451
If an accident occurs
Pull your vehicle off the road,
push the “P” position switch,
stop the hybrid system and if
the key is inserted into key
slot, remove it.
In order to avoid personal in-
juries, do not touch any high
voltage wirings and their con-
nectors, and high voltage
parts (inverter unit, hybrid
battery, etc.).
If some exposed electric
wires are protruding inside or
outside of your vehicle, an
electric shock may occur.
Never touch the electric
wires.
If fluid leaks or gets in some
parts of the vehicle, never
touch it because it may be
electrolyte (strong alkali) from
the hybrid battery. If it gets
into your skin or eyes, wash
off immediately with a large
amount of water, if possible,
boric acid solution, and get
immediate medical attention
in order to help avoid serious
injury.
If a vehicle fire occurs, extin-
guish it using a fire extin-
guisher for the exclusive use
on electric fires. Or, use a
large amount of water to pre-
vent flammable gas from be-
ing generated from the batter-
ies.
If your vehicle needs to be
towed, do it with the front
wheels raised. For details on
towing, see “If your vehicle
needs to be towed” on page
372 in Section 5.
453
CAUTION
High Voltage
Your vehicle is equipped with
cables connected to parts of
the vehicle subject to high volt-
age (about 500 V at maximum).
There are some other parts that
reach high temperatures while
you drive. Never touch battery
cables (wrapped in orange col-
ored harnesses) or their con-
nectors since they are under
high voltage and dangerous.
Caution labels are applied to
these parts to identify them.
Carefully observe the instruc-
tions on these caution labels.
00p001
2
Publication No. OM47520U
Part No. 01999-47520
Printed in Japan 01−0511 −00
U 5Quick index
If a service reminder indicator or warning buzzer comes on 125 . . .
If your vehicle will not start 356 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
If your vehicle overheats 360 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
.
If you have a flat tire 361 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . .
If your vehicle needs to be towed 372 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tips for driving during break-in period 318 . . . . . . . . . . . . . . . . . . . . . . . . . .
How to start the hybrid system 348 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
General maintenance 387 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . .
Gas station information
Fuel type:
UNLEADED gasoline, Octane Rating 87 (Research Octane Number 91)
or higher.
See page 318 for detailed information.
Fuel tank capacity:
45 L (11.9 gal., 9.9 lmp.gal.)
See page 320 for detailed information.
Engine oil:
ILSAC multigrade engine oil is recommended.
See page 401 for detailed information.
Tire information: See pages 405 through 412.
Tire inflation pressure: See page 429.
C
