map TOYOTA PRIUS 2008 2.G Navigation Manual

BASIC FUNCTIONS
34
Details of POIs in some buildings may be
displayed.
For detailed POI information, touch the
building name. You can see details of the
selected POIs.Northup screen
Headingup screen
The orientation of the map can be changed
from North−up to Heading−up by touching
the orientation symbol at the top left of the
screen.
Northup symbol
Regardless of the direction of vehicle trav-
el, North is always up.
Headingup symbol
The direction of vehicle travel is always up.
A red arrow indicates North.
— Orientation of the map

SECTION 2
DESTINATION SEARCH
35
DESTINATION SEARCH
Destination search
Quick reference (“Destination” screen) 36. . . . . . . . . . . . . . . . . . . .
Destination search 37. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Selecting the search area38 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Destination search by Home40 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Destination search by Quick access40 . . . . . . . . . . . . . . . . . . . .
Destination search by “Address”41 . . . . . . . . . . . . . . . . . . . . . . .
Destination search by “POI* Name” 44. . . . . . . . . . . . . . . . . . . . .
Destination search by “POI* Category” 47. . . . . . . . . . . . . . . . . .
Destination search by “Emergency”50 . . . . . . . . . . . . . . . . . . . . .
Destination search by “Memory”51 . . . . . . . . . . . . . . . . . . . . . . . .
Destination search by “Previous”51 . . . . . . . . . . . . . . . . . . . . . . .
Destination search by “Map”52 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Destination search by “Intersection”52 . . . . . . . . . . . . . . . . . . . .
Destination search by “Freeway Ent./Exit”53 . . . . . . . . . . . . . . .
Destination search by “Coordinates”54 . . . . . . . . . . . . . . . . . . . .
Destination search by “Phone #”55 . . . . . . . . . . . . . . . . . . . . . . .
Starting route guidance 55. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
*: Point of Interest

DESTINATION SEARCH
36
The “Destination” screen allows you to search for a destination. To display the “Destina-
tion” screen, push the “DEST” button.
1“Address”
A house number and the street address
can be input by using the input keys.
41 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2“POI Name”
Select one of the many POIs (Points of In-
terest) that have already been stored in the
system’s database. 44. . . . . . . . . . . . . . . .
3“POI Category”
A destination can be selected from the POI
category. 47. . . . . . . . . . . . . . . . . . . . . . . . .
4“Previous”
A destination can be selected from any of
the last 100 previously set destinations
and from the previous starting point.
51 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5“Memory”
The location can be selected from the reg-
istered “Memory points”. (To register
memory points, see “ — Registering
memory points” on page 88.) 51. . . . . . . .
6“Emergency”
One of the four categories of emergency
service points that are already stored in the
system’s database can be selected.
50 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7“Map”
A destination can be selected simply by
touching the location on the displayed
map. 52. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Quick reference (“Destination” screen)

DESTINATION SEARCH
38
SELECTING THE SEARCH AREA ON
THE DESTINATION SCREEN
1. Push the “DEST” button.
2. Touch “Change” on the “Destina-
tion” screen to display a map of the
United States and Canada divided into
11 areas. (For map database information
and updates, see “Map database informa-
tion and updates” on page 134.)
3. Touch one of “US1” through “CAN”
to select a search area.
4. Touch “OK” and the “Destination”
screen returns.SELECTING THE SEARCH AREA ON
THE INPUT SCREEN
Change the search area in order to set a
destination from a different area by using
“Address”, “POI Name”, “Freeway Ent./
Exit” or “Intersection”.
1. Touch the search area button like
“US9” on the input screen to display a
map of the United States and Canada
divided into 11 areas. (For map data-
base information and updates, see “Map
database information and updates” on
page 134.)
2. Touch one of “US1” through “CAN”
to select a search area.
3. Touch “OK” and the previous
screen returns.
— Selecting the search area

DESTINATION SEARCH
40
1. Push the “DEST” button.
2. Touch the home touchscreen but-
ton on the “Destination” screen.
The screen changes and displays the map
location for home and the route prefer-
ence. (See “Starting route guidance” on
page 55.)
To use this function, it is necessary to set
“Home” for the memory point. (To register
“Home”, see page 7.)
INFORMATION
Guidance starts from the current ve-
hicle position to your home if “Enter”
is touched even while driving.
1. Push the “DEST” button.
2. Touch any of the quick access
touchscreen buttons on the “Destina-
tion” screen.
The screen changes and displays the map
location of the quick access point and the
route preference. (See “Starting route
guidance” on page 55.)
To use this function, it is necessary to set
“Quick Access” for each memory point.
(To register “Quick Access”, see page 9.)
INFORMATION
Guidance starts from the current ve-
hicle position to the quick access
point if “Enter” is touched even while
driving.
— Destination search by
Home
— Destination search by
Quick access

DESTINATION SEARCH
42
3. When the desired street name is
found, touch the corresponding but-
ton.
The screen changes and displays the map
location of the selected destination and the
route preference. (See “Starting route
guidance” on page 55.)
If the same address exists in more than
one city, the current screen changes to the
city list screen.
4. Select or enter the desired city.
“Input Name”: To narrow down the listed
items by inputting the city name.
If inputting a street name first, the screen
changes. The house number can then be
input.
If the above screen appears, an address
range on the screen can be selected.
If the same address exists in more than
one city, the current screen changes to the
city list screen.

DESTINATION SEARCH
43
(b) Selecting a city to search
Touch “City”.
To search by city, the following three meth-
ods are possible.
1. Input the city name
2. Select from the nearest 5 cities
3. Select from the last 5 cities
INFORMATION
To change the search area, touch
“Search Area”.
To cancel the city setting, touch
“Any City”.
INPUTTING THE CITY NAME
1. Touch “Input City Name”.
2. Input a city name.
3. Touch the button of the desired city
name from the displayed list.
“Map”: To display the selected destination
and the route preference. (See “Starting
route guidance” on page 55.)
The current screen changes to the screen
for inputting a house number or a street
name. (See “(a) Inputting a house number
and a street name” on page 41.)

DESTINATION SEARCH
44
SELECTING FROM THE NEAREST 5
CITIES
1. Touch “Nearest 5 Cities”.
2. Touch the button of the desired city
name from the displayed list.
The current screen changes to the screen
for inputting a house number or a street
name. (See “(a) Inputting a house number
and a street name” on page 41.)
SELECTING FROM THE LAST 5 CITIES
Touch the button of the desired city
name.
If the navigation has not be used, no cities
will be displayed on the screen.
The current screen changes to the screen
for inputting a house number or a street
name. (See “(a) Inputting a house number
and a street name” on page 41.)1. Push the “DEST” button.
2. Touch “POI Name” on the “Destina-
tion” screen.
3. Input the name of the Point of Inter-
est.
4. Touch the button of the desired des-
tination.
The screen changes and displays the map
location of the selected destination and the
route preference. (See “Starting route
guidance” on page 55.)
When inputting the name of a specific
Point of Interest, and there are two or more
sites with the same name, the list screen
is displayed.
— Destination search by
“POI Name”

DESTINATION SEARCH
45
Touch the button of the desired des-
tination.
If the same name exists in more than one
city, a search can be performed more easi-
ly with “City” and “Category”. (See “(a)
Selecting a city to search” on page 45 and
“(b) Selecting from the categories” on page
47.)
INFORMATION
The desired Point of Interest can be
displayed on the map screen. (See “
— Display POI icons” on page 72.)
(a) Selecting a city to search
Touch “City”.
To search by city, the following three meth-
ods are possible.
1. Input the city name
2. Select from the nearest 5 cities
3. Select from the last 5 cities
INFORMATION
To change the search area, touch
“Search Area”.
To cancel the city setting, touch
“Any City”.

DESTINATION SEARCH
47
(b) Selecting from the categories
Touch “Category”.
If the desired POI category is on the
screen, touch the name to display a de-
tailed list of the POI category.
If the desired POI category is not on the
screen, touch “List All Categories” to list
all POI categories.
When the desired category is touched, the
POI name list screen or POI name input
screen is displayed.The destination can be set by selecting the
search point and the POI category.
1. Push the “DEST” button.
2. Touch “POI Category” on the “Des-
tination” screen.
3. Set the search point by the following
method:
1. Input the city center
2. Set the current position as the search
point
3. Set the search point via the map
screen
4. Set the search point from any destina-
tion
It is possible to display the names of POIs
located within approximately 20 miles (32
km) from the selected search point.
— Destination search by
“POI Category”
