window TOYOTA PRIUS 2007 2.G Quick Reference Guide

1
OVERVIEW BASIC HYBRID VEHICLE OPERATION
FEATURES/OPERATIONS
SAFETY AND EMERGENCY FEATURES
INDEX
ItemPage no.
BASIC HYBRID VEHICLE OPERATIONHybrid Synergy Drive System 2Keyless entry 4Key fob3Parking & turning OFF the Hybrid System 9Shifting8Smart Key 5-6Smart Key unlock functions16Tu r n i n g the Hybrid System ON 7
OVERVIEWEngine maintenance15Fuel tank door opener and cap14Hood release15Indicator symbols12-13Instrument cluster12Instrument panel10-11
Rear hatch14
FEATURES/OPERATIONSAir Conditioning/Heating 20-21Audio 22-23AUX audio jack 24Clock 24Cruise control 21Cup and bottle holders 25
Garage door opener (HomeLink®)217Light Control-Instrument panel 24Lights & turn signals16Luggage storage box 24Parking brake 25Power outlets 25Seat adjustments-Front18Seat adjustments-Rear18Seats-Head restraints18Tilt steering wheel19Window wiper & washer17
Windows19
SAFETY AND EMERGENCY FEATURESDoor locks 26Doors-Child safety locks 26Emergency flashers 27Jump starting 28Rear air vent 27Seat belts 26Seat belts-Shoulder belt anchor 26Spare tire & tools 29Tire Pressure Wa r n i n g System reset 27
1Programmable by customer.For dealer-programmable
features, please visit your Toyota dealer.
3HomeLink®is a registered trademark of Johnson Controls, Inc.

BASIC HYBRID VEHICLE OPERATION
13
OVERVIEW
FEATURES/OPERATIONS
SAFETY AND EMERGENCY FEATURES
12
OVERVIEW
Headlight indicator
Low engine oil pressure warning
2
Service indicators and reminder
Speedometer
Fuel gauge
Odometer and two trip meters
Instrument cluster
Driver seat belt reminder1
(alarm will sound if speed is over 12 mph)
Front passenger seat belt reminder1
(alarm will sound if speed is over 12 mph) Brake system warning
1
Charging system warning2
Low fuel level indicator1
Anti-lock Brake System warning1
Malfunction/Check Engine indicator1
When the Anti-lock Brake System (ABS) function is in
action, you may feel the brake pedal pulsating and
hear a noise. In this situation, to let the Anti-lock
Brake System work for you, just hold the brake pedal
down more firmly. Do not pump the brake as this will
result in reduced braking
performance.
Indicator symbols
Master warning1
High coolant temperature warning2
Open door warning1
Airbag SRS warning1
1
For details, refer to “Service reminder indicators and warning buzzers-- --
Instrument cluster” Section 2-5, 2007 Owner’s Manual.
2For details, refer to “Service reminder indicators and warning buzzers-- --
Multi-information display” Section 2-5, 2007 Owner’s Manual.
3If this light flashes, see “Cruise control” Section 2-6, 2007 Owner’s Manual.4For details, refer to “Hybrid transaxle” Section 2-6, 2007 Owner’s Manual.5For details, refer to “Smart Key system” Section 2-1, 2007 Owner’s
Manual.
Driving ready light
Engine oil replacement reminder
1
Tu r n signal indicator
Headlight high beam indicator
Cruise control indicator
3
Slip indicator
Hybrid System warning2
Vehicle Stability Control warning1
Tr a c t i o n battery warning2
Electric power steering system
warning2
Smart Key system warning5
Ta i l light indicator
Automatic headlight leveling system warning
2
Running mode position indicator4
Automatic Air Conditioner indicator
Recirculate mode indicator
Windshield air flow indicator
Rear window and outside rear view mirror
defoggers indicator
Hybrid vehicle immobilizer/Theft deterrent
system indicator
Low Tire Pressure Wa r n i n g1
Front passenger occupant classification
indicator

Garage door opener (HomeLink®)
(if equipped)
Indicator
Buttons
Garage door openers manufactured under license
from HomeLink®*can be programmed to operate
garage doors, estate gates, security lighting, etc.
Refer to the Owner’s Manualfor more details.
For programming assistance, contact the To y o t a
Customer Experience Center at 1-800-331-4331, or
visit http://www.homelink.com
*HomeLink®
is a registered trademark of Johnson Controls, Inc.
BASIC HYBRID VEHICLE OPERATION
OVERVIEW
FEATURES/OPERATIONS
SAFETY AND EMERGENCY FEATURES
16
FEATURES/OPERATIONS
Lights & turn signals
Headlights
-Automatic light cutoff system* Automatically turns
off lights when the driver’s door is opened with the
Hybrid System “OFF.”
-Daytime Running Light system* Automatically
turns on the headlights at a reduced intensity.
*If equipped
Tu r n signals
Front fog lights (if equipped)
Front fog lights come on only when the headlights
are on low beam.
Window wiper & washer
Front
Rear
17
Low beamAUTO
*
Head lights
High beam
High beam flasher Parking light
Right turn
Left turn Tu r nAdjust intervalSingle wipe
Interval wipe
Wa s h and wipe
Wa s h and wipe Slow
Interval wipe Fast
Wipe Pull to wash and wipe
Lane change
Lane change

18 19
OVERVIEW BASIC HYBRID VEHICLE OPERATION
FEATURES/OPERATIONSSAFETY AND EMERGENCY FEATURES
FEATURES/OPERATIONS
Windows
Window operation
Automatic operation (driver side only) Push the
switch completely down or pull it completely up and
release to fully open or close. To stop window mid-
way, lightly push the switch in the opposite direction.
Window lock switch Deactivates all passenger
windows. Driver’s window remains operable.
NOTE:If 12V battery is disconnected, the
window
will need to be reinitialized. Refer to the Owner’s
Manual for more details.
Window lock
switch
Seats-Head restraints
Lock release button
Seat adjustments-Front
Seat adjustments-Rear
Up
DownLock release button FrontRear Position
(2) Fold down(1) Push down Seatback angle
Driver side
Down
Up
Tilt steering wheel
Hold wheel, push lever down, set angle and return
lever.
Note: Do not attempt to adjust while the vehicle
is in motion.
Angle
Lock release
lever
(1)(2)

BASIC HYBRID VEHICLE OPERATION
21
OVERVIEW
FEATURES/OPERATIONS
SAFETY AND EMERGENCY FEATURES
20
FEATURES/OPERATIONS
Setting a speed
System
ON/OFF
Resume
2/Increase speed
Cancel1
Set/Decrease speed
Cruise control
Passenger compartment temperature
Outside temperature
Temperature
Air flow vent
Fan speed
Automatic climate control ON
Fresh or recirculated cabin air
Rear window and outside rear view mirror
defogger
Windshield air flow
Air Conditioning ON/OFF
Climate control OFF
Display the operation screen
1
Air Conditioning/Heating
1For details, refer to the “Navigation System
Owner’s Manual.”Auto A/C ON/OFF
Temperature selector
Air intake selector
Windshield vent
Rear window and outside rear view mirror
defogger
Steering wheel switches
1The set speed may also be cancelled by depressing
the brake pedal.
2If vehicle speed falls below 25 mph, the set speed
will not be resumed.
Turning system ON/OFF
With navigation system1
Ty p e 2 functions
Ty p e 1 functions
