ADVANCED PARKING GUIDANCE SYSTEM
214
Instructions given are only examples.
When and how much to turn the steer-
ing wheel will vary according to traffic
conditions, road surface conditions,
vehicle condition, etc. when parking.
It is necessary to be fully aware of this
before using the
advanced parking
guidance system.
Also, when parking, be sure to check
that the parking space will accommo-
date your vehicle before maneuvering
into it.
CAUTION
Depending on the circumstances of
the vehicle (number of passengers,
amount of luggage, etc.), the set tar-
get parking position displayed on the
screen may change. Be sure to check
visually behind and all around the ve-
hicle before proceeding.
(a) To activate the advanced parking
guidance system
To activate the advanced parking guid-
ance system, shift to “R” when the
“POWER” switch is in ON mode.
If you move the shift position out of “R”,
the screen returns to the previous
screen. Operating another function of
the navigation system will display
another screen.
Even if the shift position is in “R”, if you
push any of the mode buttons around
the display, such as “MAP/VOICE” or
“INFO·PHONE” , the screen will switch
to that mode.
— Maneuvering when
parking

ADVANCED PARKING GUIDANCE SYSTEM
215
1Camera orientation confirmation
lines
If the edge of the bumper displayed
on the screen does not match the
camera orientation confirmation
lines, the camera may not be aligned
correctly. Have the vehicle checked
by your Toyota dealer.
2Parallel parking assist mode but-
ton
Touching this button turns parallel
parking assist mode on.
See “— Parallel parking assist mode” on
page 219 for details.
3Parking assist mode button
Touching this button turns parking as-
sist mode on.
See “— Parking assist mode” on page 231
for details.
To adjust the volume of the voice guid-
ance, ask your Toyota dealer for de-
tails. PRESUPPORT SWITCH
Use this switch to turn on/off the pre
support function and to switch assist
mode between parallel parking assist
mode
and perpendicular parking assist
mode.
Pushing the pre−support switch while
“POWER” switch is in ON mode and the
vehicle is travelling below 9 mph (15 km/h)
with the shift position in any position other
than “P” or “R”, will cause the screen to
change in the following order:
Presupport function OFF (Navigation
screen, etc.)
↓
Parallel parking assist mode presup-
port screen ↓
Perpendicular parking assist mode
presupport screen
↓
Presupport function OFF (Navigation
screen, etc.)
If the pre −support function cannot be used,
two beeps will sound.

ADVANCED PARKING GUIDANCE SYSTEM
216
(b) Disabling the advanced parking
guidance system
When in the parking assist mode or par-
allel parking assist mode, in the follow-
ing case the voice guidance will say
“The guidance has been canceled”, a
message will be displayed, and the sys-
tem will be disabled. For displayed
message, see page 243.
After the following operations
Moving the steering wheel
Using the accelerator
Moving the shift position out of “R”
Applying the parking brake
Switching the screen display In the following situation
If the vehicle slips forward or stops af-
ter taking your foot off the brake pedal
If the backing speed is too fast
If normal assistance cannot be ren-
dered
due to worn tires or low tire infla-
tion pressure
If the target parking position has not
been confirmed on the target parking
position setting screen before backing
up
Any warnings displayed on the screen
are not acknowledged before backing
up
If there is a system malfunction
If the system temperature protection
function operates
If the system is disabled while backing up,
grip the steering wheel firmly and depress
the brake pedal to bring the vehicle to a
halt. The system has been completely dis-
abled, so you may either start again from
the beginning, or if you wish to finish park-
ing manually, be sure to operate the steer-
ing wheel as you would normally.
If a hands− free phone call is received, the
hands −free screen will be displayed, and
the system will be disabled.

ADVANCED PARKING GUIDANCE SYSTEM
219
Parallel parking assist mode assists
the driver with parallel parking by auto-
matically controlling the steering wheel
when backing up, in order to park in the
target position set on the screen.
CAUTION
When backing up, be sure to check
your surroundings and behind the
vehicle for safety, and back up
slowly, depressing the brake pedal
to control vehicle speed.
If you seem likely to hit nearby ve-
hicles, obstacles or people, de-
press the brake pedal to stop the
vehicle, then disable the system by
touching on the screen.
As the system only assists with parking in
a set target parking position, there are
times when the system will be unable to
render this assistance, depending on fac-
tors such as road surface or vehicle condi-
tion, or the distance to the set target park-
ing position.
Use the system with full understanding of
the fact.
If a message is displayed while maneuver-
ing, follow the procedures outlined in “—
What to do when this sort of message is
displayed” on page 243.
The illustrations here describe the proce-
dure for pulling into a parking space on the
right. For pulling into a parking space on
the left, substitute left for right and vice ver-
sa in all steps.
The operating method differs depending
on whether or not the pre− support function
is in use. PRESUPPORT FUNCTION
The presupport function can be used
when there is a space between two
parked vehicles. If a parking space is
detected, this function will inform the
driver using a tone when the vehicle is
in a position to begin backing up, and
guides the vehicle to a position from
which assistance can be given.
Guidance will not be given if the detected
space is narrow.
Parking between two vehicles
1Push the presupport switch
once
2Identify a parking space
3Get into a position to begin back
up maneuvering
— Parallel parking assist
mode

ADVANCED PARKING GUIDANCE SYSTEM
220
INFORMATION
To allow the presupport system
to activate accurately, move the ve-
hicle as slowly as possible (at a
speed that will allow the vehicle to
be stopped suddenly).
 If only one vehicle is parked, the
presupport system cannot be
used.
 The function cannot be used if the
shift position is in “P” or “R”, or if
the vehicle speed is greater than 9
mph (15 km/h).
 In order to identify parking spaces
and detect parked vehicles using
the sensors on both sides of the
front bumper, guidance cannot be
given if a space is not detected.
 Parking space guidance and
searching continues until the ve-
hicle speed is greater than 9 mph
(15 km/h) or until the function is
turned off by pushing the presup-
port switch.
(a) When the presupport function is
in use
1Push the presupport switch
once
2Sensor detection range
1. With the vehicle speed at less than
9 mph (15 km/h) and the vehicle on the
near side of the parking space, push the
presupport switch once. Confirm that
the display has switched to the “Paral-
lel parking mode” screen.

ADVANCED PARKING GUIDANCE SYSTEM
221
INFORMATION
The mode will switch with each
push of the presupport switch.
 If the shift position is in “P” or if the
vehicle speed is 9 mph (15 km/h) or
above, two beeps will sound when
the presupport switch is pushed,
and the display will not change.
 If the shift position is in “R”, the
display will not change.
1Approx. 3 ft. (1 m)
2Desired parking location
2. Move the vehicle to a position paral-
lel to the road (or road shoulder) that is
also approximately 3 ft. (1 m) away from
the parked vehicle, and then proceed
straight forward.
INFORMATION
To cancel the guidance function, turn
off the presupport function by push-
ing the presupport switch twice.

ADVANCED PARKING GUIDANCE SYSTEM
222
3. Stop the vehicle when two chimes
sound.
INFORMATION
Two chimes sound when the ve-
hicle reaches a position from
which the front edge of the leading
parked vehicle can be seen along-
side.
 Move the vehicle forward as slowly
as possible so that the vehicle can
be stopped as soon as the two
chimes sound.
 The chimes will not sound if the ve-
hicle does not arrive in a backing
up position. If the vehicle is
stopped and the shift position is
shifted to “R” before the chimes
sound, the screen shown in step 4
of “(b) When the presupport func-
tion is not in use” on page 223 is
displayed.
4. Shift to “R”.
For operation after shifting to “R”, see step
5 of “(b) When the pre −support function is
not in use” on page 223.

ADVANCED PARKING GUIDANCE SYSTEM
224
CAUTION
Be sure to stop the vehicle parallel to
the road or shoulder. If the vehicle is
not parallel, the assist location will be
very near the shoulder. If it looks like
the vehicle will hit or mount the
shoulder, depress the brake pedal to
stop the vehicle, and touch on
the screen to deactivate the system.
If there is no leading parked vehicle, the
system will display the target parking posi-
tion (green or red frame) in the position
used last time the parallel parking assist
mode was activated. 3. Shift to “R”.
4. Touch on the screen.
5. Use the arrow to align the green
frame with your target parking space,
and touch “OK”.
You can also move the green frame by
touching the screen (area other than the
arrows).
There are tricks to align the green frame.
See “
 Tips for setting the target parking
position” on page 228.
If the frame is displayed in red, you cannot
use the parallel parking assist mode to
park in that location. See “  When a red
frame is displayed in the assist mode” on
page 246.

ADVANCED PARKING GUIDANCE SYSTEM
225
When the green frame is displayed, if you
begin backing up without touching “OK”,
the message “Parking position has not
been set.” appears. If you continue to back
up, you will hear a warning tone and the
system will be disabled.
If the frame is red, there will be no guidance
even if you begin backing up.
If the orientation of the frame is opposite to
that of the target parking space, touch
.
There may be times when, due to image
distortion, the green frame does not match
the parking space lines on the road sur-
face. In this case, use the warning flag and
green extension guide line to set the target
parking position.
You may adjust the target parking position
even after starting the parallel parking as-
sist mode.
CAUTION
Always check that there are no ob-
stacles in the green frame or be-
tween your vehicle and the parking
space, and that the warning flag
and extension guide line do not
overlap any parked vehicles or
walls.
If there are obstacles in the green
frame or between your vehicle and
the parking space, or the warning
flag or extension guide line over-
laps a parked vehicle or wall, there
is a danger of collision. In this
case, do not use the parallel park-
ing assist mode. The same applies
if the green frame overlaps the
shoulder.
The warning flag is only a guide.
Be sure to directly check your sur-
roundings and behind the vehicle
for safety, and back up carefully.
If the road surface has level varia-
tions or a gradient between the
starting position and target park-
ing position, it will not be possible
to correctly set the location, which
may cause the parking position to
be misaligned or crooked. In this
case, do not use the parallel park-
ing assist mode.

ADVANCED PARKING GUIDANCE SYSTEM
226
6. Position yourself as you would
when backing up normally, and rest
your hands on the steering wheel with-
out applying any pressure. Check your
surroundings and behind the vehicle
for safety, and slowly back up, using
the brake pedal to control the vehicle’s
speed.
If you touch
, assistance is can-
celed.
If the vehicle’s backing up speed is too
fast, a warning tone will sound and the
message “Speed is too fast.” will be dis-
played. If you continue to back up at that
speed, the system will be disabled. Back
up at a speed that does not cause the
warning tone to sound.
The green frame displayed on the screen
is approximately the same size as your ve-
hicle. (The green frame displayed when
setting the target parking position is the
size of a normal parking space.)
You can change the target parking position
by touching
. If you are backing up,
or have already moved close to the target
parking position,
will turn gray, and
you will be unable to change the target.
Touch the arrows to move the target park-
ing position, and then touch “OK”.
You can only move the target parking posi-
tion left or right, and the warning flag will
not move even if you adjust the target park-
ing position.
