331
Scrapping of your Toyota
The SRS airbag and seat belt pre-
tensioner devices in your Toyota
contain explosive chemicals. If the
vehicle is scrapped with the airbags
and pretensioners left as they are,
this may cause an accident such as
fire. Be sure to have the systems
of the SRS airbag and seat belt
pretensioner removed and disposed
of by the qualified service shop or
by your Toyota dealer before you
dispose of your vehicle.
CAUTION
When your vehicle or bat-
tery needs to be disposed
of, be sure to consult your
Toyota dealer. Hybrid ve-
hicle batteries must be
collected through Toyota
dealers. If your vehicle is
disposed of without dis-
mantling, someone could
receive an electric shock
by touching the high volt-
age parts of the hybrid ve-
hicle battery. If the battery
is not disposed of proper-
ly, its contents can cause
death or serious injury.
Hybrid vehicle battery
The hybrid vehicle battery has a
limited service life. Call your Toyo-
ta dealer for information about re-
cycling or disposal of hybrid ve-
hicle battery and your vehicle.
333
Precautions for useof hybrid vehicle
The vehicle has both high voltage
DC and AC systems as well as a
12 volt system. DC and AC high
voltage are both very dangerous
and can cause death or serious inju-
ry, severe burns and electric shock.
In order to avoid personal in-
juries, do not touch the high
voltage cables (orange col-
ored) and their connectors.
Follow the caution labels at-
tached to the high voltage
parts.
Do not remove or replace the
high voltage parts such as
the inverter unit (located in
the engine compartment), hy-
brid vehicle battery (located
behind rear seat), etc.
Do not touch the service plug
located in the left side trim
of the luggage compartment
without hybrid system techni-
cal training. (See “Precau-
tions for use” on page 14 in
Section 1 2.) This component
is provided to disable the
high voltage system in case
of servicing at a Toyota deal-
er.
CAUTIONIf an accident occurs
Pull your vehicle off the road,
push the “P” position switch,
stop the hybrid system and if
the key is inserted into key
slot, remove it.
In order to avoid personal in-
juries, do not touch any high
voltage wirings and their con-
nectors, and high voltage
parts (inverter unit, hybrid ve-
hicle battery, etc.).
If some exposed electric
wires are protruding inside or
outside of your vehicle, an
electric shock may occur.
Never touch the electric
wires.
If fluid leaks or gets in some
parts of the vehicle, never
touch it because it may be
electrolyte (strong alkali) from
the hybrid vehicle battery. If
it gets into your skin or eyes,
wash off immediately with a
large amount of water, if pos-
sible, boric acid solution, and
get immediate medical atten-
tion in order to help avoid
serious injury.
If a vehicle fire occurs, extin-
guish it using a fire extin-
guisher for the exclusive use
on electric fires. Or, use a
large amount of water to pre-
vent flammable gas from be-
ing generated from the batter-
ies.
334
If your vehicle needs to be
towed, do it with the front
wheels raised. For details on
towing, see “If your vehicle
needs to be towed” on page
258 in Section 5.
335
CAUTION
High Voltage
Your vehicle is equipped with
cables connected to parts of
the vehicle subject to high volt-
age (about 500 V at maximum).
There are some other parts that
reach high temperatures while
you drive. Never touch battery
cables (wrapped in orange col-
ored harnesses) or their con-
nectors since they are under
high voltage and dangerous.
Caution labels are applied to
these parts to identify them.
Carefully observe the instruc-
tions on these caution labels.
00p001
2
Publication No. OM47509U
Part No. 01999-47509
Printed in Japan 01−0409 −00
U 7Quick index
If a service reminder indicator or warning buzzer comes on 117 . . .
If your vehicle will not start 242 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
If your vehicle overheats 246 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
.
If you have a flat tire 247 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . .
If your vehicle needs to be towed 258 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tips for driving during break-in period 204 . . . . . . . . . . . . . . . . . . . . . . . . . .
How to start the hybrid system 234 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
General maintenance 273 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . .
Gas station information
Fuel type:
UNLEADED gasoline, Octane Rating 87 (Research Octane Number 91)
or higher.
See page 204 for detailed information.
Fuel tank capacity:
45 L (11.9 gal., 9.9 lmp.gal.)
See page 206 for detailed information.
Engine oil:
API grade SL “Energy −Conserving” or ILSAC multigrade engine oil
is recommended.
See page 287 for detailed information.
Tire information: See pages 291 through 298.
Tire inflation pressure: See page 315.
