TOYOTA MR2 SPYDER 2004 W30 / 3.G Owners Manual

1232004 MR2 from Feb. ’04 Prod. (OM17518U)
ASHTRAY
To use the ashtray, pull out the lid.
When finished with your cigarette, thor-
oughly extinguish it in the ashtray to pre-
vent other cigarette butts from catching
fire. After using the ashtray, close the lid
completely.
To remove the ashtray, pull the lid and
pull it out.
CAUTION
To reduce the chance of injury in
case of an accident or sudden stop
while driving, always completely close
the ashtray after use.
Glove box
SB19026
To use the glove box, do this.
To open: Compress the lock release but-
tons.
To lock: Insert the master key and turn it
clockwise.
CAUTION
To reduce the chance of injury in
case of an accident or a sudden stop,
always keep the glove box door
closed while driving.
Front box
SB41047
To use the front box in the trunk, do
this.1. Open the trunk lid, and pull the lock release lever.

1242004 MR2 from Feb. ’04 Prod. (OM17518U)
SB19031a
2. Fix the cover by hitching the inside clipon the hood.
NOTICE
Do not place valuables in the front
box to prevent robbery.
 Do not place anything which weighs
over 5 kg (11 lb.) in the front box.
If something weighs over 5 kg (11
lb.) is placed in the front box while
driving, the front box may be dam-
aged.
 Be sure to lock the cover securely
when you close the trunk lid. If the
cover is not securely locked, it may
cause damage to the trunk lid.
SB19018
Front of vehicle
DRAINAGE OF THE FRONT BOX
In case that the water is pooled inside the
front box, remove the grommet on the
bottom of the box to drain the water.
NOTICE
Since the front box is not waterproof
completely, it is possible for the
things stored in the box to the
drenched.
Auxiliary box
SB19019
Instrument panel
To use the box, open it as shown in
the illustration.
CAUTION
To reduce the chance of injury in
case of an accident or a sudden stop,
always keep the auxiliary box closed
while driving.

1252004 MR2 from Feb. ’04 Prod. (OM17518U)
NOTICE
During hot weather, the interior of the
vehicle becomes very hot. Do not
leave anything flammable or deform-
able such as a lighter, glasses, etc.
inside.
Luggage space
SB19027a
Lean the seatback forward to use the
luggage space.
To open: Pull the lever.
To lock: Insert the master key and turn it
clockwise.
SB12059a
Folding boardFlare
CAUTION
To reduce the chance of injury in
case of an accident or a sudden stop,
always keep the luggage space door
closed while driving.

1262004 MR2 from Feb. ’04 Prod. (OM17518U)
NOTICE
Do not place valuables in the lug-
gage space to prevent robbery.
 Do not lower the soft top while
placing a luggage which is higher
than the bottom edge of the flare
inside the luggage space.
The luggage may be damaged by
hitting the folding board or the im-
properly folded soft top may flap in
the wind and cause an accident.
SB19030
When you load a long luggage
Remove the side trims on the both sides
in the luggage space when you need to
load a long luggage (except tapered
things) such as a golf bag.
The side trims can be removed by pulling
the clips (at two places).
SB19029
Removing the side trims
SB19028
Installing the side trims

1272004 MR2 from Feb. ’04 Prod. (OM17518U)
NOTICE
Do not place tapered things or a
long luggage into the luggage
space. That may damage the water
receiving bag installed behind the
side trims.
 Do not lower the soft top with a
long luggage loaded. The luggage
may touch the lower portion of the
soft top side rails and may be dam-
aged.
 Never remove the side trims except
when loading a long luggage. Other-
wise, the luggage may move while
driving and damage the water re-
ceiving bag or the luggage may be
damaged when the soft top is
opened.
Cup holders
SB19013
Front
SB19014
Center console
The cup holders are designed for hold-
ing cups or drinkcans securely in its
holes.
Front: To use the cup holders, pull them
out.
CAUTION
Do not place anything else other
than cups or drinkcans in the cup
holders, as such items may be
thrown about in the compartment
and possibly injure people in the
vehicle during sudden braking or an
accident.
Front only: To reduce the chance of
injury in case of an accident or a
sudden stop while driving, keep the
cup holder closed when it is not in
use.

1282004 MR2 from Feb. ’04 Prod. (OM17518U)
Floor mat
SB19023a
Use a floor mat of the correct size.
If the floor carpet and floor mat have two
holes, then it is designed for use with two
locking clips. Fix the floor mat with lock-
ing clip into the holes in the floor carpet.
SB19022
CAUTION
Make sure the floor mat is properly
placed on the floor carpet. If the floor
mat slips and interferes with the
movement of the pedals during driv-
ing, it may cause an accident.

1292004 MR2 from Feb. ’04 Prod. (OM17518U)
INFORMATION BEFORE DRIVING YOUR
TOYOTA
Information before driving your Toyota
Break−in period 130
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . .
Fuel 130
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . . . . . . .
Fuel pump shut off system 132
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Operation in foreign countries 132
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Three −way catalytic converter 132
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine exhaust cautions 133
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
Facts about engine oil consumption 134
. . . . . . . . . . . . . . . . . . . . . . . . . .
Iridium −tipped spark plugs 135
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brake system 135
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . .
Brake pad wear limit indicators 138
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Limited −slip differential 139
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. .
Your Toyota’s identification 139
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Theft prevention labels 140
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. .
Suspension and chassis 140
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
Tire information 141
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . .
Vehicle load limits 149
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . .
Cargo and luggage 149
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . .
Types of tires 152
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . .
SECTION 2

1302004 MR2 from Feb. ’04 Prod. (OM17518U)
Breakin period
Drive gently and avoid high speeds.
Your vehicle does not need an elaborate
break−in. But following a few simple tips
for the first 1600 km (1000 miles) can add
to the future economy and long life of
your vehicle:
Avoid full throttle acceleration when
starting and driving.
Avoid racing the engine.
Try to avoid hard stops during the first
300 km (200 miles).
Do not drive slowly with the transmis-
sion in a high gear.
Do not drive for a long time at any
single speed, either fast or slow.
Fuel
FUEL TYPE
Your new vehicle must use only
unleaded gasoline.
To help prevent gas station mix −ups, your
Toyota has a smaller fuel tank opening.
The special nozzle on pumps with un-
leaded fuel will fit it, but the larger stan-
dard nozzle on pumps with leaded gas will
not.
At a minimum, the gasoline you use
should meet specifications of ASTM
D4814 in the U.S.A.
NOTICE
Do not use leaded gasoline. Use of
leaded gasoline will cause the three
way catalytic converter to lose its ef-
fectiveness and the emission control
system to function improperly. Also,
this can increase maintenance costs.
OCTANE RATING
Select Octane Rating 87 (Research Oc-
tane Number 91) or higher.
Use of unleaded fuel with an octane num-
ber or rating lower than stated above will
cause persistent heavy knocking. If se-
vere, this will lead to engine damage. If your engine knocks...
If you detect heavy knocking even when
using the recommended fuel, or if you
hear steady knocking while holding a
steady speed on level roads, consult your
Toyota dealer.
However, occasionally, you may notice
light knocking for a short time while accel-
erating or driving up hills. This is normal
and there is no need for concern.
GASOLINES CONTAINING DETERGENT
ADDITIVES
Toyota recommends the use of gaso-
lines that contain detergent additives to
avoid buildup of engine deposits.
However, all gasoline sold in the U.S con-
tains detergent additives to keep clean
and/or clean intake systems.

1312004 MR2 from Feb. ’04 Prod. (OM17518U)
QUALITY GASOLINE
Automotive manufacturers in the U.S.,
Europe and Japan have developed a
specification for quality fuel named
WorldWide Fuel Charter (WWFC) that
is expected to be applied world wide.
The WWFC consists of four categories
that depend on required emission lev-
els. In the U.S., category 3 has been
adopted. The WWFC improves air quali-
ty by providing for better emissions in
vehicle fleets, and customer satisfaction
through better vehicle performance.
CLEANER BURNING GASOLINE
Cleaner burning gasoline, including re-
formulated gasoline that contains oxy-
genates such as ethanol or MTBE is
available in many areas.
Toyota recommends the use of cleaner
burning gasoline and appropriately blended
reformulated gasoline. These types of gas-
oline provide excellent vehicle perfor-
mance, reduce vehicle emissions, and im-
prove air quality.OXYGENATES IN GASOLINE
Toyota allows the use of oxygenate
blended gasoline where the oxygenate
content is up to 10% ethanol or 15%
MTBE. If you use gasohol in your
Toyota, be sure that it has an octane
rating no lower than 87.
Toyota does not recommend the use of
gasoline containing methanol.
GASOLINE CONTAINING MMT
Some gasoline contain an octane en-
hancing additive called MMT (Methylcy-
cropentadienyl Manganese Tricarbonyl).
Toyota does not recommend the use of
gasoline that contains MMT. If fuel con-
taining MMT is used, your emission con-
trol system may be adversely affected.
The Malfunction Indicator Lamp on the in-
strument cluster may come on. If this
happens, contact your Toyota dealer for
service.
GASOLINE QUALITY
In a very few cases, you may experience
driveability problems caused by the partic-
ular gasoline that you are using. If you
continue to have unacceptable driveability,
try changing gasoline brands. If this does
not rectify your problem, then consult your
Toyota dealer.NOTICE

Do not use gasohol other than
stated above. It will cause fuel sys-
tem damage or vehicle performance
problems.
 If driveab ility problems occur (poor
hot starting, vaporizing, engine
knock, etc.), discontinue the use.
 Take care not to spill gasohol dur-
ing refueling. Gasohol may cause
paint damage.
FUEL TANK CAPACITY
48 L (12.7 gal., 10.6 Imp. gal.)

1322004 MR2 from Feb. ’04 Prod. (OM17518U)
Fuel pump shut off system
The fuel pump shut off system stops sup-
plying fuel to the engine to minimize the
risk of fuel leakage when the engine stalls
or an airbag inflates upon collision. To
restart the engine after the fuel pump shut
off system activates, turn the ignition
switch to “ACC” or “LOCK” once and start
it.
CAUTION
Inspect the ground under the vehicle
before restarting the engine. If you
find that liquid has leaked onto the
ground, it is the fuel system has
been damaged and it is in need of
repair. In this case, do not restart the
engine.
Operation in foreign countries
If you plan to drive your Toyota in
another country...
First, comply with the vehicle registration
laws.
Second, confirm the availability of the cor-
rect fuel (unleaded and minimum octane
number).
Threeway catalytic converter
SB21013a
The threeway catalytic converter is an
emission control device installed in the
exhaust system.
Its purpose is to reduce pollutants in the
exhaust gas.
CAUTION
Keep people and combustible mate-
rials away from the exhaust pipe
while the engine is running. The
exhaust gas is very hot.
Do not drive, idle or park your ve-
hicle over anything that might burn
easily such as grass, leaves, paper
or rags.
