turn signal TOYOTA PRIUS 2007 2.G Owners Manual

3
1. Headlight and turn signal switches 110 . . . . . . . . . . . . . . . . . . . . . . . . .
2. Wiper and washer switches 117 . . . . . . .
3. “POWER” switch 139 . . . . . . . . . . . . . . . . .
4. Clock 304 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5. Multi −information display or
navigation system including
multi −information display
(For the navigation system,
see the separate “Navigation
System Owner ’s Manual”.) 160 . . . . . . . .
6. Emergency flasher switch 114 . . . . . . . . .
7. Trip meter reset button 123 . . . . . . . . . . .
8. Km/h or MPH button 124 . . . . . . . . . . . . .
9. Audio system 242 . . . . . . . . . . . . . . . . . . . .
10. Power outlet 307 . . . . . . . . . . . . . . . . . . . . .
11. “P” position switch 144 . . . . . . . . . . . . . . .
12. Electronic shift lever (R, N, D, B) 144 . . . . . . . . . . . . . . . . . . . . .
13. Key slot 138 . . . . . . . . . . . . . . . . . . . . . . . . .
14. Cruise control switch 156 . . . . . . . . . . . . .
15. Tire pressure warning reset switch 150 . . . . . . . . . . . . . . . . . . . . .
16. Smart entry and start system cancel switch 34 . . . . . . . . . . . . . . . . . . . . .
11p019

7
or
Hybrid vehicle immobilizer / Theft deterrent
system indicator light Tail light indicator light
Shift position indicator light
*4
Driving ready light
Automatic air conditioner indicator light
Recirculate mode indicator light
Smart entry and start system warning light
*5
Windshield air flow indicator light
Slip indicator light
Headlight high beam indicator light
Headlight indicator light Turn signal indicator lights
Cruise control indicator light*3
Hybrid system warning light*2
Automatic head light leveling system
warning light*2
Electric power steering system warning light*2
“AIRBAG ON” and “AIRBAG OFF”
indicator lights
Rear window and outside rear view mirror
defoggers indicator light
Hybrid battery warning light*2

30
21p128
Side door
21p139
Back door
LOCKING THE DOORS WITH SMART
FUNCTION
The smart entry and start system will
lock the doors without being inserted
into the door keyhole.
When you exit the vehicle carrying the
smart key and push the lock button on the
outside front door handle or back door
with all the doors closed, all the doors will
be locked provided that the electronic
code in the key corresponds to the regis-
tered ID code for the vehicle.
At this time, you will hear one beep and
the turn signal lights flash once. However,
when you push the lock button on the
outside front door handle or back door
with any door not closed securely, a beep
sounds for 10 seconds.
NOTICE
If the key is in the vehicle, do not
perform door locking operation, or
you might lock your keys inside the
vehicle.
INFORMATION
The rear doors are not equipped
with smart function.
When locking the doors, be sure to
push the lock button on the outside
front door handle or back door
slowly and surely. If you push the
button quickly, the doors may not
lock.
When opening or closing a door, do
not touch the lock button on the
outside door handle or back door. If
you push the button, an alarm
sounds 10 seconds.
When a wireless remote control is
used to lock the doors and a smart
key is left in the effective range of
the smart function in the vehicle,
the doors cannot be unlocked using
the smart function. In this case, use
the wireless remote function to un-
lock the doors.
You cannot activate smart unlocking
functions within 3 seconds after the
smart locking function is activated.

31
21p136
UNLOCKING THE DOOR(S) WITH
SMART FUNCTION
The smart entry and start system can
be used to unlock the door(s) without
being inserted into the door keyhole.
When you get close to your vehicle (about
1 m (3 ft.) from each outside front door
handle), and are carrying the smart key,
the electronic code emitted from the key
is automatically checked to determine if it
corresponds to the registered ID code for
the vehicle. When you take hold of the
side back of the outside door handle sur-
face, it will unlock. At this time, two
beeps sound and the turn signal lights
flash twice.When you push and hold down the back
door opener switch, carrying the smart
key, the ID code is checked in the same
way as in the front door case. And all the
doors will unlock. At this time, two beeps
sound and the turn signal lights flash
twice.
When you get close to your vehicle (about
1 m or 3 ft. from either front door), carry-
ing the smart key or unlock the back door
using smart key function, the interior light
comes on for 15 seconds if the interior
light switch is in the “DOOR” position.
However, the interior lights go out when
you push the power door lock switch in
the lock position or press the “POWER”
switch once or twice from the off setting
to select the “ACC” or “IG
−ON” mode
without depressing the brake pedal. For
further information, see “Interior lights” on
page 115.
You have 30 seconds to open a door after
operating the smart unlocking function. If
a door is not opened by then, all the
doors will be automatically locked again.
INFORMATION
The rear doors are not equipped
with smart function.
When unlocking the door(s), be sure
to take hold of the back side of the
outside door handle firmly as
shown in the illustration. Taking
hold of the handle with a gloved
hand might cause a delay in unlock-
ing.

32
When you take hold of the handle
or push the back door opener to
unlock the door(s), be sure to con-
firm that the door(s) have been un-
locked. If the two beeps and the
turn signal lights flash twice, the
doors are unlocked. At this time,
you can pull the outside door han-
dle or push the back door opener to
open the door. If you quickly move
closer to the vehicle or pull the out-
side door handle or push the back
door opener quickly, the doors
might not unlock. If you cannot
open the door by pulling the out-
side door handle or pushing the
back door at this time, push back
the outside door handle to the origi-
nal position or release your hand
from the back door and then try
again.
If you bring the smart key very
close to the outside door handle or
the back door opener, the doors
might not lock.
If another person who is not carry-
ing a smart key takes hold of an
outside door handle or push the
back door opener when you are
within the effective range of the
smart function, the door(s) may not
unlock.
If a large amount of water is ap-
plied to the outside door handle or
the back door during heavy rain or
a car wash, and someone carrying a
smart key is near the vehicle, the
door(s) might be unlocked. However,
if the outside front door handle is
not pulled out or back door opener
not pushed, the doors will lock au-
tomatically after about 30 seconds.
To ensure the unlocking door(s),
perform unlocking operation within
3 seconds after getting close to the
vehicle (about 1 m or 3 ft. from the
front doors or back door). If it
takes longer than that, unlocking
function may not be enabled.
CHANGING THE DOORS TO BE UN-
LOCKED
Each time you push the lock button
together with the panic button on the
smart key for about 5 seconds with the
hybrid system off, the setting for door
unlocking will change as follows:
1. Driver ’s door unlocking mode: If you
perform smart unlocking operation on
the driver’s door, it will unlock. Per-
forming unlocking operation on the
front passenger ’s door or back door
will unlock all the doors. When the
system switches to this m ode, one
beep sounds inside the vehicle and two
beeps sound three times.
2. All doors unlocking mode: Performing
smart unlocking operation on either
front door or back door will unlock all
the doors. When the system switches
to this mode, one beep sounds inside
the vehicle and two beeps sound twice.
3. Single door unlocking mode: The
driver ’s door or back door on which
you perform smart unlocking operation
will unlock. However, performing un-
locking operation on the front passen-
ger’s door will unlock all the doors.
When the system switches to this
mode, one beep sounds inside the ve-
hicle and two beeps sound once.

37
To lock and unlock all the doors, push
the switches slowly and securely.
To lock: Push the lock switch. All the side
doors and back door are locked simulta-
neously. At this time, the turn signal lights
will flash once.
Check to see that the doors are securely
locked.
If any of the doors is not securely closed
or if the key is in the key slot, locking
cannot be performed by the lock switch.
At this time, a beep will sound for 10
seconds on the vehicle with smart entry
and smart system. However, if the key is
in the key slot, a beep will not sound. To
stop the beep, close all the side doors
and back door securely or push the un-
lock switch.
The buzzer can be disabled. For details,
contact your Toyota dealer.
To unlock: Push the unlock switch once to
unlock the driver ’s door alone. Pushing
the switch twice within 3 seconds unlocks
all the doors simultaneously. Each time
the unlock switch is pushed, the turn sig-
nal lights will flash twice.This double switch operation to unlock all
the side doors and back door can be
changed to a single switch operation. For
details, contact your Toyota dealer.
When the unlock switch is pressed the
interior light comes on. The light remains
on for about 15 seconds unless any of the
doors is opened and then closed. (For
further information, see “Interior lights” on
page 115.)
You have 30 seconds to open a door after
using the wireless remote unlock feature.
If a door is not opened by then, all the
doors will be automatically locked again.
The timing for the automatic door lock
function can be changed. For details, con-
tact your Toyota dealer.
If the lock or unlock switch is kept
pressed in, the locking or unlocking opera-
tion is not repeated. Release the switch
and then push it again.
The following adjustments can be made in
this system. For details, contact your
Toyota dealer:
Canceling the wireless door locking or
unlocking function
Canceling the flash of the turn signal
lights
21p015a
Pushing the panic switch for 1 second
blows the horn intermittently and
flashes the headlights, tail lights and
emergency flashers and turns on the
interior light.
The panic switch is used to deter vehicle
theft when you witness anyone attempting
to break into or damage your vehicle.
The alarm will last for one minute. To stop
the alarm midway, do the follows:
Push any switch on the key.
Put the hybrid system in the “IG
−ON”
mode.
—Activating panic mode

109
OPERATION OF INSTRUMENTS AND
CONTROLS
Lights, Wipers and Defogger
Headlights and turn signals11 0
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Emergency flashers 11 4
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . .
Instrument panel light control 11 4
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Front fog lights 11 5
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . .
Interior lights 11 5
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . .
Personal lights 11 6
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . .
Luggage compartment light 11 6
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Key slot lights 11 6
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . .
Windshield wipers and washer 11 7
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear window wiper and washer 11 7
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear window and outside rear view mirror defoggers 11 8
. . . . . . . . . . .
SECTION 2– 4

11 0
23p137a
HEADLIGHTS
To turn on the following lights: Twist
the headlight/turn signal lever knob.
Position 1—Parking, tail, license plate,
side marker and instrument panel lights
Position 2—Headlights and all of the
above
Position 3 (“AUTO”)—Headlights and/or all
of the lights in position 1
They automatically turn on or off depend-
ing on the darkness of the surroundings.
Manually twist the knob to the position 2
to turn on the headlights if they are need-
ed immediately when entering a dark tun-
nel, parking structure, etc.
23p124_1
The automatic light control sensor is on
the top of the driver’s side instrument
panel.
Do not place anything on the instrument
panel, and/or do not affix anything on the
windshield to block this sensor.
Automatic light cut off system
The lights automatically turn off when the
driver ’s door is opened with the hybrid
system off. To turn them on again, press
the “POWER” switch twice from the off
setting to select the “IG−ON” mode with-
out depressing the brake pedal or actuate
the headlight switch. If you are going to
park for over one week, make sure the
headlight switch is off. When the headlight switch is turned to the
first or second clickstop, the brightness of
the instrument cluster will be reduced
slightly unless the instrument panel light
control dial is turned fully on.
NOTICE
To prevent the battery from being dis-
charged, do not leave the switch on
longer than necessary when the hy-
brid system is not running.
Headlights and turn signals
(with automatic light control system)

111
Daytime running light system
The headlights turn on at reduced intensi-
ty when the parking brake is released with
the hybrid system started, even with the
light switch in the “OFF” position.
To turn on the other exterior lights and
instrument panel lights, twist the knob to
the position 1.
To turn off the daytime running light sys-
tem, twist the knob to the position 2 or
position 3 with the headlights on or turn
the hybrid system off.
23p109b
HighLow beams—For high beams, turn
the headlights on and push the lever away
from you (position 1). Pull the lever to-
ward you (position 2) for low beams.
The headlight high beam indicator light
(blue light) on the instrument panel will
tell you that the high beams are on.
Flashing the high beam headlights
(position 3)—Pull the lever all the way
back. The high beam headlights turn off
when you release the lever.
The high beam flasher works even when
the headlight switch is off.
23p110b
TURN SIGNALS
To signal a turn, push the headlight/
turn signal lever up or down to position
1.
The hybrid system must be in the “IG −
ON” mode.
The lever automatically returns after you
make a turn, but you may have to return
it by hand after you change lanes.
To signal a lane change, move the lever
up or down to the pressure point (position
2) and hold it.

11 2
If the turn signal indicator lights (green
lights) on the instrument panel flash faster
than normal, a front or rear turn signal
bulb is burned out. See “Replacing light
bulbs—” on page 422.
23p001e
HEADLIGHTS
To turn on the following lights: Twist
the headlight/turn signal lever knob.
Position 1—Parking, tail, license plate,
side marker and instrument panel lights
Position 2—Headlights and all of the
aboveAutomatic light cut off system
The lights automatically turn off when the
driver ’s door is opened with the hybrid
system off. To turn them on again, press
the “POWER” switch twice from the off
setting to select the “IG
−ON” mode with-
out depressing the brake pedal or actuate
the headlight switch. If you are going to
park for over one week, make sure the
headlight switch is off.
When the headlight switch is turned to the
first or second clickstop, the brightness of
the instrument cluster will be reduced
slightly unless the instrument panel light
control dial is turned fully on.
NOTICE
To prevent the battery from being dis-
charged, do not leave the lights on
longer than necessary when the hy-
brid system is not running.
Headlights and turn signals
(without automatic light control system)
