fuse box TOYOTA MR2 SPYDER 2002 W30 / 3.G Owners Manual

02 MY MR2 SMT(U) L/O 0108
202
01 06 12
2002 MR2 (OM17493U)
Checking and replacing fuses
SB73035
GoodBlown
Ty p e A
SB73036
Good Blown
Ty p e B
SB73037
Good Blown
Ty p e C
SB73066
If the headlights or other electrical
components do not work, check the
fuses. If any of the fuses are blown,
they must be replaced.
See “Fuse locations” on page 182 in Sec-
tion 71 for locations of the fuses.
Turn the ignition switch and inoperative
component off. Pull a suspected fuse
straight out and check it.
Determine which fuse may be causing the
problem. The lid of the fuse box shows
the name of the circuit for each fuse. See
page 219 in Section 8 of this manual for
the functions controlled by each circuit.
Type A fuses can be pulled out by the
pullout tool. The location of the pullout
tool is shown in the illustration.

02 MY MR2 SMT(U) L/O 0108
203
01 06 12
2002 MR2 (OM17493U)
If you are not sure whether the fuse has
blown, try replacing the suspected fuse
with one that you know is good.
If the fuse has blown, push a new fuse
into the clip.
Only install a fuse with the amperage rat-
ing designated on the fuse box lid.
If you do not have a spare fuse, in an
emergency you can pull out the “D P/W”,
“P P/W” or “CIG” fuse, which may be
dispensable for normal driving, and use it
if its amperage rating is the same.
If you cannot use one of the same amper-
age, use one that is lower, but as close
as possible to the rating. If the amperage
is lower than that specified, the fuse
might blow out again but this does not
indicate anything wrong. Be sure to get
the correct fuse as soon as possible and
return the substitute to its original clip.
It is a good idea to purchase a set of
spare fuses and keep them in your ve-
hicle for emergencies.
If the new fuse immediately blows out,
there is a problem with the electrical sys-
tem. Have your Toyota dealer correct it as
soon as possible.CAUTION
Never use a fuse with a higher am-
perage rating, or any other object, in
place of a fuse. This may cause ex-
tensive damage and possibly a fire.
Adding washer fluid
SB73003
If any washer does not work, the wash-
er tank may be empty. Check the wash-
er fluid level on the level gauge. If the
washer fluid level is below “LOW”, add
washer fluid.
You may use plain water as washer fluid.
However, in cold areas where tempera-
tures range below freezing point, use
washer fluid containing antifreeze. This
product is available at your Toyota dealer
and most auto parts stores. Follow the
manufacturer ’s directions for how much to
mix with water.

02 MY MR2 SMT(U) L/O 0108
228
01 06 12
2002 MR2 (OM17493U)
A
Adding washer fluid203
. . . . . . . . . . . . . . . .
Adjustment
Seats 28
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Seat belt 30
. . . . . . . . . . . . . . . . . . . . . . . . .
Air conditioning system 107
. . . . . . . . . . . . .
Airbags 36
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Aluminum wheel precautions 197 . . . . . . . .
Antiglare inside rear view mirror 59 . . . . .
Antilock brake system warning light 70
. . . . . . . . . . . . . . . . . . . . . .
Antitheft steering column lock 76 . . . . . . .
Appearance care Cleaning the interior 170
. . . . . . . . . . . . . .
Protecting your Toyota from
corrosion 166
. . . . . . . . . . . . . . . . . . . . . .
Washing and waxing 167
. . . . . . . . . . . . . .
Auxiliary box 118
. . . . . . . . . . . . . . . . . . . . . .
Auxiliary catch, Trunk lid 14
. . . . . . . . . . . . .
B
Battery
Checking battery condition 200 . . . . . . . .
Gas caution 200 . . . . . . . . . . . . . . . . . . . . .
Handling safety 200 . . . . . . . . . . . . . . . . . .
Recharging precautions 201 . . . . . . . . . . .
Winter driving tips 140 . . . . . . . . . . . . . . . .
Before starting the engine 138 . . . . . . . . . . .
Brake pad wear limit indicators 132 . . . . . .
Brake system 129 . . . . . . . . . . . . . . . . . . . . . .
Brake system warning light 70 . . . . . . . . . . Brakes
Fluid level 191 . . . . . . . . . . . . . . . . . . . . . . .
Pad wear limit indicators 132 . . . . . . . . . .
Parking 89 . . . . . . . . . . . . . . . . . . . . . . . . . .
Breakin tips 124 . . . . . . . . . . . . . . . . . . . . . .
Brightness control 64 . . . . . . . . . . . . . . . . . . .
C
Car audio system 93
. . . . . . . . . . . . . . . . . . .
Carbon monoxide caution 127
. . . . . . . . . . .
Cassette player 94
. . . . . . . . . . . . . . . . . . . . .
Checking and replacing fuses 202 . . . . . . . .
Checking brake fluid 191
. . . . . . . . . . . . . . . .
Checking the engine oil level 188 . . . . . . . .
Checking power steering fluid 191 . . . . . . .
Child restraint Child restraint system 46
. . . . . . . . . . . . .
Installation with seat belt 48
. . . . . . . . . . .
Precautions 46
. . . . . . . . . . . . . . . . . . . . . .
Types of child restraint system 47 . . . . . .
Cigarette lighter and ashtray 116
. . . . . . . . .
Cleaning the interior 170
. . . . . . . . . . . . . . . .
Clock 116
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cold weather operation 140
. . . . . . . . . . . . .
Compact disc player 94
. . . . . . . . . . . . . . . . .
Cooling system
Coolant level 189
. . . . . . . . . . . . . . . . . . . .
Engine overheating 150
. . . . . . . . . . . . . . .
Radiator and condenser 190
. . . . . . . . . . .
Radiator and reservoir 189
. . . . . . . . . . . .
Radiator cap 150
. . . . . . . . . . . . . . . . . . . . .
Winter driving tips 140
. . . . . . . . . . . . . . . . Corrosion prevention
166
. . . . . . . . . . . . . . .
Cruise control 90
. . . . . . . . . . . . . . . . . . . . . .
Cup holders 121
. . . . . . . . . . . . . . . . . . . . . . .
D
Defogger, Rear window 65
. . . . . . . . . . . . . .
Dimensions and weight 214
. . . . . . . . . . . . .
Dimmer switch, Headlight 62
. . . . . . . . . . . .
Dinghy towing 141
. . . . . . . . . . . . . . . . . . . . .
Directional signals 62
. . . . . . . . . . . . . . . . . .
Discharge warning light 70
. . . . . . . . . . . . . .
Doityourself maintenance
Parts and tools 184
. . . . . . . . . . . . . . . . . . .
Service precautions 183
. . . . . . . . . . . . . .
Does your vehicle need repairing? 177
. . . . . . . . . . . . . . . . . . . . . . .
Driver ’s seat belt light 70
. . . . . . . . . . . . . . .
Driver ’s seat belt reminder buzzer 70 . . . . .
Driving Driving tips 139,140
. . . . . . . . . . . . . . . . . .
Manual transmission 88
. . . . . . . . . . . . . .
Sequential manual transmission 77 . . . .
Driving tips
Driving tips in various conditions 139
. . . . . . . . . . . . . . . . . . . . .
Driving with a manual
transmission 88
. . . . . . . . . . . . . . . . . . . .
Economical driving 142
. . . . . . . . . . . . . . .
Good driving practice 88
. . . . . . . . . . . . . .
Winter driving tips 140
. . . . . . . . . . . . . . . .
During Breakin 124
. . . . . . . . . . . . . . . . . . . . . . . .


02 MY MR2 SMT(U) L/O 0108
229
01 06 12
2002 MR2 (OM17493U)
E
Economical drivingSaving money on both fuel
and repairs 142 . . . . . . . . . . . . . . . . . . . .
Electrical system Battery 200,201 . . . . . . . . . . . . . . . . . . . . . .
Fuse locations 182 . . . . . . . . . . . . . . . . . . .
Fuses 202 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Emergency flasher switch 63 . . . . . . . . . . . .
Emergency, In case of Blown fuse 202 . . . . . . . . . . . . . . . . . . . . . .
Emergency flasher switch 63 . . . . . . . . . .
Flat tire 151 . . . . . . . . . . . . . . . . . . . . . . . . .
If you cannot increase the engine speed 149 . . . . . . . . . . . . . . . . . .
If you cannot shift the sequential manual transmission
selector lever 164 . . . . . . . . . . . . . . . . . .
If you lose your keys 164 . . . . . . . . . . . . . .
If your engine stalls while driving 149 . . . . . . . . . . . . . . . . . . .
If your vehicle needs to be towed 160 . . . . . . . . . . . . . . . . . . . .
If your vehicle will not start 146 . . . . . . . .
Jump starting 147 . . . . . . . . . . . . . . . . . . . .
Overheating 150 . . . . . . . . . . . . . . . . . . . . .
Towing 160 . . . . . . . . . . . . . . . . . . . . . . . . . .
Emissions Inspection and Maintenance (I/M) programs 178 . . . . . . .
Engine Before starting the engine 138 . . . . . . . . .
Checking the coolant level 189 . . . . . . . . Emission control device 126
. . . . . . . . . . .
Engine compartment 180 . . . . . . . . . . . . . .
Exhaust gas caution 127 . . . . . . . . . . . . . .
Hood release 16 . . . . . . . . . . . . . . . . . . . . .
Oil consumption 128 . . . . . . . . . . . . . . . . . .
Oil level 188 . . . . . . . . . . . . . . . . . . . . . . . . .
Overheating 150 . . . . . . . . . . . . . . . . . . . . .
Starting procedure 137 . . . . . . . . . . . . . . .
Threeway catalytic converter 126 . . . . .
Engine coolant
Temperature gauge 68 . . . . . . . . . . . . . . . .
Winter driving tips 140 . . . . . . . . . . . . . . . .
Engine coolant temperature gauge 68 . . . .
Engine immobiliser system 10 . . . . . . . . . . .
Engine oil Winter driving tips 140 . . . . . . . . . . . . . . . .
Exhaust gas cautions 127 . . . . . . . . . . . . . . .
F
Facts about engine oil
consumption 128 . . . . . . . . . . . . . . . . . . . . .
Flasher, Headlight 62 . . . . . . . . . . . . . . . . . . .
Flat tire
After changing wheels 158 . . . . . . . . . . . .
Changing tire 157 . . . . . . . . . . . . . . . . . . . .
If you have a flat tire 151 . . . . . . . . . . . . . .
Jack point 156 . . . . . . . . . . . . . . . . . . . . . . .
Jacking precautions 151 . . . . . . . . . . . . . .
Jacking up 156 . . . . . . . . . . . . . . . . . . . . . .
Loosening wheel nuts 155 . . . . . . . . . . . . .
Lowering vehicle 158 . . . . . . . . . . . . . . . . .
Wheel block 155 . . . . . . . . . . . . . . . . . . . . . Wheel nuts 157
. . . . . . . . . . . . . . . . . . . . . .
Floor mat 121 . . . . . . . . . . . . . . . . . . . . . . . . . .
Fluid level Brake 191 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power steering 191 . . . . . . . . . . . . . . . . . . .
Washer fluid 203 . . . . . . . . . . . . . . . . . . . . .
Foreign countries, Operation in 126 . . . . . .
Front box 117 . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuel Filler door o pener 18. . . . . . . . . . . . . . . . .
Fuel economy 142 . . . . . . . . . . . . . . . . . . . .
Fuel pump shut off system 126 . . . . . . . . .
Gauge 68 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Operation in foreign countries 126 . . . . .
Tank cap 18 . . . . . . . . . . . . . . . . . . . . . . . . .
Fuel information 124 . . . . . . . . . . . . . . . . . . . .
Fuel pump shut off system 126 . . . . . . . . . .
Fuses Fuse box 202 . . . . . . . . . . . . . . . . . . . . . . . .
Fuse locations 182 . . . . . . . . . . . . . . . . . . . . .
G
Gauge
Engine temperature 68 . . . . . . . . . . . . . . .
Fuel 68 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
General maintenance 175 . . . . . . . . . . . . . . .
Glove box 117 . . . . . . . . . . . . . . . . . . . . . . . . .
Good driving practice Manual transmission 88 . . . . . . . . . . . . . .
