe or your foot. Make sure the wrench
is securely engaged over the nut.
Tighten each nut a little at a time in the
order shown. Repeat the process until all
the nuts are tight.
CAUTION
When lowering the vehicle, make sure
all portions of your body and all oth-
er persons around will not be injured
as the vehicle is lowered to the
ground.

MR2 U
1402000 MR2 (OM17475U)
After changing wheels
9. Check the air pressure of the re-placed tire.
Adjust the air pressure to the specification
designated in Section 8. If the pressure is
lower, drive slowly to the nearest service
station and fill to the correct pressure.
Do not forget to reinstall the tire inflation
valve cap as dirt and moisture could get
into the valve core and possibly cause air
leakage. If the cap is missing, have a new
one put on as soon as possible.
10. Restow all the tools, jack and flat tire securely.
As soon as possible after changing
wheels, tighten the wheel nuts to the
torque specified in Section 8 with a torque
wrench. Have a technician repair the flat
tire and replace the compact spare tire
with it.CAUTION
Before driving, make sure all the
tools, jack and flat tire are securely
in place in their storage location to
reduce the possibility of personal in-
jury during a collision or s udden
braking.
SB41025
Remove the wheel ornament from the flat
tire before restowing the flat tire.

MR2 U
1412000 MR2 (OM17475U)
SB41037
NOTICE
The size of the front wheel and the
rear wheel is different. In order to
prevent the wrong installation, there
is a pin on the assembly surface in-
side the rear wheel as shown above.
Therefore, the rear wheels cannot be
installed on the front.
SB41016
From rear
(b) Using flat bed truck (a) Towing with wheel lift type truck From front
If towing is necessary, we recommend
you to have it done by your Toyota
dealer or a commercial tow truck ser-
vice. In consultation with them, have
your vehicle towed using either (a) or
(b).
Only when you cannot receive a towing
service from a Toyota dealer or com-
mercial tow truck service, tow your ve-
hicle carefully in accordance with the
instructions given in Emergency tow-
ing" in this Section.
Proper equipment will help ensure that
your vehicle is not damaged while being
towed. Commercial operators are generally
aware of the state/provincial and local
laws pertaining to towing.
Your vehicle can be damaged if it is
towed incorrectly. Although most operators
know the correct procedure, it is possible
to make a mistake. To avoid damage to
your vehicle, make sure the following pre-
cautions are observed. If necessary, show
this page to the tow truck driver.
TOWING PRECAUTIONS:
Use a safety chain system for all towing,
and abide by the state/provincial and local
laws. The wheels and axle on the ground
must be in good condition. If they are
damaged, use a towing dolly.
If your vehicle needs to be
towed

MR2 U
1422000 MR2 (OM17475U)
(a) Towing with wheel lift type truck
From frontWe recommend using a tow-
ing dolly under the rear wheels. If you do
not use a towing dolly, release the parking
brake and put the transmission in neutral.
From rear Place the ignition key in the
ACC" position.
NOTICE
 When lifting wheels, take care to
ensure adequate ground clearance
for towing at the opposite end of
the raised vehicle. Otherwise, the
bumper and/or underbody of the
towed vehicle will be damaged dur-
ing towing.
 Do not tow with the key removed or
in the LOCK" position, as the
steering lock mechanism is not
strong enough to hold the front
wheels straight while towing.
(b) Using flat bed truck
SB41057
(c) Towing with sling type truck
(c) Towing with sling type truck
NOTICE
Do not tow with sling type truck, ei-
ther from the front or rear. This may
cause body damage.
Em erg en cy to win g
SB41045
Remove the cover (front)
SB41033
Install the eyelet (front)

MR2 U
1432000 MR2 (OM17475U)
SB41046
Remove the cover (rear)
SB41034
Install the eyelet (rear)
If towing is necessary, we recommend
you to have it done by your Toyota
dealer or a commercial tow truck ser-
vice.
If a towing service is not available in
an emergency, your vehicle may be
temporarily towed by a cable or chain
secured to either the emergency towing
eyelet
∗ on the front of the vehicle or
the right emergency towing eyelet∗ on
the rear of the vehicle. Use extreme
caution when towing vehicles.
NOTICE
Only use specified towing eyelet;
otherwise your vehicle may be dam-
aged.
A driver must be in the vehicle to steer
it and operate the brakes.
Towing in this manner may be done only
on hard−surfaced roads for a short dis-
tance and at low speeds. Also, the
wheels, axles, drive train, steering and
brakes must all be in good condition.
∗: Eyelet
The eyelet is stored in the luggage space
with the jack handle.
To install: Remove the cover of eyelet and
firmly install it as shown in the illustration.

MR2 U
1442000 MR2 (OM17475U)
CAUTION
Use extreme caution when towing a
vehicle. Avoid sudden starts or er-
ratic driving maneuvers which
would place excessive stress on the
emergency towing eyelets and tow-
ing cable or chain. The eyelets and
towing cable or chain may break
and cause serious injury or dam-
age.
When installing the eyelet on the
vehicle, be sure to tighten the eye-
let securely. If the tightening is
loose, it may come off when being
towed and result in death or seri-
ous injury.
NOTICE
Use only a cable or chain specifi-
cally intended for use in towing ve-
hicles. Securely fasten the cable or
chain to the towing eyelets pro-
vided.
 Do not use the left rear eyelet. It is
not designed for towing.
Before towing, release the parking brake
and put the transmission in neutral. The
key must be in ACC" (engine off) or ON"
(engine running).
CAUTION
If the engine is not running, the pow-
er assist for the brakes and steering
will not work so steering and braking
will be much harder than usual.
If you lose your keys
You can purchase a new key at your
Toyota dealer if you can give them the
key number and master key.
Even if you lose only one key, contact
your Toyota dealer to make a new key. If
you lose all your master keys, you cannot
make new keys; the whole engine immobi-
liser system must be replaced.
See the suggestion given in Keys" in
Section 1−2.
If your keys are locked in the vehicle and
you cannot get a duplicate, many Toyota
dealers can still open the door for you,
using their special tools. If you must
break a window to get in, we suggest
breaking the side window because it is
the least expensive to replace. Be ex-
tremely cautious to avoid cuts from the
glass.

MR2 U
1452000 MR2 (OM17475U)
IN CASE OF AN EMERGENCY
If your vehicle will not start146
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
If your engine stalls while driving 149
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
If your vehicle overheats 149
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
If you have a flat tire 150
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . .
If your vehicle needs to be towed 159
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
If you lose your keys 162
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . .
SECTION 4

MR2 U
1462000 MR2 (OM17475U)
Before making these checks, make sure
you have followed the correct starting
procedure given in How to start the
engine" in Section 3 and that you have
sufficient fuel. Also check whether the
other keys will start the engine. If they
work, your key may be broken. Have the
key checked at your Toyota dealer. If
none of your keys work, the engine
immobiliser system is possibly broken.
Call your Toyota dealer. (See Keys" in
Section 1−2.)
If the engine is not turning over or is
turning over too slowly1. Check that the battery terminals are tight and clean.
2. If the battery terminals are O.K., switch on the interior light.
3. If the light is out, dim or goes out when the starter is cranked, the battery
is discharged. You may try jump start-
ing. See (c) Jump starting" for further
instructions.
If the light is O.K., but the engine still will
not start, it needs adjustment or repair.
Call a Toyota dealer or qualified repair
shop.NOTICE
Do not pull− or push−start the ve-
hicle. It may damage the vehicle or
cause a collision when the engine
starts. Also the three−way catalytic
converter may overheat and become a
fire hazard.
If the engine turns over at its normal
speed but will not start
1. The engine may be flooded because of repeated cranking. See (b) Starting a
flooded engine" for further instructions.
2. If the engine still will not start, it needs adjustment or repair. Call a Toyota
dealer or qualified repair shop.
(b) Starting a flooded engine
If the engine will not start, your engine
may be flooded because of repeated
cranking.
If this happens, turn the key to START"
with the accelerator pedal held down.
Keep the key and accelerator pedal in
these positions for 15 seconds and re-
lease them. Then try starting the engine
with your foot off the accelerator pedal.
If the engine does not start after 15 sec-
onds of cranking, release the key, wait a
few minutes and try again.
If the engine still will not start, it needs
adjustment or repair. Call a Toyota dealer
or qualified repair shop for assistance.
NOTICE
Do not crank for more than 30 sec-
onds at a time. This may overheat the
starter and wiring systems.
If your vehicle will not start
(a) Simple checks

MR2 U
1472000 MR2 (OM17475U)
(c) Jump starting
To avoid serious personal injury and
damage to your vehicle which might re-
sult from battery explosion, acid burns,
electrical burns, or damaged electronic
components, these instructions must be
followed precisely.
If you are unsure about how to follow this
procedure, we strongly recommend that
you seek the help of a competent me-
chanic or towing service.
CAUTION
Batteries contain sulfuric acid
which is poisonous and corrosive.
Wear protective safety glasses when
jump starting, and avoid spilling
acid on your skin, clothing, or ve-
hicle.
If you should accidentally get acid
on yourself or in your eyes, remove
any contaminated clothing and flush
the affected area with water imme-
diately. Then get immediate medical
attention. If possible, continue to
apply water with a sponge or cloth
while en route to the medical office.
The gas normally produced by a
battery will explode if a flame or
spark is brought near. Use only
standardized jumper cables and do
not smoke or light a match while
jump starting.
NOTICE
The battery used for boosting must
be 12 V. Do not jump start unless you
are sure that the booster battery is
correct.
JUMP STARTING PROCEDURE1. If the booster battery is installed in another vehicle, make sure the vehicles
are not touching. Turn off all unneces-
sary lights and accessories.
2. If required, remove all the vent plugs from the booster and discharged batter-
ies. Lay a cloth over the open vents
on the batteries. (This helps reduce the
explosion hazard, personal injuries and
burns.) 3. If the engine in the vehicle with the
booster battery is not running, start it
and let it run for a few minutes. During
jump starting, run the engine at about
2000 rpm with the accelerator pedal
lightly depressed.
