SAFETY AND EMERGENCY FEATURES
Jump starting
Jump start terminal
Connecting jumper cables
Connect positive (red) jumper cable to the jump
start terminal.
Connect positive (red) jumper cable to the
positive (+) terminal on the booster battery.
Connect negative (black) jumper cable to the
negative (-) terminal on the booster battery.
Connect negative (black) jumper cable to the
recommended connecting point of the vehicle
with the discharged battery.
Depress
brake pedal, and press “POWER” button
to start the vehicle.
Refer to the Owner’s Manualfor more details.
The jump start terminal is in the fuse box. To access
the terminal, open the fuse block cover and the
jump start terminal cover.
Recommended
connecting point
Exclusive jump
starting
terminal cover
