maintenance reset TOYOTA PRIUS 2010 3.G Owners Manual

428 4-3. Do-it-yourself maintenance
PRIUS_U (OM47668U) U.S.A.
■Engine oil consumption
● The amount of engine oil consumed depends on the oil viscosity, the
quality of the oil and the way the vehicle is driven.
● More oil is consumed under driving conditions such as high speeds, fre-
quent acceleration and deceleration.
● A new engine consumes more oil.
● When judging the amount of oil consumption, keep in mind that the oil
may have become diluted, making it difficult to judge the true level accu-
rately.
● Oil consumption: Max. 1.1 qt./600 miles, 0.9 Imp. qt./600 miles (1.0 L per
1000 km).
● If the vehicle consumes more than 1.1 qt. (1.0 L, 0.9 Imp.qt.) every 600
miles (1000 km), contact your Toyota dealer.
■ After changing the engine oil (U.S.A. only)
The oil change system should be rese t. Perform the following steps:
Turn the “POWER” switch OFF with the trip meter A shown.
Turn the “POWER” switch ON with the MPH or km/h button 
( P. 183) held down.
Keep pressing the button until the odometer indicates “000000” and
the multi-information display indicates that the reset is complete.
STEP1
STEP2
STEP3

443
4-3. Do-it-yourself maintenance
4
Maintenance and care
PRIUS_U (OM47668U) U.S.A.
■
How to initialize the tire pressure warning system
Park the vehicle in safe plac e and turn the “POWER” switch
OFF.
While the vehicle is moving, in itialization is not performed.
Adjust the tire inflation pressure to the specified cold tire infla-
tion pressure level. ( P. 565)
Make sure to adjust the tire pressure to the specified cold tire
inflation pressure level. The ti re pressure warning system will
operate based on this pressure level.
Turn the “POWER” switch to ON mode.
Push and hold the tire pressure
warning reset switch until the tire
pressure warning light blinks
slowly 3 times.
Wait for a few minutes with the ON mode, and then turn
“POWER” switch OFF.
STEP1
STEP2
STEP3
STEP4
STEP5

447
4-3. Do-it-yourself maintenance
4
Maintenance and care
PRIUS_U (OM47668U) U.S.A.
■Initializing the tire pressure warning system
Initialize the tires with the tire inflat
ion pressure adjusted to the specified
level.
■If you push the tire pressure warning reset switch accidentally
If initialization is performed, adjust t he tire inflation pressure to the speci-
fied level and initialize the tire pressure warning system again.
■When the initialization of the tire pressure warning system has
failed
Initialization can be completed in a few minutes. However, in the following
cases, the settings have not been recorded and the system will not operate
properly. If repeated attempts to record tire inflation pressure settings are
unsuccessful, have the vehicle inspected by your Toyota dealer.
●
When operating the tire pressure warning reset switch, the tire pres-
sure warning light does not flash 3 times.
●After carrying out the initialization procedure, the tire pressure warn-
ing light blinks for 1 minute then stays on after driving 20 minutes.
■Routine tire inflation pressure checks
The tire pressure warning system doe s not replace routine tire inflation
pressure checks. Ma ke sure to check tire infl ation pressure as part of
your routine of daily vehicle checks.

449
4-3. Do-it-yourself maintenance
4
Maintenance and care
PRIUS_U (OM47668U) U.S.A.
CAUTION
■When inspecting or replacing tires
Observe the following precautions to
prevent accidents. Failure to do so
may cause damage to parts of the drive train, as well as dangerous han-
dling characteristics, which may lead to an accident resulting in death or
serious injury.
●Do not mix tires of different ma kes, models or tread patterns.
Also, do not mix tires of remarkably different treadwear.
●Do not use tire sizes other than those recommended by Toyota.
●Do not mix differently constructed tire s (radial, bias-belted or bias-ply
tires).
●Do not mix summer, all season and winter tires.
●Do not use tires that have been used on another vehicle. 
Do not use tires if you do not know how they were used previously.
■When initializing the tire pressure warning system
Do not push the tire pressure warnin g reset switch without first adjusting
the tire inflation pressure to the spec ified level. Otherwise, the tire pres-
sure warning light may not come on even if the tire inflation pressure is
low, or it may come on when the tire inflation pressure is actually normal.

512 5-2. Steps to take in an emergency
PRIUS_U (OM47668U) U.S.A.
Follow the correction procedures.After taking the specified steps to correct the suspected problem,
check that the warning message turns off.
Warning messageDetailsCorrection procedure
(U.S.A. only) Indicates that the engine oil is
scheduled to be changed.
A buzzer also sounds.
Check the engine
oil, and change if
necessary.
Comes on approximately 4500
miles (7200 km) after the
engine oil is changed. (The
indicator will not work properly
unless the oil maintenance
data has been reset).
(U.S.A. only) Indicates that the engine oil
should be changed.
A buzzer also sounds.
Check and change
the engine oil.
Comes on approximately 5000
miles (8000 km) after the
engine oil is changed (and the
oil maintenance data has been
reset).

516 5-2. Steps to take in an emergency
PRIUS_U (OM47668U) U.S.A.
Warning messageDetailsCorrection procedure
EV-Drive Mode cannot be
switched to. A buzzer also sounds. Use the EV-Drive
Mode when it
becomes available.
The EV-Drive Mode has been
automatically cancelled. A buzzer also sounds. Drive normally for a
short time.
■ After changing the engine oil (U.S.A. only)
Make sure to reset the oil maintenance data. ( P. 428)
■ Approach warning message
In the following instances, there is the possibility that the approach warning
will not activate even when the vehicle-to-vehicle distance decreases.
● When your vehicle and the vehicle ahead are traveling at the same
speed or the vehicle ahead is traveling more quickly than your vehicle.
● When the vehicle ahead is traveling at very low speed.
● Immediately after cruise control speed is set.
● At the instant the accelerator pedal is depressed.

5
When trouble arises
523
5-2. Steps to take in an emergency
PRIUS_U (OM47668U) U.S.A.
NOTICE
■
While the engine oil level warning is displayed
Continued engine operation with low engine oil will damage the engine.
■ Engine oil maintenance message
The warning message is based on the projected driving range after engine
oil maintenance message is reset. 
The system does not monitor the purity of the engine oil.
