TOYOTA MR2 SPYDER 2000 (in English) Workshop Manual

MR2 U
482000 MR2 (OM17475U)
SB13057
1. Run the lap and shoulder belt throughor around the infant seat following the
instructions provided by its manufactur-
er and insert the tab into the buckle
taking care not to twist the belt. Keep
the lap portion of the belt tight.
CAUTION
After inserting the tab, make sure
the tab and buckle are locked and
that the lap and shoulder portions
of the belt are not twisted.
Do not insert coins, clips, etc. in
the buckle as this can prevent your
child from properly latching the tab
and buckle.
If the seat belt does not function
normally, it cannot protect your
child from injury. Contact your
Toyota dealer immediately. Do not
use the seat until the seat belt is
fixed.
SB13058
2. Fully extend the shoulder belt to put itin the lock mode. When the belt is
then retracted even slightly, it cannot
be extended.
To hold the infant seat securely, make
sure the belt is in the lock mode before
letting the belt retract.

MR2 U
492000 MR2 (OM17475U)
SB13059
3. While pressing the infant seat firmlyagainst the seat cushion and seatback,
let the shoulder belt retract as far as
it will go to hold the infant seat secure-
ly.
SB13060
CAUTION
Push and pull the child restraint sys-
tem in different directions to be sure
it is secure. Follow all the installation
instructions provided by its manufac-
turer.
SB13095
4. To remove the infant seat, press thebuckle−release button and allow the
belt to retract completely. The belt will
move freely again and be ready to
work for an adult or older child passen-
ger.

MR2 U
502000 MR2 (OM17475U)
SB13062
(B) CONVERTIBLE SEAT INSTALLATION
A convertible seat is used in forward−
facing or rear−facing position depend-
ing on the child’s age and size. When
installing, follow the manufacturer’s in-
struction about the applicable child’s
age and size as well as directions for
installing the child restraint system.
SB13101
CAUTION
Rear−facing child restraint system:
Never put a rear−facing child restraint
system on the passenger seat with
the passenger airbag manual on−off
switch in the ON" position. In the
event of an accident, the force of the
rapid inflation of the passenger air-
bag can cause death or serious injury
to the child.
SB13082
When you put a forward−facing or a
rear−facing child restraint system which
belongs to a passenger risk group on
the passenger seat, turn the passenger
airbag manual on−off switch counter-
clockwise to the OFF" position. (For
details, see SRS driver and passenger
airbags" in this Section.)
The indicator comes on when the system
is off.

MR2 U
512000 MR2 (OM17475U)
CAUTION
If you must put a rear−facing child
restraint system on the passenger
seat, make sure the passenger airbag
manual on−off switch is in the OFF"
position and that the indicator light is
on.
CAUTION
Forward−facing child restraint system:
A forward−facing child restraint sys-
tem which belongs to a passenger
risk group should never be put on
the passenger seat with the passen-
ger airbag manual on−off switch in
the ON" position, because the force
of a deploying airbag could cause
death or serious injury to the child in
forward seating position. (For details,
see SRS driver and passenger air-
bags" in this Section.)
SB13083
1. Run the lap and shoulder belt throughor around the convertible seat following
the instructions provided by its
manufacturer and insert the tab into
the buckle taking care not to twist the
belt. Keep the lap portion of the belt
tight.

MR2 U
522000 MR2 (OM17475U)
CAUTION
After inserting the tab, make sure
the tab and buckle are locked and
that the lap and shoulder portions
of the belt is not twisted.
Do not insert coins, clips, etc. in
the buckle as this may prevent your
child from properly latching the tab
and buckle.
If the seat belt does not function
normally, it cannot protect your
child from injury. Contact your
Toyota dealer immediately. Do not
use the seat until the seat belt is
fixed.
SB13084
2. Fully extend the shoulder belt to put itin the lock mode. When the belt is
then retracted slightly, it cannot be ex-
tended.
To hold the convertible seat securely,
make sure the belt is in the lock mode
before letting the belt retract.
SB13085
3. While pressing the convertible seat firmly against the seat cushion and
seatback, let the shoulder belt retract
as far as it will go to hold the convert-
ible seat securely.

MR2 U
532000 MR2 (OM17475U)
SB13086
CAUTION
Push and pull the child restraint sys-
tem in different directions to be sure
it is secure. Follow all the installation
instructions provided by its manufac-
turer.
SB13096
4. To remove the convertible seat, pressthe buckle−release button and allow the
belt to retract completely. The belt will
move freely again and be ready to
work for an adult or older child passen-
ger.
SB13087
(C) BOOSTER SEAT INSTALLATION
A booster seat is used in forward−fac-
ing position only.

MR2 U
542000 MR2 (OM17475U)
CAUTION
A forward−facing child restraint sys-
tem which belongs to a passenger
risk group should never be put on
the passenger seat with the passen-
ger airbag manual on−off switch in
the ON" position, because the force
of a deploying airbag could cause
death or serious injury to the child in
forward seating position. (For details,
see SRS driver and passenger air-
bags" in this Section.)
SB13082
When you put a forward−facing child
restraint system which belongs to pas-
senger risk group on the passenger
seat, turn the passenger airbag manual
on−off switch counterclockwise to the
OFF" position. (For details, see SRS
driver and passenger airbags" in this
Section.)
The indicator comes on when the system
is off.
SB13064
1. Sit the child on a booster seat. Runthe lap and shoulder belt through or
around the booster seat and child fol-
lowing the instructions provided by its
manufacturer and insert the tab into
the buckle taking care not to twist the
belt.
Make sure the shoulder belt is correctly
across the child’s shoulder and that the
lap belt is positioned as low as possible
on child’s hips. See Seat belts" in this
Section for details.

MR2 U
552000 MR2 (OM17475U)
CAUTION
Always make sure the shoulder belt
is positioned across the center of
child’s shoulder. The belt should be
kept away from child’s neck, but
not falling off child’s shoulder. Fail-
ure to do so could reduce the
amount of protection in an accident
and increase the chance of injury.
Both high−positioned lap belts and
loose−fitting belts could cause seri-
ous injuries due to sliding under
the lap belt during a collision or
other unintended result. Keep the
lap belt positioned as low on hips
as possible.
For child’s safety, do not place the
shoulder belt under child’s arm.
After inserting the tab, make sure
the tab and buckle are locked and
that the lap and shoulder portions
of the belt is not twisted.
Do not insert coins, clips, etc. in
the buckle as this may prevent your
child from properly latching the tab
and buckle.
If the seat belt does not function
normally, it cannot protect your
child from injury. Contact your
Toyota dealer immediately. Do not
use the seat until the seat belt is
fixed.
SB13097
2. To remove the child restraint system, press the buckle−release button and al-
low the belt to retract.

MR2 U
562000 MR2 (OM17475U)
Tilt steering wheel
SB13049
To change the steering wheel angle,
hold the steering wheel, push the lock
release lever, tilt the steering wheel to
the desired angle and return the lever
to its original position.
CAUTION
Do not adjust the steering wheel
while the vehicle is moving. It may
cause the driver to mishandle the
vehicle and an accident may occur
resulting in personal death or inju-
ries.
After adjusting the steering wheel,
try moving it up and down to make
sure it is locked in position.
Outside rear view mirrors
SB13050
Adjust the mirror so that you can see
the side of your vehicle in the mirror.
Be careful when judging the size or dis-
tance of any object seen in the outside
rear view mirror. It is a convex mirror with
a curved surface. Any object seen in a
convex mirror will look smaller and farther
away than when seen in a flat mirror.
CAUTION
Do not adjust the mirror while the
vehicle is moving. It may cause the
driver to mishandle the vehicle and
an accident may occur resulting in
personal death or injuries.
Power rear view mirror control
SB13099
To adjust a mirror, use the switches.1. Master switchTo select the mirror to be adjusted
Place the switch at L" (left) or R"
(right).
2. Control switchTo move the mirror Push the switch in the desired direc-
tion.
Mirror can be adjusted when key is in the
ACC" or ON" position.
NOTICE
If ice should jam the mirror, do not
operate the control or scrape the mir-
ror face. Use a spray de−icer to free
the mirror.

MR2 U
572000 MR2 (OM17475U)
Folding rear view mirrors
SB13051
The rear view mirrors can be folded
backward for parking in restricted
areas.
To fold the rear view mirror, push back-
ward.
CAUTION
Do not drive with the mirrors folded
backward. Both the driver and pas-
senger side rear view mirrors must
be extended and properly adjusted
before driving.
SB13088
Adjust the mirror so that you can just
see the rear of your vehicle in the mir-
ror.
To reduce glare from the headlights of
the vehicle behind you during night
driving, operate the lever on the lower
edge of the mirror.
Daylight drivingLever at position 1
The reflection in the mirror has greater
clarity at this position.
Night drivingLever at position 2
Remember that by reducing glare you also
lose some rear view clarity.
CAUTION
Do not adjust the mirror while the
vehicle is moving. It may cause the
driver to mishandle the vehicle and
an accident may occur resulting in
personal death or injuries.
Anti−glare inside rear view
mirror
